Title: Safety


1
Safety
  • The engineers role in
  • risk reduction

Peter Gostomski Ken Morison Chemical Process
Engineering
2
Space shuttle disasters
  • Challenger blew up on take off (1986)
  • O-ring on booster rocket failed
  • Leaking fuel ignited, liquid H2 tank exploded
  • Columbia destroyed during reentry (2003)
  • foam damaged wing tiles during take-off
  • tiles failed during reentry

3
Longford gas processing plant (1998)
  • Longford (Esso) supplies energy to Victoria, AU
  • Energy supplies out for 2 weeks
  • 3 million fines compensation
  • 500 million law suit for lost revenue.
  • 2 workers died

4
Firestone tyre recall (2000)
  • Firestone recalls 10 x 106 tyres in 2000
  • Tread separation causes rollover accidents
  • 40 80 deaths attributed to bad design
  • Lost sales 350 million
  • Fines 41 million
  • Ford cancels contract

5
Concorde crash (2000)
  • Concorde crashed on take-off
  • 113 people died
  • Debris on runway punctured tyre, chunks of rubber
    punctured fuel tank
  • Fire caused loss of power

6
World Trade Center (2001)
  • Two fuel-laden jets crashed into WTC towers
  • Fire caused support structure to fail
  • Towers collapsed
  • 2,792 people died

7
Power Outage North America (2003)
  • power overload caused supply to fail
  • chain reaction caused power loss in eastern US
    and Canada.
  • 50 million without power
  • Responsibility? Costs?
  • Auckland CBD lost power on/off
  • for two months in 1998

8
Engineers what role in safety?
  • Engineers solve problems
  • The cause of all problems are solutions
  • Engineers cause a lot of problems?
  • NO!
  • Engineers very good at preventing disasters

9
Engineers vs Doctors
  • Engineers try to fence off the top of the cliff
  • Doctors wait at the bottom of the cliff

10
Engineering versus other careers
  • All professional careers can affect peoples lives
  • Commerce ? large scale redundancy
  • Law ? innocent people to jail
  • Medicine ? misdiagnosis

11
Engineering activities in safety
  • Find the problem
  • What will explode? What part will fail? How much
    force on impact?
  • Measure the problem
  • Determine probability that part fails alarm
    fails
  • Toxic gas released ? how many people exposed?
  • Solve the problem
  • New designs
  • New procedures

12
Safety Goals
  • Prevent
  • Death/injury to workers
  • Death/injury to the general public
  • Damage to facilities
  • Damage to surrounding property
  • Damage to the environment

13
Key Definitions
  • Hazard physical situation that can damage
  • people
  • plant
  • environment
  • Risk likelihood of hazard occurring
  • Risk hazard probability consequence

14
Risk hazard probability consequence
  • Flammable solvent vs nonflammable solvent
    different hazard level
  • Bridge over a 5 meter gorge vs 30 m gorge
    different hazard level
  • In both cases risk is lowered
  • by removing or lowering hazard

15
Risk hazard probability consequence
  • Dangerous chemical reactor is completely
    automated.
  • no risk to workers
  • risk to neighbours?
  • risk to equipment?
  • risk to environment?
  • Ladder example

Same hazard, same probability, different
consequences
16
Risk hazard probability consequence
  • Virtually no activity is risk free!
  • Cant eliminate all hazards
  • Cant make probability zero
  • Cant eliminate all consequences
  • As long as all three components exist,
  • risk exists!

17
Risk
  • Engineers decrease risk by
  • Identify/eliminate hazards
  • Estimate/lower probability
  • Estimate/lower consequence
  • When is risk low enough?

