ASP'NET

1
ASP.NET

• Database Connection

2
ASP.NET Framework

• The ASP.NET framework includes the ADO.NET data
  access technology for working with databases and
  other OLE DB data sources
• ASP.NET pages that connect to databases must gain
  access to the system classes that provide data
  access functionality. For working with Microsoft
  Access and other databases that use OLE DB
  providers, the page must import the
  System.Data.OleDb namespace

3
Database Namespace Directive

• System.Data.OleDb namespace can be imported by
  including the following directive at the top of
  the page
• lt_at_ Import Namespace"System.Data.OleDb" gt
• This namespace includes the three basic classes
  needed to work with Access databases
• OleDbConnection - for connecting to a database
• OleDbCommand - for issuing SQL queries against
  database tables
• OleDbDataReader - for access to recordsets
  retrieved through SQL queries

4
Product Table

• Field Name Data Type Field Size Example Data
• ItemNumber Text 6 OS1111
• ItemType Text 20 Operating System
• ItemSupplier Text 20 Microsoft
• ItemName Text 50 Windows XP
• ItemDescription Memo  Windows XP is
• ItemPrice Currency  149.95
• ItemQuantity Number Long Integer 20

5
Opening a DB Connection

• A connection to a database is made by creating an
  OleDbConnection object that can be used to access
  the database.
• After the connection is established then, this
  connection's Open() method is used to open the
  database.

6
Opening a DB Connection

• OleDbConnection DBConnection DBConnection New
  OleDbConnection(ConnectionString)DBConnection.Op
  en()     orOleDbConnection DBConnection
  New OleDbConnection(ConnectionString)DBConnectio
  n.Open()

7
Opening a DB Connection

• DBConnection is a programmer-supplied reference
  the ConnectionString specifies the OLE DB
  Provider (the database type) and the Data Source
  (the physical path to the database on the
  server).
• For Access databases, the Provider is
  "Microsoft.Jet.OLEDB.4.0"
• the Data Source is in the format
  "drive\folder\folder\...\database.mdb".
• The two clauses are separated by a semicolor and
  compose a single string.

8
Opening a DB Connection Ex.

• lt_at_ Import Namespace"System.Data.OleDb"
  gtltSCRIPT runat"server"gt
• OleDbConnection DBConnection
• protected void Page_Load(object sender,
  EventArgs e)  '-- Open a database
  connection  DBConnection New OleDbConnection(
  _     "ProviderMicrosoft.Jet.OLEDB.4.0"
  _     "Data Sourced\Databases\eCommerce.mdb")
    DBConnection.Open() lt/SCRIPTgt

9
Selecting Records

• Selecting records from a database table to
  display or to edit is made through the
  OleDbCommand object.
• This selection is normally an SQL command issued
  through the OleDbCommand object against the
  database.

10
Selecting Records

• OleDbCommand DBCommand
• DBCommand New OleDbCommand(CommandString,
  DBConnection)     orOleDbCommand DBCommand
  New OleDbCommand(CommandString, DBConnection)
• DBCommand is a programmer-supplied reference. The
  CommandString is an SQL statement to access a set
  of records from the database the DBConnection is
  a reference to the database connection opened
  previously.

11
Selecting Records Ex.

• lt_at_ Import Namespace"System.Data.OleDb"
  gtltSCRIPT runat"server"gtOleDbConnection
  DBConnection
• OleDbCommand DBCommand
• String SQLStringprotected void
  Page_Load(object sender, EventArgs e)  '-- Open
  a database connection  DBConnection New
  OleDbConnection( _     "ProviderMicrosoft.Jet.OL
  EDB.4.0" _     "Data Sourced\Databases\eComm
  erce.mdb")  DBConnection.Open()  '-- Create
  and issue SQL command through the database
  connection  SQLString "SELECT FROM
  Products  DBCommand New OleDbCommand(SQLStrin
  g, DBConnection)
• lt/SCRIPTgt

12
Creating a DataReader

• Any of the SQL statement types (SELECT, INSERT,
  UPDATE, DELETE, and so forth) can be issued
  through the OleDbCommand object. When issuing a
  SELECT statement, a set of records (a recordset)
  is returned from the database and made available
  to the script. In this case a mechanism is needed
  for iterating through the recordset and
  specifying fields of data to be displayed or
  otherwise processed.
• An OleDbDataReader object represents a stream of
  database records returned from a SELECT statement
  issued through the OleDbCommand object. A data
  reader is created by using the ExecuteReader()
  method of the OleDbCommand object

13
Creating a DataReader

• OleDbDataReader DBReader DBReader
  DBCommand.ExecuteReader()     orOleDbDataReade
  r DBReader DBCommand.ExecuteReader()
• DBReader is a programmer-supplied reference
  DBCommand is a reference to the OleDbCommand
  object previously created for issuing the SQL
  statement

14
Creating a DataReader Ex.

• lt_at_ Import Namespace"System.Data.OleDb"
  gtltSCRIPT runat"server"gt OleDbConnection
  DBConnection OleDbCommand DBCommand OleDbData
  Reader DBReader
• String SQLStringprotected void
  Page_Load(object sender, EventArgs e)
•   '-- Open a database connection  DBConnection
  New OleDbConnection("ProviderMicrosoft.Jet.OLED
  B.4.0" _     "Data Sourced\Databases\eComm
  erce.mdb")  DBConnection.Open()  '-- Create
  and issue an SQL command through the database
  connection  SQLString "SELECT FROM
  Products  DBCommand New OleDbCommand(SQLStrin
  g, DBConnection)  '-- Create a recordset of
  selected records from the database  DBReader
  DBCommand.ExecuteReader()
• lt/SCRIPTgt

15
Accessing through DataReader

• An OleDbDataReader represents a stream of
  database records that are made available to a
  script one record at a time. It is a forward-only
  recordset (it cannot be read backwards), and
  individual records are made available with its
  Read() method.
• When the Read() method is called, two events
  occur
• First, it returns True if a next record is
  available in the recordset, or it returns False
  if no additional records are available.
• Second, it advances to the next record if one is
  available. These pair of events make it very easy
  to iterate through the records in the
  OleDbDataReader.

