DATA MODELLING CONCEPTS

1
COMP 332PRINCIPLES OFDATABASE DESIGN

• DATA MODELLING CONCEPTS

2
DATA MODELLING CONCEPTS OUTLINE

• Data Modelling
• Models and Databases
• Abstraction
• Entity-relationship Model
• Entities
• Attributes
• Generalization
• Relationships
• Constraints
• Aggregation

3
WHY DO WE BUILD MODELS? BCN 2

• Test a physical entity before building it
• Why is this important?
• Communicate with customers
• Why is this important?
• Visualize the final product
• Why is this important?
• Reduce the complexity of a problem
• Why is this important?

4
DATA MODELLING FOR A DATABASE
Disk bits, bytes, etc.
Files records, fields, etc.
LogicalModel relations, attributes
concrete
abstract

• need to consider two aspects of modelling
• data organization data access

5
DATA MODELS AND DATA MODELLING BCN 2.3

• model an abstraction that hides unnecessary
  details, emphasizes important details
• data model an abstraction of data
• data modelling the process of describing some
  part of the world using a data model

• A data model consists of
• data structure types specifies data
  organization
• integrity constraints restricts valid data
  organization
• operations specifies data access

A data model is a tool used to specify
theconceptual / logical organization of data
6
ABSTRACTION IN DATA MODELLING BCN 2.1

• mental process of selecting some characteristics
  and properties and excluding others that are not
  relevant

- name, address, sex, hobbies, ...

• abstraction is always for some purpose
• many different abstractions of the same thing are
  possible
• all abstractions are incomplete descriptions of
  reality

• We do not need completeness, just modelling
  adequacy!

7
QUESTION?
If you had to describe a person as an employee of
a company, what is the most relevant information
would you include?

• information about trips taken.
• information about hobbies.
• information about boy/girl friends.
• salary information.
• telephone billing information.
• information about grades.

8
QUESTION?
If you had to describe a person as a student of
HKUST, what is the most relevant information
would you include?

• information about trips taken.
• information about hobbies.
• information about boy/girl friends.
• salary information.
• telephone billing information.
• information about grades.

9
TYPES OF ABSTRACTIONS

• classification group similar instances of things

IS_MEMBER_OF
IS_MEMBER_OF
Michael Chang
Martina Hingas
San San
Anson Chan
Pete Sampras

• pick out common properties and ignore unique
  properties

10
TYPES OF ABSTRACTIONS

• aggregation group dissimilar sets of things

IS_PART_OF
account
type
balance
branch

• ignore differences among the parts and
  concentrateon the fact that they form the whole

11
TYPES OF ABSTRACTIONS

• generalization group similar sets of things
• superclass, subclass / supertype, subtype

Vehicle
IS_A
Truck
Bus
Van
Car

• note difference between classification and
  generalization
• classification applied to individual instances
  of things
• generalization applied to sets of things

12
TYPES OF ABSTRACTIONS (contd)

• Note we can combine different types of
  abstraction when modeling

student
generalization
undergrad
classification
John
. . .
Sam
Tina
aggregation
. . .
name
student id
13
ER MODEL ENTITY INSTANCE 2.1.1

• a concept, abstraction, or thing with crisp
  boundaries and meaning for the problem at hand

• Has identity existence is not dependent on its
  properties
• (does a persons name give the person
  existence?)
• Entity instance purpose
• promote understanding of the real world
• provide a practical basis for implementation
• How to identify/select entity instances?
• There is often no one correct representation
  for a given problem!
• The nature of the problem and experience
  important in selecting.

14
ER MODEL ENTITY (TYPE) 2.1.1

• a description of a set of entity instances that
  have common
• properties relationships - semantics

. . .
Beethoven
Brahms
Bach
15
ER MODEL ENTITY (contd)

• often appear as nouns in problem descriptions
• instances of an entity share a common semantic
  purpose

Why entities?
How are entities, entity instances and
abstraction related?
16
ER MODEL ATTRIBUTE
a description of data values held by an entity

• name unique within an entity
• type the domain from which an attribute can take
  its values
• continuous ? discrete

Employee
hkid
hkid name sex age entity
A071983
male
22
instance
John

• identifier(key) versus descriptor attributes

How are entities, attributes and abstraction
related?
17
ER MODEL NOTATION
complexattribute
hkid
name
skill
multi-valuedattribute
Note data can often have a duality of
representation entity ltgt attribute
Alternate notation Employee (hkid, name,
address, skill) BUT loses some semantics!
18
ER MODEL GENERALIZATION

