Porting Applications to HP-UX 64-bit

• Daniel G. Schmidt
• Technical Consultant
• DGSA
• Working with Hewlett-Packard
• 15 August 2001

2
Why 64-bit?

• Large Address Space (gt 4G)
• Large files (gt 4G) using standard API.
• Large process space.
• Performance advantage using memory in place of
  disk I/O.
• Resources
• HP-UX 11.0 Software Transition Kit (STK)
• Web Documentation
• devresource.hp.com
• docs.hp.com
• HP-UX 64-bit Porting and Transition Guide
  http//docs.hp.com80/hpux/onlinedocs/5966-9844/59
  66-9844.html
• www.software.hp.com
• HP Technical Consulting

3
Porting Code to 64-bit

• Preparing for the Port
• Acquire 64-bit versions of all 3rd party
  libraries.
• Port all of your own libraries to 64-bit.
• Rewrite assembly code to be 64-bit.
• Add DD64 M2 to makefiles
• Compiling 64-bit Modules
• LP64 Data Model
• Size of long and int now differ.
• Pointers are 64 bit values.
• Pointers and longs are 64-bit aligned.
• Predefined types size_t and ptrdiff_t are 64-bit
  integral types.
• Finding Fixing Non-Portable Constructs
• Transition warnings option (M2) in lint and cc.
• Use function prototypes.
• Consistently use strict data types.
• Verify use of any long from 32-bit source base.

4
Non-Portable Constructs

• Data Truncation
• Assigning longs to ints.
• Storing pointers in ints.
• Truncating function return values.
• Inappropriate print specifiers.
• Data Type Promotion
• Arithmetic between signed and unsigned numbers.
• Pointers
• Casting pointers to ints or ints to pointers.
• Pointer arithmetic between longs and ints.

5
Non-Portable Constructs (cont.)

• Data Alignment and Data Sharing
• Passing invalid structure references.
• Hardcoded or assumed offsets within structures.
• Using unnamed and unqualified bit fields.
• Hardcoded Constants
• Hardcoded size of data types.
• Using literals and masks that assume 32 bits.
• Hardcoded bit shift values.
• Hardcoded constants with malloc(), memory(3),
  string(3).

6
Data Truncation

• Assigning longs to ints.
• Example Problem
• include ltstdlib.hgt
• char string
• ...
• int index atol(string)
• Solutions
• long index atol(string)
• int index atoi(string)
• Other Cases
• Beware of other constructs, such as passing a
  long to a function that accepts only an int.
• Compiler Errors/Warnings
• cc M2 warning 720 ... may overflow integer.
• aCC w Warning (suggestion) 818 ... truncation
  in value may result.

7
Data Truncation

• Storing pointers in ints.
• Example Problem
• int i
• int j i
• Explanation j can only contain a truncated copy
  of i.
• Solution
• int i
• int j i
• Compiler Errors/Warnings
• cc warning 727 ... truncates pointer into 32
  bit integer.
• aCC Error 203 ... Cannot assign 'int' with
  'int '.
• aCC Error 818 ... truncation in value may
  result. (when there is a cast ie."j (int)i)

8
Data Truncation

• Truncating function return values.
• Example Problem
• char buf malloc(1024)
• Solution Without proper prototype, compiler
  assumes malloc() returns int.
• include ltstdlib.hgt
• char buf malloc(1024)
• Compiler Errors/Warnings
• cc warning 724 ... Initialization converts
  default int return type to pointer.
• cc M0 warning 714 ... Function "malloc"
  called with no prototype or definition in scope.
• aCC Error 328 ... Function 'malloc' has not
  been defined yet cannot call.

9
Data Truncation

• Storing pointers in doubles.
• Example Problem
• void func(double d) Void p (void )d ...
• ...
• void p something
• func((double)p) / real case I found in code /
• Solution doubles, with 52 bits of mantissa,
  cannot represent a pointer.
• / If you must store a pointer in a double,
• use these macros. Both require an lvalue. /
• define PTR_INTO_DOUBLE(p) (((double )((p))))
• define PTR_FROM_DOUBLE(d) (((void )((d))))
• Compiler Errors/Warnings
• cc Error 1527 ... Incompatible types in cast
  Must cast from scalar to scalar or to void type.
• aCC Error 331 ... Illegal cast expression
  cannot cast expression type 'void ' to 'double'.

10
Data Truncation

• Inappropriate print specifiers.
• Example Problem
• include ltstdio.hgt
• long val
• scanf(d, val)
• printf(Number at x is d\n, val, val)
• Solution
• ...
• scanf(ld, val)
• printf(Number at p is ld\n, val, val)
• Compiler Errors/Warnings
• None currently.

11
Data Type Promotion

• Arithmetic between signed and unsigned numbers.
• Example Problem
• long result
• int i -2
• unsigned int j 1
• result i j
• Explanation Signed value, i, is promoted to
  unsigned.
• ILP32 model yields result -1
  (0xffffffff)
• LP64 model yields result 4294967295
  (0x00000000ffffffff)
• Solution Be consistent, use same data types in
  equations.
• Use all ints, all unsigned ints, or all longs,
  depending on need.
• Learn the data type promotion rules.
• Compiler Errors/Warnings
• cc none currently.
• aCC Warning (suggestion) 887 ... Type
  'unsigned int' is smaller than type.

12
Data Type Promotion

• Comparing signed and unsigned numbers.
• Example Problem
• long L -1
• unsigned int u 1
• printf(ld s d\n, L, (L gt u) ? gt lt,
  u)
• Explanation Data is promoted differently in
  ILP32 and LP64.
• ILP32 prints -1 gt 1
• LP64 prints -1 lt 1
• Solution Be consistent, use same data types in
  comparisons.
• long u 1
• Solution Cast to same data types in
  comparisons.
• (L lt (long)u)
• Compiler Errors/Warnings
• cc warning 734 ... Different types treated as
  signed for gt.
• aCC none currently.

