Title: Chapter Twenty One


1
Chapter Twenty One
  • The p-Block Elements

2
Introduction
  • The p-block includes all the noble gases except
    helium, all the non-metals except hydrogen, all
    the metalloids, and even a few metals, including
    Al, Sn, and Pb.
  • Three of the p-block elements - O, Si, and Al -
    are the most abundant elements in Earths crust.
  • Six p-block elements - C, N, O, P, S, and Cl -
    are among the elements making up the bulk of
    living matter.
  • Five others - B, F, Si, Se, and I - are required
    in trace amounts by most plant and animal life.
  • C and S can occur in the free state.

3
The p-Block Elements
4
Properties And Trends In Group 3A
5
Properties And Trends In Group 3A
  • ns2np1 valence electron configuration
  • Boron (B) holds tightly to these valence
    electrons because of its small size. Thus, boron
    typically forms covalent compounds.
  • Aluminum (Al) readily forms 3 cations.
  • Gallium (Ga), indium (In), and thallium (Tl) all
    form 3 cationns, but also 1 cations, which are
    most stable for Tl. This is due to so - called
    inert pair on Tl.

6
Boron
  • Most of the chemistry of boron compounds is based
    on the lack of an octet of electrons about the
    central boron atom.
  • These compounds are electron deficient, and this
    deficiency causes them to exhibit some unusual
    bonding features.
  • Boron hydride (BH3) forms a coordinate covalent
    bond with another atom that has a lone pair of
    electrons to complete its octet this is called
    an adduct.
  • Diborane, B2H6, has bonding only fully explained
    by molecular orbital theory.
  • Borax, Na2B4O710H2O, a hydrated borate, is the
    primary source of boron in nature.

7
Structure Of Diborane, B2H6
three center bond
8
Aluminum
  • The most important metal of Group 3A is aluminum.
  • Pure aluminum is a malleable, ductile,
    silvery-colored metal with a density of only
    about one-third that of steel.
  • The metal is not very strong, but its strength
    increases when it is alloyed with Cu, Mg, or Si.
  • Over 5 million tons of the metal are produced per
    year in the United States
  • Most of it is used in lightweight alloys.

9
Production Of Aluminum
  • The process of isolating pure aluminum by
    electrolysis of bauxite ores is called the
    Hall-Heroult process.
  • Al(OH)4 ? Al2O3 ? Al

10
Properties And Uses Of Aluminum
  • Aluminum is a good reducing agent.
  • As an active metal, aluminum readily reacts with
    acids to produce hydrogen gas.
  • 2 Al (s) 6 H (aq) ? 2 Al3 (aq) 3 H2 (g)
  • Aluminum also dissolves in basic solutions.
  • 2 Al (s) 6 H2O (l) 2 OH- (aq) ? 2 Al(OH)4-
    (aq) 3 H2 (g)
  • Because its combustion is a highly exothermic
    reaction, powdered aluminum is used as a
    component in rocket fuels, explosives, and
    fireworks.
  • Perhaps most familiar is the use of aluminum in
    beverage cans, cookware, and as a foil for
    wrapping foods.

11
Aluminum Compounds
  • Aluminum oxide (Al2O3), also called alumina, is
    amphoteric.
  • Al2O3 (s) 6 H (aq) ? 2 Al3 (aq) 3 H2O (l)
  • Al2O3 (s) 3 H2O (l) 2 OH- (aq) ? 2
    Al(OH)4- (aq)
  • It is used in the manufacture of ceramic
    materials and is used as an abrasive for grinding
    wheels and sandpaper.
  • Among the aluminum halides, AlF3 differs
    considerably from the others in that it is the
    only one to have the properties normally
    associated with ionic substances.
  • Lithium aluminum hydride, LiAlH4, is used as a
    reducing agent in organic chemistry.
  • Aluminum sulfate is the most important industrial
    aluminum compound and is used in water treatment.

12
Bonding In Al2Cl6
13
Carbon
  • Elemental carbon exists in nature mainly as the
    two allotropes diamond and graphite
  • Newly discovered form of carbon Buckeyball, C60
  • Graphite pencils, electrodes, high-temperature
    devices, and strong graphite fibers.
  • Diamonds jewelry, industrial uses as abrasives,
    drill bits - among hardest substances known and
    high thermal conductivity
  • Carbon also exists in amorphous forms, such as
    charcoal.

