Title: Fundamental Design Tools


1
Fundamental Design Tools
An intro to several techniques used
  • Chapter 2

2
Brainstorming
  • Five to fifteen individuals
  • Discussion leader restates problem and reiterates
    rules of discussion
  • Individuals suggest ideas
  • Evaluate ideas at conclusion of discussion
  • Useful for new ideas / deadlock
  • Drawback relies on willingness to speak up

3
Class Design Problem
  • Ear Wax

An example brainstorming exercise -
4
Grade in Design? (Concept Map)
5
Six individuals
  • Useful in systematic approach and large numbers
    of ideas
  • Drawback isolation, no group synergy

6
Delphi Model
Resultant response list is reordered and evaluated
  • Expert panel generates starting points

Suggestions are regrouped and returned to
panelists
Polling process
Useful in situations where future of process is
of concern
Drawback relies on high response rate
7
  • Problem is presented to a small group
  • Group familiarizes itself with the problem

Synetics
  • Also utilizes variations such as randomly
    choosing words from a dictionary and forcing a
    fit
  • Analogies of terms are examined and relationships
    forced
  • Useful when problem to be solved has an analogy
    and group is willing to explore bizarre trains of
    thought

8
Class Design Example
  • Right to left heart shunt that needs to be closed
    minimally invasive technology.
  • When doing catheterization, need to go with the
    flow
  • Cannon droops when rapidly fired.
  • Need to get a ladder through a small space and up
    in an alleyway.

9
Web-based and Print Literature
  • Web-based search engines
  • www.amazon.com search for recent books
  • www.uspto.gov search for granted
    or pending patents
  • Trade magazines web sites, especially
    www.cancom.com
  • And www.google.com (or scholar.google.com),
    search for topics

10
Process Charts Symbols
Operations
Inspection
Transportation
Delay
Storage
See http//vubme.vuse.vanderbilt.edu/King/powerpoi
nt_slide_shows_for_cours.htm for a process
diagram package -
11
Process Chart
12
Apply Band Aid!!!!!!!!!!
13

Flowcharting

Activity
Start or end
Decision
Yes
D
No
14
Flowcharting
  • Assists in understanding processes to modify or
    improve them.
  • Broad range of charts- from simple process charts
    to fairly complicated combinations of signal,
    material, and information flows.
  • Dr. King at the doctor
  • Flowcharting Overview

15
Clinic Flow Charts

Linear system-Each event must be complete prior
to the next beginning
16
Flowcharts with Decision Points
17
Decisions Selection Chart
18
Selection Matrix Writes in a damp environment
(School)
Choice Choice Choice Choice
Demand Fountain Pen Pencil Chalk Marker
1. Writes on paper ?
2. Wont stain hands - -
3. Damp paper tolerant ? ? ?
Summary no go go recheck no go
19
Evaluation Chart
Daddy Warbucks goes New York to Rome
Commercial airline Commercial airline Ocean Liner Ocean Liner
wish weight value product value Product
High speed 3 5 15 2 6
Convenience 5 4 20 5 25
Comfort 5 3 15 5 25
Low cost 2 2 4 3 6
Food Drink 5 1 5 5 25
Total 59 87
20
Objective Tree Why go to college?
21
Quality Function Deployment Diagrams (QFD)
22
(No Transcript)
23
Example Student Work
24
TRIZ
  • Russian acronym based upon series of papers on
    the theory of inventive problem solving
  • Method of reducing design process to a
    step-by-step procedure
  • As difficulty increases, number of solution
    increases
  • Different themes of transition have finite
    variations
  • Negative interactions between desired functions

25
TRIZ - Basic
  • ID Problem
  • Restate to elaborate contradictions
  • Search for previously well solved problem
  • Search for analogous solutions

26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
