Database Conceptual and Logical Design

• Zachary G. Ives
• University of Pennsylvania
• CIS 550 Database Information Systems
• October 4, 2005

Some slide content courtesy of Susan Davidson
Raghu Ramakrishnan
2
Administrivia

• Homework 2 due now
• Homework 3 handed out (due on the 13th)

3
Modifying the DatabaseInserting Data

• Inserting a new literal tuple is easy, if
  wordyINSERT INTO PROFESSOR(fid, name)VALUES
  (4, Simpson)
• But we can also insert the results of a
  query!INSERT INTO PROFESSOR(fid, name) SELECT
  sid AS fid, name FROM STUDENT WHERE sid lt 20

4
Deleting and Modifying Tuples

• Deletion is a fairly simple operationDELETEFRO
  M STUDENT SWHERE S.sid lt 25

• So is insertion
• UPDATE STUDENT SSET S.sid 1 S.sid, S.name
  JanetWHERE S.name Jane

5
Im Building an App How Do I Talk to the DB?

• Generally, apps are in a different (host)
  language with embedded SQL statements
• Static SQLJ, embedded SQL in C
• Dynamic ODBC, JDBC, ADO, OLE DB,
• Typically, predefined mappings between host
  language types and SQL types (e.g., VARCHAR ?
  String or char)

6
The Impedance Mismatch and Cursors

• SQL is set-oriented it returns relations
• Theres no relation type in most languages!
• Solution result sets and cursors that are
  opened, read, as if from a file

7
JDBC Dynamic SQL for Java

• See Chapter 6 of the text for more infoimport
  java.sql.Connection conn DriverManager.getCon
  nection()PreparedStatement stmt
  conn.prepareStatement(SELECT FROM
  STUDENT)ResultSet rs stmt.executeQuery ()
  while (rs.next()) sid rs.getInteger(1)

8
Database-Backed Web Sites

• We all know traditional static HTML web sites

Web Browser
Web-Server
HTTP-Request GET ...
9
Interaction Is Achieved via HTML Forms

• lthtmlgt
• ltform actionhttp//my.com/some-handler-url
  methodPOSTgt
• ltinput typetext namevalue1 /gt
• ltinput typesubmit valueSend /gt
• ltinput typerest valueCancel /gt
• lt/formgt

10
DB Access with JavaApplets and Server Processes
BrowserJVM
Java Applet
TCP/UDP IP
Java-Server-Process
JDBC Driver manager
JDBC-Driver
JDBC-Driver
JDBC-Driver
Sybase
Oracle
...
11
Java Applets Discussion

• Advantages
• Can take advantage of client processing
• Platform independent assuming standard java
• Disadvantages
• Requires JVM on client self-contained
• Inefficient loading can take a long time ...
• Resource intensive Client needs to be state of
  the art
• Restrictive can only connect to server where
  applet was loaded from (for security can be
  configured)
• A common alternative is to run code on the
  server-side
• CGI, ASP/PHP/JSP, ASP.Net, servlets

12
Server Pages (P) and Servlets(IIS, Tomcat, )
Web Server
Web Server
HTTP Request
File-System
Load File
HTML
HTML?
File
HTML File
13
ASP/JSP/PHP Escapes

• lthtmlgt
• ltheadgtlttitlegtSamplelt/titlegtlt/headgt
• ltbodygt
• lth1gtSamplelt/h1gt
• lt myClass.Process(request.getParameter(test))
  gt
• lt request.getParameter(value) gt
• lt/bodygt
• lt/htmlgt

14
Servlets

• class MyClass extends HttpServlet
• public void doGet(HttpRequest req, HttpResponse
  res)
• res.println(lthtmlgtltheadgtlttitlegtTestlt/titlegtlt/he
  adgtlt/htmlgt)

15
ASP/JSP/PHP Versus Servlets

• The goal combine direct HTML (or XML) output
  with program code thats executed at the server
• The code is responsible for generating more
  HTML, e.g., to output the results of a database
  table as HTML table elements
• How might I do this?
• HTML with embedded code (P)
• Code that prints out HTML (Servlets)

16
Now How Do We Get the Database in the First
Place?

• Database design theory!
• Neat outcome we can actually prove that we have
  optimal design, in a manner of speaking
• But first we need to understand how to visualize
  in pretty pictures