14
Images from chapter 11 States of
matter Allotropes of carbon
Diamond
Graphite
15
Buckyball
Carbon Nanotubes
16
Inorganic Carbon Compounds
  • Carbon monoxide, carbon dioxide, carbonate are
    familiar oxides of carbon.
  • Carbon combines with most metals to form
    compounds called carbides.
  • Two other binary compounds of carbon are carbon
    disulfide, CS2, and carbon tetrachloride, CCl4.
  • Cyanide ion, (CN-)
  • forms an insoluble silver salt, AgCN,
  • acid, HCN, quite weak. Cyanide ion is also quite
    toxic.

17
Silicon
  • While carbon readily forms strong C-C bonds
    (rings, chains), silicon does not but it does
    form Si-O-Si containing 3-dimensional solids
  • A silicon atom, like a carbon atom, forms four
    bonds in almost all cases.
  • The most common form of naturally occurring
    silicon is silica (SiO2)n. It is a network
    covalent compound.

18
Structure of Silica, SiO2
Amorphous
19
A Two-Dimensional sheet inthe structure of Mica
20
Nitrogen
  • Nitrogen is found in greater abundance in the
    atmosphere than anywhere else.
  • There are only two important mineral sources of
    nitrogen KNO3 and NaNO3.
  • Nitrogen compounds occur in all living matter.
  • Nitrogen molecule, N2, has a very strong NN
    triple bond. Consequently it is quite unreactive
    and is used as an inert blanketing atmosphere in
    industrial operations.
  • Liquid nitrogen is used in low-temperature
    applications.
  • The only important commercial method of producing
    nitrogen is the fractional distillation of liquid
    air.

21
Fractional Distillation Of Air
22
Nitrogen Compounds
  • Nitrogen exists in compounds in all oxidation
    states -3 to 5.
  • Ammonia, NH3, is produced using the Haber
    process.
  • N2 (g) 3 H2 (g) º 2 NH3 (g) Ho -92.22 kJ
  • What are the optimum conditions for Haber
    process?
  • Urea, CO(NH2)2, is used mainly as a fertilizer.
  • Nitric acid is produced from the oxidation of
    ammonia and subsequent reaction with water.
  • Pt/Rh
  • 4 NH3 (g) 5 O2 (g) ? 4 NO (g) 6 H2O (g)
  • 2 NO (g) O2 (g) ? 2 NO2 (g)
  • 3 NO2 (g) H2O (l) ? 2 HNO3 (aq) NO (g)
  • Nitric acid is also used as an oxidizing agent.
  • The common oxides of nitrogen have oxidation
    number for N from 3 to 5.
  • Sodium azide, NaN3, is used in air-bag safety
    systems in automobiles. 2 NaN3 (s) ? 2 Na (l)
    3 N2 (g)

23
Phosphorus
  • Phosphorus is the eleventh most abundant element
    in Earths crust occurs exclusively in nature
    as phosphate PO43?
  • Elemental forms
  • White phosphorus, P4, can be cut with a knife,
    melts at 44.1 oC, is a non-conductor of
    electricity, and ignites spontaneously in air (it
    is stored under water).
  • Red phosphorus can be obtained by heating white
    phosphorus to about 300 oC in the absence of air.
    This allotrope of phosphorus forms long chains of
    phosphorus atoms joined together.

24
Molecular Structures OfWhite And Red Phosphorus
25
Compounds Of Phosphorus
  • Phosphorus forms two oxides, P4O6 and P4O10.
  • In limited O2
  • P4 (s) 3 O2 (g) ? P4O6 (s)
  • P4O6 (s) 6 H2O (l) ? 4 H3PO3 (aq)
  • phosphorous acid (diprotic)
  • In excess O2
  • P4 (s) 5 O2 (g) ? P4O10 (s)
  • P4O10 (s) 6 H2O (l) ? 4 H3PO4 (aq)
  • phosphoric acid (triprotic)
  • The oxides P4O6 and P4O10 are the acid anhydrides
    of
  • phosphorous acid and phosphoric acid,
    respectively.

