Title: Introduction to Lake Surveys Field Techniques


1
Introduction to Lake SurveysField Techniques
  • Unit 3 Module 8 Part A Lake Morphometry

2
Objectives
  • Students will be able to
  • determine common morphometric characteristics of
    lakes
  • identify characteristics of a bathymetric map.
  • describe methods used to create bathymetric maps.
  • use bathymetric maps to determine areal
    characteristics for lakes.
  • determine the importance of lake volume and mean
    depth in lakes.
  • calculate lake volume and mean depth.
  • interpret hypsographic and volumetric curves of
    lakes.
  • explain the hydraulic residence time of a lake.
  • calculate the hydraulic residence time of a lake.

3
Basic water quality assessment
  • These slides focus on learning basic field
    techniques used by limnologists
  • Morphometry - estimating critical lake basin
    measurements
  • Field Profiles - physical and chemical parameters
    measured from top to bottom of the water column
  • Sampling collecting water, sediments, and
    aquatic organisms

4
Part A Lake morphometry
5
Part A Lake morphometry
  • Goal
  • This module will help you
  • Learn how to determine common morphometric
    characteristics of lakes

6
Lake morphometry
  • Morphometry defines a lakes physical
    dimensionsand involves the quantification and
    measurement of lake basin shape.
  • These dimensions influence the lakes water
    quality and productivity levels.

7
Determining lake morphometry
  • First Step is to obtain or develop a bathymetric
    map-a bathymetric map is essentially a
    topographic map of the lake bottom that shows
    depth contours within the lake basin-used to
    estimate morphometric and many hydrological
    parameters-the reliability of your morphometric
    data will depend on the accuracy of the
    bathymetric map

8
Working with a bathymetric map
  • Many lakes have already been mapped and a good
    map will contain the following
  • name, county, and geographic location of the
    water body
  • an outline of the shoreline drawn to a known
    scale
  • depth contours drawn to a known interval
  • geographic orientation (which way is north?)
  • date of map and data collectors

9
(No Transcript)
10
Creating a bathymetric map
  • Making your own map requires measuring depths at
    precise locations
  • Sounding weight (through the ice works well)
  • A secchi disk will work if weighted
  • Fish finder, echo sounders ( sonar)

Lake mapping prior to 1950-MN DNR photo
11
Creating a bathymetric map
  • Bathymetric maps can be made by-Drawing a
    general outline of the lake or finding an aerial
    photo or map-Measuring and recording water
    depths at a number of locations-Then connecting
    the depth dots to develop simple contour lines

12
Creating a bathymetric map
  • The most commonly used method today involves
    using precise echo sounders, on board computers
    and GPS systems.There are several components to
    lake bathymetric mapping -the GPS equipment
    which will work in tandem with -the depth
    sounding equipment, and -the data collection
    process

13
Creating a bathymetric map
  • Soundings are taken during as the boat follows
    transects across the lake surface
  • Location of transects and frequency of sounding
    measurements depends on
  • Map scale
  • Basin complexity

14
Drawing the map
  • Transect location and direction is recorded on a
    hardshell which is a drawing of the lake outline
    and surrounding features.
  • Hardshells are drawn from orthorectified aerial
    photos or USGS quadrangle maps

MN DNR photo
15
A bathymetric map allows determination of these
areal characteristics
Areal characteristics
characteristic units
elevation metersfeet
surface area(Ao) hectares (ha) acres (ac)
maximum depth (z max) metersfeet
Shoreline length(L) metersfeet
Shoreline development(DL) metersfeet
FetchMax widthMax length metersfeet
Littoral Area
16
Areal characteristics
  • ExampleMorphometric (and watershed)
    characteristics for Ice Lake

17
Areal characteristics
Maximum length (fetch)
Maximum width
  • Several areal characteristics and measurements
    can be taken directly off the bathymetric map

Z max
18
Areal characteristics surface area
  • Other measurements, such as lake surface area,
    require more work
  • There are several methods for determining lake
    surface area
  • Cut and weigh method
  • Planimetry
  • Grid method
  • Digitized map

19
Surface area cut and weigh method
  • Youll need
  • A photocopy of bathymetric map (as large as
    possible and be sure to include map scale)
  • An analytical balance

20
Surface area planimetry method
  • Youll need
  • -a lake map
  • -polar compensating planimeter (200-600)

Image from http//lakewatch.ifas.ufl.edu
21
Surface area grid method
  • Youll need
  • Bathymetric map
  • Grid paper
  • Method
  • Count up the number of squares that fall within
    the shoreline of the lake
  • Use the map scale to determine area represented
    by each square