16
Accessing through DataReader

• While (DBReader.Read())   ...process database
  record
• An OleDbDataReader supplies a complete data
  record (table row) one at a time. Normally, the
  interest is in working with individual data
  fields within the record. In order to specify a
  data field, the following format is used
• DataReader("FieldName")
• DataReader is a reference to a previously created
  OleDbDataReader object. FieldName is the name of
  a table column in the database

17
DataReader - Ex.

• lt_at_ Import Namespace"System.Data.OleDb"
  gtltSCRIPT runat"server"gtOleDbConnection
  DBConnectionOleDbCommand DBCommand
  OleDbDataReader DBReader String
  SQLStringprotected void Page_Load(object
  sender, EventArgs e)  '-- Open a database
  connection  DBConnection New OleDbConnection(
   "ProviderMicrosoft.Jet.OLEDB.4.0"
  _    "Data Sourced\Databases\eCommerce.mdb")
   DBConnection.Open()  '-- Create and issue an
  SQL command through the database
  connection  SQLString "SELECT FROM
  Products  DBCommand New OleDbCommand(SQLStrin
  g, DBConnection)  '-- Create a recordset of
  selected records from the database  DBReader
  DBCommand.ExecuteReader()  '-- Read through
  the recordset one record at a time  While
  (DBReader.Read())
• ...process DBReader("ItemNumber")    ...p
  rocess DBReader("ItemName")    ...process
  DBReader("ItemPrice")

18
Closing DB Connection

• When access to a database is no longer required
  both the data reader and database connection
  should be closed.
• Each of these task is accomplished with their
  respective Close() methods, as added below to the
  continuing script.
• '-- Close the reader and database
  connections  DBReader.Close()  DBConnection.Clo
  se()

19
Binding DataReader to a Control

• Under ASP.NET a typical method of working with a
  data reader is to bind it to one of the listing
  controls aspRepeater, aspDataList, or
  aspDataGrid. In this case it is not necessary to
  iterate through the records in the data reader
  with a While...End While loop. Instead, the data
  source is bound to the control.
• The following script binds the data reader to an
  aspDataGrid control which has the id value of
  MyDataGrid
• '-- Bind the recordset to a control   MyDataGri
  d.DataSource DBReader   MyDataGrid.DataBind()

• ltaspDataGrid id"MyDataGrid" runat"server"/gt

20
Binding DataReader to a Control

• For purpose of retrieving and displaying records
  in the table, the records can be iterated within
  a While...End While loop, giving access to each
  of the individual records and their separate data
  fields.
• For purpose of retrieving and displaying records
  in the table, the data reader can be bound to one
  of the display controls where they are
  automatically iterated and bound to the control
  to produce a complete listing of the recordset.
• The method chosen -- recordset iteration or
  control binding -- depends mostly on programmer
  preferences and characteristics of the database
  application.

21
Accessing Single Table Value

• For certain applications it may not be necessary
  to extract a complete set of records from a
  database table. For instance, you may wish simply
  to get a count of the number of records in the
  table using a SELECT statement with, say, a Count
  function
• SELECT Count() FROM Products
• In this case a data reader is not required since
  no records are return by the query. All that is
  returned is a numeric value representing the
  number of records.
• Extracting single values from a table is
  accomplished with the OleDbCommand object's
  ExecuteScalar() method (rather than its
  ExecuteReader() method). The returned value can
  be assigned to a variable.

22
Accessing Single Table Value

• lt_at_ Import Namespace"System.Data.OleDb"
  gtltSCRIPT runat"server"gt OleDbConnection
  DBConnection OleDbCommand DBCommandString
  SQLString
• Integer TheCountprotected void
  Page_Load(object sender, EventArgs
  e)  DBConnection New OleDbConnection("Provider
  Microsoft.Jet.OLEDB.4.0" _     "Data
  Sourced\Databases\eCommerce.mdb")  DBConnectio
  n.Open()  SQLString "SELECT Count() FROM
  Products  DBCommand New OleDbCommand(SQLStrin
  g, DBConnection)  TheCount DBCommand.ExecuteSc
  alar()  DBConnection.Close()lt/SCRIPTgt
• The ExecuteScalar() method is used with other SQL
  functions that return single values such as MIN,
  MAX, AVG, and others.

23
Updating a Table

• The SQL INSERT, UPDATE, and DELETE statements are
  used to edit records in a database table, adding
  new records or changing or deleting existing
  records. When these statements are issued no
  recordset is returned the affected record is
  updated in place within the database.
• There is no requirement for a data reader.
  Instead, these statements are issued through the
  command object's ExecuteNonQuery() method.

24
Updating a Table

• '-- Create and issue an SQL UPDATE
• '-- command through the database
  connectionSQLString "UPDATE Products _
• SET ItemQuantity0 _
• WHERE ItemNumber'BU1111'OleDbCommand
  DBCommand New OleDbCommand(SQLString,
  DBConnection)DBCommand.ExecuteNonQuery()

25
Contingency Binding

• Occasionally, SQL SELECT statements do not return
  a recordset that can be bound to an output
  control. The recordset is empty because the SQL
  statement was in error or because no existing
  records matched the selection criteria. This
  situation may not cause a processing error, but
  you may not wish to display a partial or empty
  control where a recordset would otherwise
  display.
• Fortunately, controls that are bound to a
  recordset are displayed only when data are bound
  to them. A common way of ensuring that a control
  is displayed only when it has records to display
  is by first getting a count of the records
  matching the search criteria, then binding to the
  control only if the count is greater than 0.

26
Contingency Binding

• SQLString "SELECT Count() FROM Products WHERE
  ItemType 'Business'  DBCommand New
  OleDbCommand(SQLString, DBConnection)
• If (DBCommand.ExecuteScalar() ! 0)
      SQLString "SELECT FROM Products WHERE
  ItemType 'Business'    DBCommand New
  OleDbCommand(SQLString, DBConnection)    DBReade
  r DBCommand.ExecuteReader()    MyRepeater.Data
  Source DBReader    MyRepeater.DataBind()
  DBReader.Close()
•   DBConnection.Close()ltaspRepeater
  id"MyRepeater" runat"server"gtlt/aspRepeatergt
• In the above example a test is first made of the
  number of records retrieved by an SQL statement
  issued to retrieve records that meet a particular
  search criteria. If this count is not 0, then a
  second SQL statement is issued to retrieve the
  matching recordset.
• The record count is not assigned to a variable as
  a way to capture its value. The direct result of
  executing the DBCommand.ExecuteScalar() statement
  is tested.

