Optical Networks, Current and Future
Technologies for WDM By Bogdan Ionescu DSRG,
University of Ottawa July 5, 2000
2

• Purpose
• Introduction to WDM
• Current Technology Standpoint
• WDM Network Topologies and Architectures
• Failure Resiliency
• Switching and Routing
• QoS in WDM
• Access Networks
• SONET and WDM
• Control Plane for WDM Networks
• Direction of WDM Networks
• Conclusion

3

• 1. Purpose
• Board study of WDM technology
• Deployment
• Work in progress
• Establish future research areas in WDM

4

• 2. Introduction
• Current optical signals
• have least signal loss around the region of 1300
  or 1500 nm
• SONET use only one of these wavelengths at a time
• WDM applies same principles as FDM to the optical
  domain
• many optical signals
• each with their own wavelength (carrier freq.)
• placed onto one fiber

5

• 2. Introduction
• How WDM works?
• advances in optical components allow a window of
  wavelengths around the 1300 or 1500nm thresholds
• with latest lab technologies
• window size of 100 wavelengths
• for OC-192 (9953.28 Mb/s) gt 1 Tb/s
• this is DWDM
• e.g. of such optical components 1
• Distributed Feedback Lasers (DFB)
• Erbium-doped Fiber Amplifiers (EDFAs)
• Photo-detectors
• Multi-frequency Lasers

6

• 2. Introduction
• Optical Components for WDM 1
• Important Parameters
• Tuning Time time required for a laser/filter to
  focus on a particular wavelength
• Tuning Range spectral window, i.e. how many
  wavelengths

7

• 2. Introduction
• Properties of tunable lasers 1

8

• 2. Introduction
• Characteristics of tunable filters 1

9

• 2. Introduction
• (WDM Network Components)
• Optical Add/Drop Modules (OADM)
• signal grooming and splitting
• usually made of Arrayed-Waveguide Gratings (AWG)
  or Fiber Bragg Gratings (FBG)
• ? Crossconnect (WXC)
• key component in constructing networks
• composed of
• Mux, Dmux, switches, ? Crossconnect

10

• 2. Introduction
• (WDM Network Components)
• Reconfigurable ? routing switches
• a) employing ? converters b) employing photonic
  switches

11

• 3. Current Technology Standpoint
• Today WDM technology is mainly deployed for
  increasing pipe capacity of backbone networks.
• SONET interfaced with WDM Mux/Dmux
• used for point-to-point connections
• up to 100 times the wavelengths over same optical
  fiber
• no need to lay new fiber for multiplied capacity
  on backbone trunks
• no known deployment of switching out routing WDM
  (in development only)
• WDM Mux/Dmux simple device requires minimal
  control mechanisms for focusing lasers and
  filters.

12

• 4. WDM Network Topologies and Architectures
• Broadcast and Select 1
• sender relays information to all other nodes
• receiver node selects information of interest by
  use of enabling technology)
• e.g. a tunable filter to select the ? carrying
  info.
• tunable transmitters (TT), tunable receivers
  (TR),
• fixed transmitters (FT), fixed receivers (FR)
• Topologies
• star coupler, (N/2)log2N individual couplers
• bus, 2N couplers, high signal loss
• ring, high power dissipation better
  failure-resilience
• MAC protocols needed

13

• 4. WDM Network Topologies and Architectures
• Broadcast and Select Topologies 1

14

• 4. WDM Network Topologies and Architectures
• Broadcast and Select demonstrators 1
• LAMBDANET 16-20 late 80s and early 90s, one
  of first, built by Bell Core
• 18 ? separated by 2nm modulated _at_ 1.5 Gb/s
  over 57 km
• RAINBOW I II 1 in the early 90s by IBM
• 32 ? separated by 1nm giving 300 Mb/s in I and
  1Gb/s in II
• Other
• STARNET I II by Stanford University
• European Research and Development for Advanced
  Communications in Europe (RACE)

15

• 4. WDM Network Topologies and Architectures
• ? Routing Networks 15,17
• information is routed, switched and forwarded
  based on ?
• therefore obtain a physical and logical topology
• ? reuse throughout network gt increased capacity
• currently 4 to 32 ? networks exist and expected
  to increase to 100 (DWDM) 15
• virtual topology gives an optical layer to serve
  higher layers e.g. offering VPNs
• issues to consider
• transparency, reliability, ? reuse, virtual
  topology, static/dynamic routing ? assignment
  (RWA) 15,17,18

