Concurrency Control in Distributed MRA Index Structures

1
Concurrency Control inDistributed MRA Index
Structures
18th December 2008

• Neha Singh, S. Sudarshan
• (IIT Bombay)

2
Introduction

• Problem statement Computing aggregate queries
  over a region in a multi-dimensional space
  containing mobile point data, when the data is
  stored in a distributed system.
• Need for such aggregate queries
• Networked Virtual Environment Widely used in
  online games and training simulator
• E.g. "Run in fear if number of marching enemy
  troop exceed number of friends around you"
  (aggregate count query)
• Real-time traffic monitoring
• Issues
• Large non-static data storage requires
  distributed system dynamic spatial partitioning

• Synchronized system clocks not feasible for large
  scale distributed systems
• Combining local state information from different
  peers can give inconsistent aggregates due to
  varied communication delay between them

3
Key contributions

• A distributed multi-resolution aggregate index
  structure to support dynamic object set
• The multi-resolution aggregate tree stores
  precomputed aggregates at each tree node in a
  centralized system, to speed up aggregate queries
• We extend it to support non-static data in a
  distributed system
• Atomic updates/reads Our read protocol and
  aggregate tree update protocols ensure that
  updates are atomic to reads (aggregate queries),
• Highly concurrent update protocol We present a
  highly concurrent multi-phase update protocol
  that
• avoids blocking of reads
• minimizes contention with concurrent updates

4
Agenda

• Introduction
• Problem statement Motivation
• System Model
• Readers protocol
• Maintenance of the index structure
• Definitions
• Naive update protocol
• Multi-phase update protocol
• Experimental Analysis

5
System Model Partitioning the global space

• For partitioning, we use a quad tree based
  regular decomposition of space
• Benefits
• Partitions independent of order of data insertion
• Decomposition implicitly known by all end systems
• Mapping the regions onto the P2P overlay
• Each quad tree block has a unique centroid
• Use this as key in DHT to map the regions onto
  peer set

6
System Model MRA Tree

• An MRA-Tree (Multi-Resolution Aggregate Tree) is
  a modified multi-dimensional index
• structure that stores pre-computed aggregates at
  various resolutions in its intermediate
• nodes

• A leaf node contains the actual data points -
  ltloc, valuegt
• A non-leaf node stores aggregate for all data
  points indexed by it - COUNT,SUM,
  MINARRAY,MAXARRAY where MINARRAY,MAXARRAY are
  the min and max resp. of each child node

7
Readers Protocol
Readers Protocol
1
Relation of the query to node
Read query over region Q
Nodes read
Q Is contained orpartially overlaps
1

• Query traverses the index structure top down,
  starting from root node and selectively exploring
  the nodes

2

Q
N
Q Encloses
3
Encloses so further traversal not required
4
Q Disjoint
Intersecting with Q and read
Further traversal not necessary
Intersecting with Q but not read
8
Readers Protocol
Readers Protocol
1

• Naïve Read Method
• Get lock on all nodes while traversing down the
  tree
• Release lock after read is completed
• However
• This reduces the concurrency of the index
  structure for concurrent updates
• Needed
• Release of locks early
• At the same time prevent updates coming from
  top-down to overtake
• Solution Use Crabbing Protocol Acquire lock on
  all the child nodes before releasing the lock on
  the parent

9
Maintenance of Index Structure
Maintenance of Index Structure
2

• Aim To update the distributed aggregate tree
  such that these operations are atomic while
  causes minimum blocking to read
• We consider two types of updates
• Move operation
• Within the same node
• Across different nodes
• Insertion / deletion operation
• Index tree needs to be updated only in case of
  transfer across different nodes and insertion /
  deletion operation
• Since our application is data-driven, updates
  percolate from leaf nodes to the higher levels of
  the hierarchy

10
Definition Update Tree
Maintenance of Index Structure
2

• Update Tree Set of all the nodes (UT) of the
  distributed MRA tree whose stored
• aggregate values are affected by the transaction
  T

Insertion / Deletion operation
Move operation
Consists of all ancestor nodes of the leaf node
Consists of ancestors up to lowest common
ancestor of the leaf nodes
N
Insertion / Deletion
A
11
Definition Update Tree
Maintenance of Index Structure
2

• Importance of Update Tree
• Although updates propagate up from leaf nodes,
  only nodes in update tree are affected
• Hence locks can be acquired top-down from root of
  update tree
• going to the tree root each time would overload
  site containing root
• We use order of lock acquire at root node of
  update tree to serialize concurrent intersecting
  read and update queries

