Multivariate Analysis

1
Multivariate Analysis

• Muhammad Qaiser Shahbaz
• Department of Statistics
• GC University, Lahore

2
Multivariate Analysis

• Multivariate Analysis is a study of several
  dependent random variables simultaneously.
• These analysis are straight generalization of
  univariate analysis.
• Certain distributional assumptions are required
  for proper analysis.
• The mathematical framework is relatively complex
  as compared with the univariate analysis.
• These analysis are being used widely around the
  world.

3
Some Multivariate Distributions

• The Multivariate Normal Distribution
• Generalization of famous Normal Distribution
• The Wishart Distribution
• Generalization of the ChiSquare Distribution
• The Hotellings T2Statistic and Distribution
• Generalization of square of Studentst statistic
  and distribution
• The Willks Lambda Statistic
• Generalization of ratio of two ChiSquare
  statistic

4
Some Multivariate Measures

• The Mean Vector
• Collection of the means of the variables under
  study
• The Covariance Matrix
• Collection of the Variances and Covariances of
  the variables under study
• The Correlation Matrix
• Collection of Correlation Coefficients of the
  variables involved under study
• The Generalized Variance
• Determinant of the Covariance Matrix

5
Some Multivariate Tests of Significance

• Testing significance of a single mean vector
• Testing equality of two mean vectors
• Testing equality of several mean vectors
• Testing significance of a single covariance
  matrix
• Testing equality of two covariance matrices
• Testing equality of several covariance matrices
• Testing independence of sets of variates
• Testing independence of variates

6
Some Multivariate Techniques

• The Hotellings T2 Statistic
• The Multivariate Analysis of Variance and
  Covariance
• The Multivariate Experimental Designs
• The Multivariate Profile Analysis
• The Multivariate Regression Analysis
• The Generalized Multivariate Analysis of Variance
• The Principal Component Analysis
• The Factor Analysis

7
Some Multivariate Techniques

• The Canonical Correlation Analysis
• The Discriminatory Analysis
• The Cluster Analysis
• The Multidimensional Scaling
• The Correspondence Analysis
• The Classification Trees
• The Path Analysis
• The Structural Equations Models
• The Seemingly Unrelated Regression Models

8
The Factor Analysis

• Deals with the grouping of like variables in
  sets.
• Sets are formed in decreasing order of
  importance.
• Sets are relatively independent from each other.
• Two types are commonly used
• The Exploratory Factor Analysis
• The Confirmatory Factor Analysis
• One of the most commonly used technique in social
  and psychological sciences

9
The Exploratory Factor Analysis

• This technique deals with exploring the structure
  of the data.
• The variables involved under the study are
  equally important.
• Variables are grouped together on the basis of
  their closeness.
• Groups are generally formed so that they are
  orthogonal to each other but this assumption can
  be relaxed.
• This technique exactly explains the Covariances
  of the variables.

10
Exploratory Factor Analysis

• Two major types of exploratory factor analysis
  are available based upon the underlying
  assumptions.
• The Orthogonal Factor Analysis
• Based upon the assumption that the established
  factor are orthogonal so they can not be further
  factorized.
• The Oblique Factor Analysis
• Based upon the assumption that the established
  factors are not orthogonal and so can be further
  factorized.

11
Orthogonal Factor Model

• Based upon the model for each of the underlying
  variable.
• The Factor Analysis model is

12
Structure of Covariance Matrix

• The model for all the variables is
• The Covariance Matrix is decomposed as

13
Some Measures in Factor Analysis

• The Factor Analysis Model is
• The quantity is loading of ith variable
  on jth factor and measures the degree of
  dependence of a variable on a factor.
• The ith communality that measures the portion
  of variation of ith variable explained by jth
  factor is given as

14
Structure of Variance and Covariance

• The Factor Analysis Model is
• Variance of ith variable is given as
• The Covariance between ith and kth variable is

15
Extraction Methods

• Principal Component Extraction
• Extract the Factors to Maximize the Variance
• Maximum Likelihood Extraction
• Maximize the probability of observing the
  underlying correlation matrix
• Generalized Least Square Extraction
• Minimize the difference between offdiagonal
  elements of observed and reproduced correlation
  matrix
• Principal Axis Factoring
• Uses estimated communalities instead of 1s in
  diagonal element of the correlation matrix
• Alpha Factoring
• Used to obtain the consistent factors in repeated
  samples

16
Factor Rotation

• Rotation is done to simplify the solution of
  factor analysis.
• Interpretations can be easily done from rotated
  solution.
• Two types of rotations are available
• Orthogonal Rotation factors formed are
  orthogonal
• Oblique Rotation factors formed are correlated

17
Orthogonal Rotations

• Rotated factors are orthogonal.
• Several rotation methods are available depending
  upon their work. Most common are given.
• Varimax Rotation (Kaiser1958)
• Minimize complexity of factors by maximizing
  variance of loading on each factor.
• Quartimax Rotation (Mulaik1972)
• Minimize complexity of variables by maximizing
  variance of loading on each variable.
• Equamax Rotation (Harman1976)
• Simplify both variables and factors. Compromise
  between Varimax and Quartimax.

