High Resolution Satellite Imagery

1
High Resolution Satellite Imagery

• DigitalGlobe QuickBird

Phil Poole Matt Egan SKM
WALIS, 2005
2
Agenda

• Welcome
• Overview - SKM DigitalGlobe
• QuickBird
• What's Next?
• Tomorrow is here today

3
Sinclair Knight Merz

• Spatial Services Business valued at A20m
• Local office in Perth
• DG Team (Melbourne) - DigitalGlobe Distributor
  for Australia, New Zealand and the Pacific
  Islands. E-Cognition Reseller
• Representatives in Perth, Hobart, Brisbane,
  Sydney, Darwin and New Zealand
• Find out More
• www.skmconsulting.com
• www.digitalglobe.com.au (coming soon)

4
DigitalGlobe

• DigitalGlobe formerly EarthWatch
• DigitalGlobe is an Imaging and Information
  Company
• Delivering information products worldwide
• Providing solutions for your information needs
• Business Strategy
• Serve the worldwide GIS data market
• Sub-meter resolution QuickBird satellites
• www.digitalglobe.com web-enabled database
• Global partnerships for sales and marketing
• QuickBird Satellite Imagery
• Worlds highest resolution commercial imaging
  satellite.
• Find out more
• www.digitalglobe.com

5
The Beginning

• QuickBird launched on Oct. 18, 2001
• Placed in 98 degree inclination, polar, sun
  synchronous, low earth orbit at 450 km altitude
• Based on a new 0.5 meter US Government operating
  license received December 2000
• Satellite is in optimal health and has commenced
  imaging upon completion of a verification and
  calibration period as of 1 February 2002.

6
QuickBird Spacecraft Specifications

• 61-centimetre panchromatic Resolution
• 2.44-metre Multispectral Resolution
• 11 bit dynamic range
• 10.7 Meter RMSE Relative Accuracy
• 57 scenes per orbit
• 0 25 off-nadir
• 4 seconds to per Scene
• 16.5 km swath
• Push broom sensor
• 98 sun-sync orbit
• 1 - 6 day revisit
• 14 orbits/day
• 57 Scenes Per Orbit

7
Standard Popular Products

• Panchromatic - Black and White
• Multispectral Used for Analysis
• Pan-sharpened
• Natural color (R,G,B) - Similar to Aerial
  Photography
• Color infrared (NIR,R,G) False Colour
• Multispectral 4 Band - Higher Resolution MS

Riverside, California
8
High Resolution Satellites Superiority
Better Resolution and Faster Delivery
NOAA Weather Satellites
OrbView-3 / 4 Space Imaging
Digital Globe
OrbView-1
OrbView-2
NASA Environmental Satellites
ImageSat
SPOT Image
Collection Time
Aerial Photography
Landsat
RadarSat
Russian Satellite
Indian Satellite
4 Weeks
0.5 m
Resolution
Source C.E. Unterberg, Towbin 1999
9
Quickbird Imagery Largest Footprint

• Widest Scene
• More targets per scene
• Builds archive faster
• Easier Mosaicking
• Fewer GCPs
• Faster large area collections

10
Latest News

• 2 New Satellites in Build Launch dates in 2006
  46cm Resolution
• CitySphere to be Launched Perth Included
• EPP Launch of Energy Partner Program BHP,
  Apache Marathon on board
• Worldview Ground systems in place and stabilized

• Archive growing
• Google vs Microsoft Geo Search engine war
• Orthorectifed imagery now available as an
  official product
• SKM sign Reseller Agreement with Definiens as
  eCognition Reseller July 1st 2005

11
Expanding DigitalGlobe Infrastructure
Three remote ground terminals (Alaska, Norway,Pa)
North Pole, Alaska
12
Imagery for Parcel Mapping Code Enforcement
One of the most important uses for QuickBird
imagery is for property tax revenue (parcel
mapping) and building code enforcement purposes.
Nale Report, 2002
13
Computed Impervious Surfaces per parcel
14
Storm Water Runoff
Individual parcels taxed according to amount of
impervious surfaces
15
Vegetation Index
Harvard
17th Ave.
16
Update GIS Databases
Automatic Land Cover feature extraction based on
multispectral imagery
17
eCognition Automated Feature Extraction
FCC
Raster to Vector Conversion and Semi-Automated
Clean Up
Raster Roads
18
Tomorrow is Here Today
19
Imagery / GIS meets Joe Soap
20
Imagery / GIS meets Joe Soap
21
Imagery / GIS meets Joe Soap
22
Imagery / GIS meets Joe Soap
23
Imagery / GIS meets Joe Soap
24
Imagery / GIS meets Joe Soap
25
QuickBird Imagery is Cost Effective

• Many municipalities update 0.25-0.5m imagery
  every 3-4 years
• Municipalities cannot afford to acquire 0.25
  imagery annually
• For many purposes, higher resolution aerial
  photography is not necessary
• Satellite imagery is a cost-effective solution
  for current land base updates in interim years
• Find the change with satellite orthoimagery on an
  annual basis, focus on the change with higher
  resolution aerial orthophotos
• Satellite imagery provides current and accurate
  data needed for planning and management decisions
• Important for an enterprise GIS to link timely
  image information with other current city-wide
  databases, especially for fast growing areas
• A whole State Coverage Approach will bring cost
  savings to every organisation involved as well as
  reducing the overall spend on imagery from
  Government each year.
• Once used additional benefits will be found for
  the imagery such as those demostrated today

26
Websites of interest
www.skmconsulting.com/digitalglobewww.digitalglo
be.com http//www.definiens-imaging.com
www.gim.act.gov.au www.earthetc.comhttp//ea
rth.google.comhttp//maps.google.comwww.digita
lglobe.com.au (Coming soon) www.thelist.gov.ta
s.au