12
Definition Conflicting Updates
Maintenance of Index Structure
2

• Conflicting updates Two updates U1 and U2 are
  said to be conflicting updates
• if U1T n U2T ? F, where U1T and U2T are the
  corresponding update trees

N2
N1
N1
U1
U2
U1

• Importance
• Common part of two update trees is connected and
  has a unique highest node
• Order of access to this node serialization
  order of concurrent conflicting updates

13
Naïve Update Protocol
Maintenance of Index Structure
2

• X-Lock on all update tree nodes and then update
  them
• Order of acquiring locks top-down, as bottom-up
  can lead to deadlock with read query

Step II Update and Release Lock
Step I Acquire Lock Phase

• X-locks is acquired on all update tree nodes top
  down starting from root node

• Updates propagate bottom-up
• Nodes release locks after updating agg
• Root node releases lock only after update over in
  both legs

A
14
Naïve Update Protocol
Maintenance of Index Structure
2
Key modifications
Problem Low concurrency

• Lock retained on root node of update tree for
  the entire duration
• It being X-locked results in low concurrency and
  higher read time
• Issues
• Read query comes top-down, and updates go
  bottom-up
• Root node last to be updated and first to be read
• Still need to ensure update is atomic for read

• We propose a highly concurrent multi-phase update
  protocol
• Key modifications
• Allow concurrent read while acquiring locks and
  updating other nodes
• Introduce a new locking mode U-lock compatible
  with S-lock
• Nodes updated top-down
• Split the update process in 3 phases
• Prevent read to overtake top-down update and read
  inconsistent value
• Use crabbing protocol while acquiring locks to
  update nodes

1
2
3
15
Multi Phase Update Protocol
Maintenance of Index Structure
2

• Update Lock Mode A new locking mode compatible
  with read
• Locked nodes for possible future modification
• Can be upgraded to X-lock when needed

1
S U X
S True True False
U False False
X False
Compatibility Matrix

• U-S True gt Read Query can proceed while update
  is modifying other nodes of the update tree
• U-U False gt Conflicting updates need to wait
  for each other

16
Maintenance of Index Structure
2
Multi-phase update Protocol Update split into 3
phases
2
Acquire Lock Phase
Propagate Phase
Refresh Phase

• U-locks upgraded to X-locks
• Stored pendingUpdates get executed top-down
• X-locks acquired on child nodes then lock
  released Crabbing Protocol

U-locks acquired top-down starting from root node
Update gets propagated bottom-up from leaf nodes
and are stored as pendingUpdates
3
17
Multi Phase Update Protocol- Correctness and
efficiency
Maintenance of Index Structure
2

• Serialization Order
• R - U Order Order of read query S-lock and
  update X-lock at update tree root node
• U - U Order Order of U-lock point at the highest
  node of the common twig pattern
• Importance of separation of Acquire Lock and
  Propagation phases
• U-locks acquired bottom-up
• Acquiring U-locks top-down cannot lead to
  deadlock with read (as in the naïve case)
• But, merging both phases can lead to deadlock
  between concurrent conflicting updates
• Importance of Crabbing protocol
• Used for upgrading U-lock to X-lock top-down
• Thus read query cannot overtake an update
• It sees the state either before or after refresh
  on all intersecting nodes
• gt Update atomic for read

18
Multi Phase Update ProtocolScenario I Can the
propagated leaf node value change before update
gets over?
Maintenance of Index Structure
2

• Consider a new max value (m) was propagated up
  during the propagate phase
• What if this max gets changed between the time it
  is propagated up and it gets executed at the
  nodes?

Getting a U-lock for this entire duration between
propagate and refresh phases, ensures that no
other update can change the nodes value being
propagated up the tree
19
Maintenance of Index Structure
2
Multi Phase Update ProtocolScenario II Can the
stored pendingUpdate value get stale?
10

• Assume U decreases max aggregate
• value at node B to 3

10
6
10
C
D
2
6
8
4
6
A
3
B
4
1
3
4
20
Maintenance of Index Structure
2
Multi Phase Update ProtocolScenario II Can the
stored pendingUpdate value get stale?
10

• Assume U decreases max aggregate
• value at node B to 3

10
6
4
10
C
D
2
6
8
4
4
6
A
3
B
4
1
3
4
21
Maintenance of Index Structure
2
Multi Phase Update ProtocolScenario II Can the
stored pendingUpdate value get stale?
10

