Learning Structured Classifiers for Statistical Dependency Parsing

1
Learning Structured Classifiers for Statistical
Dependency Parsing

• Qin Iris Wang
• Supervisors Dekang Lin Dale Schuurmans
• University of Alberta
• May 7th, 2008

2
Ambiguities in NLP
I saw her duck.
How about I saw her duck with a telescope.
3
Dependency Trees
head -gt modifier one and only one head

• A dependency tree structure for a sentence
  represents
• Syntactic relations between word pairs in the
  sentence

with
a
telescope
duck
saw
I
her
Over 100 possible trees!
1 million trees for a 20-word sentence
4
My Thesis Research

• Goal
• Improve dependency parsing via different
  statistical machine learning approaches
• Method
• Tackle the problem from different angles
• Employ and develop advanced supervised and
  semi-supervised machine learning techniques
• Achievement
• State-of-the-art accuracy for English and Chinese

5
Overview

• Dependency parsing model
• Learning dependency parsers
• Strictly lexicalized dependency parsing
• Extensions to Large Margin Training
• Training Dependency Parsers via Structured
  boosting
• Semi-supervised Convex Training for Dependency
  Parsing
• Results
• Conclusion

6
Dependency Parsing Model

• X an input sentence Y a candidate dependency
  tree
• a dependency link from word i to
  word j
• the set of possible dependency trees
  over X

Edge/link-based factorization
A vector of features
A vector of feature weights
7
Features for an Arc
Lots and sparse!

• Word pair indicator
• Part-of-Speech (POS) tags of the word pair
• Pointwise Mutual Information (PMI) for that word
  pair
• Distance between words

Abstraction or smoothing
8
My Work on Dependency Parsing

• 1. Strictly Lexicalized Dependency Parsing (Wang
  et al. 2005)
• MLE similarity-based smoothing
• 2. Improving Large Margin Training (Wang et al.
  2006)
• Local constraints capture local errors in a
  parse tree
• Laplacian regularization - semi-supervised large
  margin training enforce similar links to have
  similar weights -- similarity smoothing
• 3. Structured Boosting (Wang et al. 2007)
• Global optimization, efficient and flexible
• 4. Semi-supervised Convex Training (Wang et al.
  2008)
• Combine large margin loss with least squares loss

9
Overview

• Dependency parsing model
• Learning dependency parsers
• Strictly lexicalized dependency parsing
• Extensions to Large Margin Training
• Training Dependency Parsers via Structured
  boosting
• Semi-supervised Convex Training for Dependency
  Parsing
• Results
• Conclusion

10
Strictly Lexicalized Dependency Parsing
-- IWPT 2005
11
Contributions

• All the features are based on word statistics and
  no POS tags or grammatical categories needed
• Using similarity-based smoothing to deal with
  data sparseness

12
POS Tags for Handling Sparseness in Parsing

• All previous parsers use a POS lexicon
• Natural language data is sparse
• Bikel (2004) found that of all the needed bi-gram
  statistics, only 1.49 were observed in the Penn
  Treebank
• Words belonging to the same POS are expected to
  have the same syntactic behavior

13
An Alternative Method to Deal with Sparseness

• Distributional word similarities
• Distributional Hypothesis --- Words that appear
  in similar contexts have similar meanings
  (Harris, 1968)
• Soft clusters of words
• Advantages of using similarity smoothing
• Computed automatically from the raw text
• Making the construction of Treebank easier

POS hard clusters of words
14
Similarity-based Smoothing
skipped, regularly )
Context
regularly 5
skipped 3
P (
S (regularly)
S (skipped)
frequently 0.365862routinely 0.286178periodica
lly 0.273665often 0.24077constantly
0.234693occasionally 0.226324who
0.200348continuously 0.194026repeatedly
0.177434
Skipping 0.229951skip 0.197991skips
0.169982sprinted 0.140535bounced
0.139547missed 0.134966cruised
0.133933scooted 0.13387jogged 0.133638
15
Similarity-based Smoothing
skipped, regularly )
regularly 5
skipped 3
P (
Pairs seen in the training data
skip frequently skip routinely skip
repeatedly bounced often bounced who bounced
repeatedly
Similar Contexts
16
Overview

• Dependency parsing model
• Learning dependency parsers
• Strictly lexicalized dependency parsing
• Extensions to Large Margin Training
• Training Dependency Parsers via Structured
  boosting
• Semi-supervised Convex Training for Dependency
  Parsing
• Results
• Conclusion

17
Improved Large Margin Dependency Parsing via
Local Constraints and Laplacian Regularization
-- CoNLL 2006
18
Contributions

• Large margin vs. generative training
• Included distance and PMI features, but fewer
  dynamic features
• Local constraints to capture local errors in a
  parse tree
• Laplacian regularization (based on distributional
  word similarity) to deal with data sparseness
• Semi-supervised large margin training

19
(Existing) Large Margin Training
Exponential constraints!

