IETF Working Group
CSCI 344 Spring 1998
Presentation
Brett Neely IP Next Generation
2
To boldly go where no network has gone before ...
3
Internet Protocol The Next Generation
4

• Internet Protocol - The Next
• Generation (IPng)
• Idea for the name taken from Star Trek
• Officially known as IPv6 (Internet Protocol
  version 6)
• Will be the successor to IPv4
• 4 1 6? Versions goofed up Version 5
  assigned to the ST protocol. When IETF first
  started planning a successor to IPv4, a document
  incorrectly listed the current version as 6.
  So, they started working on version 7 before
  version 6.
• To escape the confusion of version numbers, the
  project was given the name IP - The Next
  Generation
• Specifications for IPv6 were presented at the
  Toronto IETF meeting, July 1994

5

• What to do?
• The Internet address space as specified by IPv4
  is currently filling up quickly.
• Options
• Limit the total size of the Internet
• Disrupt the network by changing the technology

6

• Birth of IPv6
• IETF started working on the problem of limited
  address space in late 1990
• By February 1992, four separate proposals for an
  update to IPv4 were being worked on
• IETF formed IPng area in late 1993
• An IPng working group BOF was held at July, 1994
  Toronto IETF meeting
• The selected proposal for IPv6 is known as SIPP
  (Simple Internet Protocol Plus)
• SIPP originally had 64 bit IP addresses, which
  was later expanded to 128 bits

7

• Why IPv6?
• Running out of address space - expand size of
  Internet addresses
• Router tables grow at a rate 1.5 times the
  growth of computer memory technology - change
  routing methods to keep router tables
  manageable. IPv6 allows the creation of
  network hierarchies which will improve routing.
• Quality of Service IPv6 has quality of
  service options. Certain Internet traffic
  flows can be labeled for special handling -
  useful for realtime audio and video. (example
  RealAudio) Realtime transmissions need
  consistent throughput to provide regular
  service.

8

• How IPv6?
• A simple, flexible transition from IPv4 -
  Internet hosts can upgrade to IPv6 one at a
  time and not goof up the network. It would be
  impossible to get everyone to switch at the
  same time.
• It is possible that IPv4 and IPv6 will coexist
  on the Internet for several years
• Hosts keep existing IP addresses when they
  switch from IPv4 to IPv6
• Most parts of the existing Internet will not
  have to be renumbered - Routers may be
  renumbered

9

• IPv6 Security
• The current Internet has many security problems,
  lacks security technology beneath the
  application layer
• IPv6 includes extensions which support
  authentication, integrity, and confidentiality
  (Fridays lecture)
• These extensions appear as additional headers
  inside the IP packet
• Support for these extensions is REQUIRED in all
  implementations of IPv6

10

• Revise Standards
• Many of the IETF standards are affected by IPv6
• At least 27 of 51 full Internet standards must
  be revised for IPv6
• This includes any standard which mentions
  32-bit IP addresses even if the address is
  not used otherwise

11

• The 6Bone
• The 6Bone The IPv6 internet backbone
• Experimental network for IPv6, not connected to
  the Internet
• Became operational around July 1996
• Around 40-50 hosts in 32 countries
• Used to assist in evolution and deployment of
  IPv6
• Web page http//www.6bone.net
• The web page has network statistics, including
  daily ping tests for all hosts (tests
  connection reliability)
• The 6Bone project is in the process of becoming
  an IETF workgroup

12

• IPng Web Sites
• http//www.ietf.org/html.charters/ipngwg-charter.
  html
• http//playground.sun.com/pub/ipng/html/ipng-main
  .html

13

• IPng Mailing List
• To subscribe

  Send email to majordomo_at_sunroof.eng.sun.com
  In message body subscribe
  ipng
• Mailing list archive

  ftp//playground.sun.com/pub/ipng/mail-archive/

14

• Internet Draft
• Router Renumbering for IPv6
• Filename draft-ietf-ipngwg-router-renum-03.txt
• March 12 1998
• Expires in September 1998

15

• Internet Draft Router Renumbering
• Dynamic router configuration
• Combination of IPv6 Neighbor Discovery and
  Address Autoconfiguration features
• All implementations MUST include the
  authentication algorithm (HMAC-MD5) specified
  in RFC 2104. Other authentication algorithms
  can optionally be supported.
• All Router Renumbering commands are authenticated

16

• Internet Draft Router Renumbering
• Two types of RR messages Commands and Replies
• Commands are sent TO a router
• Replies are sent FROM a router

17

• Internet Draft Router Renumbering
• Processing RR commands has three steps
• Header check
• Authentication check
• Command execution

18

• RFC 1884
• IPv6 Addressing Architecture
• December 1995

19

• RFC 1884 IPv6 Addressing
• Addresses are 128 bits (IPv4 addresses are 32
  bits)
• Three types of addresses Unicast, Anycast,
  Multicast
• Unicast An address for a single interface
  (Example your computer is assigned one IP
  address when you dial in with PPP)
• Multicast An address for a set of interfaces.
  Packets sent to Multicast addresses are
  delivered to all hosts
• Anycast (New) An address for a set of
  interfaces. Packets sent to Anycast addresses
  are delivered to one host (the nearest one)

20

• RFC 1884 IPv6 Addressing
• 128 bit addresses
• Written in 16-bit hexadecimal fields, separated
  by colons. Example 4F03689000C30158
• IPv6 addresses as URLs - Colons are used to
  specify the port number. For a web page
  address, the current proposal is to use
  http//4F03689000C3015881
  (port number outside of square brackets)
• Square bracket method used in web browsers ONLY,
  not in HTML code.

21

• RFC 1884 IPv6 Address Space
• How many addresses are possible with 128 bit
  addresses?
• 340,282,366,920,938,463,463,374,607,431,768,211,4
  56
• 665,570,793,348,866,943,898,599 addresses per
  square meter of the surface of the planet Earth

22

• RFC 1884 The Unspecified Address
• 00000000
• May never be assigned to any interface
• Useful A host sends it in IP packets as the
  source address before it learns what its true
  address really is
  (Autoconfiguration)
• May not be used as a destination address

23

• RFC 1884 The Loopback Address
• 00000001
• May never be assigned
• May not be used as a source address

24

• 41st IETF Meeting
• Held in Los Angeles, CA, USA
• March 29 - April 3, 1998

25

• IPng at the 41st IETF
• Meeting times/dates
• Monday, March 30, 730-1000pm
• Tuesday, March 31, 345-445pm
• Thursday, April 2, 900-1130am
• Some of the topics to be discussed
• Document Status
• Router Renumbering
• Mobile IPv6 Status
• Multicast Listener Discovery Protocol
• ICMP Name Lookups

26

The End