17
Databases AnonymousA 6-Step Program

1. Requirements Analysis what data, apps, critical
   operations
2. Conceptual DB Design high-level description of
   data and constraints typically using ER model
3. Logical DB Design conversion into a schema
4. Schema Refinement normalization (eliminating
   redundancy)
5. Physical DB Design consider workloads, indexes
   and clustering of data
6. Application/Security Design

18
Entity-Relationship Diagram(based on our running
example)
Underlined attributes are keys
PROFESSORS
fid
name
relationship set
Teaches
entity set
semester
Takes
STUDENTS
COURSES
serno
subj
cid
sid
name
exp-grade
attributes (recall these have domains)
19
Conceptual Design Process

• What are the entities being represented?
• What are the relationships?
• What info (attributes) do we store about each?
• What keys integrity constraints do we have?

STUDENTS
Takes
name
exp-grade
sid
20
Translating Entity Sets toLogical Schemas SQL
DDL
Fairly straightforward to generate a schema
CREATE TABLE STUDENTS (sid INTEGER,
name VARCHAR(15) PRIMARY KEY (sid) )
CREATE TABLE COURSES (serno INTEGER,
subj VARCHAR(30), cid CHAR(15),
PRIMARY KEY (serno) )
21
Translating Relationship Sets

• Generate schema with attributes consisting of
• Key(s) of each associated entity (foreign keys)
• Descriptive attributes

CREATE TABLE Takes (sid INTEGER, serno
INTEGER, exp-grade CHAR(1), PRIMARY
KEY (?), FOREIGN KEY (serno) REFERENCES
COURSES, FOREIGN KEY (sid) REFERENCES
STUDENTS)
22
OK, But What about Connectivityin the E-R
Diagram?

• Attributes can only be connected to entities or
  relationships
• Entities can only be connected via relationships
• As for the edges, lets consider kinds of
  relationships and integrity constraints

Teaches
PROFESSORS
COURSES
(warning the book has a slightly different
notation here!)
23
Logical Schema Design

• Roughly speaking, each entity set or relationship
  set becomes a table (not always be the case see
  Thursday)
• Attributes associated with each entity set or
  relationship set become attributes of the
  relation the key is also copied (ditto with
  foreign keys in a relationship set)

24
Binary Relationships Participation

• Binary relationships can be classified as 11,
  1Many, or ManyMany, as in

1n
mn
11
25
1Many (1n) Relationships

• Placing an arrow in the many ? one direction,
  i.e. towards the entity thats refd via a
  foreign key
• Suppose profs teach multiple courses, but may not
  have taught yet
• Suppose profs must teach to be on the roster

Teaches
PROFESSORS
COURSES
Partial participation (0 or more)
Teaches
PROFESSORS
COURSES
Total participation (1 or more)
26
Many-to-Many Relationships

• Many-to-many relationships have no arrows on
  edges
• The relationship set relation has a key that
  includes the foreign keys, plus any other
  attributes specified as key

Takes
COURSES
STUDENTS
27
Examples

• Suppose courses must be taught to be on the
  roster
• Suppose students must have enrolled in at least
  one course

28
Representing 1n Relationships in Tables
CREATE TABLE Teaches( fid INTEGER, serno
CHAR(15), semester CHAR(4), PRIMARY KEY
(serno), FOREIGN KEY (fid) REFERENCES
PROFESSORS, FOREIGN KEY (serno) REFERENCES
Teaches)

• Key of relationship set

CREATE TABLE Teaches_Course( serno INTEGER,
subj VARCHAR(30), cid CHAR(15), fid
CHAR(15), when CHAR(4), PRIMARY KEY
(serno), FOREIGN KEY (fid) REFERENCES
PROFESSORS)
Or embed relationship in many entity set
29
11 Relationships

• If you borrow money or have credit, you might
  get
• What are the table options?