• However,
• Exponential number of constraints
• Loss ignoring the local errors of the parse tree
• A large number of bi-lexical features,
  over-fitting the training corpus

20
Local Constraints (An Example)
4
1
2
3
school
The
boy
skipped
regularly
loss
6
5
score(The, boy) gt score(The,
skipped) 1 score(boy, skipped) gt
score(The, skipped) 1
score(skipped, school) gt score(school,
regularly) 1 score(skipped, regularly) gt
score(school, regularly) 1
5
1
2
5
6
3
6
4
21
Laplacian Regularization

• Enforce the similar links (word pairs) to have
  similar weights

S similarity matrix of word pairs L(S)
Laplacian matrix of S D(S) a diagonal
matrix L(S) D(S) S
22
Refined Large Margin Objective
only for bi-lexical features
polynomial constraints!
23
Overview

• Dependency parsing model
• Learning dependency parsers
• Strictly lexicalized dependency parsing
• Extensions to Large Margin Training
• Training Dependency Parsers via Structured
  boosting
• Semi-supervised Convex Training for Dependency
  Parsing
• Results
• Conclusion

24
Simple Training of Dependency Parsers via
Structured Boosting
-- IJCAI 2007
25
Contributions

• Structured Boosting a simple approach to
  training structured classifiers by applying a
  boosting-like procedure to standard supervised
  training methods
• Advantages
• Global training
• Simple efficient
• General, can be easily applied to other tasks
• Successfully applied to dependency parsing

26
Local Training Examples

• Given training data (X, Y)

local examples
Word-pair Link-label Instance_weight
Features The-boy L 1 W1_The,
W2_boy, W1W2_The_boy, T1_DT, T2_NN,
T1T2_DT_NN, Dist_1, boy-skipped L 1
W1_boy, W2_skipped, skipped-school R 1
W1_skipped, W2_ school,
skipped-regularly R 1 W1_skipped,
W2_regularly, The-skipped N 1
W1_The, W2_skipped, The-school N 1
W1_The, W2_school,
L left link R right link N no link
27
Local Training Methods

• Learn a local link classifier given a set of
  features defined on the local examples
• For each word pair in a sentence
• No link, left link or right link? (3-class
  classification)
• However,
• The parameters of the local model are not being
  trained to consider the global parsing accuracy

28
Global Training for Parsing

• Incorporate the effects of the parser directly
  into the training algorithm --- directly capture
  the relations between the links of an output tree
• Unfortunately, available structured training
  techniques are
• Expensive, specialized, complex to implement
• Require a lot of effort to apply to parsing

Need efficient global training algorithms!
29
Structured Boosting for Dependency Parsing
Global training efficient ?
Training sentences (X, Y)
Compare with the gold standard trees
Local training examples
Re-weight the mis-parsed examples
Dependency parsing algorithm
Link score
Local link classifier c

c1
c2
c3
ck
Dependency trees
30
Overview

• Dependency parsing model
• Learning dependency parsers
• Strictly lexicalized dependency parsing
• Extensions to Large Margin Training
• Training Dependency Parsers via Structured
  boosting
• Semi-supervised Convex Training for Dependency
  Parsing
• Results
• Conclusion

31
Semi-supervised Convex Training for Dependency
Parsing
-- ACL 2008
32
Contributions

• Combined a structured large margin loss on
  labeled data and a least squares loss on
  unlabeled data
• Obtained an efficient, convex, semi-supervised
  large margin training algorithm for learning
  dependency parsers

33
More Data Is Better Data

• The Penn Treebank
• 4.5 million words
• About 200 thousand sentences
• Annotation 30 person-minutes/ sentence
• Limited expensive!

• Raw text data
• News wire
• Wikipedia
• Web resources
• Plentiful free

Supervised learning
Semi/ unsupervised learning
34
Semi-supervised Structured SVM
Non-convex!
Both and are variables

• where

35
Our Approach
Convex!
36
Efficient Optimization Alg.

• Using stochastic gradient steps
• Parameters are updated locally on each labeled
  and unlabeled sentence
• is solved by calling CPLEX
• The objective is globally minimized after a few
  iterations

• Gradient on labeled sentence i

Gradient on unlabeled sentence j
37
Overview

• Dependency parsing model
• Learning dependency parsers
• Strictly lexicalized dependency parsing
• Extensions to Large Margin Training
• Training Dependency Parsers via Structured
  boosting
• Semi-supervised Convex Training for Dependency
  Parsing
• Results
• Conclusion