18
Oblique Rotation

• Rotated factors are correlated.
• Several methods are available depending upon the
  permitted amount of correlation in rotated
  factors.
• Direct Oblimin Rotation
• Simplify factors by minimizing cross products of
  loading. Depends upon the provided value of
  correlation among factors.
• Promax Rotation
• Orthogonal factors rotated to oblique position.
  Orthogonal factor loadings are raised to a
  positive power.

19
Test for Model Fit

• The goodness of fitted factor analysis model can
  be tested by using the ChiSquare statistic. The
  null hypothesis to be tested is
• The test statistic for this test has been
  developed by Lawley (1940) and Bartlett (1954).
• The Measure of Sampling Adequacy, given by Kaiser
  and Rice (1974) provide some sort of evidence
  about model fit.

20
The Factor Scores

• The values of factors for given values of
  variables are Factor Scores.
• Various methods are available for factor scores
• Bartletts Method (Bartlett 1938)
• The Regression Method (Thompson 1934)

21
Example1

• Data from 100 individuals was collected on 10
  dimensions to see the satisfaction level. A
  portion of data is given below

22
Specifying the Analysis
23
Specifying the Analysis
24
Specifying the Analysis
25
The Output
26
The Output
27
The Output
28
The Output
29
The Output
30
The Output
31
Canonical Correlation Analysis

• Deals with the study of relationship between two
  sets of variates.
• Goal is to find the Linear Combination of
  variables that are maximally correlated with each
  other.
• It is an extension of Principal Component
  Analysis.
• The linear combination of variables are obtained
  under certain constraints.
• The sets of variates can treated as dependent and
  independent sets.

32
Canonical Correlation Analysis

• The primary purpose is to find the pairs of
  linear combination of variables so that they are
  highly correlated.
• As many pairs are obtained as there are variables
  in the set with smaller number of variables.
• The pairs are obtained so that they have
  correlation in decreasing order.
• Can be used to test the independence of sets of
  variates in case of Multivariate Normality.

33
Canonical Correlation Analysis

• The aim in canonical correlation analysis is to
  obtain the maximum correlation between sets of
  variates called Canonical Correlation.
• Another aim is to obtain the vectors of
  coefficients to obtain the linear combination of
  variables called Canonical Variates.
• Predictive Validity of Multivariate Regression
  can also be judged using canonical correlation
  analysis.

34
Theoretical Framework

• The Canonical Correlation Analysis is based upon
  the Joint Covariance (Joint Correlation) matrix
  of two sets of variates.
• The joint covariance matrix of two sets of
  variates containing p and q variates is given
  as

35
Theoretical Framework

• The Canonical Correlations are obtained by
  solving the determinantial equation
• The ith pair of Canonical Variates is given as
• The coefficient vectors are obtained by solving

36
Testing Significance of Canonical Correlations

• Several tests of significance can be tested by
  using canonical correlation analysis.
• A test of overall independence of two sets of
  variates can be based upon the testing of the
  hypothesis that all the Canonical Correlations
  are simultaneously zero. This test was developed
  by Willks (1932). The null hypothesis here is
• Testing this hypothesis is equivalent to testing
  the Significance of Regression Matrix in
  Multivariate Regression.

37
Testing Significance of Canonical Correlations

• A more general test of significance is to test
  that first k canonical correlations are
  nonzero whereas the last sk canonical
  correlations are zero. The null hypothesis is
• The test statistic for testing this hypothesis is

38
Measures of Association

• Certain measures of association are available in
  Canonical Correlation Analysis to decide about
  the model fit. Some are given
• Generalized Measure of Association
  (Rozeboom1965)
• Generalized Coefficient of Determination
  (Yanai1974)

39
Proportion of Variation in Canonical Correlation
Analysis

• The Correlation between actual variates and
  canonical variate is given as
• Proportion of Variation of a variable explained
  by the canonical variate is

40
A Glimpse of STATISTICA
41
Example2

• Data from 100 individuals was collected on 10
  dimensions to see the satisfaction level. A
  portion of data is given below. We will see the
  relationship is two sets of variates.

42
Specifying the Analysis
43
Specifying the Analysis
44
The Output
45
The Output
46
The Output
47
The Output
48
The Canonical Variates

• The Canonical Variates for first set are

49
The Canonical Variates

• The Canonical Variates for second set are

50
The Structural Equation Models

• One of the most powerful techniques in
  Statistical Analysis.
• Deals with modeling of different types of
  variables.
• The variables may be discrete or continuous.
• Allows wide variety of variables that can be
  included.
• Allows the use of variables as well as factors as
  dependent and independent variables.