16

• 4. WDM Network Topologies and Architectures
• ? Routing Networks

17

• 4. WDM Network Topologies and Architectures
• ? Routing Networks demonstrators 1
• Multiwavelength Optical Network (MONET) program
• developed by Bellcore funded by DARPA 18,19
• uses 8 ? spaced by 200 GHz modulated _at_ 2.5
  Gb/s, in a ring topology
• latest demonstrators gave 10 Gb/s for 2000 km
• All-Optical Network (AON) between MIT and DCE
  20
• uses 20 ? spaced by 50 GHz (0.4nm)
• Multiwavelength Transport Network by RACE 18
• uses 4 ? spaced by 500 GHz modulated _at_ 622 Mb/s
  or 2.5 Gb/s
• Other WSAPNET, OPEN, MOSAIC, OPERA 18,16

18

• 4. WDM Network Topologies and Architectures
• WDM Ring 5
• conceptually similar to a SONET ring
• main difference is in failure-resiliency
• Wavelength Cross Connect (WXC) interconnected in
  a ring topology
• WXC use ? switching and conversion
• allows for better service protection than SONET
• ? (lightpath) protection in addition to path and
  line protection.
• i.e. laser failure is fixed by converting ?, no
  need for rerouting gt faster recovery
• flexible and higher routing capacities
• 8 identifies eight types of WDM rings
• 25 studies several failure-resilient WDM rings

19

• 4. WDM Network Topologies and Architectures
• WDM Mesh Networks 5
• same optical components as for WDM rings i.e.
  WXCs
• protocols are more complex
• failure-resiliency 9
• routing ? assignment 10
• likely to be used for backbone infrastructures

20

• 4. WDM Network Topologies and Architectures
• Example of interconnected WDM network
  infrastructure Mesh, Ring, and Access (
  Discussed Later )

21

• 5. Failure Resiliency
• (Currently in SONET)
• SONET/SDH survivable architectures 1
• Automatic Protection Switch (APS) protocol
• protects against fiber cuts by automatically
  redirecting traffic
• 11 protection
• same signal is transmitted through two
  non-intersecting paths
• destination decides on which signal to choose
• 11 protection
• two non intersecting paths working and reserved
• reserved path is idle or used by low priority
  traffic in non-breakdown times

22

• 5. Failure Resiliency
• (Currently in WDM )
• WDM networks will likely mirror SONET/SDH
  survivable architectures.
• Two type of classifications 11-14
• Protection
• protection resource are reserved ahead of time
• protection resource may be used by low priority
  traffic at non-breakdown times
• Restoration
• alternate routes of spare resources are
  discovered at failure detection time
• if discovery of alternates fails, data is lost
• better resource utilization at non-breakdown
  times
• slower than protection scheme (reconfig.. path)

23

• 5. Failure Resiliency
• (Currently in WDM )
• Two main schemes extensively implemented
• First scheme Fiber Protection Switching
• applied to point-to-point and ring architectures
• working fiber is backed up by another disjointed
  fiber
• entire fiber is switched
• granularity of one fiber

24

• 5. Failure Resiliency
• (Currently in WDM )
• Second scheme At the Wavelength Level 6
• applied to cross-connected mesh architectures
• slower but more bandwidth efficient
• Three variants
• link
• fastest failure detection
• recovery is local to one point (i.e. _at_ link
  level)
• path
• reroutes between two end nodes
• full advantage of network spare capacity
• slower to detect and recover
• disjoint-link path
• at path setup time, an alternate path is selected
  as well
• traffic restored immediately

25

• 5. Failure Resiliency
• (IP over WDM)
• For IP over WDM/DWDM
• abolishes current architecture
• IP over ATM over SONET over WDM
• functional overlap
• slow to scale
• failure resiliency at different layer may
  interfere with each other and provide network
  instability

26

• 5. Failure Resiliency
• (IP over WDM)
• Detection and restoration at different layers

27

• 5. Failure Resiliency
• (IP over WDM)
• Proposed joint protection/restoration scheme
  coordinated at both IP and WDM layers 6
• needs traffic engineering for WDM networks
• Optical control framework needed at optical layer
• Key is combining 21
• recent advances in IP-MPLS-based control plane
  constructs
• with OXC technology
• this is proposed by MP?S 21
• sharing of information between IP WDM layers
• IP to directly access WDM channels

