Title: Switching Systems


1
Chapter 4
  • Switching Systems

2
Chapters Outline
  • Switching Concepts
  • Circuit Switching space division
  • Circuit Switching time division
  • Time Slot Interchanger
  • Circuit Switching Systems
  • Circuit Switching Applications
  • Customer Switching
  • Architecture of the Definity PBX System
  • Message Switching
  • Packet Switching datagram implementation
  • Packet Switching virtual circuit implementation

3
Switching Concepts
  • Earlier telephone switching was done manually by
    having operators negotiate with each others until
    a connection is established
  • Switching systems provide economic benefits,
    considering that we have more users than
    communication links
  • Centralized switching reduces the number of
    interconnecting links

4
Switching
  • A method of establishing connections and sending
    information between nodes on a network.
  • Circuit switching - establishing a connection
    between two devices on a network, before they
    begin transmitting data.
  • The advantage of circuit switching is that it
    guarantees two devices exclusive use of a
    communications channel.

5
Switching
6
Message Switching
7
Packet Switching
8
Switching Systems
  • The combined collection of hardware and software
    that establishes connections between lines and
    trunks in order to complete calls.
  • Although makes and models differ between
    manufacturers, all modern switches share four
    essential elements
  • Switching matrix
  • Line or trunk circuits
  • Central control computer
  • Common equipment

9
Local Switching Systems
  • A local switch performs the following functions
  • Provides dial tone to a local subscriber
  • Accepts and interprets signals (including
    off-hook notification, dial tones, and so on)
    from the local subscriber
  • Receives signals from the destinations local
    switch about when to terminate the call
  • Records local subscriber billing information
  • Stores information about subscribers (such as
    what type of service they have chosen) in a
    subscriber database
  • Tests and maintains the subscribers local loop

10
Tandem Switching
  • A tandem switch may perform the following
    functions
  • Provide termination for trunks at Class 1, 2, 3,
    and 4 central offices
  • Gather and transmit information about telephone
    network traffic and congestion
  • Determine the fastest path over the PSTN for
    long-distance calls
  • Carry data and voice signals between central
    offices
  • Test and maintain trunks
  • Assist in trunk configuration

11
Lucents ESS Switch
12
Nortels DMS Switch
13
Nortels DMS Switch
14
Switch Signaling
  • The exchange of information between the
    components of a telephone network or system for
    the purposes of establishing, monitoring, or
    releasing phone circuits as well as controlling
    system operations.
  • Switch-signaling functions include
  • Transmitting Address Information
  • Supervising
  • Transmitting Information

15
Switching Equipment
  • Major functions of switching equipment at a
    central office
  • Dial tone
  • Customer and phone number identification
  • Call setup
  • Call routing
  • Call supervision
  • Line testing and maintenance

16
Central Office Hierarchy
  • Serving area (of a local office) - the
    geographical boundary that includes all its
    subscribers. It extends roughly three miles in
    all directions from the central office (CO).
  • Trunk - a transmission route between switches
    that typically has a great deal more capacity
    than a feeder.
  • Regional offices - Class 1 central offices.

17
Central Office Hierarchy
18
The Telecommunications Act of 1996
19
The Telecommunications Act of 1996
  • The Act codified requirements for the
    interconnection of all local exchange carriers.
    These policies included
  • Interconnecting with other service providers and
    not imposing any barriers to interconnection
  • Enabling nondiscriminatory resale of their
    services to competitors
  • Providing number portability, or the ability of
    telecommunications service users to retain their
    same telephone number without hampering the
    quality, reliability, or convenience of their
    phone service
  • Allowing competitors to access and connect to
    their facilities

20
The Telecommunications Act of 1996
  • To increase competition in local phone service,
    the Act placed the following requirements on all
    ILECs
  • Negotiating interconnection agreements in good
    faith
  • Providing competitors with the same type and
    quality of access to their facilities that they
    themselves could obtain at their cost
  • Providing competitors with access to subscriber
    information, such as telephone numbers and
    billing data
  • Offering nondiscriminatory, wholesale prices for
    telecommunications services to all competitors

21
(No Transcript)
22
Switching Concepts
23
Type of switching
  • Circuit Switching a physical path is provided
    for the duration of the call
  • Message Switching customer exchange information
    using store-and-forward techniques. A message is
    delivered as a whole - telegraph service, email,
    etc..
  • Packet Switching A message is fragmented into
    packets where each packet may take a different
    rout along the network -- Internet

24
Type of Switching
25
Functions of a Switching System
  • Attending
  • Path selection
  • rout selection
  • busy testing
  • path establishment
  • network interconnection
  • signal transmission
  • alerting
  • supervision

26
Switching Concepts
27
Circuit Switching Space Division Switching
  • Old technology
  • replaced by digital switched network
  • its characteristics include
  • establishment of spatial path through the network
  • links are maintained for the duration of the call
  • signals can be digital or analog
  • uses metallic devices or semiconductor elements
  • networks may be made of several stages

28
Circuit Switching Space-Division
29
Circuit Switching Time Division
  • It builds on the concepts of time-division
    multiplexing
  • multiplexed information is transferred from input
    points to output points
  • Uses a chip set known as the time-slot-interchange
    r to assist in the connecting input multiplexed
    channels to output multiplexed channels

30
Circuit Switching Time-Division Switching
31
TSI -- Time Slot IntechangerEX Mitel, ATT,
Motorola Chip Set
32
Functions of a Circuit Switching System
  • Battery Feed
  • Overvoltage Protection
  • Ringing Signals
  • Supervision
  • CODEC
  • Hybrid circuits separate the incoming and
    outgoing signals going to coming from receivers
    and transmitters two-to-four-wire conversion
  • Testing detection of faults on lines and trunks
  • Known as BORSCHIT circuit (traceable to Iwerson
    of ATT Bell Labs.