• a relationship between an entity and one or more
  refined versions

generalization
Musicalinstrument
instrument-type
Windinstrument
Stringinstrument
Percussioninstrument
size
discriminator
Violin
Cello
Viola
specialization
discriminator an attribute of enumeration type
that indicates which property of an entity is
being abstracted by a generalization
19
ER MODEL INHERITANCE
the assumption of properties by a subtype from
its supertype

• promotes reusability, reduces redundancy
• only define properties in one place
• subtype may add new properties (attributes)
• single inheritance versus multiple inheritance
• inheritance conflicts may arise

20
ER MODEL INHERITANCE

• conflict resolution by
• user-defined order
• predefined order
• redefine names

amount
account
service-charge
interest-rate
statement-fee
statement-fee
Checking Savings
service-charge
statement-fee
interest-rate
21
MULTIPLE INHERITANCE EXAMPLE
id
University member

U
U
id
id
Student
Employee


id
id
id
id


U
U
id ?
? id
TA
22
MULTIPLE INHERITANCE EXAMPLE
id
id
Student
Employee


id
id
id
id


U
U
id ?
? id
TA
23
MULTIPLE INHERITANCE EXAMPLE
Vehicle

U
U
weight
displacement
size
size
Land vehicle
Water vehicle


U
U
U
U
Car
Amphibious vehicle
Boat
name conflict
24
ER MODEL RELATIONSHIP INSTANCE 2.1.1
a physical or conceptual connection between
entity instances
Teaches
Works-for
25
ER MODEL RELATIONSHIP (TYPE)

• a description of a set of relationships with
  common semantics

Teaches
Course
Person
ER diagram

• often appear as verbs in
• problem descriptions

• conceptually, relationships are inherently
  bi-directional

• a relationship is not the same as a pointer!

26
ER MODEL RELATIONSHIP (contd)

• there can be several relationships between the
  same two entities

Person
Works-for
Attended
Works-for
Attended
University

• or even with the same entity

Person
Manages
Married-to
How are relationships, relationship instancesand
abstraction related?
27
RELATIONSHIP DEGREE

• unary (reflexive)relates an entity to itself

• binaryrelates two entities

• ternaryrelates three entities

More on this later!

• n-ary - relates any number of entities

• In practice, the vast majority of relationships
  are binary

28
RELATIONSHIP RELATIONSHIP ATTRIBUTE
What about an attribute like grade?
A
B
A-
C
A
B
29
RELATIONSHIP RELATIONSHIP ATTRIBUTE (contd)

• Possibility 1 use many attributes for grade

(a) in Student
(b) in Course
30
RELATIONSHIP RELATIONSHIP ATTRIBUTE (contd)

• Possibility 2 use a multi-valued attribute for
  grade

(a) in Student
(b) in Course
31
RELATIONSHIP RELATIONSHIP ATTRIBUTE (contd)

• Possibility 3 use a relationship attribute

32
RELATIONSHIP RELATIONSHIP ATTRIBUTE

• When to associate an attribute with a
  relationship?

?
salary
name
hkid
address
name
address

• Usually needed only for many to many
  relationships!

33
RELATIONSHIP ROLE NAME

• role one end of a relationship

employee
employer

• for binary relationships there are two roles

• often appear as nouns in problem descriptions

34
RELATIONSHIP ROLE NAME
role one end of a relationship
Boss
Worker
Boss

• It is necessary to use role names when a
  relationshiprelates instances from the same
  entity

35
DATA MODEL CONCEPTS AND INSTANCES
ExtentionalInstance(s), Data
IntentionalDefinition, Meta-data
36
DATA MODEL (INTEGRITY) CONSTRAINTS

• constraint a logical restriction or property of
  data that

• for any set of data values, we can determine
  whether the constraint is true or false
• we expect to be true always
• we can enforce
• adds additional semantics (meaning) to data
• inherent part of the data structure type
  definition of the data model
• e.g., every attribute must be atomic
  (single-valued)
• explicit specified independently on data
  structure types or a property of the data
• e.g., enrollment quota for a course

37
DATA MODEL (INTEGRITY) CONSTRAINTS

• on attributes salary is between 0 and 100,000
• on entities every manager is also an employee
• on relationships every employee works in at most
  one department

Manager
Employee
38
ATTRIBUTE CONSTRAINTS

• domain

set of positive integers from 0 to 9999
set of character strings of length 20 or less
. . .
set of positive integers up to 999 999
. . .
hkid
name
salary
address
employee-id
job-class
Employee
39
ATTRIBUTE CONSTRAINTS