28

• 5. Failure Resiliency
• (IP over WDM)
• Proposed architecture for MPLS-based traffic
  engineering 6
• automatic topology discovery
• OXC to dynamically learn networks
• no manual intervention
• state information dissemination
• extension to link-state routing, e.g. OSPF
• link attributes added to state tables and
  advertisement
• max. available link BW
• max. reservable link BW
• current BW reservation
• current BW usage

29

• 5. Failure Resiliency
• (IP over WDM)
• path selection
• RWA problem
• which LSP (Label Switched Path) to choose for
  required ? QoS values
• choose a centralized or distributed algorithm
• path management
• establish, maintain, tear-down of LSP
• use of signaling protocols such as
• RSVP
• CR-LDP (Constraint-Based Routed Label Distributed
  Protocol)
• This allows for Joint Protection/Restoration at
  the IP/WDM Layers

30

• 6. Switching and Routing
• Have seen so far the physical and control
  mechanisms required for switching / routing in
  WDM networks
• Primary problem Contention Resolution
• Contention in WDM when packets are switched
  and two or more packets trying to leave the same
  port on the same ?
• Three types of contention resolution mechanisms
  4
• optical buffering
• deflection routing
• ? conversion

31

• 6. Switching and Routing
• Optical Buffering (deflection in time) 4
• delay lines
• fixed fiber lines each giving pre-calculated
  delays
• delays in term of packet durations 1,2,3 ..., m
• packet sent directly to output or to required
  delay line based on required delay
• recirculation fiber loops
• based on fiber loop delay line with multiple ?
  channels
• at contention, packet is converted to ? available
  in the loop
• kept circulating by corresponding passive fixed
  filter
• converted to ? available at output when
  contention is resolved
• both suffer from increased signal to noise ratios

32

• 6. Switching and Routing
• Deflection Routing (deflection in space) 4
• one packet routed along desired minimum
  distance-routing link
• others are forwarded to greater than minimum
  distance-routing links
• (optical buffer may still be used here)
• source-destination pair routes are no longer
  fixed, i.e. different routes possible as in IP
• parameters that affect performance of deflection
  routing
• network diameter (max. of hops)
• deflection cost (increase in hops)
• problems similar to IP routing can arise esp. in
  asynchronous transmission networks
• wondering packets, throughput collapse

33

• 6. Switching and Routing
• ? Conversion (deflection in ? domain) 4
• convert additional packets to a different ?
  following the same next hop link as original
  packet
• needs mechanism for choosing alternate ? but on
  same output fiber
• best results were obtained if combined with
  buffering
• reduced probability of signal loss in buffering

34

• 6. Switching and Routing
• General Comparison
• Buffering
• better network throughput at higher hardware and
  control cost
• Deflection Routing
• easier to implement, cannot offer ideal network
  performance
• ? Conversion
• in-between with less signal loss

35

• 7. QoS in WDM
• Differentiated Optical Services (DoS) 2
• Provide Classes of Optical Services
  (DiffServ)based on
• lightpath characteristics
• jitter
• ? wander
• crosstalk
• amplified spontaneous emission
• available failure-resiliency characteristics
• protection
• restoration
• signal regeneration
• 3R, retiming and reshaping (signal dependant),
  non-transparent but re-clocking
• 2R, regeneration, no retiming gt jitter
• 1R no retiming and reshaping, simplest and most
  transparent to optical format

36

• 7. QoS in WDM
• DoS set of parameters characterize quality and
  impairments of optical link
• quantitative delay, jitter, BER, BW
• functional monitoring, protection, security
• Need for Classification and Mapping of Optical
  Service
• grouping OCh into classes reflecting previous
  QoS parameters
• mapping aggregate DiffServ flows into
  corresponding OCh grouping
• admission ctrl. and policing to ensure that
  ingress DiffServ flows do not exhaust available
  optical resources
• Architecture involves edge-devices performing the
  above functions with a simple WDM core
• Need for monitoring control plane to core
  devices

37

• 7. QoS in WDM
• E.G. Optical Service Classification

38

• 7. QoS in WDM
• General Mechanisms to enforce QoS
• optical buffering according to
  priorities/classes
• deflection routing according to
  priorities/classes
• ? conversion according to priorities/classes
• MPLS/OSPF/RSVP
• Monitoring by way of
• OADMs (Optical Add /Drop Modules
• or opto-electric-opto conversion