27
Contingency Binding

• Even though an aspRepeater is coded on the page
  it does not display unless data are bound to it.
• If the DataBind() method is issued (when the
  record count ltgt 0), then the Repeater is
  displayed.
• If the DataBind() method is not issued (when the
  record count 0), then the Repeater is not
  displayed. The control is displayed only when it
  has data to display -- when it is bound to a
  recordset.
• This is the case for all bound controls, and it
  relieves the programmer from having to script the
  visibility of a control depending on the number
  of records retrieved.

28
Display Table Values

• lt_at_ Import Namespace"System.Data.OleDb" gt
• ltSCRIPT runat"server"gt
• OleDbConnection DBConnection
• OleDbCommand DBCommand
• OleDbDataReader DBReader
• String SQLString
• protected void Page_Load(object sender, EventArgs
  e)
• '-- Display table header
• MyTable.Text "lttable border""1""
  style""border-collapsecollapse""gt"
• MyTable.Text "lttr style""background-colorF
  0F0F0""gt"
• MyTable.Text "ltthgtNolt/thgt"
• MyTable.Text "ltthgtTypelt/thgt"
• MyTable.Text "ltthgtSupplierlt/thgt"
• MyTable.Text "ltthgtNamelt/thgt"
• MyTable.Text "ltthgtPricelt/thgt"
• MyTable.Text "ltthgtQtylt/thgt"
• MyTable.Text "lt/trgt"

29
Display Table Values

• DBConnection New OleDbConnection
  ("ProviderMicrosoft.Jet.OLEDB.4.0 Data
  Sourcec\inetpub\wwwroot\eCommerce.mdb")
• DBConnection.Open()
• SQLString "SELECT FROM Products ORDER BY
  ItemNumber
• DBCommand New OleDbCommand(SQLString,
  DBConnection)
• DBReader DBCommand.ExecuteReader()
• While (DBReader.Read())
• '-- Display table rows
• MyTable.Text "lttrgt"
• MyTable.Text "lttdgt" DBReader("ItemNumber"
  ) "lt/tdgt"
• MyTable.Text "lttdgt" DBReader("ItemType")
  "lt/tdgt"
• MyTable.Text "lttdgt" DBReader("ItemSupplie
  r") "lt/tdgt"
• MyTable.Text "lttdgt" DBReader("ItemName")
  "lt/tdgt"
• MyTable.Text "lttd align""right""gt"
  DBReader("ItemPrice") "lt/tdgt"
• MyTable.Text "lttd align""right""gt"
  DBReader("ItemQuantity") "lt/tdgt"
• MyTable.Text "lt/trgt"
• DBReader.Close()
• DBConnection.Close()

30
Display Table Values

• '-- Display table footer
• MyTable.Text "lt/tablegt"
• lt/SCRIPTgt
• lthtmlgt
• ltbodygt
• ltform runat"server"gt
• ltaspLabel id"MyTable" runat"server"/gt
• lt/formgt
• lt/bodygt
• lt/htmlgt
• DisplayTable.aspx

31
Display Table Values

• When the possibility exists that an SQL query
  will not return a set of records, it is always a
  good idea to anticipate and deal with the
  possibility that column headings may display but
  no rows of data appear.
• As was suggested previously, the script is
  modified to check for a returned recordset and
  provide explanation if none were retrieved.
• SQLString "SELECT Count() FROM Products WHERE
  ItemType'Business'DBCommand New
  OleDbCommand(SQLString, DBConnection)If
  (DBCommand.ExecuteScalar() ! 0)
  ...Else    MyTable.Text "lttrgtlttd
  colspan""6"" style""colorFF0000""gt"    MyTabl
  e.Text "No matching records"    MyTable.Text
  "lt/tdgtlt/trgt"
• DisplayTableCheck.aspx

32
CalculatingTable Values

• Since field values from a database table are
  available during iteration of the table,
  additional processing can be performed to
  generate new information based on those values.
• In the following example the ItemPrice and
  ItemQuantity fields are multiplied to derive the
  inventory value for each product. These values
  are accumulated across all records and reported
  in a total line appended to the output table.

33
CalculatingTable Values

• protected void Page_Load(object sender, EventArgs
  e)   Decimal Amount   Decimal Total
  0  '-- Display table header  MyTable.Text
  "lttable border""1"" style""border- _
• collapsecollapse""gt"  MyTable.Text "lttr
  style""background-colorF0F0F0""gt"  MyTable.Tex
  t "ltthgtNolt/thgt"  MyTable.Text
  "ltthgtTypelt/thgt"  MyTable.Text
  "ltthgtSupplierlt/thgt"  MyTable.Text
  "ltthgtNamelt/thgt"  MyTable.Text
  "ltthgtPricelt/thgt"  MyTable.Text
  "ltthgtQtylt/thgt"  MyTable.Text
  "ltthgtAmountlt/thgt"  MyTable.Text "lt/trgt"

34
CalculatingTable Values

• DBConnection New OleDbConnection
  _    ("ProviderMicrosoft.Jet.OLEDB.4.0
  _    Data Sourced\Databases\eCommerce.mdb")DB
  Connection.Open()
• SQLString "SELECT FROM Products _
• ORDER BY ItemNumberDBCommand New
  OleDbCommand _
• (SQLString, DBConnection)DBReader
  DBCommand.ExecuteReader()

35
CalculatingTable Values

• While (DBReader.Read())
• '-- Calculate item amount
• Amount DBReader("ItemPrice")
  DBreader("ItemQuantity")
• Total Amount
• '-- Display table rows
• MyTable.Text "lttrgt
• MyTable.Text "lttdgt" DBReader("ItemNumber")
  "lt/tdgt
• MyTable.Text "lttdgt" DBReader("ItemType")
  "lt/tdgt
• MyTable.Text "lttdgt" DBReader("ItemSupplier")
  "lt/tdgt
• MyTable.Text "lttdgt" DBReader("ItemName")
  "lt/tdgt
• MyTable.Text "lttd align""right""gt"
  DBReader("ItemPrice") "lt/tdgt
• MyTable.Text "lttd align""right""gt"
  DBReader("ItemQuantity") "lt/tdgt
• MyTable.Text "lttd align""right""gt" _
• FormatNumber(Amount) "lt/tdgt
• MyTable.Text "lt/trgt

