Gastrointestinal Stromal Tumors Current Concepts 2005

1
Gastrointestinal Stromal TumorsCurrent Concepts
2005

• Reviewed byKlaus Gottlieb, MD, FACP, FACG
• Endoscopic Ultrasound and Interventional
  Endoscopy
• Spokane, WA

2
In the Beginning

• there were smooth muscle tumors of the
  gastrointestinal tract. And darkness reigned over
  the face of these tumors and there was much
  confusion

3
but now there are Guidelines

• European Consensus Conference Recommendations
  (Meeting in Lugano March 2004) just published in
  Ann Oncol. 2005 Apr16(4)566-78.
• NCCN Sarcoma Guideline (GIST chapter) updated in
  2005

4
Terminology

• Stromal or mesenchymal tumors of the GI tract
  are divided into two groups
• Those identical to tumors of the soft
  tissuearising in the rest of the body
• Lipomas, Schwannomas, Hemangiomas, Usual
  Leiomyomas, etc.
• Stromal tumors arising from the smooth muscle of
  the alimentary tract GIST

5
Gastrointestinal Stromal Tumors

• Most often located in the stomach and proximal
  small intestine
• Can occur in any portion of the GI tract that
  contains smooth muscle
• Occasionally found in the omentum, mesentery and
  peritoneum

6
GIST

• Most common benign non-epithelial tumor of the GI
  tract
• 1 of primary GI cancers
• Small asymptomatic GISTs are found at autopsy in
  more than 50 percent of individuals over the age
  of 50
• GIST treatment trials estimate an annual
  incidence of 4,500 6,000 new cases

7
Evolution of our Understanding

• GISTs originally thought to derive from smooth
  muscle, but only rarely showed clear-cut features
  of complete muscle differentiation
• Some stromal tumors had ultrastructural evidence
  of autonomic neural differentiation
  (gastrointestinal autonomic nerve tumors, GANTs)

8
Immunophenotyping

• Work in the 1990s Some tumors classified as GIST
  were truly myogenic, some neural, others
  bidirectional and some had the null phenotype
• Up to two-thirds were CD34 positive
• Unfortunately, Schwannomas and a proportion of
  true smooth muscle tumors were also CD 34 positive

9
Enter CD117

• CD117 molecule (or antigen) is part of the c-kit
  receptor, a membrane tyrosine kinase
• The c-kit receptor is a product of the c-kit or
  KIT protooncogene
• The CD117 antigen is expressed by almost all
  GISTs in contrast to other spindle-cell tumors of
  the GI tract
• In 80 percent of GISTs c-kit activation is the
  result of an activating KIT mutation

10
Membrane (Receptor) Tyrosine Kinase
11
A Tyrosine Kinase primer

• Protein tyrosine kinases (PTKs) catalyze the
  phosphorylation of tyrosine residues.
• the total number of PTKs does not exceed 1000
  (human genome project)
• two main classes of PTKs receptor PTKs and
  cellular, or non-receptor, PTKs.
• Of the 91 protein tyrosine kinases identified
  thus far, 59 are receptor tyrosine kinases and 32
  are non-receptor tyrosine kinases.
• PTKs are involved in cellular signaling pathways
  and regulate key cell functions such as
  proliferation, differentiation, anti-apoptotic
  signaling and neurite outgrowth.
• Unregulated activation of these enzymes, through
  mechanisms such as point mutations or
  over-expression, can lead to various forms of
  cancer as well as benign proliferative
  conditions.
• more than 70 of the known oncogenes and
  proto-oncogenes involved in cancer code for PTKs.

• existence of aberrations in PTK signaling
  occurring in inflammatory diseases and diabetes.

