Reactive Systems Design 159'734

1
Reactive Systems Design 159.734

• 01257358
• H Dayal S Ranadewa

2
The Components of Reactive Architecture

• Behaviours and Mechanism for merging the output
  of the concurrent behaviours.
• Many applications have a series of behaviours
  operating in a sequence.
• Ex Picking up and disposing an empty soft drink
  can.
• Behaviours include search for a can, move toward
  the can, pick up the can, search for the recycle
  bin, move toward the bin, drop the can.

3
Behaviours as Objects in OOP
4
Primitive Move-To-Goal Behaviour

• Ex Pick up the Trash
• Robot must move to the Red Coke Can and pick it
  up and then move to the Blue Bin and drop it
• Single generic behaviour would be move-to goal
  (colour)
• move-to-goal (goal-colour)

5
Where do releasers go in OOP?

• Perception serves two purposes
• 1) To Release a behaviour
• 2) Guide the behaviour
• The Releaser it self is a perceptual schema
  and can execute independently and is not bound to
  a motor schema
• It is common to have the releaser be part
  of the behaviour. This requires a Coordinated
  Control Program. Although the behaviour is always
  active if the releaser is not satisfied the
  coordinated control program short circuits
  processing.

6
Design Methodology
7
Case Study Unmanned Vehicle to Autonomously
Navigate around an outdoor course of white lines
painted on grass

• Step 1 Describe the Task
• Robot must follow a path with turns,
  obstacles and a sand pit.
• Step 2 Describe the Robot
• Determine the basic physical abilities of
  the robot and limitations and consider the fixed
  constraints.
• Step 3 Describe the Environment
• This step is a key factor in determining the
  situatedness of the robot and identifies the
  perceptual opportunities for the behaviours

8
Case Study Unmanned Vehicle to Autonomously
Navigate around an outdoor course of white lines
painted on grass

• Step 4 Describe how the robot should act in
  response to its environment
• Identify one or more behaviours. Identify
  what the Robot should do?
• Ex follow_line behaviour
• Perceptual Schema Use the white lines to
  compute the centroid.
• Motor Schema Convert the percept to a
  command to steer the motor.

•
  Behaviour Table

9
Case Study Unmanned Vehicle to Autonomously
Navigate around an outdoor course of white lines
painted on grass

• Step 5 Refine each behaviour
• Concentrate on the design of each individual
  behaviour
• Step 6 Test each behaviour independently
• The only way to verify the perceptual schema
  is to try in the real world.

10
Case Study Unmanned Vehicle to Autonomously
Navigate around an outdoor course of white lines
painted on grass

• Step 7 Test with other behaviours
• Perform integration testing with the
  behaviours combined in the actual environment
• Ex follow_line did not work well with visual
  distractions! In the presence of distractions the
  robot needed to ignore vision and deploy
  move_ahead. Use the sonar as a releaser for
  move_ahead. Sonar releaser for move_ahead
  inhibited the follow_line and the lack of a sonar
  releaser inhibited move_ahead.
• New Behaviour Table

11
Representing a Sequence of Behaviours

• 1 Finite State Automata
• Provides a set of popular mechanisms for
  specifying what
• a program should be doing at a given time.
  FSA can be
• written as a table or a state diagram.
• 2 Scripts
• Abstract behaviours often use scripts or
  related construct called skills to provide a
  different way of generating logic for a seqence
  of behaviours. Encourages the designer to think
  of the robot ad task in terms of a screenplay.
• 3 Skills
• Skills collect behaviour like primitives
  called Reaction-Action-Packages (RAPs) into a
  sketchy plan which is filled in as the robot
  executes.

12
Finite State Automata

• States
• current state q element of set of states K
• Initial State
• s or q0, starting state
• Transition Function
• ? a function that specifies the next state when
  the stimulus ? is encountered. ? is the set of
  stimuli
• Final State the terminating states (F)

13
FSA example
Range far
Time remaining
Time elapsed
Move ahead
Follow line
Range near
MK Follow line, Move ahead, ? Range
near, Range far, Time remaining, Time elapsed s
Follow line, F Follow line, Move ahead
14
FSA example for Pick Up the Trash Behaviour
Table
15
Contd. FSA example for Pick Up the Trash
16
FSA for picking up and recycling Coke Cans
State Transitions
17
Scripts

• Abstract Behaviours use scripts/skills to create
  a generic template.
• Scripts encourage the designer to think of the
  robot and the tasks.
• The use of scripts in robots can be thought of as
  a screenplay where the actors are robots reading
  the scripts.
• Scripts allow improvisation and when an
  exception is encountered the robot will follow
  the subscript.

18
Robot Script of Pick Up the Trash
19
Scripts

• Skills
• sets of behaviours
• Props, Cues
• percepts, sensor inputs
• Sub-script
• exception handling
• Causal Chain
• Sequence of behaviours
• Focussing of attention

20
Summary

• Reactive implementation consists of one or more
  behaviours and a mechanism for combining the
  output of concurrent behaviour.
• Designer must develop individual behaviours and
  assemble them into a sequence or abstract
  behaviour
• Finite State Automata offer a method of
  representing the coordination logic needed to
  control a sequence of behaviours
• Scripts are an equivalent with a more natural
  story like flow of control.
• A Behaviour Table represents the releasers, motor
  perceptual schemas for each behaviour.
• Must fully specify the ecological niche of the
  robot in order to design useful behaviours.
• The control should rely on the world to inform
  the robot as to what to do next rather than rely
  on the program to remember and maintain state.