33
Interfaces in a Circuit Switching System
  • Station Line Interface detect off-hook, CODEC
    functions, detect on Hook, communicate with the
    switching control subsystem, detect faults
  • Trunk Interfaces provides interfacing to various
    transmission links in the overall hierarchical
    network
  • CO trunks
  • DID
  • Digital/Analog
  • Auxiliary
  • Local Area Network Interfaces
  • ISDN PRI

34
Interfaces in a Circuit Switching Switching
System
  • Service Circuits
  • tone detection circuits
  • tone clock circuits
  • pooled modem circuits
  • recorded announcement circuits
  • recording for traffic measurement and billing
    functions, used to devise a particular traffic
    pattern depending on BUSY-HOUR call rate

35
Circuit Switching Software
  • Plays a very important role in circuit switching
    systems
  • call processing software
  • origination -- detection of call request
  • digit collection
  • digit translation
  • routing
  • alerting
  • answer
  • drop
  • System Administration
  • System Maintenance
  • Billing and record keeping

36
Circuit Switching Software
  • Testing
  • Traffic engineering
  • Services changes and rearrangement
  • Feature Selection
  • Data Base Management
  • Maintenance
  • fault recognition
  • fault recovery
  • system integrity
  • auditing
  • system recovery

37
Circuit Switching Applications
  • local exchange switching designed to serve the
    general public
  • trunk switching tandem, toll, and transien
    switches
  • gateway switching rout traffic between national
    and international calls, must accommodate
    different signaling format
  • customer switching PBX, KEY systems

38
Call translation in a Local Exchange Switch
39
Key Telephone Systems
  • A system that gives all telephone users within an
    organization centralized access to one of many
    incoming PSTN lines.
  • A KTS typically consists of a wall-mounted
    control console that connects to the
    organizations internal phones and to the
    telephone companys end office.
  • This console, called a key service unit (KSU),
    signals the telephone attendant about incoming
    calls, controls busy indica-tor lights on line
    buttons, and tracks call information, among other
    tasks.

40
Key Telephone Systems
41
Key Telephone Systems
42
Key Telephone Systems
  • Features of electronic KTSs include
  • Call forwarding
  • Caller identification
  • Direct inward dialing
  • Do not disturb
  • Message waiting
  • Music on hold
  • Station restriction
  • Voice mail

43
Private Branch Exchange (PBX)
  • A switch owned and operated by a business or
    other private organization that connects multiple
    telephone sets to one or more of the telephone
    companys central offices.
  • Provides call setup and routing within an
    organization.
  • Whereas a KTS depends on a CO for dial tone, a
    PBX actually provides its connected telephones
    with dial tone.
  • A PBX can connect an organization to the PSTN
    through a trunk, a connection with significantly
    more bandwidth than a local loop which serves to
    directly connect switches.

44
Private Branch Exchange (PBX)
45
Components of a PBX
  • A PBX consists of four significant elements
  • Station lines - the lines that connect individual
    telephone sets to the switch.
  • Central processor - the computer that oversees
    all PBX operations, including processing incoming
    calls, outgoing calls, call setup, routing,
    supervision, and data gathering
  • Switching module - The equipment that
    accomplishes call setup, routing, and
    supervision, just as a switch in a central office
    does.
  • Trunks - The lines that connect the switch to COs.

46
Components of a PBX
47
Features Offered by a PBX
  • Automatic call distribution (ACD)
  • Automated route selection (ARS)
  • Computer-telephony integration (CTI)
  • Power failure provisions
  • Station message detail recording (SMDR)
  • System management
  • Trunk queuing
  • Unified messaging
  • Wireless capabilities

48
(No Transcript)
49
Private Branch Exchange (PBX)
  • Owned or leased and operated on customer premises
  • station users are connected to the PBX and the
    PBX is connected to the local exchange switch via
    trunks, or digital transmission facility such as
    T1
  • In the network hierarchical, a PBX is classified
    as a customer premises equipment

50
PBX Core Functions
  • Station to station calling capability
  • Concentration of customer stations to central
    office capability
  • Attendant handling of incoming calls from the
    central office (manually or automated)

51
PBX Enhanced Functions
  • Automatic call distribution (intercept operators,
    department store catalog divisions, directory
    assistance, customer services
  • calls are distributed among attendants (agents)
    to maximize efficiency
  • calls are queued, if all agents are busy
  • management information data are collected to
    administer switching facilities and the size of
    agent groups