12
Membrane (Receptor) Tyrosine Kinase Families
Adapted from Hubbard,1999
Extracellular
Intracellular
13
Membrane (Receptor) Tyrosine Kinase Families
Adapted from Hubbard,1999
Extracellular
Intracellular
Epidermal Growth Factor Receptor Family
14
Membrane (Receptor) Tyrosine Kinase Families
Adapted from Hubbard,1999
Extracellular
Intracellular
Insulin Receptor Family
15
Membrane (Receptor) Tyrosine Kinase Families
Adapted from Hubbard,1999
Extracellular
Intracellular
Platelet-Derived Growth Factor Receptor Family
including KIT
16
Membrane (Receptor) Tyrosine Kinase Families
Adapted from Hubbard,1999
Extracellular
Intracellular
Vascular Endothelial Growth Factor Receptor
Family
17
Membrane (Receptor) Tyrosine Kinase Families
Adapted from Hubbard,1999
Extracellular
Intracellular
Fibroblast Growth Factor Receptor Family
18
Membrane (Receptor) Tyrosine Kinase Families
Adapted from Hubbard,1999
Extracellular
Intracellular
Hepatocyte Growth Factor Receptor Family
19
Membrane (Receptor) Tyrosine Kinase Families
Adapted from Hubbard,1999
Extracellular
Intracellular
Ret Receptor (Orphan)
20
TK Receptor Activation and Signal Transduction
Ligand
Extracellular
Intracellular
Inactive Receptor
21
TK Receptor Activation and Signal Transduction
Ligand
Extracellular
Intracellular
Receptor Dimerization
22
TK Receptor Activation and Signal Transduction
Extracellular
P
P
Intracellular
P
P
P
P
Receptor Auto-Phosphorylationand Activation
23
TK Receptor Activation and Signal Transduction
Ligand
Extracellular
P
P
Intracellular
P
P
P
P
24
TK Receptor Activation and Signal Transduction
Ligand
Extracellular
P
P
Intracellular
Y
P
P
P
P
Intracellular SignalingMolecule
25
TK Receptor Activation and Signal Transduction
Ligand
Extracellular
P
P
Intracellular
Y
Y
P
P
P
P
Recruitment and Phosphorylationof Signaling
Molecule
26
TK Receptor Activation and Signal Transduction
Ligand
Extracellular
P
P
Intracellular
Y
Y
P
P
P
P
ATP
ADP
Recruitment and Phosphorylationof Signaling
Molecule
27
TK Receptor Activation and Signal Transduction
Ligand
Extracellular
P
P
Intracellular
Y
Y
P
Y
P
P
P
P
Activation of SignalingMolecule
anddownstreamSignaling Pathway
ATP
ADP
28
GIST and c-kit

• Reminder the c-kit receptor is one of many
  membrane tyrosine kinase receptors involved in
  cellular signaling pathways
• GISTs are identified by
• either c-kit immunoreactivity (detection of the
  CD117 antigen)
• or the presence of activating mutations in KIT or
  PDGFRa (more about PDGFRa in a minute)

29
C-kit gain-of-function mutations

• In normal cells activation of the of the c-kit
  tyrosine kinase requires the presence of an
  endogenous ligand (KIT ligand, c-kit ligand, or
  stem cell factor)
• Approx 80 of GISTs have KIT protooncogene
  mutations that lead to activation of the c-kit
  receptor resulting in spontaneous receptor
  activation not requiring a ligand

30
KIT mutations

• Approx 80 of GISTs have KIT protooncogene
  mutations
• Observed both in sporadic and hereditary cases
• At least six families with germ line mutations in
  KIT autosomal dominant predisposition to GISTs
  with hyperpigmentation, urticaria pigmentosa, and
  dysphagia in some members

31
Not straightforward

• C-kit activation normally associated with KIT
  mutations
• C-kit activation sometimes without KIT mutations
• Some c-kit negative tumors have KIT mutations
• Some c-kit negative GISTs have activating
  mutations in a different TK (tyrosine kinase),
  PDGFRa

32
PDGFR alpha mutations

• A subset of GISTs lacking c-kit mutations have
  activating mutations in the PGFRa gene (platelet
  derived growth factor receptor alpha), another
  tyrosine kinase
• In one series such mutations were found in 14 of
  40 KIT-mutation negative GIST tumors and
  activation of downstream signaling intermediates
  were indistinguishable from those with
  KIT-mutations

33
Clinical Relevance

• Imatinib (Gleevec) is very effective for CD114
  positive GISTs
• It also has antitumor effficacy in tumors that
  lack KIT mutations but have alterations in the
  PDGF pathway
• Some PDGFRa mutations are imatinib-sensitive,
  others not
• therefore, patients with advanced tumors that are
  histologically c/w GIST should not be denied a
  trial of imatinib if they are c-kit negative

34
Interstitial Cells of Cajal

• Interstitial cells of Cajal (ICC) form the
  interface between the autonomic innervation of
  the bowel wall and the smooth muscle itself
• GI pacemaker cells
• Ultrastructural and immunophenotypic features of
  both neuronal and smooth muscle differentiation
  (just like GISTs)

35
An ICC in action
Note contractions of the triangularly shaped ICC,
note that processes contact smooth muscle cells.
36
Are GISTs derived from ICCs?

