Using the 8254 Timer-Counter

1
Using the 8254 Timer-Counter

• Understanding the role of the systems 8254
  programmable Interval-Timer/Counter

2
Motivation

• We want to explore the Pentiums support for
  multiprocessing (as distinguished from
  multitasking, which we already examined)
• The algorithms for multiprocessor startup will
  require us to use some timed delays (for
  example, a delay of 10 milliseconds)
• Various other systems programming tasks require
  the use of carefully timed delays

3
The 8254 PIT

• The 8254 Programmable Interval-timer is used by
  the PC system for (1) generating timer-tick
  interrupts (rate is 18.2 per sec), (2) performing
  dynamic memory-refresh (reads ram once every 15
  microseconds), and (3) generates beeps of PC
  speaker
• When the speaker-function isnt needed, the 8254
  is available for other purposes

4
Counter decrements when pulsed
COUNT REGISTER
CLK
LSB
MSB
OUT
LSB
MSB
LATCH REGISTER
GATE
STATUS
TIMER/COUNTER CHANNEL
5
Three timer/counter channels
8284 PCLK
1193182 Hz
Channel 0
CLK0
OUT0
Interrupt IRQ0
GATE0
Port 0x61, bit 4
Channel 1
CLK1
OUT1
DRAM refresh
GATE1
Port 0x61, bit 5
CLK2
Channel 2
OUT2
GATE2
speaker
AND
Port 0x61, bit 0
8254 PIT
5 V
Port 0x61, bit 1
6
8254 Command-Port
7 6 5 4
3 2 1 0
CHANNEL
OUTPUT MODE
COMMAND
binary / BCD
Output Mode 000 one-shot level 001
retriggerable 010 rate-generator 011
square-wave 100 software strobe 101
hardware strobe
Counting Mode 0 binary 1 BCD
Channel-ID 00 chn 0 01 chn 1 10 chn 2
Command-ID 00 Latch 01 LSB r/w 10 MSB
r/w 11 LSB-MSB r/w
Commands are sent to the 8254 via io/port 0x43
7
Programming a PIT channel

• Step 1 send command to PIT (port 0x43)
• Step 2 read or write the channels Latch
• via port 0x40 for channel 0
• via port 0x41 for channel 1
• via port 0x42 for channel 2

8
Status/control (via port 0x61)
7 6 5 4
3 2 1 0
R/O
R/O
R/O
R/O
R/W
R/W
R/W
R/W
OUT2 1 on 0 off
memory parity check
i/o channel check enable
speaker 1 on 0 off
OUT1 1 on 0 off
memory parity check enable
GATE2 1 on 0 off
i/o channel check
9
Algorithm for 10-ms delay

• Step 1 turn off Channel 2 counting (and disable
  PC speaker) by clearing bits 0 and 1 at i/o
  port 0x61 (called PORT_B)
• Step 2 issue command to 8254 to accept a new
  value in Channel 2 Latch Register, by outputing
  10110000b to io-port 0x43 i.e., chn2, r/w
  LSB/MSB, one-shot, binary

10
Algorithm (continued)

• Step 3 compute the frequency-divisor for a ten
  millisecond delay (one hundredth of one second)
  by dividing CLK2 frequency (1,193,182 Hz) by
  one-hundred
• Step 4 write quotients LSB, followed by its
  MSB, to channel 2 Latch (io-port 0x42)

11
Algorithm (continued again)

• Begin the Channel 2 countdown (set bit 0 at
  io-port 0x61) and immediately read and save the
  Pentiums TimeStamp Counter
• Spin in a tight loop until the OUT2 signal goes
  active (Channel 2 count exhausted) by testing bit
  5 at io-port 0x61
• Immediately re-read TimeStamp Counter
• Perform subtraction (to get CPU cycles)

12
Algorithm (concluded)

• Divide cycle-count by ten-thousand, to get
  processors clock-speed in Mega-Hertz (i.e., in
  millions of cycles-per-second)
• Display this quotient in decimal format!

13
In-class exercise

• The Real-Time Clock chip automatically updates
  its clock/calendar registers once each second
• Register values cannot be reliably read while the
  RTCs update is in progress
• Most significant bit in RTC register 0x0A
  provides indication of update-in-progress
• How long does the RTC update last?

14
Algorithm for update-duration

• Wait until a new RTC update begins
• Immediately read the TimeStamp Counter
• Wait until this update-operation finishes
• Immediately read the TimeStamp Counter
• Wait until the next update begins
• Immediately read the TimeStamp Counter
• The RATIO of these two time-intervals gives
  update-duration as a fraction of one second