• functional dependency

X
employee-id salary
Suppose we are told that no two employees have
the same employee-id
40
FUNCTIONAL DEPENDENCY (FD)

• Let X, Y be sets of attributes and f a
  time-varying function from X to Y.
• fX Y
• is a functional dependency if at any point in
  time, for a given value of x in X there will be
  at most one value of y in Y
• X is called the determinant of the FD

41
FUNCTIONAL DEPENDENCY (FD) (contd)

• X and Y can be sets of attributes X ºX1UX2UUXn
  X1X2Xn

item
quantity
employee-id
customer-id
item
date
date
Order
customer-id, item, date quantity

• If any Xi is not needed to determine Y, then Y is
  only partially dependent on X
• employee-id, name salary

otherwise, Y is fully dependent on X
42
APPLYING FDs TO DATA MODELLING

• Keys (Identifiers)

Given
X
Y
Z
X
X Y X Z
E1

• Value of X unique in E1 gt X is a candidate key
  of E1
• (a minimal set of attributes that uniquely
  identifies an entity instance)
• Usually choose one candidate key as the primary
  key

• Does every entity have a primary key?

43
APPLYING FDs TO DATA MODELLING (contd)
discriminator attribute(s) that uniquely
identifies an instance given a key value for the
strong entity
employee-id
employee-id
name
name
name
address
Has
Dependent
Employee
hkid
age
salary
job-class

• internal key only attributes of the entity
  itself are required to uniquely identify an
  instance of the entity
• strong entity

• external key attributes of one or more related
  entities are needed to uniquely identify an
  instance of the entity
• weak entity

44
APPLYING FDs TO DATA MODELLING (contd)

• Forming entities
• Suppose we just start with FDs

X U X V X Y
W Z W T
X
U
V
Y
W
Z
T
E1
E2
45
ENTITY CONSTRAINTS GENERALIZATION COVERAGE
2.2.1
overlapping
disjoint
46
ENTITY CONSTRAINTS GENERALIZATION COVERAGE
(contd)
complete (total)
incomplete (partial)
47
ENTITY CONSTRAINTS GENERALIZATION COVERAGE
(contd)
overlapping, incomplete
overlapping, complete
48
ENTITY CONSTRAINTS GENERALIZATION COVERAGE
(contd)
disjoint, complete
disjoint, incomplete
49
RELATIONSHIP CONSTRAINTS CONNECTIVITY 2.1.3

• specifies the number of instances of a
  relationship in which an entity may participate
  (relationship cardinality)

Teaches
(0,1)
(1,1)
Instructor
Course

• For a given course, how many instructors can
  teach it?
• assume each course can be taught by one and only
  one instructor

• For a given instructor, how many courses can he
  teach?
• assume an instructor does not have to teach any
  course and may teach at most one course in a
  given semester

50
RELATIONSHIP CONSTRAINTS CONNECTIVITY
(c,d)
(a,b)
E1
E2
R
max-card(E1,R)
min-card(E1,R)

• minimum cardinality (min-card)
• min-card(E1,R) minimum number of relationships
  in which each entity of E1 can participate in R

min-card(E1,R) 0 optional participation min-ca
rd(E1,R) gt 0 mandatory participation

• maximum cardinality (max-card)
• max-card(E1,R) maximum number of relationships
  in which each entity of E1 can participate in R

51
RELATIONSHIP CONSTRAINTS CONNECTIVITY

• special cardinalities
• max-card N an unlimited upper bound (?)

• max-card(E1,R) 1 and max-card(E2,R) 1
• one-to-one relationship (11)
• max-card(E1,R) 1 and max-card(E2,R) N
  ormax-card(E1,R) N and max-card(E2,R) 1
• one-to-many relationship (1N)
• max-card(C1,A) N and max-card(C2,A) N
• many to many relationship (NM)

52
QUESTION?
?
?
10..40
1..5

• A student must enroll in at least one course and
  can enroll in at most five courses

• A course must have at least ten students enrolled
  in it and cannot have more than forty students
  enrolled in it.

