Title: Robot vision


1
  • ROBOT VISION

2
INTRODUCTION
  • Robot vision-
  • - a brief introduction
  • Machine vision-
  • Vision for robots requires the ability to
    identify and accurately determine the positions
    of all relevant three dimensional objects within
    the robot work place.
  • David G. Lowe

3
Definition of Robot vision
  • Robot vision may be defined as the process of
    extracting, characterizing, and interpreting
    information from images of a three dimensional
    world 1
  • 1 www.ite.his.se/ite/research/automation/course/
    vision.htm

4
Purpose Of A Machine Vision System
  • Analyzes images and produces descriptions of what
    is being imaged.
  • Input to the system- Image
  • Output from the system- satisfy two criteria.

5
Robot Vision-Fundamental Tasks
  • -Image transformation
  • -Image analysis
  • -Image understanding

6
General Purpose Robot Vision(1)
  • Important thing-
  • System should capture the relevant
    data and with the motion of the object it should
    be able to update the information.
  • Four steps to General Purpose Robot Vision
  • - Object verification and tracking
  • - Fast extraction of stable image
  • features

7
General Purpose Robot Vision (2)
  • - Object model acquisition
  • - Efficient indexing of the model
  • database
  • David G. Lowe

8
Vision Sensors
  • Special Vision Sensors
  • - Eye-in-hand Vision System
  • Fiber optic sensors
  • Laser sensors
  • Ultrasonic Transducers
  • Passive infra-red sensors
  • Radar systems- Not generally used
  • Neuromorphic Sensors

9
Stereo Vision
  • Stereovision is basically inferring scene
    geometry from two or more images taken
    simultaneously from slight different viewpoints
  • Stereo Vision- Feeling of Depth

10
Active/Dynamic Stereo Vsion
  • Active vision seeks to gather scene information
    dynamically and selectively by probing and
    exploring the entire visual field for the
    information that is salient to the particular
    task at hand

  • John Pretlove

11
Advantages Of Active Vision
  • Stabilizes the image
  • figure-ground separation
  • Better range estimation
  • Lessening the effect of occlusions
  • Useful in Robot Navigation

12
Research Issues
  • -Sensor Technology
  • -Approach to Human Vision
  • -Neural Networks