52
PBX
53
Example of a PBX System Lucent Technologies
Definity PBX
  • Features
  • call conferencing 6 parties
  • call forward
  • hold
  • transfer
  • hunt groups
  • attendant services, primary and night service
    attendant.
  • digital, analog, and ISDN station types support
  • system administration terminal (SAT)

54
Basic Architecture of the Definity PBX
  • Uses time division switching to handle switching
    functions
  • uses 256 time slot TDM bus
  • 5 time slots are used for communication among the
    control complex and the peripherals of the system
  • The bus provides means of communications among
    two types of circuit boards angels and the
    archangel.
  • Port boards are referred to by the angels and
    they include analog, digital, ISDN, DS1, ton
    detector, CO trunks, DID(direct inward dialing)
    trunks,

55
Lucent Technologies Definity PBX Architecture
56
Intra-system communication
  • Carried over 5 dedicated time slots
  • uplink and down link messages
  • scenario of a user going off hook
  • the angel detects the off-hook condition
  • waits for a downlink message asking it if it has
    anything for the control complex
  • it report the off-hook condition using an uplink
    message defined for its type
  • the archangel sends a series of downlink messages
    to connect tone generator circuits to the user
    (dial tone)
  • the angel collects the dialed digits, sends them
    in an uplink message

57
Store and Forward Switching
  • Message Switching
  • Packet Switching
  • datagram implementation
  • virtual circuit implementation

58
Message Switching
  • the message is sent as a whole
  • email
  • telegraphy
  • effective
  • no delay associated with setting the call. A rout
    does not have to be pre-established.
  • Message switching networking may provide protocol
    conversion and error checking functions
  • disadvantages
  • delay in message delivery no real-time
    communication

59
Packet Switching
  • History
  • Defense Department looking for ways to secure
    communications in case of war
  • In the hierarchical network, if you take a node
    (regional switch), you knock out communication in
    a large geographical part of the country
  • In packet switching networks, weight is
    distributed among nodes a number of nodes can be
    taken out while communications are maintained.
  • Hard to tap conversations in packet switched
    networks

60
Packet-Switching Networks
  • Includes X.25, ISDN, ATM and frame-relay
    technologies
  • Data is broken into packets, each of which can be
    routed separately
  • Advantages better line efficiency, signals can
    always be routed, prioritization option
  • Disadvantages transmission delay in nodes,
    variable delays can cause jitter, extra overhead
    for packet addresses

61
Packet-Switching Techniques
  • Datagram
  • each packet treated independently and referred to
    as a datagram
  • packets may take different routes, arrive out of
    sequence
  • Virtual Circuit
  • preplanned route established for all packets
  • similar to circuit switching, but the circuit is
    not dedicated

62
Packet-Switched Routing
  • Adaptive routing changes based on network
    conditions
  • Factors influencing routing are failure and
    congestion
  • Nodes must exchange information on network status
  • Tradeoff between quality and amount of overhead

63
Packet-Switched Congestion Control
  • When line utilization is gt80, queue length grows
    too quickly
  • Congestion control limits queue length to avoid
    througput problems
  • Status information exchanged among nodes
  • Control signals regulate data flow using
    interface protocols (usually X.25)

64
(No Transcript)
65
Packet Switching
  • Does not was resources like circuit switching
  • being in use in many WAN application
  • classified by two implementations
  • datagram implementation
  • virtual circuit implementation

66
Packet Switching Datagram Implementation
  • sequential delivery of packets is not guaranteed
  • packets may not be delivered at all or may be
    duplicated
  • all packets must contain the full destination
    address

67
Packet Switching Datagram Implementation
68
Switching at the Node
69
Packet Switching Virtual Circuit Implementation
  • A DTE places a call to another DTE by sending a
    special packet into the network indicating a
    desire to setup a connection
  • The network then sets up a rout for subsequent
    packet transfer
  • The rout stay in place for the duration of the
    connection
  • Virtual circuit connection is end-to-end
    connection between two users over a
    store-and-forward network
  • In virtual circuit connections
  • the user sees the packet delivered in sequence
  • no routing decisions are needed

70
Computer Telephony Integration
  • Significant call control functions that CTI
    enables, include
  • Automatic dialing from a PC interface
  • Call screening based on incoming phone number
    identification
  • Call forwarding programmed through a simple PC
    interface
  • Automated attendant services
  • Call logging and the collection of call
    accounting data

71
Computer Telephony Integration
  • Some of the significant media processing features
    that CTI enables include
  • Voice message recording and playback
  • Fax storing and sending
  • Speech recognition and text-to-speech translation
    (for instance, your CTI-enabled computer could
    read an e-mail message to you)
  • Online call recording

72
Computer Telephony Integration
  • Some of the customer data management features
    that CTI enables include
  • Access to personal phone books saved on the
    network
  • Caller database records that appear when a number
    is selected from the phone book
  • Retrieval of customer calling patterns and
    billing information
  • Access to customer schedules

73
Computer Telephony Integration
74
Power Equipment
75
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