53
ER MODEL EXAMPLE RELATIONSHIPS
11 relationship
(0,1)
(1,1)
1
1
optional
mandatory
Capital-of
54
ER MODEL EXAMPLE RELATIONSHIPS
1N relationship
(1,N)
(0,1)
N
1
mandatory
optional
Assigned-to
55
ER MODEL EXAMPLE RELATIONSHIPS
NM relationship
(0,N)
(0,N)
N
M
optional
optional
Works-on
56
N-ARY RELATIONSHIP CONNECTIVITY

• defined with respect to the other n-1 ends

• given a ternary relationship among classes (A, B,
  C), the connectivity of the C end states how many
  C instances may appear in relationship with a
  particular pair of (A, B) instances

0..1

? 0 or 1 professor

• for each (course, student)

• a student will not take the same course from more
  than one professor, but a student may take more
  than one course from one professor and a
  professor may teach more than one course

• for each (student, professor)

? many courses

• for each (course, professor)

? many students
57
QUESTION?

0..3
0..1
? 0, 1, 2 or 3 days
? 0 or 1 classrooms
? many courses
58
N-ARY RELATIONSHIP CONNECTIVITY CONSTRAINTS

• connectivity (max-card) can be expressed as a
  functional dependency

FDs emp dept dept emp
FDs emp dept
59
TERNARY RELATIONSHIP CONNECTIVITY

• 1 if only one instance of an entity can be
  related with one instance of each of the other
  two associated entities
• e.g., if E2, E3 E1, then max-card E1 is 1

N if more than one instance of an entity can be
related with one instance of each of the other
two associated entities
60
TERNARY RELATIONSHIP CONNECTIVITY (contd)
not allowed since for a given project, P, and
notebook, A, there is more than one technician
61
TERNARY RELATIONSHIP CONNECTIVITY (contd)
not allowed since the same employee, X, works on
the same project, N, at different locations
62
TERNARY RELATIONSHIP CONNECTIVITY (contd)
not allowed since the same engineer and project
combination, (N, Y), have two managers
63
TERNARY RELATIONSHIP CONNECTIVITY (contd)
all combinations are allowed
64
CONNECTIVITY CONSTRAINTS WEAK ENTITY 2.1
65
CONNECTIVITY CONSTRAINTS WEAK ENTITY (contd)

• a weak entity may be related to more than one
  strong entity, but may depend on only some of
  these for its identity

Employee
1
How to show which entity it is dependent on?
Has
Has
N
Attends
Dependent
N
1
School
66
AGGREGATION/COMPOSITION RELATIONSHIP

• a special type of relationship in which there is
  a part-of relationship between one entity and
  another entity

• existence of a component may depend on the
  existence of the aggregate entity of which it is
  a part mandatory existence (called composition)

Course-offering
Course
A

• a component may also exist independent of the
  aggregate entity of which it is a part optional
  existence(called aggregation)

Disk
Computer
A
67
AGGREGATION/COMPOSITION RELATIONSHIP

• sometimes it is not clear whether the parts
  should be related with composition or aggregation

Car

• Which aggregation relationship to use is a matter
  of the database designers interpretation of
  reality and/or the requirements of the application

68
WHEN TO USE AGGREGATION/COMPOSITION?

• Would you use the phrase part of to describe
  the relationship or name it Has? (But be
  CAREFUL! Not all Has relationships are
  aggregationsgt)
• Are operations on the whole automatically applied
  to the part(s) composition?
• Are some attribute values propagated from the
  whole to all or some of the parts?
• Is there an intrinsic asymmetry to the
  relationship where one entity is subordinate to
  the other(s)?

• It is not wrong to use a relationship rather than
  aggregation!(When in doubt, use a relationship!)

69
EXAMPLE ENTITY-RELATIONSHIP DIAGRAM (ERD)
N
1
Department
Division
A
1
1
Is- managed-by
Has
N
1
1
boss
Is- occupied-by
Manager-of
1
N
Employee
Office
N
worker
N
1
N
Uses
P
Manages
Works- on
Language
N
M
Project
M
70
SUMMARY ER DIAGRAM CONSTRUCTS
entity
relationship
Is- managed-by
1
1
Department
Employee
(a) one-to-one
Has
1
N
Department
Employee
(b) one-to-many
Works- on
N
M
Employee
Project
(c) many-to-many
71
SUMMARY ER DIAGRAM CONSTRUCTS
Enrolled- in
(10,40)
(1,5)
Student
Course
(d) explicit cardinality
Works- on
N
M
Employee
Project
(e) relationship attribute
time
(f) recursive (with role names)
N
1
Division
Department
(g) aggregation
A
72
SUMMARY ER DIAGRAM CONSTRUCTS
(h) ternary relationship
Uses
N
M
Employee
Project
P
Language
(i) generalization
