Title: Sreeni%20Padmanabhan


1
Sreeni Padmanabhan
  • SPE AU 1617
  • Tel 571-272-0629
  • Email sreeni.padmanabhan_at_uspto.gov

2
Chemical Polymorphism
  • Polymorphism
  • Polymorphs Allotrophs
  • Examples Elements / Inorganic / Organic
  • Carbon graphite diamond
  • ZnS zinc blend and wurtzite
  • Progesterone 5 forms
  • Chloramphenicol 4 (1 amorphous and 3
    crystalline) forms

3
Example of a Hexamorphic Crystal System (1)
4
Photomicrographs
5
Properties
  • Various forms
  • Pseudomorphs
  • Polymorphs
  • Different Physical properties solubility, mp,
    density, hardness, crystal shape, optical and
    electrical properties, vapor pressure
  • Bioavailability, dissolution rate, chemical
    physical stability, color, flow, filterability,
    etc.

6
Characterization
  • Crystallography Single crystal X ray
    diffraction
  • X-ray Powder Diffraction
  • Microscopy Polarizing Optical Microscopy
    Thermal Microscopy
  • Thermal Methods of Analysis Thermogravimetry
    Differential Thermal Analysis and Differential
    scanning calorimetry
  • Vibrational Spectroscopy Raman IR Spectroscopy
  • Chemical Environment NMR Spectroscopy

7
Emphasis on Polymorphism - WHY
  • Solid forms are often critical in the development
    of Active Pharmaceutical ingredients
  • Ground state most stable but least soluble
  • For optimum bioavailability must balance
    properties of stability and solubility
  • Disappearing act of Polymorphs
  • New forms leads to Newer Drug Products
  • New Forms --------- Newer Patents??

8
Polymorphism Patentability
  • Patent Strategies often involve first patenting
    compounds and then applying for patents on
    various polymorphs --- are these polymorphs
    separately patentable?
  • Polymorphs with unexpected properties may support
    Patentability

9
Patentability Example 1
  • Claim 1 A polymorph of benzocaine characterized
    by X-ray diffraction pattern characterized by a
    peak having a diffraction angle (Ø ) of about
    21.6.
  • Claim 2 A method of treating pain comprising
    administering a polymorph of benzocaine
    characterized by X-ray diffraction pattern
    characterized by a peak having a diffraction
    angle (Ø ) of about 21.6.

10
Example 1 (Contd.)
  • Specification
  • Benzocaine hydrochloride was crystallized out of
    acetone, i.e., Form A
  • Benzocaine hydrochloride was crystallized out of
    toluene, i.e., Form B
  • Benzocaine hydrochloride was crystallized out of
    ethanol/water, i.e., Form C (a hemihydrate)
  • The compound is useful for treating pain.
  • X-ray powder diffraction data for each of the
    Forms A, B and C is included.

11
Example 1 Contd Prior art
  • The prior art teaches Polymorphic form G of
    benzocaine hydrochloride, crystallized out of
    n-butanol, useful for treating headache. X-ray
    diffraction data is also given - d values
    38.5, 28.4, 21.5 ----.

12
Example 1 Patentable Claim?
  • Polymorphic form B of benzocaine hydrochloride
    having the following X-ray powder diffraction
    pattern, expressed in terms of d interplanar
    spacing and relative intensities ( I/Imax) R¹
  • dspacing 21.6, 21.6, 20.8, 20.6, 18.5, 17.6.
  • R¹ values 88, 35, 100, 78, 10, 12.

13
Patentability Example 2
  • Claim
  • Polymorph form 2 Tricor having the following
    X-ray powder diffraction pattern expressed in
    terms of d spacing and relative intensities(
    R¹)
  • D spacing 8.95 6.37 5.64
  • R¹ 15, 28, 100.
  • Specification
  • Describes the process of making crystallizing
    the polymorph and also the use of the polymorph
    as a carbohydrate lowering drug.