Describes
Borrower
CreditReport
ssn
rid
delinquent?
debt
name
30
Roles Labeled Edges

• Sometimes a relationship connects the same
  entity, and the entity has more than one role
• This often indicates the need for recursive
  queries

Includes
qty
Assembly
Subpart
id
Parts
name
31
DDL for Role Example
CREATE TABLE Parts (Id INTEGER, Name
CHAR(15), PRIMARY KEY (ID) ) CREATE
TABLE Includes (Assembly INTEGER,
Subpart INTEGER, Qty INTEGER,
PRIMARY KEY (Assemb, Sub), FOREIGN KEY
(Assemb) REFERENCES Parts, FOREIGN KEY (Sub)
REFERENCES Parts)
32
Roles vs. Separate Entities
Married
Husband
Wife
id
id
name
name
Married
What is the difference between these two
representations?
Husband
Wife
id
Person
name
33
ISA Relationships Subclassing(Structurally)

• Inheritance states that one entity is a special
  kind of another entity subclass should be
  member of base class

id
People
name
ISA
Employees
salary
34
But How Does this Translateinto the Relational
Model?

• Compare these options
• Two tables, disjoint tuples
• Two tables, disjoint attributes
• One table with NULLs
• Object-relational databases

35
Weak Entities

• A weak entity can only be identified uniquely
  using the primary key of another (owner) entity.
• Owner and weak entity sets in a one-to-many
  relationship set, 1 owner many weak entities
• Weak entity set must have total participation

Feeds
People
Pets
name
weeklyCost
name
species
ssn
36
Translating Weak Entity Sets

• Weak entity set and identifying relationship set
  are translated into a single table when the
  owner entity is deleted, all owned weak entities
  must also be deleted

CREATE TABLE Feed_Pets ( name VARCHAR(20),
species INTEGER, weeklyCost REAL, ssn
CHAR(11) NOT NULL, PRIMARY KEY (pname, ssn),
FOREIGN KEY (ssn) REFERENCES Employees,
ON DELETE CASCADE)
37
N-ary Relationships

• Relationship sets can relate an arbitrary number
  of entity sets

Student
Project
IndepStudy
Advisor
38
Summary of ER Diagrams

• One of the primary ways of designing logical
  schemas
• CASE tools exist built around ER (e.g. ERWin,
  PowerBuilder, etc.)
• Translate the design automatically into DDL, XML,
  UML, etc.
• Use a slightly different notation that is better
  suited to graphical displays
• Some tools support constraints beyond what ER
  diagrams can capture
• Can you get different ER diagrams from the same
  data?

39
Schema Refinement Design Theory

• ER Diagrams give us a start in logical schema
  design
• Sometimes need to refine our designs further
• Theres a system and theory for this
• Focus is on redundancy of data
• Lets briefly touch on one key concept in
  preparation for Thursdays lecture on
  normalization

40
Not All Designs are Equally Good

• Why is this a poor schema design?
• And why is this one better?

Stuff(sid, name, cid, subj, grade)
Student(sid, name) Course(cid, subj) Takes(sid,
cid, exp-grade)
41
Focus on the Bad Design

• Certain items (e.g., name) get repeated
• Some information requires that a student be
  enrolled (e.g., courses) due to the key

sid name cid subj exp-grade
1 Sam 570 AI B
23 Nitin 550 DB A
45 Jill 505 OS A
1 Sam 505 OS C
42
Functional DependenciesDescribe Key-Like
Relationships

• A key is a set of attributes where
• If keys match, then the tuples match
• A functional dependency (FD) is a generalization
• If an attribute set determines another, written A
  ! Bthen if two tuples agree on A, they must
  agree on Bsid ! Address
• What other FDs are there in this data?
• FDs are independent of our schema design choice

43
Formal Definition of FDs

• Def. Given a relation scheme R (a set of
  attributes) and subsets X,Y of R
• An instance r of R satisfies FD X ? Y if, for
  any two tuples t1, t2 2 r, t1X t2X
  implies t1Y t2Y
• For an FD to hold for scheme R, it must hold for
  every possible instance of r
• (Can a DBMS verify this? Can we determine this
  by looking at an instance?)

44
General Thoughts on Good Schemas

• We want all attributes in every tuple to be
  determined by the tuples key attributes
• What does this say about redundancy?
• But
• What about tuples that dont have keys (other
  than the entire value)?
• What about the fact that every attribute
  determines itself?
• Stay tuned for Thursday!