38
Experimental Design

• Data set (Linguistic Data Consortium), split into
  training, development and test sets
• English
• PTB 50 K sentences (split standard)
• Chinese
• CTB4 15 K sentences (split Wang et al. 2005)
• CTB5 19 K sentences (split Corston-Oliver et
  al. 2006)
• Features
• Word-pair indicator, POS-pair, PMI, context
  features, distance

39
Experimental Design Cont.

• Dependency parsing algorithm
• A CKY-like chart parser with
  complexity
• Evaluation measure
• Dependency accuracy percentage of words that
  have the correct head

40
Results - 1 (IWPT 05)
Evaluation Results on CTB 4.0 ()
An undirected tree root A directed tree
41
Results - 2 (CoNLL 06)
much simpler feature set
Evaluation Results on CTB4 - 10 ()
42
Results - 3 (IJCAI 07)
Evaluation Results on Chinese and English ()
43
Results - 4 (ACL 08)
Evaluation Results on Chinese and English ()
44
Comparison with State-of-the-art
IWPT 2005
IJCAI 2007
Chinese Treebank 4.0 Chinese Treebank 5.0
45
Overview

• Dependency parsing model
• Learning dependency parsers
• Strictly lexicalized dependency parsing
• Extensions to Large Margin Training
• Training Dependency Parsers via Structured
  boosting
• Semi-supervised Convex Training for Dependency
  Parsing
• Results
• Conclusion

46
Conclusion

• I have developed several statistical approaches
  to learning dependency parsers
• Strictly lexicalized dependency parsing
• Extensions to Large Margin Training
• Training Dependency Parsers via Structured
  boosting
• Semi-supervised Convex Training for Dependency
  Parsing
• Achieved state-of-the-art accuracy for English
  and Chinese

47
Thanks!
48

• Features,
• Linguistic intuitions
• Models

Training criteria, Regularization, smoothing
NLP
Machine learning
49
Ambiguities In NLP
Courtesy of Aravind Joshi
I like eating sushi with tuna.
50
Dependency Trees vs. Constituency Trees
S
NP
VP
V
NP
N
Dt
N
Mike
ate
the
cake
A Constituency tree
51
Dependency Tree

• A dependency tree structure for a sentence
• Syntactic relationships between word pairs in
  the sentence

obj
obj
mod
obj
subj
with
tuna
sushi
I
like
eating
with
tuna
sushi
I
like
eating
52
Dependency Parsing

• An increasingly active research area (Yamada
  Matsumoto 2003, McDonald et al. 2005, McDonald
  Pereira 2006, Corston-Oliver et al. 2006, Smith
  Eisner 2005/06, Wang et al. 2006/07/08, Koo et
  al. 2008)
• Dependency trees are much easier to understand
  and annotate than other syntactic representations
• Dependency relations have been widely used in
• Machine translation (Fox 2002, Cherry Lin 2003,
  Ding Palmer 2005)
• Information extraction (Culotta Sorensen 2004)
• Question answering (Pinchak Lin 2006)
• Coreference resolution (Bergsma Lin 2006)

53
Scoring Functions
A vector of feature weights
A vector of features

• Feature weights can be learned via either
  a local or a global training approach

54
Score of Each Link / Word-pair

• The score of each link is based on the features
• Considering the word pair (skipped, regularly)
• (skipped, regularly) 1
• POS (skipped, regularly) (VBD, RB) 1
• PMI (skipped, regularly) 0.27
• dist (skipped, regularly) 2 dist2(skipped,
  regularly) 4

55
However,

• POS tags are not part of natural text
• Need to be annotated by human effort
• Introduce more noise to training data
• For some languages, POS tags are not clearly
  defined
• Such as Chinese or Japanese
• A single word is often combined with other words

Can we use another smoothing technique rather
than POS?
56
Feature Representation

• Represent a word w by a feature vector
• The value of a feature c is

where P(w, c) is the probability of w and c
co-occur in a context window
57
Similarity-based Smoothing

• Similarity measure cosine
• In (Dagan et al., 1999)

58
Comparison With An Unlexicalized Model

• In the unlexicalized model, the input to the
  parser is the sequence of the POS tags, which is
  opposite to our model
• Using gold standard POS tags
• Accuracy of the unlexicalized model 71.1
• Our strictly lexicalized model 79.9


59
Large Margin Training

• Minimizing a regularized loss (Hastie et at.,
  2004)

i the index of the training sentences Ti the
target tree Li a candidate tree the
distance between the two trees
60
Objective with Local Constraints

• The corresponding new quadratic program

polynomial constraints!
j number of constraints in A
61
Combining Local Training witha Parsing Algorithm
62
Standard Boosting for Classification
training examples
Increase the weight of mis-classified examples
Local predictor h

hk
h1
h2
h3
63
Structured Boosting

• Train a local link predictor, h1
• Re-parse training data using h1
• Re-weight local examples
• Compare the parser outputs with the gold standard
  trees
• Increase the weight of mis-parsed local examples
• Re-train local link predictor, getting h2
• Finally we have h1 , h2 , , hk

