First Analysis of the Auger APF Light Source

1
First Analysis of the Auger APF Light Source

• Eli Visbal (Carnegie Mellon University)
• Advisor Stefan Westerhoff

2
Overview

• Cosmic Rays and Auger
• Atmospheric Calibration Overview
• APF Light Sources
• Determination of Aerosol Phase Function
• Fluorescence Detector Event Reconstruction
• Problems and Future Work
• Summary and Conclusions

3
Cosmic Rays

• Cosmic Rays are very energetic particles
• These particles can have energies over 1020 eV
• When these particles enter the atmosphere they
  produce a shower of lower energy secondary
  particles
• The origin of those with highest energies remains
  a mystery
• This is in part due to magnetic deflection
• GZK cutoff prevents particles above 6x1019 eV
  from traveling more than roughly 150 million
  light years

4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
Pierre Auger Observatory

• Hybrid detector
• Located in Malargue, Argentina
• 4 Fluorescence Detector and 1600 Surface Detector
  Stations

12
Auger Observatory
13
Fluorescence Detector

• Cosmic Rays are studied by observing nitrogen
  fluorescence light caused by relativistic
  electrons created in a shower

14
Fluorescence Detector
15
Shower Profile
16
Atmospheric Calibration

• Cherenkov beam builds up along shower axis
• Atmospheric transmission
• Multiple scattering
• Aerosol (Mie) and Molecular (Rayleigh) scattering
• Aerosol phase function (normalized differential
  scattering cross section) must be known to
  account for multiple-scattering and Cherenkov
  subtraction

17
APF Light Sources

• APF light sources shoot a near-horizontal pulse
  across the field of view of a FD
• One FD at Coihueco and one at FD Los Morados
• Wavelengths used 330nm, 360nm and 390nm

18
APF Light Sources
Coihueco FD Alpha 26 degrees Beta 38
degrees Gamma 20 degrees
19
APF Shot
APF Shot as seen by the Coihueco fluorescence
detector
20
APF Measurement
21
Geometrical Corrections
22
Phase Function Fit
Mie
Rayleigh
Fit Function
23
APF shot Angle Determination
Rayleigh Dominated Data

• A Rayleigh dominated night was found
• According to theory scattering should be
  symmetric about 90 degrees

Scattering angle radians
24
APF Fits
25
FD Reconstruction

• Signal that reaches the telescope must be
  processed with reconstruction software to measure
  total energy
• Simulated aerosol phase function used now
• How big of correction when applying measured
  function?

26
Effects on Energy Reconstruction
27
Current Problems

• Unstable fit
• Geometry of APF needs to be measured
• High angle and low angles not fit
• Only one wavelength currently used
• Quality of data
• Too Many Parameters in Fit

28
Conclusions

• Aerosol phase function measured successfully
• Energy correction less than 1
• Some additional work required
