Title: Johan J. Lukkien, j.j.lukkien@tue.nl


1
Computer Networks2002/2003
  • Routing
  • Johan Lukkien

2
Layer tasks
  • Basic service
  • addressing, data format, fragmentation,
    congestion, error messages
  • Neighbor greeting
  • configuration routers find out about their
    environment, (other routers, end-stations)
  • Routing
  • forwarding, route computation selection
  • methods, protocols
  • dynamic, based on metrics (e.g., delay,
    bandwidth, link error rate) or static
  • Quality of the service
  • Requirements
  • robustness, stability
  • preferable automatic configuration (e.g.
    assigning addresses)
  • Slides following assume connection-less service

3
Neighbor greeting
  • ....(Auto-)configuration
  • End nodes
  • find adjacent routers
  • see difference between locally accessible nodes
    and those accessible through a router
  • find link addresses of adjacent nodes
  • find out own network address
  • Routers, in addition
  • find network addresses of end nodes
  • Note
  • dependent on type of connection (point-to-point,
    LAN)

4
Soft state
  • Typically, state information that is only
    temporary valid
  • values of variables of other processes, machines
  • state of environment, connections
  • in principle, invalidation is interference
  • Note making copies violates the principle
    never copy volatile information
  • however, for scalability a replication strategy
    of shared objects is needed
  • Methods to maintain consistency
  • send updates keep-alive messages
  • depends on modification frequency timers
  • only upon interaction, request Im alive
    message
  • e.g. refresh a router table entry only upon
    message sent

5
Finding things service advertisement discovery
  • Use a local database
  • e.g. look it up in a phone book
  • Use a special location to find that database
  • e.g. dial the telephone directory service
  • giving either the nearest or all service
    providers
  • Broadcast what youre looking for
  • dial a number that rings all phones and tell what
    you ned
  • Broadcast the service that you provide
  • dial the same number and tell what youve got

6
Issues on a LAN
  1. E? need their layer 3 addresses
  2. R? need to know and announce enough info (e.g.,
    layer 3 addresses) such that packets for E1,E2
    will be forwarded to the LAN
  3. R? need to know link addresses of adjacent nodes
  4. E? need to know the data link address of an
    adjacent router
  5. E1, E2 should be able to communicate directly
  6. E? should be able to find the best router per
    partner
  7. Nodes on the same LAN do not depend on routers to
    communicate

7
IP solutions
  • Routers know network number and mask of each of
    their outgoing links (2)
  • manually configured
  • On that link you find the link address of the
    next hop (endnode or router) through the Address
    Resolution Protocol (3,5,7)
  • A router can send an ICMP redirect message
    for D, use this router IP, not me (6)
  • why IP and not data link address?

8
ARP (RFC 826)
  • Message as payload of LAN message
  • next protocol is (R)ARP (e.g. 16806 on
    ethernet)
  • cannot leave the LAN as such
  • protocol where resolution is requested for
  • Broadcast request, unicast reply
  • test use own IP address
  • Upon receipt of request or reply
  • add association to cache
  • answer request, if requested target

9
ARP Example
  • Router F1, F3 can serve as ARP proxy
  • advantage/disadvantage
  • ...or source knows if destination is off the
    network

10
Reverse ARP (RFC 903), BOOTP (RFC 951)
  • Find IP address corresponding to given data link
    address (1)
  • basic auto-configuration
  • although it needs a server that is configured
    with this association
  • Extended into BOOTP (1,4)
  • message in IP packet
  • router (relay agents) can forward the message
  • how to deal with addressing?
  • can specify a host/bootfile combination
  • vendor specific options
  • rather than (type, length, value) encoded fields
  • repaired by the special vendor-specific field
    63.82.53.63 (4 bytes, hex.) .... magic cookie

11
DHCP (1,4)
  • Extends BOOTP
  • packet includes magic cookie and option 1653 ?
  • Extras
  • dynamic address assignment
  • using leases
  • re-use of addresses
  • no database needed
  • no addresses needed for powered-off nodes

12
DHCP
  • Fields
  • Seconds either to obtain priority or specifying
    relay delay
  • flagsltgt0 reply to broadcast address
  • client IP0 server fills in your id
  • relay IPltgt0 server responds
  • to that address
  • options routers, subnet mask,
  • DNS servers, time servers,
  • lease time
  • reuse host-name and
  • boot-file name space
  • option overload to store
  • options there as well ?
  • at most 256 options, half of which are free to use