36
CalculatingTable Values

•  '-- Display table footer  MyTable.Text "lttr
  align""right"" style""background-colorF0F0F0""
  gt"  MyTable.Text "lttd colspan""6""gtltbgtTotal
  lt/bgtlt/tdgt"  MyTable.Text "lttdgt"
  FormatCurrency(Total) "lt/tdgt"  MyTable.Text
  "lt/trgt"  MyTable.Text "lt/tablegt"lt/SCRIPTgtlt
  htmlgtltbodygtltform runat"servergtltaspLabel
  id"MyTable" runat"server"/gtlt/formgtlt/bodygtlt/html
  gt
• Two variables are declared at the beginning of
  the script Amount holds the calculation of
  ItemPrice times ItemQuantity for each product
  Total is the accumulator for all the Amounts and
  is initialized to 0.
• Within the processing loop Amount is calculated
  as DBReader("ItemPrice") DBReader("ItemQuantity"
  ) for this product. This calculated Amount is
  added to the Total. Within a new table column
  this Amount is displayed with FormatNumber()
  formatting.
• At the end of the processing loop variable Total,
  having accumulated all the individual Amounts, is
  displayed in an added table row. It is formatted
  as a dollar amount.
• DisplayTableCalc.aspx

37
Binding to Data Display Controls

• The preferred ASP.NET method to display database
  records is to bind the recordset to a list
  control such as the aspRepeater, aspDataList,
  or aspDataGrid control.
• For an aspRepeater control, templates are
  provided to describe output formatting. A table
  can be used to display rows and columns of
  records, with individual data items bound to the
  table cells. Also, alternating row formatting can
  be specified. A column can be provided for
  displaying a calculated amount for each item, and
  a row can be added to the bottom of the table for
  display of the inventory total.

38
Binding to a Repeater

• lt_at_ Import _ Namespace"System.Data.OleDb"
  gtltSCRIPT runat"server"gt OleDbConnection
  DBConnection OleDbCommand DBCommand
  OleDbDataReader DBReader String SQLString
  Decimal Amount Decimal Total 0

39
Binding to a Repeater

• protected void Page_Load(object sender, EventArgs
  e)  If (! Page.IsPostBack)     DBConnection
  New OleDbConnection _      ("ProviderMicrosoft
  .Jet.OLEDB.4.0Data Sourced\Databases\eCommerce.
  mdb")
• DBConnection.Open()    SQLString "SELECT
  FROM Products ORDER BY ItemNumber    DBComman
  d New OleDbCommand(SQLString,
  DBConnection)    DBReader DBCommand.ExecuteRea
  der()    RepeaterOutput.DataSource
  DBReader    RepeaterOutput.DataBind()
•     DBReader.Close()    DBConnection.Close(
  )

40
Binding to a Repeater

• Decimal GetAmount(Decimal Pric, Decimal
  Quantity)
• Amount Price Quantity  Total
  Amount  Return Amount Decimal GetTotal()
•
•  Return Totallt/SCRIPTgt

41
Binding to a Repeater

• lthtmlgtltbodygtltform runat"server"gtltaspRepeater
  id"RepeaterOutput" runat"server"gt  ltHeaderTem
  plategt    lttable border"1" style"border-collaps
  ecollapse"gt      lttr style"background-colorA0
  A0A0 colorFFFFFF"gt        ltthgtNolt/thgt
  ltthgtTypelt/thgt        ltthgtSupplierlt/thgt        ltt
  hgtNamelt/thgt        ltthgtPricelt/thgt        ltthgtQty
  lt/thgt        ltthgtAmountlt/thgt      lt/trgt  lt/Head
  erTemplategt

42
Binding to a Repeater

•   ltItemTemplategt    lttrgt      lttdgtlt
  Container.DataItem("ItemNumber") gt
  lt/tdgt      lttdgtlt Container.DataItem("ItemType")
  gt lt/tdgt      lttdgtlt Container.DataItem("ItemSu
  pplier") gt lt/tdgt      lttdgtlt
  Container.DataItem("ItemName") gt lt/tdgt      lttd
  align"right"gtlt Container.DataItem("ItemPrice")
  gt
• lt/tdgt      lttd align"right"gtlt
  Container.DataItem("ItemQuantity")gt
• lt/tdgt      lttd align"right"gt
• lt FormatNumber(GetAmount(Container.DataItem("Ite
  mPrice"), _
• Container.DataItem("ItemQuantity")))
  gtlt/tdgt    lt/trgt  lt/ItemTemplategt

43
Binding to a Repeater

•   ltAlternatingItemTemplategt    lttr
  style"background-colorF0F0F0"gt      lttdgtlt
  Container.DataItem("ItemNumber")
  gtlt/tdgt      lttdgtlt Container.DataItem("ItemType
  ") gtlt/tdgt      lttdgtlt Container.DataItem("ItemS
  upplier") gtlt/tdgt      lttdgtlt
  Container.DataItem("ItemName") gtlt/tdgt      lttd
  align"right"gtlt Container.DataItem("ItemPrice")
  gt
• lt/tdgt      lttd align"right"gtlt
  Container.DataItem("ItemQuantity") gt
• lt/tdgt      lttd align"right"gt
• lt FormatNumber(GetAmount(Container.DataItem("Ite
  mPrice"), _
• Container.DataItem("ItemQuantity")))
  gtlt/tdgt    lt/trgt  lt/AlternatingItemTemplategt

44
Binding to a Repeater

• ltFooterTemplategt    lttr align"right"gt      ltth
  colspan"6" style"background-colorA0A0A0 _
• colorFFFFFF"gtTotallt/thgt      lttdgtlt
  FormatCurrency(GetTotal()) gtlt/tdgt    lt/trgt    lt
  /tablegt  lt/FooterTemplategtlt/aspRepeatergtlt/fo
  rmgtlt/bodygtlt/htmlgt
• Repeater.aspx

45
Binding to a Repeater

• The script links to the database, extracts a
  recordset, and binds the associated data reader
  to the Repeater control.
• Scripting is placed inside the If Not
  Page.IsPostBack condition because the control
  only needs to be populated the first time the
  page loads.
• Although it does not occur in this example, the
  control would retain its data through the page's
  View State if a page postback were made.

46
Binding to a Repeater

• Data values extracted from the Products table are
  bound to the table cells with a simple binding
  expression in the format lt Container.DataItem("F
  ieldName") gt. A calculated amount for each item
  is given by a function call to GetAmount() which
  passes the ItemPrice and ItemQuantity from the
  associated record
• lt FormatNumber(GetAmount(Container.DataItem("Ite
  mPrice") _
• Container.DataItem("ItemQuantity"))) gt
• The function receives these values as arguments
  Price and Quantity, and multiplies them to derive
  the item Amount. At the same time, this Amount is
  added to variable Total to accumulate the total
  value of inventory. Variables Amount and Total
  have been declared as global variables for access
  by the Repeater and by the function. The function
  returns the calculated Amount, which is formatted
  as a number with the built-in FormatNumber()
  function.

