Approaches to Modeling and Learning User Preferences

1
Approaches to Modeling and Learning User
Preferences

• Marie desJardins
• University of Maryland Baltimore County
• Presented at SRI International AI Center
• March 10, 2008
• Joint work with Fusun Yaman, Michael Littman, and
  Kiri Wagstaff

2
Overview

• Representing Preferences
• Learning Planning Preferences
• Preferences over Sets
• Directions / Conclusions

3

• Representing Preferences

4
What is a Preference?

• (Partial) ordering over outcomes
• Feature vector representation of outcomes (aka
  objects)
• Example Taking a vacation. Features
• Who (alone / family)
• Where (Orlando / Paris)
• Flight type (nonstop / onestop / multistop )
• Cost (low / medium / high)
• Languages
• Weighted utility function
• CP-net
• Lexicographic ordering

5
Weighted Utility Functions

• Each value vij of feature fi has an associated
  utility uij
• Utility Uj of object oj ltv1j, v2j, , vkjgt
• Uj ?i wj uij
• Commonly used in preference elicitation
• Easy to model
• Independence of features is convenient
• Flight example
• U(flight) .8u(Who) .8u(Cost).6u(Where)
  .4u(Flight Type)

6
CP-Nets

• Conditional Preference Network
• Intuitive, graphical representation of
  conditional preferences under a ceteris paribus
  (all-else-being equal) assumption

I prefer to take a vacation with my family,
rather than going alone If I am with my family, I
prefer Orlando to Paris If I am alone, I prefer
Paris to Orlando
who
family gt alone
family Orlando gt Paris alone Paris gt Orlando
where
7
Induced Preference Graph

• Every CP-net induces a preference graph on
  outcomes
• The partial ordering of outcomes is given by the
  transitive closure of the preference graph

alone ? Orlando
who
family gt alone
alone ? Paris
family Orlando gt Paris alone Paris gtOrlando
family ? Paris
where
family ? Orlando
8
Lexicographic Orderings

• Features are prioritized with a total ordering
  f1, , fk
• Each value of each feature is prioritized with a
  total ordering, vi1vim
• To compare o1 and o2
• Find the first feature in the feature ordering on
  which o1 and o2 differ
• Choose the outcome with the preferred value for
  that feature
• Travel example
• Who gt Where gt Cost gt Where gt Flight-Type gt
• Family gt Alone
• Orlando gt Florida
• Cheap gt Expensive

9
Representation Tradeoffs

• Each representation has some limitations
• Additive utility functions cant capture
  conditional preferences, and cant easily
  represent hard constraints or preferences
• CP-nets, in general, only give a partial
  ordering, cant model integer/real features
  easily, and cant capture tradeoffs
• Lexicographic preferences cant capture
  tradeoffs, and cant represent conditional
  preferences

10

• Learning Planning Preferences

11
Planning Algorithms

• Domain-independent
• Inputs initial state, goal state, possible
  actions
• Domain-independent but not efficient
• Domain-specific
• Works for only one domain
• (Near-) optimal reasoning
• Very fast
• Domain-configurable
• Use additional planning knowledge to customize
  the search automatically
• Broadly applicable and efficient

12
Domain Knowledge for Planning

• Provide search control information
• Hierarchy of abstract actions (HTN operators)
• Logical formulas (e.g., temporal logic)
• Experts must provide planning knowledge
• May not be readily available
• Difficult to express knowledge declaratively

13
Learning Planning Knowledge

• Alternative Learn planning knowledge by
  observation (i.e., from example plans)
• Possibly even learn from a single complex example
• DARPAs Integrated Learning Program
• Our focus Learn preferences at various decision
  points
• Charming Hybrid Adaptive Ranking Model
• Currently Learns preferences over variable
  bindings
• Future Learn goal and operator preferences

14
HTN Hierarchical Task Network

• Objectives are specified as high-level tasks to
  be accomplished
• Methods describe how high-level tasks are
  decomposed down to primitive tasks

travel(X,Y)
travel(X,Y)
short-distance travel
payDriver
rideTaxi(X,Y)
getTaxi(X)
travel(X,Y)
High-level tasks
long-distance travel
HTN operators
Primitive actions
travel(Ay,Y)
buyTicket(Ax,Ay)
fly(Ax,Ay)
travel(X,Ax)
15
CHARM Charming Hybrid Adaptive Ranking Model

• Learns preferences in HTN methods
• Which objects to choose when using a particular
  method?
• Which flight to take? Which airport to choose?
• Which goal to select next during planning?
• Which method to choose to achieve a task?
• By plane or by train?
• Preferences are expressed as lexicographic
  orderings
• A natural choice for many (not all) planning
  domains

16
Summary of CHARM

• CHARM learns a preference rule for each method.
• Given an HTN, initial state, and the plan tree
• Find an ordering on variable values for each
  decision point (planning context)
• CHARM has two modes
• Gather training data for each method
• Orlando (tropical, family-oriented, expensive)
  is preferred to Boise (cold,
  outdoors-oriented, cheap)
• Learn preference rule in each method

17
Preference Rules

• A preference rule is a function that returns lt,
  , or gt, given two objects represented as vectors
  of attributes.
• Assumption Preference rules are lexicographic
• For every attribute there is a preferred value
• There is a total order on the attributes
  representing the order of importance
• A warm destination is preferred to a cold one.
  Among destinations of the same climate, an
  inexpensive one is better than an expensive one.

