Title: Problem 10'38


1
Problem 10.38
  • Gena Urowsky
  • April 4, 2007

2
Problem Statement
  • On the basis of the photomicrograph (i.e., the
    relative amounts of the microconstituents) for
    the lead-tin alloy shown in figure 10.15 and the
    Pb-Sn phase diagram (Figure 10.7), estimate the
    composition of the alloy, and then compare this
    estimate with the composition given in the figure
    legend of Figure 10.15.
  • Make the following assumptions
  • (1) the area fraction of each phase and
    microconstituent in the photomicrograph is equal
    to its volume fraction
  • (2) the densities of the a and ß phases as well
    as the eutectic structure are 12.7, 7.3, and 8.7
    g/cm3, respectively and
  • (3) this photomicrograph represents the
    equilibrium microstructure at 180ºC (355ºF).

3
Photomicrograph
4
Phase Diagram
Q
P
C1
5
Background Information
  • mass volume density
  • Lever Rule
  • Tie line constructed across two phase region at
    temperature of alloy
  • Overall alloy composition is located on tie line
  • Fraction of one phase is computed by taking
    length of tie line from overall alloy composition
    to the phase boundary for the other phase, and
    dividing by total tie line length
  • Fraction of other phase determined in same manner

6
Area ? Volume
  • a (lead rich) large dark regions 20 by area
  • Thus a is 20 by volume
  • Eutectic (a and ß layers) 80 by area
  • Eutectic is 80 by volume

7
Composition Fractions
  • C1 0.513052 ? 51.3 wt Sn
  • Composition is then 100-51.3 48.7 wt Pb

8
Alternate Method
  • Yields the same results as the previous method

9
Comparison
  • Calculated composition
  • 51.3 wt Sn - 48.7 wt Pb
  • Book gives value of 50 wt Sn - 50 wt Pb
  • Very close wt values

10
Exactness, Usefulness, and Applications
  • Probably not exact as 20 from photomicrograph
    was estimation
  • Digital imaging yields 20.6, which is close, but
    again not exact
  • Temperature is 180ºC and we used values for 183ºC
    which is close, but not exact
  • Since this is the data wed be receiving (the
    photomicrograph) its good to know how to deal
    with the information and process it accordingly
  • Determine information about a given solder by
    examining the micrograph and determining
    composition
