Breeding Decision Trees Using Evolutionary
Techniques

• Papagelis Athanasios - Kalles
  DimitriosComputer Technology Institute AHEAD RM

2
Introduction

• We use GAs to evolve simple and accurate binary
  decision trees
• Simple genetic operators over tree structures
• Experiments with UCI datasets
• very good size
• competitive accuracy results
• Experiments with synthetic datasets
• Superior accuracy results

3
Current tree induction algorithms

• .. Use greedy heuristics
• To guide search during tree building
• To prune the resulting trees
• Fast implementations
• Accurate results on widely used benchmark
  datasets (like UCI datasets)
• Optimal results ?
• No
• Good for real world problems?
• There are not many real world datasets available
  for research.

4
More on greedy heuristics

• They can quickly guide us to desired solutions
• On the other hand they can substantially deviate
  from optimal
• WHY?
• They are very strict
• Which means that they are VERY GOOD just for a
  limited problem space

5
Why GAs should work ?

• GAs are not
• Hill climbers
• Blind on complex search spaces
• Exhaustive searchers
• Extremely expensive
• They are
• Beam searchers
• They balance between time needed and space
  searched
• Application on bigger problem space
• Good results for much more problems
• No need to tune or derive new algorithms

6
Another way to see it..

• Biases
• Preference bias
• Characteristics of output
• We should choose about it
• e.g small trees
• Procedural bias
• How we will search?
• We should not choose about it
• Unfortunately we have to
• Greedy heuristics make strong hypotheses about
  search space
• GAs make weak hypotheses about search space

7
The real world question

• Are there datasets where hill-climbing techniques
  are really inadequate ?
• e.g unnecessarily big misguiding output
• Yes there are
• Conditionally dependent attributes
• e.g XOR
• Irrelevant attributes
• Many solutions that use GAs as a preprocessor so
  as to select adequate attributes
• Direct genetic search can be proven more
  efficient for those datasets

8
The proposed solution

• Select the desired decision tree characteristics
  (e.g small size)
• Adopt a decision tree representation with
  appropriate genetic operators
• Create an appropriate fitness function
• Produce a representative initial population
• Evolve for as long as you wish!

9
Initialization procedure

• Population of minimum decision trees
• Simple and fast
• Choose a random value as test value
• Choose two random classes as leaves

A2
Class2
Class1
10
Genetic operators
11
Payoff function

• Balance between accuracy and size

• set x depending on the desired output
  characteristics.
• Small Trees ? ? x near 1
• Emphasis on accuracy ? ? x grows big

12
Advanced System Characteristics

• Scalled payoff function (Goldberg, 1989)
• Alternative crossovers
• Evolution towards fit subtrees
• Accurate subtrees had less chance to be used for
  crossover or mutation.
• Limited Error Fitness (LEF) (Gathercole Ross,
  1997)
• significant CPU timesavings and insignificant
  accuracy loses

13
Second Layer GA

• Test the effectiveness of all those components
• coded information about the mutation/crossover
  rates and different heuristics as well as a
  number of other optimizing parameters
• Most recurring results
• mutation rate 0.005
• crossover rate 0.93
• use a crowding avoidance technique
• Alternative crossover/mutation techniques did not
  produce better results than basic
  crossover/mutation

14
Search space / Induction costs

• 10 leaves,6 values,2 classes
• Search space gt50,173,704,142,848 (HUGE!)
• Greedy feature selection
• O(ak) aattributes,kinstances (Quinlan 1986)
• O(a2k2) one level lookahead (Murthy and Salzberg,
  1995)
• O(adkd) for d-1 levels of lookahead
• Proposed heuristic
• O(gen k2a).
• Extended heuristic
• O(genka)

15
How it works? An example (a)

• An artificial dataset with eight rules (26
  possible value, three classes)
• First two activation-rules as below
• (15.0 ) c1 ? A(a or b or t) B(a or h or q or
  x)
• (14.0) c1 ? B(f or l or s or w) C(c or e or
  f or k)
• Huge Search Space !!!

16
How it works? An example (b)
17
Illustration of greedy heuristics problem

• An example dataset (XOR over A1A2)

A1 A2 A3 Class
T F T T
T F F T
F T F T
F T T T
F F F F
F F F F
T T T F
T T F T
18
C4.5 result tree

A3t
A1t
A2f
A2t
t
f
t
f
Totally unacceptable!!!
19
More experiments towards this direction
Name Attrib. Class Function Noise Instanc. Random Attributes
Xor1 10 (A1 xor A2) or (A3 xor A4) No 100 6
Xor2 10 (A1 xor A2) xor (A3 xor A4) No 100 6
Xor3 10 (A1 xor A2) or (A3 and A4) or (A5 and A6) 10 class error 100 4
Par1 10 Three attributes parity problem No 100 7
Par2 10 Four attributes parity problem No 100 6
20
Results for artificial datasets
C4.5 GATree
Xor1 6712.04 1000
Xor2 5318.57 9017.32
Xor3 796.52 788.37
Par1 7024,49 1000
Par2 636.71 857.91
21
Results for UCI datasets
22
C4.5 / OneR deficiencies

• Similar preference biases
• Accurate, small decision trees
• This is acceptable
• Not optimized procedural biases
• Emphasis on accuracy (C4.5)
• Not optimized trees size
• Emphasis on size (OneR)
• Trivial search policy
• Pruning as a greedy heuristic has similar
  disadvantages

23
Future work

• Minimize evolution time
• crossover/mutation operators change the tree from
  a node downwards
• we can classify only the instances that belong to
  the changed-nodes subtree.
• But we need to maintain more node statistics

24
Future work (2)

• Choose the output class using a majority vote
  over the produced tree forest (experts voting)
• Pruning is a greedy heuristic
• A GAs pruning?
