Recent Progress on Automatic Phoneme Alignment

1
Recent Progress on Automatic Phoneme Alignment

• Hung-Yi Lo and Hsin-Min Wang

2
Outline

• A Minimum Boundary Error Framework for Automatic
  Phonetic Segmentation (ICSLP06, ISCSLP06)
• Phonetic Boundary Refinement Using Support Vector
  Machine (submitted to ICASSP06)
• Introduction
• Reduced support vector machine
• Phone-transition-dependent SVM classifier
• Experimental results
• Progress on Manually Corpus Labeling

3
Automatic Corpus Segmentation Problem
4
Boundary Refinement Using SVM
5
Introduction to Support Vector Machine
6
Support Vector Machines Formulation

• Solve the quadratic program for some

min
(QP)
s. t.
,
7
Reduced Support Vector Machine

• Overcoming computational and storage difficulties
  in nonlinear SVM by using a rectangular kernel.
• Choose a small random sample
  of .
• Replace by
  in nonlinear SVM.
• Only need to compute and store
  numbers for the rectangular kernel.
• Computational complexity reduced from
  to .
• The nonlinear classifier is defined by the
  optimal solution by solving a
  quadratic programming problem.

8
Feature Extraction in Refinement Stage

• Each frame represented by a 45-dim vector
• 39 MFCC-based coefficients
• Zero crossing rate
• Bisector frequency
• Burst degree
• Spectral entropy
• General weighted entropy
• Subband energy
• Two features were extracted for each hypothesis
  boundary
• Symmetrical Kullback-Leibler distance
• Spectral feature transition rate
• Each hypothesized boundary was represented by the
  feature vectors of the left and right frames next
  to it and the two boundary feature, which is a
  92-dim augmented vector.

9
Phone-Transition-Dependent SVM Classifier
10
Phone Transition Clustering

• For each specific phone transition case, we
  gather all augmented vectors associated with the
  human-labeled phone boundaries, and compute the
  mean vector.
• For each one of the three phone transition
  classes, sonorant to non-sonorant, sonorant to
  sonorant, non-sonorant to non-sonorant, apply
  K-means algorithm to cluster the phone
  transitions according to their mean vectors.
• Note that only the phone transitions with enough
  instances are considered in this step.
• The number of clusters is determined according to
  the cross-validation accuracy that the resulting
  SVM classifiers achieve in the training data.
• We assign the phone transitions, which are
  ignored in Step 2), to the nearest clusters
  according to the distances between their mean
  vectors and the cluster centers.

11
Discriminative Feature Extraction

• For each partition subset, two discriminative
  features, namely discriminative weighted entropy
  and discriminative subband energy are extracted
  to replace the general weighted entropy and
  subband energy.
• Discriminative weighted entropy
• where is a weight vector and is
  the element of normalized power spectrum. The
  weight vectors of each partition subset is
  trained by linear SVM, to maximize the variation
  of the weighted entropy feature close to the true
  boundary.

12
Discriminative Feature Extraction

• Discriminative subband energy
• where is
  pre-defined subband energy and the
• weight score defined as
• where and are the mean and
  standard deviation of the j-th subband energy for
  the training samples of the left or negative
  class.

13
Boundary Recognition Using SVM

• A RSVM classifier trained for each phone
  transition subset.
• Augmented vector associated with the true
  boundaries are the positive training samples.
• Randomly selected augmented vector at least 20ms
  away from the true boundary as the negative
  training example.
• Gaussian kernel with weighted Euclidean distance
  is applied.
• In the testing phase, the augmented vector around
  the hypothesized boundary are examined by the
  classifier according to which the phone
  transition belong.
• The position with the maximum classifier output
  is recognized as the refined boundary.

14
Experimental Setup

• TIMIT corpus (dialect sentences are excluded)
• Training set 3696 utterances
• Testing set 1312 utterances
• Context independent HMMs used for preliminary
  alignment
• 50 phone models (left-to-right topology)
• 3 states for each HMM
• 5265 mixtures totally
• Frame window size and shift are 20 ms and 5 ms
  respectively.
• 12 MFCCs and log energy, and their first and
  second differences
• CMS and CVN are applied.

15
Experimental Setup

• Phone transition cluster is determine by
  cross-validation on the TIMIT training data.
• 20 in the sonorant to non-sonorant class
• 16 in the sonorant to sonorant class
• 10 in the non-sonorant to non-sonorant class
• In the refinement phase, 5 hypothesized
  boundaries extracted every 5 ms around the
  initial boundary within 10 ms will be examined
  by SVM.

16
Experimental Results
17
Thank you