13
DHCP example
  • Can have server on different net

14
ICMP Router Discovery (RFC 1256) (4)
  • Routers advertise every 7-10 minutes
  • valid for 30 min. default
  • to broadcast address or unicast to configured
    address
  • Clients send sollicitations
  • destination see above

15
IPX solutions
  • Node number is link local address
  • Broadcast request for network number (1,3,5,7)
  • no reply 0
  • Broadcast request for best router to given
    destination network (4,6)
  • replying router is indeed alive

16
Routing protocols
  • Generally robust, stable, simple, ....
  • Provide routers with information issues
  • convergence, settling time after change
  • count-to-infinity problem
  • lazy, reactive
  • existence of (temporary) loops
  • long- or short-lived
  • hierarchy
  • Calculate routes (routing algorithm) issues
  • optimality
  • delay per packet, network use
  • adaptive
  • deal with special conditions
  • congestion, mobility
  • support multiple paths

17
The Optimality Principle
  • Optimal paths to a certain point form a tree (or
    acyclic graph)
  • Each router B needs to be able to determine
    NextB(x) the next step on the path to from B to x
  1. A subnet.
  2. A sink tree for router B.

18
Determine the tables
  • Using a distributed algorithm
  • distributed shortest path
  • similar to distributed spanning tree but now for
    each node as root
  • basis for Distance Vector Routing
  • Using a local, sequential algorithm
  • based on information obtained directly from the
    point of change
  • e.g. locally, the shortest path algorithm of
    Dijkstra
  • basis for Link State Routing

19
Dijkstras algorithm sketch
  • Note the dot denotes infinity

20
Distance Vector Routing
  1. A subnet
  2. Input from A, I, H, K, and the new routing table
    for J

21
Counting to infinity
  • Good news spreads rapidly
  • Bad news spreads slowly
  • since the distance to a destination D through a
    neighbor cannot differ very much from your own

22
Link State Routing
  • Each router does the following (repeatedly)
  • discover neighbors, particularly, learn their
    network addresses
  • using one of the neighbor discovery methods
    discussed before
  • measure cost to each neighbor
  • e.g. by exchanging a series of packets
  • construct a packet containing this
  • send this packet to all other routers
  • using what route information? chicken / egg
  • what if re-ordered? or delayed?
  • compute locally the shortest path to every other
    router when this information is received

23
Distributing the Link State Packets
  • Typically, flooding
  • routers recognize packets passed earlier
  • sequence number
  • thus avoiding the exponential packet explosion
  • first receivers start changes already while
    changes are being reported
  • sequence numbers wrap around or might be
    corrupted
  • add an additional age field that is decremented
    once a second packets wont be too long in the
    system
  • but, need additional robustness in order to deal
    with effect of packet forgeing
  • acknowledgements

24
Building Link State Packets
  1. A subnet
  2. The link state packets for this subnet

25
Hierarchical Routing
26
Routing for Mobile Hosts
27
Routing for Mobile Hosts
28
The IP way
  • Internet is made up of autonomous systems (AS)
  • routing within an AS interior gateway protocol
  • originally, RIP routing information protocol
  • distance vector, derived from Bellman-Ford
  • first link state protocol was not robust enough
  • Open Shortest Path First (OSPF) since 90
  • routing between ASs exterior gateway protocol
  • Border Routing Protocol

29
OSPF
  • Resources assumed to be freely usable since
    within AS
  • Requirements
  • Open, known to everyone
  • Support several metrics
  • Dynamic adaptation
  • note stability is important here
  • Use multiple paths load balancing
  • Hierarchy
  • Safeguard against forged routing info
  • Tunneling support

30
Represent network as a graph
  • Essentially three types of connection
  • point-to-point
  • LAN (broadcast link)
  • multi-access without broadcast

31
ASs, backbones, and areas
  • AS divided into numbered areas
  • One area(0) is called the backbone area
  • All areas connected to the backbone
  • inter-area routes go through backbone
  • Each router runs the link-state algorithm for
    each area it is part of
  • flooding between adjacent routers
  • on a LAN designated router

32
Message
  • IP packets

5-66
33
BGP
  • Between managerial (political?) domains
  • not my problem....
  • rule-based
  • Distance vector
  • but keeps track of paths
  • which are matched against the rules
  • and solve the counting to infinity