26
Molecular Structures OfP4O6 And P4O10
27
Oxygen
  • Oxygen is one of the most active non-metals and
    one of the most important.
  • The chief reactions of elemental, atmospheric
    oxygen are oxidation processes.
  • Uses of oxygen include
  • manufacture of iron, other metals, welding,
    manufacture of chemicals, water treatment,
    oxidizer, and respiration therapy.
  • Ozone, O3, is a powerful oxidizing agent,
    especially in acidic solution. It is also found
    in the upper atmosphere.

28
Sulfur
  • Sulfur forms many compounds similar to those of
    oxygen. However They are differ in important
    way
  • Hydrogen bonding in O compounds, but not in S
    compounds.
  • S can employ an expanded valence shell, but O
    cannot.
  • Elemental sulfur exists as several molecular
    species
  • solid - S8 , vapor - S2
  • Elemental sulfur is mined using the Frasch
    process.
  • A small amount of sulfur is used directly in
    vulcanizing rubber and as a pesticide.
  • Sulfuric acid, H2SO4, is a strong acid and the
    sulfates, SO42-, have many important uses.
    Concentrated H2SO4 is an oxidizing agent and
    dehydrating agent.
  • Sulfur dioxide and sulfites, SO32-, are widely
    used in the food industry as decolorizing agents
    and preservatives.

29
The Frasch Process For Mining Sulfur
30
Structures Of The Sulfate And Thiosulfate Ions
thiosulfate
sulfate
31
Halogens
  • Halogens are all non-metals with ns2np5 valence
    shell electron configuration.
  • Halogen elements exist as diatomic molecules, X2.
  • Fluorine is the most reactive, iodine is the
    least. The oxidizing power decreases from F2 to
    I2.
  • Halogens occur naturally only as the halides (X)
    and are converted to halogens usually by
    electrolysis.
  • Fluorine is the strongest oxidizing agent of the
    elements, and is used to make UF6 and SF6.
  • Chlorine is used as an oxidizer and is important
    in combination with carbon compounds.
  • Bromine is a liquid at RT
  • Iodine is a sublimable solid at RT

32
(No Transcript)
33
Hydrogen Halides
  • All of the hydrogen halides are acids. All
    except HF are strong acid.
  • The hydrogen halides can be prepared by direct
    combination of the elements.
  • H2 (g) X2 (g) ? 2 HX (g)
  • In addition, they all are produced by reaction of
    an acid with a halide.

34
Oxoacids And Oxoanions Of Halogens
  • In its compounds, fluorine always has the
    oxidation number 1.
  • The other halogens, however, can have positive
    oxidation numbers 1, 3, 5, 7.
  • These oxidation numbers are found in the oxoacids
    of Cl, Br, and I.

35
(No Transcript)
36
Occurrence Of The Noble Gases
  • Except for helium and radon, the noble gases are
    found only in the atmosphere.
  • Helium is found in some natural gas deposits,
    particularly those underlying the Great Plains of
    the United States.
  • Most of the noble gases, except Ar, have escaped
    from the atmosphere since Earth was formed. Argon
    is a product of the radioactive decay of
    potassium-40, a fairly abundant naturally
    occurring isotope (0.012).

37
Summary
  • Because they only have three valence electrons,
    boron atoms tend to form electron-deficient
    compounds and this leads to some unusual bonding
    patterns.
  • Aluminum, an active metal, reacts with acids and
    strong bases.
  • Carbon is the key element in organic chemistry,
    but the free element also has uses.
  • Silicon is the key element of the mineral world.
  • Tin and lead are slightly more active than
    hydrogen, with tin (II) being a good reducer and
    lead (IV) a good oxidizer.

38
Summary
  • Some of the nitrogen compounds described in the
    chapter are ammonia, urea, nitric acid, ammonium
    salts, hydrazine, and hydrazoic acids and azides.
  • Oxygen forms compounds with all elements except
    the lighter noble gases. Ozone is an allotropic
    form of oxygen.
  • The halogens are non-metals and occur naturally
    only as the halides.
  • Interest in the noble gases centers on their
    physical properties and inertness.
Write a Comment
User Comments (0)
About PowerShow.com
