EOS 840 Hyperspectral Imaging Applications

1
EOS 840 Hyperspectral Imaging Applications
October 13, 2004 Week 7
Ron Resmini v 703-735-3899 ronald.g.resmini_at_boein
g.com Office hours by appointment
2
Outline

• Spectral libraries
• Reading for next week
• Review/context/a thread...
• Thinking about spectra (a review)
• Algorithms
• My semester project status
• Your semester project status

3
Review/Context/A Thread...

• HSI RS is based on the measurement of a physical
  quantityas a function of wavelength its
  spectroscopy
• HSI is based on discerning/measuring the
  interaction oflight (photons, waves) with matter
• The sun is the source or active systems or very
  hot objects
• Earth RS scenarios involve the atmosphere
• There are complex interactions in the atmosphere
• There are complex interactions between light and
  targetsof interest in a scene
• There are complex interactions between light,
  targets ofinterest, and the atmosphere
• Theres a lot (lots!) of information in the
  spectra

4
(No Transcript)
5

• Spectral parameterization
• Albedo/brightness
• Band depth
• Band width
• Band shape/superimposed features
• Spectral slope
• Spectral indices
• Derivative spectroscopy
• Wavelet transform
• Combinations
• Pre-processing transforms e.g., SSA
• All must have a physical basis!
• Tie all observations to physical reality!!

6

• Collections of spectra in hyperspace
• Resmini (2003)
• Density
• Volume
• Orientation
• Clustering/ of clusters/cluster spacing
• Mixing trends (binary, ternary, linear,
  non-linear)
• Eigenvectors/eigenvalues
• etc...
• Still vastly uncharted territory with lots of
  potential for understanding HSI...imho

7
Algorithms
8

• Algorithm "classes"/overview
• Distance Metrics
• Angular Metric
• SMA/OSP/DSR/CEM
• Derivative Spectroscopy/other Parameterization
  Methods
• Spectra in hyperspace
• Some real scatter plots
• Use ENVI to view scatter plots

9

• Real data show very complicatedscatter plots
• blobs, elongated blobs, etc...
• binary, ternary mixing trends
• Radiance, reflectance, emissivity
• which to use? when?

10

• Whole pixel/single-pixel, non-statistical
  distance metrics
• Distance between points (spectra) in hyperspace
• Spectra as vectors
• Absolute difference/absolute difference squared
• Derivative difference/derivative difference
  squared
• Euclidean distance
• Relative difference
• BE/Hamming distance (see Jia and Richards, 1999)
• There are others, too...
• ENVI...
• Application strategies (i.e., in-scene
  spectra/library spectra)
• Mixed pixels...

11

• Spectra as vectors
• Angular separation of vectors (spectra)
• Spectral Angle Mapper (SAM)
• Invariant to albedo
• Running SAM in ENVI
• Application strategies(i.e., in-scene
  spectra/library spectra)
• Mixed pixels...

12

• Statistical distance metrics
• (essentially preprocessing for supervisedclassifi
  cation)
• Minimum distance
• Mahalanobis distance
• Maximum likelihood distance
• Parallelpiped
• Jeffries-Matusita distance/Bhattacharyya distance
• Spectral divergence (see sec. 10.2.2 of Richards
  and Jia, 1999)
• Other...
• Application strategies (i.e., in-scene spectra)
• Mixed pixels...

13
Minimum Distance
Mahalanobis Distance
Maximum Likelihood
14
Jeffries-Matusita (JM) Distance
...the distance between a pair of probability
distributions is... from p. 244 of Richards and
Jia (1999)
Where B is the Bhattacharyya distance
See sec. 10.2.3 of Richards and Jia (1999).
15

• The mixed pixel
• Building a mixed pixel - ENVI, MS Excel
• Linear spectral mixture analysis
• Determining quantity of material
• Endmember selection
• Manual
• Convex hull
• Pixel-Purity Index (PPI)
• Adaptive/updating/pruning...
• Other (e.g., N-FINDR, ORASIS, URSSA, etc...)
• Wild outliers

16

• Spectral mixture analysis
• applications
• scene characterization
• material mapping
• anomaly detection
• other...

17
A linear equation...
x
A
b
5 endmembers in a 7-band spectral data set
18

• Unmixing inversion
• Interpretation of results
• RMS, RSS, algebraic and geometricinterpretations
  (pg. 155 of Strang, 1988)
• Band residual cube
• Iterative process
• Fraction-plane color-composites
• Change detection with fraction planes
• Inversion constraints?...
• Application strategies (i.e., in-scenespectra/lib
  rary spectra)

19

• application strategies (continued)
• directed search? anomaly detection?
• Shade/shadow
• shade endmember
• shade removal
• Other...
• objective endmember determinationTompkins et al.

20

• Is the mixing linear?
• Non-linear spectral mixture analysis
• Checker-board mixtures
• Intimate mixtures
• Spectral transformations (e.g., SSA)and use of
  ENVI

21
...Recap Where have we been? Where are we
going? BTW...Always do the math!

