Intellilight Optical Transport Service IOTS

1
Intellilight Optical Transport Service (IOTS)

2
Presentation Outline

• Benefits of Optical Networking
• What is Optical Networking?
• Optical Networking Technologies
• What is DWDM?
• Optical Solutions - Yesterday and Today
• What is Advanced Optical Solutions(AOS)?
• Why Verizon and WITS2001

3
IT network initiatives are exploding

• IT Department funding is growing 5-9 while
  demands are growing 2-3 times that rate
• IT Departments are burdened by storage growth
  rate
• IT Departments need to consolidate multiple
  network service
• IT Departments need to extend LANs beyond the
  campus

New Services
Traditional Services
All of these initiatives drives your demands on
your network
4
while some network demands stay constant!

• Highest possible need for network security
• Security as in protecting the network
• Security as in maintaining application
  availability
• Constant need for scalability
• Scalability as in more bandwidth
• Scalability as in adding more locations
• Scalability as in networking more applications
• Increasing need for reliability
• Reliability as in application performance
• Reliability as in faster recovery

5
at any and all locations!

• Our customers want to reach any site even
  future sites
• This reduces need for IT / Real Estate
  interdepartmental planning
• This minimizes need for overlay networks
• This drives consolidation benefits across entire
  IT budget

Campus 2
Campus 1
All protocols and all service levels must be
available at any site even at sites that are
currently unknown!
New Site n
6
Customers want to network any protocol

• Our customers want to network campus locations
  across the WAN
• Network Service must support all enterprise
  protocols
• Network Hardware must be certified to operate
  across Government networks
• Network Hardware must allow for use of current or
  better management of application domains

Campus 1
Campus 2
GbE Voice FC FICON ESCON ATM FR
GbE Voice FC FICON ESCON ATM FR

MAN
Customers need to extend applications across the
MAN
7
What is Optical Networking?

• Optical Networking Definition
• is the utilization of fiber systems in the
  transfer and management of data from location to
  location across the fiber system.
• Categories of Optical Data Services
• Switched Services - protocol management
• TLS/Gigabit Ethernet, Frame Relay, ATM
• Transport Services - protocol transport
• Architectures - Point to Point or Ring
• Delivery Method - ILEC, Network Integration or
  Hybrid
• Protocols Transported

8
Optical Networking Technologies
Synchronous Optical Network (SONET)
A fiber-optic transmission system for high-speed
digital traffic. Ring and point to point
architectures, standard OC interfaces and
electrical DS1 and DS3 connections.
Optical Interfaces OC-3 155 Mbps OC-12 622
Mbps OC-48 2.48 Gbps
9
Optical Networking Technologies
Dense Wave Division Multiplexing (DWDM)

• High bandwidth, multi-channel, protocol
  independent data transport over single fiber pair
• Supports optical data protocols including
  SONET, ESCON, FICON, Fibre Channel, GigE, D1
  Video, ETR/CLO, Fast Ethernet, ISC.

10
What is Dense Wave Division Multiplexing (DWDM) ?
Dense Wave Division Multiplexing is a technology
that utilizes the properties of refracted light
to both combine and separate optical signals
based on their wavelengths within the optical
spectrum. The Greek letter lambda ( ? ) , is
often used to designate individual
wavelengths. DWDM allows for a more efficient
use of existing fiber by providing multiple
optical paths along a single pair of fibers DWDM
allows for a greater range of protocol
transmission better suited than legacy network
for data centric applications. (Eg. GigE, ESCON,
Fibre Channel, D1 video, ISC)
11
What is Dense Wave Division Multiplexing (DWDM) ?
At Ingress Multiple Optical signals of differing
wavelengths are combined to form a single optical
signal.
At Egress A single Optical signals is refracted
to separate multiple Optical signals of
differing wavelengths.
12
Capacity Enrichment with Optical NetworkingAny
Speed-------------------------Any Protocol
Traditional Capacity Expansions
More Fiber
Y Mb/s
. . .
DWDM
Time Division Multiplexing
OC-48/ STM-16
OC-12/ STM-4
OC-192/ STM-64
600 Mb/s
2.5 Gb/s
N X 100 Gb/s

• Size of transport pipe independent of bit rate
• Virtually unlimited capacity growth potential
• Growth accomplished within established
  infrastructure
• Optimum solution to keep pace with business growth

10 Gb/s

• Size of transport pipe dictated by bit rate
• Limited capacity growth potential
• Growth accomplished through
• infrastructure upgrades

13
Benefits of DWDM

• Increases bandwidth (speed and distance)
• Does not require replacement or upgrade their
  existing legacy systems
• Provides "next generation" technologies to meet
  growing data needs
• Less costly in the long run because increased
  fiber capacity is automatically available don't
  have to upgrade all the time

14
Yesterdays Fragmented Networks
Technology purchased a la carte to support
requirements
Specialized Transport Network
Separate SONET Network
15
Todays Optical Solution
Supports Many Interfaces ATM/IP SONETOC3-OC48,
DS1, DS3 Gigabit Ethernet - 1000Mg Fast Ethernet
- 100Mg ESCON FICON Fibre Channel FDDI D1 Video
Optical Ring could be made up of DWDM, SONET,
NextGen SONET or a combination of architectures
depending upon customer interface requirements
16
Verizon Components