39

• 8. Access Networks
• Passive Optical Networks (PON) 5
• placed at WDM Ring access level
• a bus or star topology
• medium access protocol (MAC) coordinates
  transmission amongst users
• are less expensive than WDM rings due to lack of
  active components
• SONET rings
• Room for QoS here as well
• Dynamic Resource Allocation for Quality of
  Service on a PON with Home networks 7

40

• 8. Access Networks
• Example of current Access Networks for WDM

41

• 9. SONET and WDM
• 10 years to finish migration to SONET 5
• Large investment made in SONET equipment
• North American Total as of 1998, 4.5 billion
• For WDM to be accepted readily it has to
  integrate/be backward compatible with SONET
• Optical Transport Networks (OTN) 1
• switched/routed WDM networks (OC-48 to OC-192)
• composed of WXC nodes
• control system for setup and teardown of
  lightpaths, monitoring, and fault recovery
• needs definition of frame format (currently being
  defined 22)
• OCh frame format to borrow SONET concepts

42

• 9. SONET and WDM
• SONET Frame must be easily encapsulated into OCh
  frame
• e.g. OC-48 SONET frame cannot fit in an OCh
  payload at OC-48 due to required OCh overhead
  bytes.
• Some WDM equipment must have physical SONET
  interfaces as specified in 23
• SONET side need not be aware of WDM
• WDM equipment might have to do ? conversion at
  SONET interface
• APS of WDM must not interfere with that of SONET
• must react faster than SONET (50 ms)
• recovery at lower level (WDM) 1st
• Recall WDM restoration is faster but detection
  is slower

43

• 9. SONET and WDM
• E.G. on WDM ring a WXC can directly drop and add
  into the optical medium the ? used in the SONET
  ring
• Organizations dealing with interoperability
  issues
• Optical Internetworking Forum (www.oiforum.com)
• ITU-T Study Group 15 (www.itu.int/ITU-T/com15/inde
  x.html)
• SONET Interoperability Forum (www.atis.org/atis/si
  f/sifhom.htm)

44

• 10. Control Plane for WDM Switches/Routers
• WDM OTN networks need to support
• APS
• QoS
• Monitoring
• Security
• Interoperability (SONET, PON, ....)
• Each device (edge or core) needs to support some
  or all points above
• need to define frame format
• signaling protocols (setup and teardown of ?
  paths)
• MIBs
• management protocols

45

• 10. Control Plane for WDM Switches/Routers
• A uniform control plane that is distributed,
  supporting heterogeneous environments is needed
• Recall SONET suffers immensely from lack of a
  standardized management platform
• Ongoing effort to integrate, control, and manage
  existing networks in a vendor independent way
  24
• CORBAs Xo/JIDM specification is a foundation 5
• joint effort by major Telco. Industries
• integrates management and control architectures
  for
• ATM, SONET, WDM, IP, and others
• This allows WDM networks to fully support OAMP
• i.e. operations, administration, maintenance, and
  provisioning

46

• 11. Direction of WDM Networks
• More than just the current point-to-point
  fat-pipe capacity
• IP over WDM/DWM for OTN support
• OSPF/MPLS/RSVP
• increase in control, monitoring, management
• Support for QoS reaching into core
• Advances in tuned lasers, filters, ? converters
• increase in tuning speed and range
• increase in ? window along base ?s (1300,1500
  nm)
• allow WDM to become circuit/packet switched
  networks offering value-added features opening up
  diverse IP and WDM services to the paying public

47

• 12. Conclusion
• Currently WDM applied in increasing
  point-to-point capacity
• Increasing towards providing WDM OTN with value
  added features
• WDM / SONET Integration
• Many critical components missing
• IP over WDM protocol integration
• Control Plane
• Traffic monitoring and measurement
• Traffic engineering
• QoS developed leveraging above protocols
• WDM access networks supporting QoS

