Proteomic Characterization of Alternative
Splicing and Coding Polymorphism

• Nathan Edwards
• Center for Bioinformatics and Computational
  Biology
• University of Maryland, College Park

2
Mass Spectrometry for Proteomics

• Measure mass of many (bio)molecules
  simultaneously
• High bandwidth
• Mass is an intrinsic property of all
  (bio)molecules
• No prior knowledge required

3
Mass Spectrometry for Proteomics

• Measure mass of many molecules simultaneously
• ...but not too many, abundance bias
• Mass is an intrinsic property of all
  (bio)molecules
• ...but need a reference to compare to

4
High Bandwidth
5
Mass is fundamental!
6
Mass Spectrometry for Proteomics

• Mass spectrometry has been around since the turn
  of the century...
• ...why is MS based Proteomics so new?
• Ionization methods
• MALDI, Electrospray
• Protein chemistry automation
• Chromatography, Gels, Computers
• Protein sequence databases
• A reference for comparison

7
Sample Preparation for Peptide Identification
8
Single Stage MS
MS
m/z
9
Tandem Mass Spectrometry(MS/MS)
m/z
Precursor selection
m/z
10
Tandem Mass Spectrometry(MS/MS)
Precursor selection collision induced
dissociation (CID)
m/z
MS/MS
m/z
11
Peptide Identification

• For each (likely) peptide sequence
• 1. Compute fragment masses
• 2. Compare with spectrum
• 3. Retain those that match well
• Peptide sequences from protein sequence databases
• Swiss-Prot, IPI, NCBIs nr, ...
• Automated, high-throughput peptide identification
  in complex mixtures

12
Why dont we see more novel peptides?

• Tandem mass spectrometry doesnt discriminate
  against novel peptides......but protein
  sequence databases do!
• Searching traditional protein sequence databases
  biases the results towards well-understood
  protein isoforms!

13
What goes missing?

• Known coding SNPs
• Novel coding mutations
• Alternative splicing isoforms
• Alternative translation start-sites
• Microexons
• Alternative translation frames

14
Why should we care?

• Alternative splicing is the norm!
• Only 20-25K human genes
• Each gene makes many proteins
• Proteins have clinical implications
• Biomarker discovery
• Evidence for SNPs and alternative splicing stops
  with transcription
• Genomic assays, ESTs, mRNA sequence.
• Little hard evidence for translation start site

15
Novel Splice Isoform

• Human Jurkat leukemia cell-line
• Lipid-raft extraction protocol, targeting T cells
• von Haller, et al. MCP 2003.
• LIME1 gene
• LCK interacting transmembrane adaptor 1
• LCK gene
• Leukocyte-specific protein tyrosine kinase
• Proto-oncogene
• Chromosomal aberration involving LCK in
  leukemias.
• Multiple significant peptide identifications

16
Novel Splice Isoform
17
Novel Splice Isoform
18
Novel Frame
19
Novel Frame
20
Novel Mutation

• HUPO Plasma Proteome Project
• Pooled samples from 10 male 10 female healthy
  Chinese subjects
• Plasma/EDTA sample protocol
• Li, et al. Proteomics 2005. (Lab 29)
• TTR gene
• Transthyretin (pre-albumin)
• Defects in TTR are a cause of amyloidosis.
• Familial amyloidotic polyneuropathy
• late-onset, dominant inheritance

21
Novel Mutation
Ala2?Pro associated with familial amyloid
polyneuropathy
22
Novel Mutation
23
Searching ESTs

• Proposed long ago
• Yates, Eng, and McCormack Anal Chem, 95.
• Now
• Protein sequences are sufficient for protein
  identification
• Computationally expensive/infeasible
• Difficult to interpret
• Make EST searching feasible for routine searching
  to discover novel peptides.

24
Searching Expressed Sequence Tags (ESTs)

• Pros
• No introns!
• Primary splicing evidence for annotation
  pipelines
• Evidence for dbSNP
• Often derived from clinical cancer samples

• Cons
• No frame
• Large (8Gb)
• Untrusted by annotation pipelines
• Highly redundant
• Nucleotide error rate 1

25
Compressed EST Peptide Sequence Database

• For all ESTs mapped to a UniGene gene
• Six-frame translation
• Eliminate ORFs lt 30 amino-acids
• Eliminate amino-acid 30-mers observed once
• Compress to C2 FASTA database
• Complete, Correct for amino-acid 30-mers
• Gene-centric peptide sequence database
• Size lt 3 of naïve enumeration, 20774 FASTA
  entries
• Running time 1 of naïve enumeration search
• E-values 2 of naïve enumeration search results

26
Compressed EST Peptide Sequence Database

• For all ESTs mapped to a UniGene gene
• Six-frame translation
• Eliminate ORFs lt 30 amino-acids
• Eliminate amino-acid 30-mers observed once
• Compress to C2 FASTA database
• Complete, Correct for amino-acid 30-mers
• Gene-centric peptide sequence database
• Size lt 3 of naïve enumeration, 20774 FASTA
  entries
• Running time 1 of naïve enumeration search
• E-values 2 of naïve enumeration search results