64
Dynamic Features

• Also known as non-local features
• Take into account the link labels of the
  surrounding word-pairs when predicting the label
  of current pair
• Commonly used in sequential labeling (McCallum
  et al 2000, Toutanova et al. 2003)
• A simple but useful idea for improving parsing
  accuracy
• Wang et al. 2005
• McDonald and Pereira 2006

65
Dynamic Features
with
a
telescope
duck
I
saw
her
with
a
spot
duck
I
saw
her

• Define a canonical order so that a words
  children are generated first, before it modifies
  another word
• telescope/spot are the dynamic features for
  deciding whether generating a link between saw
  with or duck with

66
Results - 1
Table 1 Boosting with static features
67
Variants of Structured Boosting

• Using alternative boosting algorithms for
  structured boosting
• Adaboost M2 (Freund Schapire 1997)
• Re-weighting class labels
• Logistic regression form of boosting (Collins et
  al. 2002)

68
Structured Boosting (An Example)
Gold tree
saw
duck
her
with
telescope
I
a
Parsers output
At each iteration, Increasing instance weights
that are mis-parsed
Iter 1
Try harder!
I
saw
her
with
duck
a
telescope
Try harder!
Iter 2
I
saw
duck
her
with
telescope
a

Good job!
Iter T
I
saw
her
telescope
duck
with
a
69
Similarity Between Word Pairs

• Similarity between two words Sim(w1, w2) (Lin,
  1998)
• Construct a feature vector for w that contains a
  set of words occurring within a small context
  window
• Compute similarities between the two feature
  vectors
• Using cosine measure
• e.g., Sim (skipped, missed) 0.134966
• Similarity between word pairs geometric average

Sim (skipped, regularly, missed, often)
70
A Generative Parsing Model
5
3
2
1
4
school 4
skipped 3
? 0
regularly 5
The 1
kid 2
71
Similarity-based Smoothing
similarity-based Prob.
MLE-based Prob.
Similar Contexts of C
regularly 5
skipped 3
regularly 5
skipped 3
skip frequently skip routinely skip
repeatedly Bounced often Bounced
who Bounced repeatedly
72
Similarity-based Smoothing

• Finally,

P(E C) a PMLE(E C) (1 a) PSIM(E C)
C is the frequency count of the corresponding
context C in the training data
(skipped, regulary) 1 (The, kid) 95
73
Dependency Parsing Algorithms

• Use a constituency parsing algorithm
• Simply treat dependencies as constituents
• With complexity
• Eisners dependency parsing algorithm
  (Eisner 1996)
• It stores spans, instead of subtrees
• Only the end-words are active (still need a head)

74
Existing Semi/unsupervised Alg.

• EM / self-training
• Local minima
• The disconnect between likelihood and accuracy
• Same mistakes can be amplified at next iteration
• Standard semi-supervised SVM
• Non-convex objective on the unlabeled data
• Available solutions are sophisticated and
  expensive (e.g, Xu et al. 2006)

75
Structured Boosting

• A simple variant of standard boosting algorithms
  Adaboost M1 (Freund Schapire 1997)
• Global optimization
• As efficient as local methods
• General, can use any local classifier
• Also, can be easily applied to other tasks

76
Dependency Trees

• A dependency tree structure for a sentence
  represents
• Syntactic relations between word pairs in the
  sentence

mod
obj
subj
obj
det
gen
Over 100 possible trees!
with
a
telescope
duck
saw
I
her
1 million trees for a 20-word sentence
77
Constraints on

• is represented as an adjacency matrix
• Use rows to denote heads and columns to denote
  children
• Constraints on
• All entries in are between 0 and 1
• Sum over all entries on each column is 1
  (one-head rule)
• All the entries on the diagonal are zeros (no
  self-link rule)
•
  (anti-symmetric rule)
• Connectedness (no-cycle)

78
Structured Boosting (An Example)
saw
her
duck
I
with
a
telescope
Instance_weight of saw-with
Instance_weight of duck-with
Weights of local examples

Iter 1 2 3 T
79
Local Constraints
w1 common node
Convex!
Correct link
Missing link

• With slack variables

80
Future Work - 1

• Using alternative boosting algorithms for
  structured boosting
• Adaboost M2 (Freund Schapire 1997)
• Re-weighting class labels
• Logistic regression form of boosting (Collins et
  al. 2002)

81
Future Work - 2

• Multilingual dependency parsing
• Apply our techniques to other languages, such as
  Czech, German, Spanish, French

82
Future Work - 3

• Domain adaptation
• Apply my parsers to other domains (e.g.,
  biomedical data)
• Lack of annotated resources in these domains
• Blitzer et al. 2006, McClosky et al. 2006