51
The Structural Equation Models

• Combination of Regression Analysis and
  Exploratory Factor Analysis.
• Some other names of the technique are Causal
  Models, Simultaneous Equation Models, Path
  Analysis, Confirmatory Factor Analysis, Latent
  Variables Modeling.
• In fact all the alternative names are special
  cases of this technique.

52
Terminology of Structural Equation Models

• Latent Variables
• The unobserved variables or factors in the
  analysis, either dependent or independent.
• Manifest Variables
• The observed variables in the analysis, either
  dependent or independent.
• Path Diagram
• The diagrammatic presentation of Structural
  Equation Model.

53
Notions of Path Diagram

• The Manifest variables are represented by the
  squares or rectangles.
• The Latent variables are represented by the
  circles or ovals.
• The relationships between variables are
  represented by single sided arrows.
• Direction of the arrow shows the direction of the
  relationship.
• Double sided relationships are represented by
  double sided arrows.

54
Some Rules of Path Diagram

• All the dependent (endogenous) variables have
  arrows that are directing to them.
• All the independent (exogenous) variables have
  their variances and covariances represented
  explicitly or implicitly. If variances and
  covariances are not represented explicitly then
• For latent variables, variances not explicitly
  represented in the diagram are assumed to be 1.0,
  and covariances not explicitly represented are
  assumed to be 0.
• For manifest variables, variances and covariances
  not explicitly represented are assumed to be free
  parameters.

55
A Simple Path Diagram
56
Two Special Cases of Structural Equation Models

• Two special cases of structural equation models
  are widely used on the basis of their
  applicability. These are
• Confirmatory Factor Analysis
• Path Analysis

57
Confirmatory Factor Analysis

• It is like Exploratory Factor Analysis but with
  the exception that number of factors are
  specified in advance.
• The model contain one latent and one manifest
  variable.
• Uses the same model as used by exploratory factor
  analysis.
• The confirmatory factor analysis model is
  generally under identified.

58
The Path Analysis

• Widely used in Economics.
• All the variables included in the analysis are
  manifest.
• Also known as the Simultaneous Equation Models.
• The underlying model of the analysis is

59
Theoretical Framework

• The General Structural Equation Model is

60
Estimation of Model Parameter

• Estimation of parameters in Structural Equation
  Models is not easy.
• The Maximum Likelihood or Generalized Least
  Squares Method can be used for estimation
  purpose.
• One very important thing in parameter estimation
  is to decide whether parameters are estimable or
  not.
• If parameters are estimable then model is exactly
  or over identified.

61
Identification of the Model

• A simple rule for identification of the model
  parameters and hence for identification of the
  structural equation model is given below
• Any parameter of the structural equation model
  that can be represented as a function of one or
  more elements of the variancecovariance matrix
  of the structural model is identifiable. If all
  parameters are identifiable then the model is
  identified.

62
General Use of Structural Equation Models

• The general use of Structural Equation Models is
  to test a theory, postulated for a given
  framework. The theory is tested by using the
  estimate of population covariance matrix.
• A theory is said to be acceptable if its
  generated estimate of the covariance matrix is
  most consistent with the population covariance
  matrix.

63
Testing Adequacy of the Model

• The adequacy of the Structural Equations Model
  can be tested by using the ChiSquare statistic
  that is based upon the minimum of the residual
  function when convergence is achieved.
• An insignificant result of this test indicates
  that the model fits the data reasonably well and
  hence is adequate.

64
Some Useful Measures

• Normed Fit Index (Bentler Bonett1980)
• Value of greater than 0.9 indicates good fit.
  This index may underestimate the fit of a good
  fitting model.
• NonNormed Fit Index
• This index may go outside the (01) range. In
  small samples this may be too small.

65
Some Useful Measures

• Incremental Fit Index (Bollen1989)
• This index is less variable as compared with the
  NonNormed Fit Index.
• Comparative Fit Index (Bentler1988)

66
Some Useful Measures

• Absolute Fit Index (McDonald Marsh1990)
• This index depends only on the model under
  study.
• Goodness of Fit Indices (Bentler1983)
• This index is similar to the R2 of Regression
  Analysis.

67
Some Useful Measures

• Parsimony Fit Index (Mulaik et al.1989)
• Depends upon number of estimated parameters.
• Akaike Information Criterion (Akaike1987)
• Small values of these indices indicates good
  fit.
• Root Mean Square Residual

68
ExampleConfirmatory Factor Analysis

• In a study by Jöreskog and Lawley (1968), nine
  psychological tests were administered to 72
  students of seventh and eight grade. The
  Correlation Matrix of the scores is given. We
  will run a Confirmatory Factor Analysis of the
  data.

69
Path Diagram of the Model
70
Specifying the Analysis
71
The Output
72
The Output
73
ExampleStructural Model

• Jöreskog and Sörbom (1982) used following data
  on Home Environment and Mathematics achievement.
  Following correlation matrix was used. We will
  fit structural model on this data.

74
Path Diagram of the Model
75
Specifying the Analysis
76
The Output
77
The Output
78

• Thank You