• It is postulated that GISTs originate from CD34
  positive stem cells within the wall of the gut
  and differentiate toward the pacemaker cell
  phenotype (ICC)
• Benign GISTs which tend to lack expression of
  CD34 may be composed of more mature ICCs
• Malignant GISTs may represent dedifferentiated
  ICCs that maintain a CD34-positive stem cell
  phenotype
• Attractive hypothesis but still open to question

37
Histopathology

• Differential Diagnosis
• HE stain Melanoma, leiomyoma/sarcoma,
  peripheral nerve sheath tumor, desmoid
• Histology difficult
• Immunophenotyping crucial
• 95 are positive for C-kit (CD117)
• 60-70 positive for CD34
• Negative for alpha-smooth muscle actin (SMA)
  (leiomyoma)
• Negative for S100 protein (Schwannoma)
• Negative for Desmin (desmoids)

38
C-kit (CD117)
HE stain
39
Spindle-cell tumor with High mitotic rate
40
GIST Cellular Morphology

• Three relatively distinctive types
• Spindle cell type 70 percent
• Epithelioid type 20 percent, more commonly
  c-kit negative and found in omentum and mesentery
• Mixed type 10 percent
• Histologic type may be of prognostic
  significance, worse with epitheloid

41
(No Transcript)
42
(No Transcript)
43
Determinants of Malignant Behavior

• Size More than 3 cm in diameter(most malignant
  GISTs are larger than 10 cm at diagnosis)
• Mitotic rate gt 25 mitoses per 50 high power
  fields
• Caveat Even very small lesions (lt 2 cm) with a
  low mitotic rate occasionally metastasize

44
(No Transcript)
45
Other factors

• Site of origin better prognosis for gastric
  GISTs (?)
• Imaging characteristics EUS and CT
• Tumor biology
• C-kit mutations
• Chromosomal gains and losses
• DNA ploidy

46
KIT mutations

• Most KIT mutations effect exon 11, others 9,13,17
• The type of exon 11 deletion may affect
  prognosis deletions of codons 562 to 579
  (563-569 always malignant)
• Exon 11 mutations are more likely to respond to
  iminitab

47
Imatinib (Gleevec) a Tyrosine Kinase Inhibitor

• Imatinib mesylate is a protein-tyrosine kinase
  inhibitor that inhibits the Bcr-Abl tyrosine
  kinase, the constitutive abnormal tyrosine kinase
  created by the Philadelphia chromosome
  abnormality in chronic myeloid leukemia (CML).
• Imatinib is also an inhibitor of the receptor
  tyrosine kinases for platelet-derived growth
  factor (PDGF) and stem cell factor (SCF), c-kit,
  and inhibits PDGF- and SCF-mediated cellular
  events. In vitro, imatinib inhibits proliferation
  and induces apoptosis in gastrointestinal stromal
  tumor (GIST) cells, which express an activating
  c-kit mutation

48
Action on Bcr-Abl TK similar to c-kit TK
49
Clinical Manifestations

• Major presentations
• Overt GI bleeding 40 percent
• Abdominal mass 40 percent
• Abdominal pain 20 percent
• Location
• Stomach 50 percent
• Small bowel 25 percent
• Colon 10 percent
• Omentum/mesentery 7 percent
• Esophagus 5 percent

50
Metastatic spread

• GISTs behave differently than other soft
  tissue sarcomas
• GISTs frequently metastasize to the liver and
  rarely to regional lymph nodes
• GISTs virtually never metastasize to lungs
  whereas this is the most common site of
  metastasis for leiomyosarcomas

51
Diagnostic Work-Up

• CT scan
• Leiomyomas solid hypodense lesions
• GISTs typically enhance with IV contrast
• Endoscopy
• Smoothly contoured submucosal mass, possible
  central umbilication
• EUS
• Hypoechoic mass arising from muscularis propria

52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
The incidental (asymptomatic) UGI subepithelial
mass

• No firm clinical guidelines or consensus
• Surface Endoscopy can establish a lipomatous
  nature of the mass
• If mass is gt 1 cm referral for EUS, if lt 1 cm
  repeat EGD in one year, if stable probably no
  follow-up
• If mass arises from muscle layer (4th EUS layer
  mass) and is gt 3 cm referral for surgery (likely
  GIST)

60
The incidental (asymptomatic) UGI subepithelial
mass

• Clinical conundrum The 1 - 3 cm mass
• 4th layer mass should undergo EUS-FNA and c-kit
  staining
• If a GIST is found discuss management strategies,
  esp. surgery
• If results are indeterminate or patient does not
  wish (or is not a candidate for) resection,
  endoscopic follow up

61
Endoscopic Follow-Up

• Recommendations depend on the age of the patient,
  index of suspicion, etc.
• One reasonable strategy EUS follow-up a year
  later and if lesion is stable for two consecutive
  follow-up periods, lengthening of the follow-up
  period

Adapted from Hwang JH, Kimmey MB.The incidental
upper gastrointestinal subepithelial
mass.Gastroenterology. 2004 Jan126(1)301-7.
62
Questions?