47
Binding to a Repeater

• Incidentally, were it not for the fact that the
  inventory Total is calculated by accumulating
  item Amounts, the function call to GetAmount()
  would not be needed.
• If only the item Amount is calculated, it could
  be done by including the calculation inside the
  Repeater cell
• lt FormatNumber(Container.DataItem _
• ("ItemPrice") Container.DataItem _
• ("ItemQuantity")) gt

48
Binding to a Repeater

• Still, there is coding consistency in always
  using function calls for calculated values. This
  consistency is maintained by displaying the
  inventory Total at the bottom of the Repeater
  table by a function call to GetTotal()
• lt FormatCurrency(GetTotal()) gt
• The function simply returns the value of variable
  Total. This value could have been displayed
  without a function call by embedding the variable
  itself inside the binding expression
• lt FormatCurrency(Total) gt

49
Binding to a DataGrid

• An aspDataGrid control provides both the easiest
  and the most elaborate methods for displaying
  database output. On one hand, the control can
  automatically generate columns of output data to
  match the columns of input data with only minimal
  specifications. On the other hand, the control
  can be altered in numerous ways to produce
  specialized output.
• In its minimal state the aspDataGrid control
  requires only a single line of code
• ltaspDataGrid id"DataGridOutput"
  runat"server"/gt

50
Binding to a DataGrid

• DBConnection New OleDbConnection _
• ("ProviderMicrosoft.Jet.OLEDB.4.0 _
• Data Sourced\Databases\eCommerce.mdb")
• DBConnection.Open()
• SQLString "SELECT ItemNumber, ItemType,
  ItemSupplier, _
• ItemName, ItemPrice, ItemQuantity FROM Products
  _
• ORDER BY ItemNumber
• DBCommand New OleDbCommand(SQLString,
  DBConnection)
• DBReader DBCommand.ExecuteReader()
• DataGridOutput.DataSource DBReader
• DataGridOutput.DataBind()
• DBReader.Close()
• DBConnection.Close()
• Datagrid.aspx

51
Binding to a DataGrid

• The control is quick and functional but you
  probably wish to have more control over its
  display characteristics.
• In the following example, selected columns are
  bound to the DataGrid using ltaspBoundColumngt and
  ltTemplateColumngt controls. In this case only
  those specified columns are displayed. Formatting
  styles are also applied to the grid.

52
Binding to a DataGrid

• lt_at_ Import _
• Namespace"System.Data.OleDb" gtltSCRIPT
  runat"server"gt OleDbConnection DBConnection
  OleDbCommand DBCommand OleDbDataReader
  DBReader String SQLString

53
Binding to a DataGrid

• protected void Page_Load(object sender, EventArgs
  e)
• If (!Page.IsPostBack)
•     DBConnection New OleDbConnection
  _       ("ProviderMicrosoft.Jet.OLEDB.4.0 _
• Data Sourced\Databases\eCommerce.mdb")    DB
  Connection.Open()    SQLString "SELECT FROM
  Products _
• ORDER BY ItemNumber    DBCommand New
  OleDbCommand _
• (SQLString, DBConnection)    DBReader
  DBCommand.ExecuteReader()    DataGridOutput.Data
  Source DBReader    DataGridOutput.DataBind()
      DBReader.Close()    DBConnection.Close()


54
Binding to a DataGrid

• lthtmlgtltbodygtltform runat"server"gtltaspDataGrid
  id"DataGridOutput" runat"server" _
• AutoGenerateColumns"False" _
• CellPadding"2" _
•    GridLines"Horizontal" BorderWidth"1" _
•      HeaderStyle-BackColor"A0A0A0" _
•      HeaderStyle-ForeColor"FFFFFF" _
•    HeaderStyle-Font-Bold"True" _
• HeaderStyle-HorizontalAlign"Center" _
• ItemStyle-VerticalAlign"Top" _
• AlternatingItemStyle-BackColor"F0F0F0"gt

55
Binding to a DataGrid

•   ltColumnsgt  ltaspBoundColumn    DataField"Ite
  mNumber"    HeaderText"No"/gt
• ltaspBoundColumn    DataField"ItemType"    Hea
  derText"Type"/gt
• ltaspBoundColumn    DataField"ItemSupplier"
   HeaderText"Supplier"/gt
• ltaspBoundColumn    DataField"ItemName"    Hea
  derText"Name"/gt

56
Binding to a DataGrid

• ltaspBoundColumn    DataField"ItemPrice"    Hea
  derText"Price"    ItemStyle-HorizontalAlign"Rig
  ht"/gt
• ltaspBoundColumn    DataField"ItemQuantity"
   HeaderText"Qty"    ItemStyle-HorizontalAlign"R
  ight"/gt
• ltaspTemplateColumn    HeaderText"Description"
      ItemStyle-VerticalAlign"Top"gt

57
Binding to a DataGrid

• ltItemTemplategt      ltdiv style"width170px
  height40px _
• font-size8pt line-height8pt _
• overflowauto"gt        lt Container.DataItem(
  "ItemDescription") gt      lt/divgt    lt/ItemTempl
  ategt
• lt/aspTemplateColumngtlt/Columnsgtlt/aspDataGridgt
  lt/formgtlt/bodygtlt/htmlgt
• DataGrid2.aspx

58
Binding to a DataGrid

• Notice that the specification AutoGenerateColumns
  "False" is coded for the DataGrid so that display
  columns are not automatically generated.
• One of the database fields, ItemDescription, is
  an Access Memo field containing free-form text. A
  Memo field can hold over 65,000 characters. When
  setting up the DataGrid, special provision needs
  to be made for this field otherwise its entire
  contents would display, making for a very long
  and cumbersome output display. An
  ltaspTemplateColumngt is added to the DataGrid to
  handle this field.