14
Example 2 (Contd.)
  • Prior art (Reference - A)
  • Teaches Polymorph 1 of Tricor, with a similar use
  • Does not disclose or suggest that Tricor may
    assume distinct, crystalline forms having
    different properties
  • Does not teach a method to make polymorph 2 of
    Tricor.
  • Prior art (reference - B )
  • Lists 16 carbohydrate lowering drug compounds,
    including Tricor
  • Refers to a pharmaceutically acceptable salt,
    hydrate or polymorph thereof, without
    specifically mentioning a polymorph of Tricor.

15
Example 2 (Contd.)
  • The Prior art does not teach that Tricor may
    assume distinct, crystalline, polymorphic forms
    having different physical properties
  • Is a rejection under 35 USC 103 over A in view of
    B proper?

16
Example 2 (Contd.)
  • Obviousness Considerations
  • Whether the claimed Polymorph would have been
    prima facie obvious over Polymorph 1
  • Polymorph 2 is an additional form of an old
    product and both products have similar utility.
    In general, changing the form, purity or another
    characteristic of an old product in an expected
    manner that does not alter its properties, does
    not result in a new non-obvious product.

17
Example 2 (Contd.)
  • Note
  • This conclusion may change on a case by case
    basis depending on the particular facts at issue.
    Obviousness considerations include the
    expectation that the other polymorphic form would
    have been expected to have existed and that one
    would have been motivated to have prepared it,
    and that one would have known how to have
    prepared this other form.
  • Note that, secondary considerations, such as
    unexpected results are always considered. These
    might include unexpected increases in activity or
    bioavailability.

18
Example 2 (Contd.)
  • In this case, no prima facie case of obviousness
    has been established since the prior art does not
    establish that
  • ------- Polymorphic form 2 of Tricor was known,
    and
  • ------- that there were methods of making
    Polymorph 2 of Tricor, known in the prior art.

19
Patentability Example 3
  • Claim
  • A synthetic crystalline zeolite molecular sieve
    having a composition 0.90.1Na2OAl2O32.4-3.4SiO2
    0.45H2O having an X-Ray diffraction pattern
    containing the following d-spacings 8.5, 7.4
    ----
  • Specification
  • Describes how the X-ray pattern was determined
    and how the crystals were prepared
  • Discloses its use as a desiccant and adsorbant.

20
Example 3 (Contd.)
  • Prior art
  • Zeolite R with the following chemical formula
    0.90.2Na2OAl2O33.4-3.6SiO2XH2O, X is about 7
    for the fully hydrated form having an X-ray
    diffraction pattern containing the following d
    spacings 8.55, 7.45 -----
  • Process conditions for making the claimed zeolite
    and the prior art zeolite are similar. Zeolite R
    is useful as a desiccant and adsorbant.
  • Is a rejection under 35 USC 102 or 103 proper?

21
Example 3 (Contd.)
  • 102/103 Rejection
  • Is it proper, if made?
  • The claimed zeolite and prior art zeolite appear
    similar chemically but from the X-Ray pattern it
    is found that there are apparent differences in
    the d values.
  • These apparent differences may be insufficient to
    distinguish that which is claimed from the prior
    art since d value measurements are imprecise
    and the difference in values between the prior
    art and the claimed invention are within the
    limits of experimental variation.
  • Conclusion
  • The rejection is proper there is insufficient
    difference between the two zeolites to conclude,
    absent further evidence, that the claimed
    invention is different than that in the prior
    art.

22
Example 3 (Contd.)
  • The slight differences in d spacings may be
    reasonably attributed to such factors as the
    apparatus used for X-Ray study, humidity,
    temperature, orientation of powder sample, etc.

23
References
  • Chemical Engineering News, The Right Stuff,
    Feb 24,2003, pages 32-34
  • Journal of Pharmaceutical Sciences,
    Pharmaceutical Applications of Polymorphism 58,
    911-929 (1969)
  • Polymorphism in Pharmaceutical Solids,Drugs and
    the Pharmaceutical SciencesV95 Brittain,
    H.G., (1999).

24
Sreeni Padmanabhan
  • SPE AU 1617
  • Tel 571-272-0629
  • Email sreeni.padmanabhan_at_uspto.gov
