Presentation Scope

1
(No Transcript)
2
Presentation Scope

• Comstar
• I-Direct
• Infosat
• Infosat Connect
• Proposed Network
• Infosat Connect
• SCPC VSAT
• Broadband Wireless
• Routing, Security Optimization

3
Comstar

• Comstar ISA Ltd. has over 10 years of experience
  of offering the best fit solutions with an
  extensive service product offering Innovating
  everyday

4
Comstar

• Comstar ISA Ltd. Is the service provider of
  choice for mission critical wireless networks in
  Pakistan. Delivering everyday

5
I-Direct

• iDirect Technologies is a Leading High-Technology
  Company Producing Innovative IP-Based Wireless
  Products.

• Enabler Of Fast, Easy And Efficient Broadband IP
  Anywhere
• Developers Of the Only Satellite Technology Built
  From The Ground up to Support Standards based IP
  and Ethernet
• Experts In Real-time And Non Real-time Enterprise
  Applications In A Shared IP Environment
• Fastest Growing VSAT Hub manufacturer in the world

6
I-Direct
7
Infosat

• In business since 1986
• Largest, full service satellite provider in
  Canada
• 60 MHz of Ku-band bandwidth
• Revenue in 2005, 40M
• gt10,000 subscribers
• Supplier to Federal Government through NMSOs,
  Supply Arrangements, and direct purchases

Infosat HQ
8
Background

• Offices in Vancouver, Calgary, Edmonton, and
  Montreal
• 100 North American Dealers
• Network Operation Centre manned 24/7
• Largest MSAT airtime Service Provider
• Largest iDirect (Connect) network in the world

9
Commercial Customers

• Oil Gas
• Shell, Petro Canada, Exxon, Pason
• Mining Engineering
• De Beers, Placer Dome, Tech Cominco, SNC-Lavalin
• Telecommunication Carriers
• Bell, MTS, NWTel, Verizon

10
Government Customers

• Provincial Governments
• BC, AB, SK, MB, PQ, ON, YK
• Federal Government of Canada
• Coast Guard, House of Commons
• US Government
• Coast Guard, DoD
• State of New Mexico
• State of Alaska
• Other
• UN Agencies, Relief Organizations, Universities
• Power Utilities

11
Satellite Communications
BGAN
Inmarsat

• Iridium

MSAT
HSe
SkyCom
Connect
12
Infosat Comstar Relationship

• Infosat has made a substantial equity investment
  in Comstar and has become one of the major
  sponsors of Comstar.
• Infosat brings its experience of being the
  largest I-Direct operator in the world to
  Pakistan and collaborates with Comstar on
  Technical and Marketing areas.
• Infosat will monitor the Comstar Hub on 247
  basis at its NOC in Canada.
• Comstar and Infosat design solutions for the
  Pakistan market and our Connect Service has
  Infosats guarantee of true international quality.

13
Applications for Satellite Communications

• Remote areas - no other reliable coverage
• High speed data in fringe landline and cell
  coverage areas
• Need is temporary, quick installation
• Broadcast - one to many
• Wide area coverage requirements - fleet

14
Fixed Satellite Services Comparison
Connect
Market Type
Access Method
Topology
Functions
Return Data Rates
15
Connect

• Two-way, high speed data service for commercial
  applications
• Efficiencies of a shared TDMA system (allows
  sharing of both the inbound and outbound
  channels)
• Ideally suited for multi-site, corporate WAN

16
Connect Services

• Connect Net
• Secure Plus
• VPN Connectivity between customer remote sites
  within Pakistan and with sites anywhere in the
  world using external security devices like IPSec
  / K9 routers etc.
• Build an affordable secure Nationwide Network
• After Dark
• High Speed Internet Connectivity anywhere in the
  country between 7 PM to 7AM
• Ideal for Call Centers and Night Hawks
• X-NET
• High Speed Internet Connectivity simply anywhere

• From the Himalayas to the southern beachesbe
  connected at high speed

17
Connect Services

• Connect Transact
• SWIPE
• Cost effective, reliable and secure Connectivity
  for POS (Point of Sale) and ATM (Automated Teller
  Machine) Applications
• Setup a POS or an ATM anywhere you wish
• Supervise
• Cost effective, reliable and secure Connectivity
  for SCADA (Supervisory Control and Data
  Acquisition) Applications
• Get the critical data from the factory, depot,
  pipeline, highway, irrigation systems, dams etc
  in real time at a fraction of the cost.
• Eye
• IP Camera enabled service for remote
  surveillance
• See the real pictureget live pictures from your
  remote offices / factories delivered straight to
  your office or home