• Equipment
• ILEC Nortel Optera Metro 5200
• Considering additional equipment providers
• NI Flexible Equipment
• Fiber
• ILEC Verizon fiber
• NI Procure fiber from third party vendor
• Network Management
• Verizon SPOC
• Installation/Maintenance/Monitoring

17
What is IntelliLight Optical Transport Service
(IOTS)?

• New product offering utilizing Metro Ring DWDM
  technology to be offered as a dedicated ring
  product.
• It is part of the IntelliLight Suite of Products

18
Intellilight Optical Transport Service
19
IntelliLight Optical Transport Service
Metro Ring DWDM A metro ring DWDM is comprised of
Nodes, Miles and Amplifiers. Whereas a SONET
rings capacity is measured by bandwidth, DWDMs
are measured by quantity of optical paths. This
product will offer 32 protected or 64 unprotected
paths.
Application of rates 4 Nodes 30 Miles 1 Mid-Span
Amp 4 At-Node Amps
Customer Premises
Wire Center
Node C
Node B
8 miles
5 miles
3 miles
Node A
Node D
Customer Premises
Customer Premises
Ampl.
7 miles
7 miles
WireCenter
20
IntelliLight Optical Transport Service
The Metro Ring DWDM itself does not perform
protection switching in the event of a fiber cut
like SONET, however, the individual channels are
provisioned as either protected or unprotected.
Customer Premises
Wire Center
Node C
Node B
8 miles
5 miles
3 miles
Node A
Node D
Customer Premises
Fiber Cut
Ampl.
7 miles
7 miles
WireCenter
21
IntelliLight Optical Transport Service
Protected Channels If a fiber cut should occur
along one of the signals paths, the channel will
reroute and NOT fail.
Application of rates 1 Protected Channel
Customer Premises
Wire Center
Node B
Node C
5 miles
8 miles
3 miles
Node A
Node D
Customer Premises
Fiber Cut
7 miles
7 miles
Ampl.
Available Interfaces OC3, OC3c, OC12, OC12c,
OC48, OC48c, ESCON, FICON, Fibre Channel, ETR,
FDDI, ISC, Fast Ethernet, Gigabit Ethernet, D1
Video
Wire Center
CFA 101 OMC 1 CLLI-A CLLI-C
22
IntelliLight Optical Transport Service
Unprotected Channels for SONET Rings If a fiber
cut should occur along one of the signals paths,
the channel will NOT reroute and will fail.
Application of rates 4 Unprotected Channels 4
SONET Nodes
Customer Premises
Wire Center
E SONET ADM W
W SONET ADM E
Fiber Cut
Node B
Node C
5 miles
3 miles
8 miles
E SONET ADM W
Node A
Node D
W SONET ADM E
Customer Premises
7 miles
7 miles
Ampl.
CFA 101 OMC 1 CLLI-A CLLI-B CFA 101 OMC 1
CLLI-B CLLI-C CFA 101 OMC 1 CLLI-C CLLI-D CFA
101 OMC 1 CLLI-D CLLI-A
Available Interfaces OC3, OC3c, OC12, OC12c,
OC48, OC48c, ESCON, FICON, Fibre Channel, ETR,
FDDI, ISC, Fast Ethernet, Gigabit Ethernet, D1
Video
Wire Center
23
Applications
STORAGE AREA NETWORKING Remote Data Backup and
Restore Point-in-time copy of data to a remote
location and restoration of data in the event of
disaster or loss Remote Data Replication Continuou
s copying of data to another location for data
mirroring Each location contains live, production
data Disaster Recovery Recovery and restoration
services for damaged, deleted or destroyed data,
or site-wide disaster Storage Hosting Outsourced
primary data storage and storage on demand at an
off-site storage facility Managed Storage Data
administration and management provided as an
outsourced service
24
WITS2001 Offering

• Nodes - can be at the CO or Customer Premises
• Primary (up to 16 protected channels)
• Expansion (next 16 protected channels)
• Ring Mileage - node to node
• Network Optimization - Amplifiers
• Mid-span
• At-Node
• Optical Transport Channels
• Protected
• Unprotected

25
Protocol Speed Matrix
26
IntelliLight Optical Transport Service

• CLIN Structure
• Separate CLIN for each tariffed rate, structured
  by term plan period (36 months, 60 months)
• Separate Disconnect CLINs for 3 and 5 year term
  plans at full service rate
• Credit CLINs - structured to recognize months in
  service by customer
• Service Credits
• Two Credits Failure in excess of 4 hours/1
  occurrence per month
• Failure in excess of 1 minute on protected
  channel/NTE 1 occurrence per month

27
Benefits of Intellilight Optical Transport Service

• Market Driven
• Meets customers increased need for higher
  bandwidth services
• Allows customers to deploy new applications that
  are transported over new data protocols
• Offers a full set of optical solutions
• Includes broad variety of protocols, speeds,
  architectures and technology
• Customer applications are the solution drivers
• Verizon will meet customer requirements by
  utilizing the most feasible technology (e.g.,
  Frame, ATM, IP, DWDM, SONET, or a combination)
• Implement Converged Networks that support full
  range of bandwidths, data interfaces,
  architectures and optical service applications
• Leverage existing network infrastructure