59
Binding to a DataGrid

• ltaspTemplateColumn HeaderText"Description _
• ItemStyle-VerticalAlign"Top"gt
• ltItemTemplategt
• ltdiv style"width170px height40px
  font-size8pt _
• line-height8pt overflowauto"gt
• lt Container.DataItem("ItemDescription") gt
• lt/divgt
• lt/ItemTemplategt
• lt/aspTemplateColumngt

60
Binding to a DataGrid

• Within the ltItemTemplategt an HTML division is
  included with width and height settings to
  restrict its size. Also, overflowauto is applied
  to the division that displays a vertical scroll
  bar on the container if its contents cannot be
  fully displayed. Using this setting permits
  display of the ItemDescription field without it
  taking up too much real estate on the page.
• When using template columns in a DataGrid a
  binding expression is in the format
• lt Container.DateItem("FieldName") gt

61
Adding Calculation to a DataGrid

• The above example does not display a calculated
  column or an inventory total as in the previous
  Repeater. However, these can be easily added to
  the DataGrid using the same techniques as used
  for the Repeater.
• Of course, a template column, rather than a bound
  column, is added to the DataGrid since bound
  columns only map to existing recordset fields,
  not to calculated values.

62
Binding to a DataList with Calculations

• The aspDataList control gives a different look
  to the output since all data items for a single
  record appear in a single table cell rather than
  being arranged in a grid.
• It is based on the use of templates to describe
  the output format, and embedded binding
  expressions show the locations of displayed data.

63
Binding to a DataList with Calculations

• Decimal Amount
• Decimal Total 0
• protected void Page_Load(object sender, EventArgs
  e)
• If (!Page.IsPostBack)
• DBConnection New OleDbConnection
  ("ProviderMicrosoft.Jet.OLEDB.4.0 _
• Data Sourced\Databases\eCommerce.mdb")
• DBConnection.Open()
• SQLString "SELECT FROM Products ORDER BY
  ItemNumber
• DBCommand New OleDbCommand(SQLString,
  DBConnection)
• DBReader DBCommand.ExecuteReader()
• DataListOutput.DataSource DBReader
• DataListOutput.DataBind()
• DBReader.Close()
• DBConnection.Close()

64
Binding to a DataList with Calculations

• Decimal GetAmount(Decimal Price, _
• Decimal Quantity)
• Amount Price Quantity
• Total Total Amount
• Return Amount
• Decimal GetTotal()
• Return Total

65
Binding to a DataList with Calculations

• lt/SCRIPTgt
• lthtmlgt ltbodygt ltform runat"server"gt
• ltaspDataList id"DataListOutput" runat"server"
  GridLines"Both" _ CellPadding"3"
  RepeatColumns"2" RepeatDirection"Horizontal"gt
• ltItemTemplategt
• ltimg src"../Pictures/lt Container.DataItem("Item
  Number") gt.jpg" _ width"70" align"left"gt
• lttable border"0" cellpadding"0"
  cellspacing"0"gt
• lttrgtlttdgtltbgtNumber lt/bgtlt/tdgt
• lttdgtlt Container.DataItem("ItemNumber") gt lt/tdgt
• lt/trgt
• lttrgtlttdgtltbgtType lt/bgtlt/tdgt
• lttdgtlt Container.DataItem("ItemType") gt lt/tdgt
• lt/trgt

66
Binding to a DataList with Calculations

• lttrgtlttdgtltbgtSupplier lt/bgtlt/tdgt
• lttdgtlt Container.DataItem("ItemSupplier")
  gtlt/tdgtlt/trgt lttrgtlttdgtltbgtTitle lt/bgtlt/tdgt
• lttdgtlt Container.DataItem("ItemName") gt
  lt/tdgtlt/trgt lttrgtlttdgtltbgtPrice lt/bgtlt/tdgtlttdgt
• lt Container.DataItem("ItemPrice") gt lt/tdgtlt/trgt
  lttrgtlttdgtltbgtQuantity lt/bgtlt/tdgtlttdgt
• lt Container.DataItem("ItemQuantity")
  gtlt/tdgtlt/trgt lttrgtlttdgtltbgtAmount lt/bgtlt/tdgtlttdgtltbgt
• lt FormatNumber(GetAmount(Container.DataItem("Ite
  mPrice"), Container.DataItem("ItemQuantity"))) gt
  lt/bgtlt/tdgtlt/trgt
• lt/tablegt
• lt/ItemTemplategt
• ltFooterTemplategt ltbgtInventory Total lt
  FormatCurrency(GetTotal()) gtlt/bgt
• lt/FooterTemplategt
• lt/aspDataListgt lt/formgt lt/bodygt lt/htmlgt
  FullDataListCalc.aspx

67
Binding to a DataList with Calculations

• Binding to the DataList is virtually the same as
  for the Repeater and DataList controls. In this
  case a product picture is added to the display
  with an ltimg/gt tag whose src attribute links the
  ItemNumber from the database with the graphic
  file name. That is, image file BU1111.jpg is
  referenced by ItemNumber BU1111 with ".jpg"
  appended. Information inside the template cells
  of the DataList are arranged in its own table to
  control alignment.
• There are numerous ways to display
  server-generated data on a Web page. No one
  method is the "right" way. Much will depend on
  how much trouble you wish to spend in producing
  the displays or how much control you want over
  the process.

68
Adding Calculation to a DataGrid

• ltaspTemplateColumn
• ItemStyle-VerticalAlign"Top"
• ItemStyle-HorizontalAlign"Right"gt
• ltHeaderTemplategt Amount lt/HeaderTemplategt
• ltItemTemplategt
• lt FormatNumber(GetAmount _
• (Container.DataItem("ItemPrice"), _
• Container.DataItem("ItemQuantity"))) gt
• lt/ItemTemplategt
• ltFooterTemplategt
• lt FormatCurrency(GetTotal()) gt
• lt/FooterTemplategt
• lt/aspTemplateColumngt

69
Binding to a DropDownList

• The most popular server control for making
  selections from databases is the DropDownList.
• It is populated with record identifiers for
  choosing which of the records in the table to
  display or otherwise take action on.
• In the following example a list of ItemNumbers
  from the Products table is displayed. The
  selection retrieves the associated record.