Area squares counted X area of one square
22
Surface area digitized lake maps
  • Youll need
  • Bathymetric map
  • Digitizing software (e.g., ArcPad)
  • Digitizing pad
  • Method
  • Software dependent

www.remetrix.com
23
Areal characteristics shoreline length
  • Shoreline length (L) circumference or perimeter
    of lake
  • The linear measurement of the lakes entire
    perimeter at a given water level
  • Provides a measurement of the amount of interface
    between the lake and surrounding land

24
Areal characteristics shoreline development
  • Shoreline development (SLD) a measure of how
    much the lakes surface shape deviates from being
    a perfect circle.
  • Important is assessing the potential habitat
    available
  • For a lake that is a perfect circle the SLD 1
  • A reservoir that impounds water in valleys may
    have an SLD gt 4.

Calculating SLD
25
Areal characteristics littoral area
  • The littoral (shallow near shore) zone is the
    portion of a lake where sufficient light can
    penetrate to the lake bottom.
  • It is also sometimes defined as that portion of
    the lake that is less than 15 feet in depth.
  • The littoral zone is where the majority of the
    aquatic plants are found and is a primary area
    used by young fish.

26
Volumetric characteristics
characteristic units
Volume (V) Cubic metersacre feet
Stratum volume Cubic metersacre feet
Mean depth(z mean or z) metersfeet
Hypsographic curve Graph (depth vs area)
Volumetric curve Graph (depth vs volume)
Hydraulic retention time (HRT) years
  • Bathymetry also allows determination of several
    volumetric characteristics

27
Volumetric characteristics volume
  • Importance
  • Total lake volume can influence a lakes dilution
    capacity.
  • Allows the determination of mixed layer
    (epilimnion) volume.
  • Or hypolimnion e.g. determining available trout
    habitat with temperatures from 4 to 25 oC and DO
    gt 5 mg/L.

28
Volumetric characteristics volume
29
Calculating Lake Volume
  • Atop the area at the top of the layer
  • Abottom the area at the bottom of the layer
  • z the distance between contour lines
  • V the volume of one layer

30
Mean depth (z)
  • Mean depth (z) volume ? surface area
  • Mean depth is important for the following
    reasons
  • Shallow lakes are generally more productive than
    deep lakes and mean depth is a quick way of
    assessing overall depth
  • Also indicates the potential for waves and mixing
    events to disrupt bottom sediments
  • If volume is not available you could collect
    numerous lake depth measurements and average
    them. Of course this is not as accurate and only
    practical for small lakes.

31
Hypsographic curves
  • Hypsographic curve Area as a function of depth
  • To estimate the amount of potential bottom
    spawning habitat for brook trout or bass (perhaps
    defined by a range of temperature and dissolved
    oxygen)
  • To estimate the littoral zone area potentially
    available for macrophyte growth (limnologically
    defined as the depth to 1 of surface light).
    Often the epilimnion volume is used as an
    approximation. Often related to secchi depth by
    fisheries folks.
  • To estimate the area of sediments exposed to low
    oxygen. This allows you to predict internal
    phosphorus release (Nurenberg 1985).

32
(No Transcript)
33
Volumetric Curve
  • Volumetric Curve volume as a function of depth
  • When used in conjunction with temperature and DO
    profiles, this curve can be used to estimate
    fisheries habitat.

34
(No Transcript)
35
Hydraulic residence time (HRT)
  • HRT is the time required to refill an empty lake
    with its natural inflow.
  • A large deep lake with a moderate inflow will
    have a longer HRT than a small, shallow lake with
    the same inflow.

36
HRT - importance
  • HRT is needed to determine annual lake budgets
    for water, nutrients, heat, oxygen contaminants,
    and herbicides.
  • It also provides an estimate of the turnover time
    for water in a lake, or flushing time

37
Calculating HRT
  • A lakes residence time is calculated by dividing
    the lakes volume by its average annual water
    outflow.
  • Lake managers calculate outflow on an annual
    basis so that seasonal variation doesnt unduly
    influence results.
  • Volume (V) is usually expressed in acre-feet, and
    mean outflow is expressed as acre-feet/year.

38
Calculating HRT cont.
  • So the formula looks like this
  • HRT (years) lake volume (acre-ft) / mean
    outflow (acre-ft/yr)

39
Calculating SLD
BACK
If A lake area, then a circle with area A has
a perimeter
(1)
(2)
(Formula for area based on radius)
(6)
(3)
(collect terms)
(4)
(7)
Substituting eq.(3) into eq. (1)
(By definition)
(5)
(8)
Substituting eq(6) into eq. (7)
40
(No Transcript)
