Argo FloatLab Database

1
Argo FloatLab Database

• Donald Denbo
• PMEL Developers Forum on Databases
• April 25, 2005

2
Background

• Argo is a global array of 3,000 free-drifting
  profiling floats that will measure the
  temperature and salinity of the upper 2000 m of
  the ocean.  This will allow, for the first time,
  continuous monitoring of the temperature,
  salinity, and velocity of the upper ocean, with
  all data being relayed and made publicly
  available within hours after collection. It will
  improve our understanding of the ocean's role in
  climate.
• Argo deployments began in 2000 and today the
  array is over 59 complete.
• PMELs role includes deploying 80-100 floats per
  year and providing delayed-mode salinity
  calibrations.

3
Float Application

• The Problem
• Manage metadata for Argo data centers.
• Keep accurate records of laboratory tests.
• Automate communication with floats during
  testing.
• Retrieve ARGOS data transmitted during dock test.
• Previous practice
• Hand enter float commands using a terminal
  emulator and hand record results on paper records.

4
The Solution

• Communicate directly with floats using the
  SerialIO library.
• Keep a complete record of all communications in a
  separate log file for each float.
• Retain all important measurements returned from
  the float during testing.
• Use a database to simplify and automate storage
  and retrieval of important data.
• Provide an application that manages the entire
  life cycle of the instrument from when it arrives
  at PMEL until it stops functioning.

5
Dock Test
ARGOS
PostgreSQL
http
Floats db
telnet
jdbc
Lab Tests
log
Serial I/O
jdbc
Salinity Test
Floatlab db
socket
Matlab
MySQL
6
Database Selection

• MySQL 4.1.x chosen
• InnoDB storage engine
• Transaction safe
• Fully ACID compliant (Atomicity, Consistency,
  Isolation, and Durability)
• Crash recovery
• Row level locking
• Foreign Key constraints supported

7
Tables

• Dictionaries
• People, ships, morbidity, parameter ranges
• Implemented as Java HashMap
• Metadata
• Equipment, launch time/location, etc.
• Java objects containing related data referenced
  to float.
• Test Data
• Weight, Air Bladder, Short Workout, Dock, Dock
  Results, Salinity, Final Checks
• One Java object per Test referenced to float.
