The PSI Planetbuilding Code: Multizone, Multiuse

1
The PSI Planet-building Code Multi-zone,
Multi-use

• S. J. Weidenschilling
• PSI Retreat
• August 20, 2007

2
Hybrid Collisional Code

• Neither particle-in-a-box nor N-body
• Designed to treat radially extended swarm of
  bodies orbiting a star
• Large dynamic size range, from dust grains to
  giant planets
• Both serial and parallel versions

3

• Collisions and stirring occur when orbits
  overlap, even for different zones (not a series
  of separate particle-in-box simulations)
• Mutual gravitational stirring and dynamical
  friction (energy exchange) for bodies in crossing
  orbits
• Long-range perturbations by large bodies, even if
  orbits dont overlap
• Explicit transport of mass between zones due to
  collisions, gas drag, tidal interactions with
  nebula, shepherding by massive bodies, etc.

4
Discrete Bodies

• Bodies larger than threshold mass (1024 g) are
  treated as discrete
• Allows late-stage simulations after large bodies
  have formed
• Individual values of M, a, e, i evolve with time
• Interact with continuum by viscous stirring,
  dynamical friction

5

• Gravitational scattering of discrete bodies
  treated as stochastic events, allows impulsive
  changes in orbital elements
• Angular orbital elements assumed evenly
  distributed, scattering treated as 2-body
  interactions
• New version of serial code includes a symplectic
  N-body integrator
• Discrete bodies can be designated with specified
  masses and orbits (i.e., planets)

6
Example Calculation Accretion in Inner Solar
System

• Planetesimal swarm 0.5 - 4 AU
• Swarm mass 7 Earth masses
• Initial planetesimal diameter 1 km
• Fragments retained to d 1/8 km
• Model time to 5 MY

7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
Collisional evolution of the asteroid belt Dust
production
30
Collisional evolution of planetesimal swarm
during migration of outer planets
31
Under Development

• Secular perturbations on planetesimals and
  embryos due to giant planets or stellar
  companions
• Modeling circumstellar debris disks, including
  dust production over stellar lifetimes gt 10 My
• Extension to small particle sizes, with radiation
  pressure and Poynting-Robertson drag
• Parallel version with symplectic N-body integrator