18
Connect Services

• Connect Enterprise
• On-Line
• Solution for Bank Branch Network, designed to
  prioritize critical banking application traffic,
  and simultaneously run other applications like
  E-mail, File transfers, Intranet, Internet, ATM
  etc.
• Bring your branch on-line today, pick a
  location, we will Connect
• One-Net
• Corporate Connectivity for all kinds of traffic
  include ERP (Enterprise Resource Planning) like
  SAP, Oracle, People Soft, JD Edwards etc.
  E-Mail, Intranet, Internet etc.
• Bring your organization together.

19
Connect Services

• Connect Specials
• Rescue
• On-Demand Connectivity for backup / disaster
  recovery applications
• No Downtime.
• V-Meet
• Save time and resources with virtual meeting
  through on-demand video conferencing
• Its like being there.
• On-Air
• Broadcast your live feed or live video through
  Infosat from anywhere in the country
• - never miss the action again.

20
Connect Services

• Connect Specials (contd..)
• Mobile Our auto deploy antennas will keep you
  connected wherever you move, no technical
  expertise required as connectivity establishes as
  soon as your vehicle stops Be connected on the
  move
• E-1 Low cost and intelligent solutions for E-1
  satellite links, tested and approved by Ericsson
  Offer cellular services anywhere
• E-Learning Two-way connectivity solutions for
  Distance Learning and Telemedicine education
  and health for all.
• Talk Time Legal Voice Over IP Solution covered
  by WorldCall - LDI (Long Distance International)
  license, can be used in conjunction with other
  services let the voice ride for freelegally.


21
Connect

• Up to 18 Mbps downstream and 4.2 Mbps upstream
• TCP acceleration - mitigates latency of IP
  traffic over satellite
• QoS (Quality of Service)
• IP addresses, protocols can be prioritized for
  different types of traffic (voice, video
  streaming, File Transfer, HTTP, etc.)

22
Connect - NetModem

• Simple One Box Solution

Satellite Modem
Packeteer QoS/Prioritization
Mentat / Peribit TCP Acceleration
IP Router

All of these boxes are replaced with one iDirect
unit
23
Connect Terminal

• Antenna size of 1.2m sufficient for all of
  Pakistan
• Easy install no AC power required at the
  antenna
• 2, 4 or 10 watt RF transmitter at C or Ku band
  frequencies
• RJ45 Ethernet 10/100 interface supports IP data
  and voice

24
Connect Hub
Private Hub
Hub Chassis
Model 5IF Hub
Solution for an Enterprise Full Featured TDMA
Hub Single OB/IB Hub Support for Star and Mesh
Topologies
Solution for a Teleport Full Featured MF-TDMA
Hub Extremely Flexible and Scalable Hub Support
for Star, Mesh, SCPC Topologies 1IF and 5IF
Models

• Compact, 20 Slot, 10U, 19 Rack Mountable
• Scalable Grow As You Need
• Flexible
• Multiple Multi-inroute Networks Within the Same
  Chassis
• Multiple RF Outputs Up to 5 Different
  Satellites From One Chassis
• MN Universal Line Card Redundancy
• N1 Power and Fan Redundancy

25
Connect Hub

• By simply adding a separate line card, the
  Infosat Hub can provide dedicated Downlink
  Uplink to each customer or a group within a
  customer
• It can also support multiple satellite links on
  multiple bands

26
Connect Flexibility
27
Connect NMS

• Integrated NMS System
• ALL Features Manageable from NMS
• Application QoS, CIR, VLANs, IP
• Comprehensive Network Management System
• Configuration, Monitoring, Fault Isolation,
  Analysis
• Client-Server, 3-Tier Architecture
• Modularity, Flexibility, Simplifies Maintenance
• Linux Server Back-End
• Performance, Stability,
• Maturity, Accessibility
• SQL Database
• SNMP Proxy

28
Business Continuity

• Overlay a Business Continuity SLA for mission
  critical sites which require a robust Disaster
  Readiness Recovery solution

29
(No Transcript)
30

• Questions, comments and feedback For further
  information
• www.infosat.com
• www.comstar.com.pk
• www.idirect.net
• sales_at_comstar.com.pk
