Symmetric Encryption

1
Symmetric Encryption
2
Content

• Block cipher
• DES

3
Block cipher

• Definition a block cipher is a function which
  map n-bit plaintext blocks to n-bit ciphertext
• n is called blocklength.
• The function is parameterized by a k-bit key K.
• The function must be one-to-one (invertible)
• n gt 64 (larger than stream cipher)

4
Adversaries Assumptions and Attacks

• Adversarys ability
• has access to all data transmitted over the
  ciphertext channel
• knows all details of the encryption function
  except the secret key
• Classses of attack (for a fixed key)
• Ciphertext-only
• Known-plaintext
• Chosen-plaintext (the attacker has the
  capability to choose arbitrary plaintexts to be
  encrypted and obtain the corresponding
  ciphertexts.)
• Adaptive chosen-plaintext (choosing subsequent
  plaintexts based on the information from the
  previous encryptions)

5
Broken cipher

• A block cipher is totally broken if a key can be
  found,
• and partially broken if an adversary is able to
  recover part of the plaintext (but not the key)
  from ciphertext.

6
Modes of operation

• A block cipher encrypts plaintext in fixed-size
  n-bit blocks (often n 64). For messages
  exceeding n bits, the simplest approach is to
  partition the message into n-bit blocks and
  encrypt each separately.
• electronic codebook (ECB)
• cipher-block chaining (CBC)
• Cipher feedback (CFB)
• output feedback (OFB)

7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
Multiple encryption
12
Classical ciphers

• Transposition ciphers
• CAESAR
• Substitution ciphers
• simple substitution cipher or monoalphabetic
  substitution cipher
• affine cipher
• Polygram substitution
• Polyalphabetic substitutions and Vigenère ciphers
• Polyalphabetic cipher machines and rotors

13
Vigenère ciphers

• Key ABCDEF AB CDEFA BCD EFABCDEFABCD
• Plaintext CRYPTO IS SHORT FOR CRYPTOGRAPHY
• Ciphertext CSASXT IT UKSWT GQU GWYQVRKWAQJB
• Key ABCDAB CD ABCDA BCD ABCDABCDABCD
• Plaintext CRYPTO IS SHORT FOR CRYPTOGRAPHY
• Ciphertext CSASTP KV SIQUT GQU CSASTPIUAQJB

14
Polyalphabetic cipher machines and rotors
15
Cryptanalysis of classical ciphers
16
Cryptanalysis of classical ciphers
17
Data Encryption Standard (DES)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Example