70
Binding to a DropDownList

• ltaspDropDownList id"ItemNumber"
  runat"server"/gt
• ltaspButton Text"Select" OnClick"Display_Produc
  t" runat"server"/gtltaspRepeater
  id"ProductDisplay" runat"server"gt  ltHeaderTemp
  lategt    lttable border"1" cellpadding"3"
  style"border-collapsecollapse"gt    lttr
  style"background-colorF0F0F0"gt      ltthgtNolt/th
  gt      ltthgtTypelt/thgt      ltthgtSupplierlt/thgt
    ltthgtTitlelt/thgt      ltthgtPricelt/thgt      ltthgtQt
  ylt/thgt    lttrgt  lt/HeaderTemplategt

71
Binding to a DropDownList

•   ltItemTemplategt    lttrgt      lttd
  align"center"gtlt Container.DataItem("ItemNumber"
  ) gtlt/tdgt      lttdgtlt Container.DataItem("ItemTy
  pe") gtlt/tdgt      lttdgtlt Container.DataItem("Ite
  mSupplier") gtlt/tdgt      lttdgtlt
  Container.DataItem("ItemName") gtlt/tdgt      lttd
  align"right"gtlt Container.DataItem("ItemPrice")
  gtlt/tdgt      lttd align"right"gtlt
  Container.DataItem("ItemQuantity")
  gtlt/tdgt    lt/trgt    lttrgt      lttd
  colspan"6"gtlt Container.DataItem("ItemDescriptio
  n") gt
• lt/tdgt    lt/trgt
• lt/ItemTemplategt
• ltFooterTemplategt
• lt/tablegt
• lt/FooterTemplategt
• lt/aspRepeatergt

72
Binding to a DropDownList

• protected void Page_Load(object sender, EventArgs
  e)  If (!Page.IsPostBack)     DBConnection
  New OleDbConnection _      ("ProviderMicrosoft.J
  et.OLEDB.4.0" _      "Data Sourced\Databases
  \eCommerce.mdb")    DBConnection.Open()    SQL
  String "SELECT ItemNumber FROM Products _
• ORDER BY ItemNumber    DBCommand New
  OleDbCommand(SQLString, DBConnection)    DBReade
  r DBCommand.ExecuteReader()
•   ItemNumber.DataSource DBReader    ItemNu
  mber.DataTextField "ItemNumber    ItemNumber.
  DataBind()    DBReader.Close()    DBConnection
  .Close()
• DropDownList.aspx

73
Binding to a DropDownList

• The ItemNumber field is retrieved from all
  records in the Products table, and the recordset
  is made available in ascending order.
• Binding this set of ItemNumbers to the
  DropDownList requires the statements
• ItemNumber.DataSource DBReader ItemNumber.Da
  taTextField "ItemNumber ItemNumber.DataBind()

• The DataSource property identifies the set of
  records to be used. In the case of a recordset
  retrieved as a data reader from a database, it is
  the data reader that is the source of data for
  the control.

74
Binding to a DropDownList

• The DataTextField property identifies the field
  from the recordset that displays as items in the
  list. In this example the ItemNumber field is
  displayed, being the only field retrieved from
  the table. (Optionally, the DataValueField could
  be specified if using a different value from the
  ItemNumber. In this case the ItemNumber is used
  as both the Text and Value properties of the
  list.)
• Finally, the DataBind() method is called to bind
  the ItemNumbers to the DropDownList.
• When the "Select" button is clicked, the
  Display_Product subroutine is called to display
  information about the selected product

75
Binding to a DropDownList

• void Display_Product (Src As Object, Args As
  EventArgs)  DBConnection New OleDbConnection
  _    ("ProviderMicrosoft.Jet.OLEDB.4.0"
  _    "Data Sourced\Databases\eCommerce.mdb")
   DBConnection.Open()  SQLString "SELECT
  FROM Products " _              "WHERE
  ItemNumber '" ItemNumber.SelectedItem.Text
  "'  DBCommand New OleDbCommand(SQLString,
  DBConnection)  DBReader DBCommand.ExecuteReade
  r()  ProductDisplay.DataSource
  DBReader  ProductDisplay.DataBind()  DBReader.
  Close()  DBConnection.Close()
• The statement to notice is the SQL command
• SQLString "SELECT FROM Products "
  _            "WHERE ItemNumber '"
  ItemNumber.SelectedItem.Text "'"which uses the
  Text property of the selection from the
  DropDownList to retrieve all fields from the
  associated Products record.

76
Composing of SQL Strings

• You need to become familiar with this method of
  inserting values inside SQL statements. It can
  appear confusing, but it's rather
  straight-forward if you concentrate. The
  statement simply inserts a script-generated value
  inside literal strings of SQL text to arrive at
  an SQL statement in the format
• SELECT FROM PRODUCTS WHERE ItemNumber 'value'

• So, the literal string "SELECT FROM PRODUCTS
  WHERE ItemNumber '" is concatenated with the
  value of the selected item ItemNumber.SelectedItem
  .Text along with a final closing single-quote
  string "'".

77
Binding to a DropDownList

• A DataValueField, in addition to the
  DataTextField, can be defined when a Value
  property for a drop-down selection needs to be
  different from its Text property. For instance,
  to provide a listing of ItemNames from which to
  choose, still using the ItemNumber to retrieve
  the associated record, binding of both Text and
  Value properties is required.
• The binding statements include both DataTextField
  and DateValueField bindings
• ItemNumber.DataSource DBReaderItemNumber.Data
  TextField "ItemName"
• ItemNumber.DataValueField
  "ItemNumberItemNumber.DataBind()

78
Binding to a DropDownList

• The SQL statement to supply these values to the
  DropDownList includes retrieval of both fields
  and ordering by the names
• SQLString "SELECT ItemNumber, ItemName _
• FROM Products ORDER BY ItemName
• In the Display_Product subprogram the SQL
  statement to retrieve a record identifies the
  Value property of the selection, rather than the
  Text property, as the value to use in retrieving
  the matching record
• SQLString "SELECT FROM Products "
  _       "WHERE ItemNumber '" _
  ItemNumber.SelectedItem.Value "'
• DropDownList2.aspx

79
Binding to a ListBox

• These same binding techniques used for a
  DropDownList apply to the aspListBox control,
  where multiple items can be selected from the
  list.
• ltaspListBox id"ItemNumbers" _
  SelectionMode"Multiple" runat"server"/gt
• Use Ctrl-Click or Shift-Click to select one or
  more items from the following ListBox.

80
Binding to a ListBox

• When retrieving selected records from the
  database the SQL statement must use multiple
  conditions within the WHERE clause to match
  against the multiple selections. For example, if
  the first three items in the list are selected,
  then the SQL statement would have to be
• SELECT FROM Products WHERE ItemNumber'DB1111'
  _
• OR ItemNumber'GR3333' OR ItemNumber'WB4444
• The multiple conditions need to be appended to
  the SQL statement for as many item as are
  selected. This is accomplished within a For
  Each...Next loop that iterates through all the
  items in the list and concatenates a condition
  test to the SQL statement for each selected item.