• Assume U decreases max aggregate
• value at node B to 3
• What if max value of node A
• changes meanwhile?
• This cannot happen because
• Any transaction attempting to modify the max
  value of A would intersect with U on at least
  node C.
• Thus would be executed serially

10
6
4
10
C
D
2
6
8
4
4
6
A
3
B
4
1
3
4
22
Maintenance of Index Structure
2
Multi Phase Update ProtocolScenario II Can the
stored pendingUpdate value get stale?
10

• Assume U decreases max aggregate
• value at node B to 3
• What if max value of node A
• changes meanwhile?
• This cannot happen because
• Any transaction attempting to modify the max
  value of A would intersect with U on at least
  node C.
• Thus would be executed serially
• Note Caching min/max values on parent node helps
  reduce update latency by greatly reducing number
  of nodes required to be locked

10
6
4
10
C
D
2
6
8
4
4
6
A
3
B
4
1
3
4
23
Multi Phase Update ProtocolScenario III
Multiple updates to an entity
Maintenance of Index Structure
2

• Consider an entity to be transferred by an update
  U1 from A to B and then by U2 from B to C
• Logically, U1 should get reflected on nodes B and
  D before U2
• Causal order of execution at node B
• makes sure that U1 completes before U2
• begin

24
Divisible Aggregates
Maintenance of Index Structure
2

• Consider an update transaction which causes only
  change in the sum
• and count of the leaf nodes and no change in
  min/max
• Observation
• Change in the agg for all nodes in the update
  tree is known
• No need to propagate these changes bottom-up
• Overview of update protocol
• Such transactions can have only one update phase
• X-lock acquired top-down using crabbing protocol
• Updates are executed and locks released

25
Comparative Analysis of the Update Methods
Maintenance of Index Structure
2
Aim Estimate difference in concurrency provided
by the update protocols

• d communication delay per link
• m - edges in the longer leg
• N root node of update tree

Acquire Lock Phase dm
Update Phase dm
Naïve Update Protocol
N locked for Read Query
Acquire Lock Phase dm
Propagate Phase dm
Refresh Phase
2d (m-2)d
Multi Phase Update Protocol
Update Phase
2d (m-2)d
Updating only Divisible Aggregates
26
Experimental Setup
Experimental Analysis
3

• Synthetic data set with non-uniform distribution
  of data points
• DHT used FreePastry implementation of Pastry
  DHT
• Parameters for quadtree
• fmin 14
• Every peer node specifies its threshold (t) as
  count of the number of entities it can support
• Threshold can be as low as 0
• We study the distributed MRA trees update
  protocol
• Running time of read queries with and without
  updates
• Running time of updates

27
For getting MRA index structure of varying
depths, use peer threshold as the lever
Experimental Analysis
3
Variation of the min/max depth of the
partitioning tree
Depth of the quad tree increases as the threshold
approaches µ (entities/ peers)
Depth
Threshold / µ
28
Read query time taken depends number of nodes
read, and not the query region size
Experimental Analysis
3
Variations of the read query duration as query
region increases, with no updates
Variations of the read query duration as nodes
read increase, with no updates
Time (ms)
Time (ms)
400
350
300
250
Query region / Total area (in )
Nodes covered
29
Update time taken directly proportional to
update tree nodes
,
Experimental Analysis
3
Variation of average update time with increase in
number of update tree nodes
Time (ms)
Naive protocol
MultiPhase locking protocol
Number of nodes
30
Average read time taken increases much less for
multi-phase update protocol as compared to naive
protocol
Experimental Analysis
3
Read Query Duration for different Naïve Update
Workloads
Read Query Duration for different MP Update
Workloads
F2 gt F1 (Frequency of updates)
F2 gt F1 (Frequency of updates)
Time (ms)
Time (ms)
Number of nodes
Number of nodes
31
Conclusion

• We propose a Distributed Multi-Resolution
  Aggregate Tree index structure for answering
  aggregate queries over mobile entities
• We point out problems with concurrent updates and
  propose the multi-phase update protocol
• ensures that updates and aggregate queries are
  atomic wrt each other
• minimizes contention and avoid deadlock
• Analysis and experimental results show
• The multi-phase update protocol requires a longer
  update time
• But offers high concurrency for the read queries
  as compared to naïve update protocol

32
Thank you!
Questions?