27
SBH-graph
ACDEFGI, ACDEFACG, DEFGEFGI
28
Compressed SBH-graph
ACDEFGI, ACDEFACG, DEFGEFGI
29
Sequence Databases CSBH-graphs

• Original sequences correspond to paths

ACDEFGI, ACDEFACG, DEFGEFGI
30
Sequence Databases CSBH-graphs

• All k-mers represented by an edge have the same
  count

1
2
2
1
2
31
cSBH-graphs

• Quickly determine those that occur twice

2
2
1
2
32
Correct, Complete, Compact (C3) Enumeration

• Set of paths that use each edge exactly once

ACDEFGEFGI, DEFACG
33
Correct, Complete (C2) Enumeration

• Set of paths that use each edge at least once

ACDEFGEFGI, DEFACG
34
Patching the CSBH-graph

• Use artificial edges to fix unbalanced nodes

35
Compressed EST Database

• Gene centric compressed EST peptide sequence
  database
• 20,774 sequence entries
• 8Gb vs 223 Mb
• 35 fold compression
• 22 hours becomes 15 minutes
• E-values improve by similar factor!
• Makes routine EST searching feasible
• Search ESTs instead of IPI?

36
Novel Peptide Computational Infrastructure

• Binaries (C)
• cSBH-graph construction
• Condor grid-enabled
• Eulerian path k-mer enumeration
• Suitable for large graphs
• Data-model for peptide identification
• Spectra (gt5 million)
• Peptide identifications
• Mascot, SEQUEST, X!Tandem, NIST
• Genomic context of peptides

37
Novel Peptide Computational Infrastructure

• Condor grid-enabled MS/MS search
• Mascot, X!Tandem, (Inspect, OMSSA)
• TurboGears python web-stack
• SQLObject Object-Relational-Manager
• MVC web-application framework
• Suitable for AJAX web-services too
• Integration with UCSC genome browser
• caBIG compatible web-services
• Java applet for viewing spectra

38
Peptide Identification Navigator
39
Peptide Identification Navigator
40
Spectrum Viewer
41
Spectrum Viewer
42
Back to the lab...

• Current LC/MS/MS workflows identify a few
  peptides per protein
• ...not sufficient for protein isoforms
• Need to raise the sequence coverage to (say) 80
• ...protein separation prior to LC/MS/MS analysis
• Potential for database of splice sites of
  (functional) proteins!

43
Microorganism Identification by MALDI Mass
Spectrometry

• Direct observation of microorganism biomarkers in
  the field.
• Peaks represent masses of abundant proteins.
• Statistical models assess identification
  significance.

B.anthracisspores
MALDI Mass Spectrometry
44
Key Principles

• Protein mass from protein sequence
• No introns, few PTMs
• Specificity of single mass is very weak
• Statistical significance from many peaks
• Not all proteins are equally likely to be
  observed
• Ribosomal proteins, SASPs

45
Rapid Microorganism Identification Database
(www.RMIDb.org)

• Protein Sequences
• 8.1M (2.9M)
• Species
• 18K
• Genbank,
• Microbial, Virus, Plasmid
• RefSeq
• CMR,
• Swiss-Prot
• TrEMBL

46
Rapid Microorganism Identification Database
(www.RMIDb.org)
47
Informatics Issues

• Need good species / strain annotation
• B.anthracis vs B.thuringiensis
• Need correct protein sequence
• B.anthracis Sterne a/ß SASP
• RefSeq/Gb MVMARN... (7442 Da)
• CMR MARN... (7211 Da)
• Need chemistry based protein classification

48
Conclusions

• Proteomics can inform genome annotation
• Eukaryotic and prokaryotic
• Functional vs silencing variants
• Peptides identify more than just proteins
• Untapped source of disease biomarkers
• Compressed peptide sequence databases make
  routine EST searching feasible

49
Future Research Directions

• Identification of protein isoforms
• Optimize proteomics workflow for isoform
  detection
• Identify splice variants in cancer cell-lines
  (MCF-7) and clinical brain tumor samples
• Aggressive peptide sequence enumeration
• dbPep for genomic annotation
• Open, flexible informatics infrastructure for
  peptide identification

50
Future Research Directions

• Proteomics for Microorganism Identification
• Specificity of tandem mass spectra
• Revamp RMIDb prototype
• Incorporate spectral matching
• Primer design
• k-mer sets as FASTA sequence databases
• Uniqueness oracle for exact and inexact match
• Integration with Primer3
• Tiling, multiplexing, pooling, tag arrays

51
Acknowledgements

• Chau-Wen Tseng, Xue Wu
• UMCP Computer Science
• Catherine Fenselau, Steve Swatkoski
• UMCP Biochemistry
• Calibrant Biosystems
• PeptideAtlas, HUPO PPP, X!Tandem
• Funding National Cancer Institute