81
Binding to a ListBox

• void Display_Product (Src As Object, Args As
  EventArgs)  SQLString "SELECT FROM
  PRODUCTS WHERE
• ListItem Item
• foreach (Item in ItemNumbers.Items)
• If (Item.Selected True)        SQLString
  "ItemNumber '" Item.Value _
• "' OR "
• SQLString Left(SQLString, Len(SQLString) -
  4)

82
Binding to a ListBox

• DBConnection New OleDbConnection
  _    ("ProviderMicrosoft.Jet.OLEDB.4.0"
  _    "Data Sourced\Databases\eCommerce.mdb")
   DBConnection.Open()  DBCommand New
  OleDbCommand_
• (SQLString, DBConnection)  DBReader
  DBCommand.ExecuteReader()  ProductDisplay.DataSo
  urce DBReader  ProductDisplay.DataBind()  DB
  Reader.Close()  DBConnection.Close()

83
Binding to a ListBox

• The SQL statement is composed by first assigning
  the literal text string "SELECT FROM Products
  WHERE " to the SQLString variable.
• Now, a For Each...Next loop checks whether an
  item in the list has been selected. If so, then
  that item's Value (its associated ItemNumber) is
  concatenated to the SQLString as a selection
  criterion
• SQLString "ItemNumber'" Item.Value "' OR
  ".
• If, for example, the first item in the list is
  selected, then SQLString contains, at this point,
• SELECT FROM Products WHERE ItemNumber'DB1111'
  OR
• Continuing through the loop, all selected items
  are appended to SQLString as a selection
  criterion. Thus, if the first three items are
  selected, SQLString contains the following string
  at completion of the loop
• SELECT FROM Products WHERE ItemNumber'DB1111'
  OR _ ItemNumber'GR3333' OR ItemNumber'WB4444'
  OR
• Listbox.aspx

84
Binding to a ListBox

• The string continues to be built in this fashion
  for as many items as are selected. At completion,
  though, the SQL statement is not in valid format
  because it has an extra " OR " on the end of the
  string. Therefore, these extra four characters
  (counting the blank spaces) need to be removed
• SQLString Left(SQLString, Len(SQLString) - 4)
• The left-most (length - 4) characters of
  SQLString are reassigned to the variable. Now a
  valid SQL statement is stored in SQLString.
• The remainder of the script is identical to
  before. The SQL statement is issued to retrieve
  the matching records and the resulting data
  reader is bound to the Repeater control.

85
Binding to a RadioButtonList

• A RadioButtonList control (but not a RadioButton
  control) can bind to data from a database.
• This control has DataTextField and DataValueField
  properties, the former serving as the text label
  for the button and the latter as the value for
  the button.
• If DataValueField is not defined, then the
  DataTextField serves as both the label and the
  value.

86
Binding to a RadioButtonList

• In the following example, the ItemType field from
  the Products table is used as the data source for
  the list of radio buttons. Clicking the "Select"
  button displays all the products of that type.
• The RadioButtonList and accompanying button are
  defined with the controls
• ltaspRadioButtonList id"RadioList"
  runat"server"/gtltaspButton Text"Select _
• OnClick"Display_Products" runat"server"/gtwith
  binding script similar to that used for the
  drop-down list and which is run when the page is
  first loaded.

87
Binding to a RadioButtonList

• DBConnection New OleDbConnection
  _  ("ProviderMicrosoft.Jet.OLEDB.4.0"
  _  "Data Sourced\Databases\eCommerce.mdb")DBC
  onnection.Open()SQLString "SELECT DISTINCT
  ItemType FROM Products _
• ORDER BY ItemTypeDBCommand New
  OleDbCommand(SQLString, DBConnection)DBReader
  DBCommand.ExecuteReader()RadioList.DataSource
  DBReaderRadioList.DataTextField
  "ItemTypeRadioList.DataBind()DBReader.Close(
  )DBConnection.Close()

88
Binding to a RadioButtonList

• The SQL statement used to retrieve button labels
  and values selects only the unique ItemType
  values from the field (multiple products have the
  same ItemType values only one occurence of each
  type is retrieved with the DISTINCT selector)
• SQLString "SELECT DISTINCT ItemType FROM
  Products _
• ORDER BY ItemType"
• The SQL statement is composed to select all
  records from the database where ItemType matches
  the RadioList.SelectedItem.Text value of the
  checked button. That subset of records is bound
  to the Repeater. Notice that the binding
  statements are surrounded by a test for a button
  selection. Data are retrieved and bound to the
  Repeater only if a button has been clicked. Of
  course, this test is not necessary if any of the
  buttons is preselected.

89
Binding to a RadioButtonList

• void Display_Products (Src As Object, Args As
  EventArgs)  If (RadioList.SelectedIndex ! -1)
      DBConnection New OleDbConnection
  _      ("ProviderMicrosoft.Jet.OLEDB.4.0"
  _      "Data Sourced\Databases\eCommerce.mdb")
      DBConnection.Open()    SQLString "SELECT
  FROM Products " _          "WHERE ItemType
  '" RadioList.SelectedItem.Text
  "'    DBCommand New OleDbCommand(SQLString,
  DBConnection)    DBReader DBCommand.ExecuteRea
  der()    ProductDisplay4.DataSource
  DBReader    ProductDisplay4.DataBind()    DBRe
  ader.Close()    DBConnection.Close()
• RadioButton.aspx

90
Binding to a RadioButtonList

• Recall that radio buttons themselves can trigger
  a subroutine call without having to provide a
  separate "Select" button. Code the
  RadioButtonList with AutoPostBack"True" and
  OnSelectedIndexChanged"subprogram" properties.
• ltaspRadioButtonList id"RadioList"
  runat"server"  AutoPostBack"True"  OnSelectedI
  ndexChanged"Display_Product"/gt
• Coding of the Display_Products subprogram is
  identical to where a selection is made with a
  separate "Submit" button, with the exception that
  it is not necessary to test for a checked button.

91
Binding to a CheckBoxList

• Binding to and selecting from an aspCheckBoxList
  control operate in the same fashion as for a
  ListBox control.
• Since more than one item can be checked, you need
  to iterate though all the boxes to discover those
  that are checked, and build an appropriate SQL
  statement as a concatenation of multiple
  selection criteria.

92
Repeater

• FullRepeater.aspx
