Real-Time Vision on a Mobile Robot Platform

1
Real-Time Vision on a Mobile Robot Platform

• Mohan Sridharan
• Joint work with Peter Stone
• The University of Texas at Austin
• smohan_at_ece.utexas.edu

2
Motivation

• Computer vision challenging.
• State-of-the-art approaches not applicable to
  real systems.
• Computational and/or memory constraints.
• Focus efficient algorithms that work in
  real-time on mobile robots.

3
Overview

• Complete vision system developed on a mobile
  robot.
• Challenges to address
• Color Segmentation.
• Object recognition.
• Line detection.
• Illumination invariance.
• On-board processing computational and memory
  constraints.

4
Test Platform Sony ERS7

• 20 degrees of freedom.
• Primary sensor CMOS camera.
• IR, touch sensors, accelerometers.
• Wireless LAN.
• Soccer on 4.5x3m field play humans by 2050!

5
The Aibo Vision System I/O

• Input Image pixels in YCbCr Color space.
• Frame rate 30 fps.
• Resolution 208 x 160.
• Output Distances and angles to objects.
• Constraints
• On-board processing 576 MHz.
• Rapidly varying camera positions.

6
Robots view of the world
7
Vision System Flowchart
8
Vision System Phase 1 Segmentation.

• Color Segmentation
• Hand-label discrete colors.
• Intermediate color maps.
• NNr weighted average Master color cube.
• 128x128x128 color map 2MB.

9
Vision System Phase 1 Segmentation.

• Use perceptually motivated color space LAB .
• Offline training in LAB generate equivalent
  YCbCr cube.

10
Vision System Phase 1 Segmentation.
11
Vision System Phase 1 Segmentation.

• Use perceptually motivated color space LAB.
• Offline training in LAB generate equivalent
  YCbCr cube.
• Reduce problem to table lookup.
• Robust performance with shadows, highlights.
• YCbCr 82, LAB 91.

12
Sample Images Color Segmentation.
13
Sample Video Color Segmentation.
14
Some Problems

• Sensitive to illumination.
• Frequent re-training.
• Robot needs to detect and adapt to change.
• Off-board color labeling time consuming.
• Autonomous color learning possible

15
Vision System Phase 2 Blobs.

• Run-Length encoding.
• Starting point, length in pixels.
• Region Merging.
• Combine run-lengths of same color.
• Maintain properties pixels, runs.
• Bounding boxes.
• Abstract representation four corners.
• Maintains properties for further analysis.

16
Sample Images Blob Detection.
17
Vision System Phase 2 Objects.

• Object Recognition.
• Heuristics on size, shape and color.
• Previously stored bounding box properties.
• Domain knowledge.
• Remove spurious blobs.
• Distances and angles known geometry.

18
Sample Images Objects.
19
(No Transcript)
20
Vision System Phase 3 Lines.

• Popular approaches Hough transform, Convolution
  kernels computationally expensive.
• Domain knowledge.
• Scan lines green-white transitions candidate
  edge pixels.

21
Vision System Phase 3 Lines.

• Incremental least square fit for lines.
• Efficient and easy to implement.
• Reasonably robust to noise.
• Lines provide orientation information.
• Line Intersections can be used as markers.
• Inputs to localization.
• Ambiguity removed through prior position
  knowledge.

22
Sample Images Objects Lines.
23
Some Problems

• Systems needs to be re-calibrated
• Illumination changes.
• Natural light variations day/night.
• Re-calibration very time consuming.
• More than an hour spent each time
• Cannot achieve overall goal play humans.
• That is not happening anytime soon, but still

24
Illumination Sensitivity Samples.

• Trained under one illumination
• Under different illumination

25
Illumination Sensitivity Movie
26
Illumination Invariance - Approach.

• Three discrete illuminations bright,
  intermediate, dark.
• Training
• Performed offline.
• Color map for each illumination.
• Normalized RGB (rgb use only rg) sample
  distributions for each illumination.

27
Illumination Invariance Training.

• Illumination bright color map

28
Illumination Invariance Training.

• Illumination bright map and distributions.

29
Illumination Invariance Training.
30
Illumination Invariance Testing.
31
Illumination Invariance Testing.
32
Illumination Invariance Testing.
33
Illumination Invariance Testing.
2
34
Illumination Invariance Testing.

• Testing - KLDivergence as a distance measure
• Robust to artifacts.
• Performed on-board the robot, about once a
  second.
• Parameter estimation described in the paper.
• Works for conditions not trained for
• Paper has numerical results.

35
Adapting to Illumination changes Video
36
Some Related Work

• CMU vision system Basic implementation.
• James Bruce et al., IROS 2000
• German Team vision system Scan Lines.
• Rofer et al., RoboCup 2003
• Mean-shift Color Segmentation.
• Comaniciu and Peer PAMI 2002

37
Conclusions

• A complete real-time vision system on board
  processing.
• Implemented new/modified version of vision
  algorithms.
• Good performance on challenging problems
  segmentation, object recognition and illumination
  invariance.

38
Future Work

• Autonomous color learning.
• AAAI-05 paper available online.
• Working in more general environments, outside the
  lab.
• Automatic detection of and adaptation to
  illumination changes.
• Still a long way to go to play humans ?.

39
Autonomous Color Learning Video

• More videos online
• www.cs.utexas.edu/AustinVilla/

40
THATS ALL FOLKS ?
www.cs.utexas.edu/AustinVilla/
41
(No Transcript)
42
Question 1 So, what is new??

• Robust color space for segmentation.
• Domain-specific object recognition line
  detection.
• Towards illumination invariance.
• Complete vision system closed loop.
• Accept cannot compare with other teams, but
  overall performance good at competitions

43
Vision 1 Why LAB??

• Robust color space for segmentation.
• Perceptually motivated.
• Tackles minor changes shadows, highlights.
• Used in robot rescue

44
Vision 2 Edge pixels Least Squares??

• Conventional approaches time consuming.
• Scan lines faster
• Reduces colors needing bounding boxes.
• LS easier to implement fast too.
• Accept have not compared with any other method

45
Vision 3 Normalized RGB ??

• YCbCr separates luminance but not good for
  practice on Aibo.
• Normalized RGB (rgb)
• Reduces number of dimensions - storage.
• More robust to minor variations.
• Accept have compared with YCbCr alone LAB
  works but more storage and calculations

46
Illumination Invariance Training.
47
Illumination Invariance Testing.