• More on the statistical characterizationof
  multi-dimensional data
• Covariance matrices
• Eigenvectors of the covariance matrix
• Geometric interpretation
• Half-way to PCA...
• Statistics with ENVI

22

• Orthogonal Subspace Projection (OSP)
• Derivation in detail (next several slides...)
• Application of the filter
• Endmembers
• Statistics
• Interpretation of results
• OSP w/endmembers unconstrained SMA
• Different ways to apply the filter/application
  strategies(i.e., in-scene spectra/library
  spectra)

23
OSP/LPD/DSR Scene-Derived Endmembers
(Harsanyi et al., 1994)
24
(No Transcript)
25
(No Transcript)
26
The value of xT which maximizes l is given by xT
dT
This is equivalent to Unconstrained SMA
27
Statistical Characterization of the
Background (LPD/DSR)
(Harsanyi et al., 1994)
28
(No Transcript)
29
Constrained Energy Minimization (CEM)

• The description of CEM is similar to that of
  OSP/DSR (previous slides)
• Like OSP and DSR, CEM is an Orthogonal Subspace
  Projection (OSP)family algorithm
• CEM differs from OSP/DSR in the following,
  important ways
• CEM does not simply project away the first n
  eigenvectors
• The CEM operator is built using a weighted
  combination of theeigenvectors (all or a subset)
• Though an OSP algorithm, the structure of CEM is
  equally readily observed bya formal derivation
  using a Lagrange multiplier

• CEM is a commonly used statistical spectral
  matched filter
• CEM for spectral remote sensing has been
  published on for over 10 years
• CEM has a much longer history in the
  multi-dimensional/array signalprocessing
  literature
• Just about all HSI tools today contain CEM or a
  variant of CEM
• If an algorithm is using M-1d as the heart of its
  filter kernel (where M is thedata covariance
  matrix and d is the spectrum of the target of
  interest), thenthat algorithm is simply a CEM
  variant

30

• The statistical spectral matched filter (SSMF)
• Derivation in detail
• Application of the filter
• Statistics
• Endmembers (FBA/MCEM)
• Interpretation of results
• Many algorithms are actually the basic SSMF
• Different ways to apply the filter/application
  strategies(i.e., in-scene spectra/library
  spectra)
• Matched filter in ENVI

31
Derivation taken from
Stocker, A.D., Reed, I.S., and Yu, X., (1990).
Multi-dimensional signal processing for
electro-Optical target detection. In Signal
and Data Processing of Small Targets 1990,
Proceedingsof the SPIE, v. 1305, pp. 218-231.
J of Bands
Form the log-likelihood ratio test of Hº and H1
32
Some algebra...
33
A trick...recast as a univariable problem
After lots of simple algebra applied to the r.h.s
Now, go back to matrix-vector notation
34
Take the natural log
35
Constrained Energy Minimization (CEM)
(Harsanyi et al., 1994)
36
(No Transcript)
37
An Endnote...

• Previous techniques exploit shape and albedo
• this can cause problems...
• Sub-classes of algorithms developed to mitigate
  this
• shape, only, operators
• MED, RSD of ASIT, Inc.
• MTMF of ENVI

38
Last Class of Algorithms

• Spectral feature fitting/derivativespectroscopy
• Spectral parameterizations
• Wavelets
• Band depth/band depth mapping
• Application strategies (i.e., in-scenespectra/lib
  rary spectra)
• Mixed pixels...

39
Another Endnote...

• Performance prediction/scoring/NP-Theory, etc...
• Hybrid techniques
• still some cream to be skimmed...
• Caveat emptor...
• lots of reproduction of work already accomplished
• who invented what? when?
• waste of resources
• please do your homework!read the lit.!

40
My Semester Project Status

• Tools/approach
• 1D and 2D analytical solutions to heat equation
• FlexPDE finite element modeling
• Data analysis with ENVI
• Analytical solutions to 1D and 2D heat equation
• Additional TIMS data analysis in ENVI
• TES on going (this is a challenge)
• Literature research on-going
• Additional modeling with FlexPDE
• Dealing with (as yet) unconstrained parameters

41
Surface Temperature vs. Lava Tube Roof Thickness
Tenviron 0º C TLava 1200º C
42
Numerical 2D Modeling
43
(No Transcript)
44
Analytical solution to
On the following
(Tenviron 0º C)
Y 0
Radiative boundary condition added
Y D
45
The Solution
and
D Lava tube roof thickness
Solve with a root-finding algorithm
46
Another Approach...
47
X0
XL
Y0

YD
X0
XL
Y0
Y0

YD
YD
48
The Solution
Technique Principle of superposition and
separation of variables
Evaluate the boundary condition at y D
Evaluate the coefficients
49
(No Transcript)
50
The B.C. at Y D
At y D
51
My Semester Project Issues

• Constraining the value of h
• What should the diameter of the lava tube be?
• Distinguishing sky lights from unbroken tube roof
• Widely ranging surface temperatures in the data
• Validity of B.C.s used in modeling
• Radiative upper B.C.?
• Mapping/contouring roof thickness throughoutthe
  entire TIMS Kilauea scene
• Need to double-check my math!
• Other...

52
Your Semester Project Status
A Few More Project Challenges For You

• A matched filter algorithm based on a
  distribution other than normal
• Compare the technique of sec. 13.5.2 in textbook
  with a spectralmixture analysis approach to data
  classification
• Can/should the technique of 13.5.2 be used to
  build an adaptivespectral matched filter
  algorithm?
• Implant signatures in HSI cubes with ENVI. Run
  algorithms to findthe signatures record
  results. Remove one or more bands andrepeat.
  Is there a Hughes Phenomenon?
• Compare various lossy compression algorithms for
  tolerable limitsof information loss
• Compare exploitation based on log residuals with
  exploitationbased on ELM or other atmospheric
  compensation

53
Backup Slides
54
Lagrange Multiplier Derivation of CEM Filter
Minimizing E is equivalent to minimizing each yi2
(for k 1, 2, 3, ... )
55
In Matrix Notation
56
(No Transcript)