18
Learning Lexicographic Preference Models

• Existing algorithms return one of many models
  consistent with the data
• The worst case performance of such algorithms is
  worse than random selection
• Higher probability of poor performance if there
  are fewer training observations
• A novel democratic approach Variable Voting
• Sample the possible consistent models
• Implicit sampling models that satisfy certain
  properties are permitted to vote
• Preference decision is based on the majority of
  votes

19
Variable Voting

• Given a partial order, lt, on the attributes and
  two objects, A and B
• D attributes that are different in A and B
• D most salient attributes in D with respect to
  lt
• The object with the largest number of preferred
  values for the attributes in D is the preferred
  object

X1 X2 X3 X4 X5
A 1 0 1 0 0
B 0 0 1 1 1
20
Learning Variable Ranks

• Initially, all attributes are equally important
• Loop until ranks converge
• Given two objects, predict a winner using the
  current beliefs
• If the prediction was wrong, decrease the
  importance of the attribute values that led to
  the wrong prediction
• The importance of an attribute never goes beyond
  its actual place in the order of attributes
• Mistake bounds algorithm, learns from its
  mistakes
• Mistake bound is O( n2 ), where n is the number
  of attributes

21
Democracy vs. Autocracy
VariableVoting
22

• Preferences Over Sets

23
Preferences over Sets

• Subset selection applications
• Remote sensing, sports teams, music playlists,
  planning
• Ranking, like a search engine?
• Doesnt capture dependencies between items
• Encode, apply, learn set-based preferences

24
User Preferences

• Depth utility function (desirable values)
• Diversity variety and coverage
• Geologist near far views (context)

25
Encoding User Preferences

• DD-PREF a language for expressing preferred
  depth and diversity, for sets

Diversity
Depth
or
?
26
Finding the Best Subset

• Maximize
• where

subset valuation
utility of subset s
Depth
diversity value of s
Diversity
27
Learning Preferences from Examples

• Hard for users to specify quantitative values
  (especially with more general quality functions)
• Instead, adopt a machine learning approach
• Users provide example sets with high valuation
• System infers
• Utility functions
• Desired diversity
• Feature weights
• Once trained, the system can select subsets of
  new data (blocks, images, songs, food)

28
Learning a Preference Model

• Depth utility functions
• Probability density estimation KDE (kernel
  density estimation) Duda et al., 01
• Diversity average of observed diversities
• Feature weights minimize difference between
  computed valuation and true valuation
• BFGS bounded optimization Gill et al., 81

29
Results Blocks World

• Compute valuation of sets chosen by true
  preference, learned preference, and random
  selection
• As more training sets are available, performance
  increases (learned approximates true)

Mosaic
Tower
30
Rover Image Experiments

• Methodology
• Six users 2 geologists, 4 computer scientists
• Five sets of 20 images each
• Each user selects a subset of 5 images from each
  set
• Evaluation
• Learn preferences on (up to 4) examples,select a
  new subset from a held-out set
• Metrics
• Valuation of the selected subset
• Functional similarity between learned preferences

31
Learned Preferences
Subset of 5 images, chosen by a geologist, from
20 total
Learned feature weights Learned feature weights
Rock 0.3
Soil 0.1
Sky 1.0
Learned diversities Learned diversities
Rock 0.8
Soil 0.9
Sky 0.5
32
Subset Selection
Subset of 5 images, chosen by a geologist, from
20 total
5 images chosen from 20 images, using greedy
DD-Select and learned prefs
5 images chosen by the same geologist from the
same 20 new images
33
Current Work

• Extending to document data
• Text (discrete) features
• Menu World Chinese restaurant dish selection
• How do you combine multiple preferences with
  different priorities?
• Rover dust devils, carbonate rocks,
  cross-bedding
• Priorities that can change over time

34

• Future Directions

35
Future Directions

• Hybrid preference representation
• Decision tree with lexicographic orderings at the
  leaves
• Permits conditional preferences
• How to learn the splits in the tree?
• Support operator, goal orderings for planning
• Incorporate concept of set-based preferences into
  planning domains

Questions?