48
13. References 1 J. Elmirghani and H.
Mouftah, Technologies and Architectures for
Scalable Dynamic Dense WDM Networks, IEEE
Commun. Mag., vol. 38, no. 2, February 2000, pp.
58-66. 2 N. Golmie, T. Ndousse and D. Su, A
Differentiated Optical Services Model for WDM
Networks, IEEE Commun. Mag., vol. 38, no. 2,
February 2000, pp. 68-73. 3 I. Van de Voorde,
and C. Martin, The SuperPON Demonstrator An
Exploration of Possible Evolution Paths for
Optical Networks, IEEE Commun. Mag., vol. 38,
no. 2, February 2000, pp. 74-82. 4 S. Yao and
B. Mukherjee, Advances in Photonic Packet
Switching An Overview, IEEE Commun. Mag., vol.
38, no. 2, February 2000, pp. 84-94. 5 D.
Cavendish, Evolution of Optical Transport
Technologies From SONET/SDH to WDM IEEE Commun.
Mag., vol. 38, no. 6, June 2000, pp. 164-172. 6
Y. Ye, S. Dixit and M. Ali, On Joint
Protection/Restoration in IP-Centric DWDM-Based
Optical Networks IEEE Commun. Mag., vol. 38, no.
6, June 2000, pp. 174-183. 7 J. Jang and E.
Park, On Joint Protection/Restoration in
IP-Centric DWDM-Based Optical Networks IEEE
Commun. Mag., vol. 38, no. 6, June 2000, pp.
174-183. 8 S. Johansson et al., "A
Cost-Effective Approach to Introduce an Optical
WDM Network in the Metropolitan Environment,"
IEEEJSAC, vol. 16, no. 7, Sept. 1998, pp.
1109-22. 9 S. Ramamurthy and B. Mukherjee,
"Survivable WDM Mesh Networks, Part I -
Protection," Proc. INFOCOM'99, Vol. 2, 1999, pp.
744-51. 10 A. Mokhtar and M. Aziziglu,
"Adaptive Wavelength Routing in All-Optical
Networks," IEEE/ACM Trans. Net., vol. 6, no.
2,Apr. 1998, pp. 197-206.
49
13. References 11 P. Demeesteretal.,
"Resilience in Multilayer Networks," IEEE Commun.
Mag., Aug. 1999, vol. 37, no. 8, pp. 70-76. 12
S. Shew, "Fast Restoration of MPLS Label Switched
Paths," Internet draft, work in progress, Oct.
1999. 13 S. Makam et al., "Protection/Restorati
on of MPLS Networks," Internet draft, work in
progress, June 1999. 14 M. Medard, S. Finn,
and R. Barry, "WDM Loop-back Recovery in Mesh
Network," Proc. IEEE INFOCOM '99, vol. 2, pp.
752-59. 15 D. J. Blumenthal et al., "Special
Issue on Photonic Packet Switching Technologies,
Techniques and Systems," 1EEE/OSA J. Lightwave
Tech., vol. 16, no. 12, Dec. 1998. 16 H. T.
Mouftah and J. M. H. Elmirghani, Photonic
Switching Technology-Systems and Networks, IEEE
Press, July 1998. 17 R. L. Cruz et al. (Eds.),
"Special Issue on Optical Networks," IEEE JSAC,
vol. 14, no. 5, June 1996. 18 M. Fujiwara et
al. (Eds.), "Special issue on Multiwavelength
Optical Technology and Networks," IEEEIOSA J.
Lightwave Tech., vol. 14, no. 6, June 1996. 19
M. Wang, Ed., Feature Topic on Multiwavelength
Fiber Optic Communication, IEEE Commun. Mag.,
vol. 36, no. 12, Dec. 1998. 20 D. A. Smith et
al., "Evolution of the Acousto-Optic Wavelength
Routing Switch," 1EEE1OSA J. Lightwave Tech.,
vol. 14, no. 6, June 1996, pp. 1005-19.
50
13. References 21 D. Awduche et al.,
"Multiprotocol Lambda Switching," Internet draft,
work in progress, Nov. 1999. 22 ITU-T Rec.
G.709, "Network Node Interface for the Optical
Transport Networks," work in progress, SG 15.
23 ITU-T Rec. G.957, "Optical Interfaces for
Equipments and Systems Relating to the
Synchronous Digital Hierarchy," July 1995. 24
R. Pease, "Companies Demonstrate Multivendor,
Multitechnology Network Management," Lightwave,
Nov. 1999. 25 J. Manchester, P. Bonenfant, and
C. Newton, "The Evolution of Transport Network
Survivability," IEEE Commun. Mag., vol. 37, no.
8, Aug. 1999, pp. 44-57.