13
Pointers

• Casting pointers to ints or ints to pointers.
• Example Problem
• struct S sptr
• ...
• sptr (struct S )((int)sptr sizeof(struct
  S))
• Explanation
• 64-bit pointers dont fit in 32 bits so they get
  truncated.
• Solution
• ...
• sptr sptr 1
• Compiler Errors/Warnings
• cc warning 727 ... truncates pointer into 32
  bit integer.
• aCC Error 818 ... truncation in value may
  result.

14
Pointers

• Pointer arithmetic between longs and ints.
• Example Problem
• long L 0x123
• int ptr L
• if (L ptr)
• ...
• Explanation
• ptr points to upper half of L not to L itself.
• ptr is 0 because L is 0x00000000 00000123.
• Solution
• ...
• long ptr L
• Compiler Errors/Warnings
• cc warning 728 ... Cast converts long to
  int.
• aCC error 440 Cannot initialize int with
  long .

15
Data Alignment and Data Sharing

• Invalid structure references.
• Example Problem
• typedef struct
• char p
• int value
• S
• S structptr
• int intptr (int )structptr
• intptr1 20 / set value within struct /
• Explanation
• 64-bit longs and pointers change the size of
  structures.
• 64-bit longs and pointers change the offsets
  within structures.
• Solution Use the structure definition.
• structptr-gtvalue 20
• Compiler Errors/Warnings
• None currently.

0
96
32
64
p
i
ILP32
p
i
LP64
16
Data Alignment and Data Sharing

• Hardcoded or assumed offsets within structures.
• Example
• typedef struct
• int i
• char p,c
• S
• Explanation
• 64-bit constraints can change the alignment and
  padding of structures.
• Best to put largest, most strictly aligned
  elements first in structure definition.
• Be extra careful when reading binary data
  structures!
• Compiler Errors/Warnings None.

17
Data Alignment and Data Sharing

• Using unnamed and unqualified bit fields.
• Example Problem
• struct char foo
• long 3 /unnamed/
• short s5
• S
• Explanation
• Padding varies. In this case, LP64 is less
  restrictive.
• Solution
• Dont define unnamed or unqualified bit fields.
• Compiler Errors/Warnings
• cc warning 750 ... Unnamed, non-zero bitfields
  do not affect alignment.
• aCC none.

0
8
11
32
16
foo
s
pad
ILP32
foo
s
LP64
18
Hardcoded Constants

• Hardcoded size of data types.
• Example Problem
• offset n 4 / assumes 32 bits /
• Solution
• offset n sizeof(int) / offset of true int
  /
• Solution
• offset n sizeof(long) / offset of true
  long /
• Solution
• long val
• offset n sizeof(val) / offset to size of
  val /
• Compiler Errors/Warnings
• None.

19
Hardcoded Constants

• Using literals and masks that assume 32 bits.
• Watch for these and other typical hardcoded
  constants
• 4 Number of bytes in 32-bit word.
• 32 Number of bits in 32-bit word.
• 0x80000000 Min value of signed 32-bit word.
• 0x7fffffff Max value of signed 32-bit word.
• 0xffffffff Max value of unsigned 32-bit word.
• Use defined data types as found in ltinttypes.hgt
• Compiler Errors/Warnings
• None currently.

20
Hardcoded Constants

• Hardcoded bit shift values.
• Example Problem
• unsigned long n
• n 1 ltlt (32 - 1) / set sign bit /
• Explanation Cannot assume 32-bit longs!
• Solution
• include ltlimits.hgt
• unsigned long n
• n LONG_MAX
• Solution
• include ltlimits.hgt
• unsigned long n
• n 1L ltlt (LONG_BIT - 1)
• Compiler Errors/Warnings
• None.

21
Hardcoded Constants

• Hardcoded constants with malloc(), memory(3),
  string(3).
• Example Problem
• include ltstdlib.hgt
• define BSIZE 4096
• char ptr_buf
• ptr_buf (char )malloc(BSIZE 4)
• Explanation Assumes pointer is 4 bytes.
• Solution
• ...
• void ptr_buf
• ptr_buf (void )malloc(BSIZE sizeof(void
  ))
• Compiler Errors/Warnings
• None currently.

22
64-bit Safe vs. 64-bit Aware

• 64-bit Safe .
• Compile for 64-bit (DD64 or DA2.0W).
• Fix all compile errors.
• Consider fixing compile warnings including M2
  warnings.
• Insure that all non-portable constructs are
  fixed.
• 64-bit Aware.
• Convert program internals to use the 64-bit
  addressing.
• Beware of programs that do their own memory
  management.

23
Performance

• Impacts of port.
• Larger process/data space affects cache and TLB
  hit rates.
• 64-bit long integer division is slow.
• 32-bit array indices must be sign extended
  repeatedly.
• Code is always position independent (PIC).
• Tuning.
• Avoid mixing 32 and 64-bit operations.
• Fix array references to use long indices.
• Avoid 64-bit long division.
• Use Onoextern if object modules are not in
  shared library.
• Use ESfic if fully archive bound.

24
Porting Code to 64-bit Summary

• Why?
• Large files address space.
• Performance advantage of memory over disk I/O.
• Beware!
• Data size differences (pointers, longs and
  predefined types).
• Data truncation (casts, return values...).
• Data type promotion pitfalls.
• Data alignment and padding differences.
• Hardcoded constants.
• 64-bit Safe vs. 64-bit Aware.
• Compile DA2.0W, fix compile/link errors and
  possibly M2 warnings.
• Convert program to really use 64-bit addressing.
• Impacts.
• Performance costs are real but tuning can help.