18
Risk
  • What is acceptable risk?
  • societal/political decision
  • engineers identify, calculate, lower risk
  • society decides acceptable level of risk
  • Problem 1 Not everyone realises risk ? 0
  • 2 Public perception depends on
    situation

19
Risk acceptable levels
  • Public perception of risk depends on a number of
    features
  • Control individual control, avoidable,
    survivable
  • Knowledge understanding, observable, familiar
  • Magnitude number of people exposed
  • Others factors

20
Unknown risk
controllable risk
uncontrollable risk
Known risk
21
Magnitude
  • 7 people died in the Challenger Space Shuttle
  • 113 died in the Concord crash
  • 2792 died in 9/11
  • About 1.2 people die in each fatal car crash
  • 400 000 people die in car crashes worldwide each
    year

22
Estimate risk (numerical)
  • Fatal Accident Rate (FAR)
  • FAR deaths/1000 people/105 hours
  • 105 hours ? lifetime ? 35 years (8 hr day)

23
FAR example
  • How dangerous is being an engineering student?
    Over the last 10 yrs we have had 22 deaths
  • 1 death ? terrible hacky sack injury
  • 3 deaths ? American lecturer shot rude students
  • 1 death ? sleeping student fell off chair
  • 2 deaths ? engineering cafeteria food poisoning
  • 15 deaths ? listening to boring lectures

24
FAR example
  • 22 deaths over 10 yrs
  • 900 students/yr 9,000 students total
  • Death rate 22 deaths/9,000 students/10 years
  • Death rate 0.000244 deaths/student/yr
  • FAReng 0.000244 1000 people 35 years
  • FAReng 8.6

25
FAR
  • Simple measure of safety
  • Historical analysis of industry or activity
  • Prediction tool
  • Estimate FAR for building a new bridge
  • Compare estimate to bridge building industry
    average

26
Estimate risk (numerical)
  • Fatal Accident Rate (FAR)
  • FAR deaths/1000 people/105 hours
  • 105 hours ? lifetime ? 35 years (8 hr day)

27
FAR Rock climbing
  • FAR 4,000
  • per 1,000 people for 35 yrs
  • People that fall are replaced

28
FAR Rock climbing
  • 100 people in a climbing club spend 10 days/yr at
    6 hrs/day climbing, 1 person dies over 5 yrs
  • 10 days/yr 6 hrs/day 5 yrs 300 hrs
  • Death rate 1 deaths/(300 hrs 100 people)
  • 0.000033 deaths/person-hr
  • Far Death rate 1000 people 105 hrs
  • 3,333

29
Risk Reduction (for discussion)
  • Travelling by plane is more hazardous than by
    car.
  • Travelling by car is riskier than by plane.

30
Traveling is more hazardous by plane than by car.
  • Planes
  • 13,000 meters
  • 1,000 km/hr
  • Low temp. pressure
  • 200 400 people
  • 100,000 200,000 liters of fuel
  • Cars
  • Ground level
  • 100 km/hr
  • normal temp press.
  • 1 6 people
  • 40 80 litres of fuel

31
Traveling by car is riskier than by plane.
  • Planes
  • High quality parts
  • High redundancy
  • 2 engines, 2 pilots, etc
  • Many safety devices
  • Sensors, alarms
  • High maintenance
  • Cars
  • The Warehouse
  • Little redundancy
  • 1 engine, 1 driver, etc.
  • Some safety devices
  • Sensors, alarms
  • Maintenance?

32
Traveling by car is riskier than by plane.
  • Planes
  • Preflight checklist
  • Airport design
  • Traffic control
  • Air traffic controllers
  • Training
  • Flight simulators
  • Pilot licence
  • Cars
  • Predriving checklist(?)
  • Parking lot design
  • Traffic control
  • Traffic lights
  • Training
  • PlayStation/Xbox
  • Watching Mum or Dad
  • Car licence

33
Planes versus Cars The risk?
  • FARCar 30 FARPlane 40
  • Risk per 109 km
  • RiskCar 4.4 RiskPlane 0.2
  • www.rvs.uni-bielefeld.de/publications/Incidents/DO
    CS/Research/Rvs/
  • Article/probability.html
  • NZ risk about 10 per 109 km

34
Risk Reduction Strategies
  • Procedural (people activities)
  • procedures, alarms, training
  • Active (automatic devices)
  • switches, relief valves, auto-shutdown, sprinkler
    systems
  • Passive (no moving parts)
  • Stronger fuel tank, less fragile heat tiles
  • Inherent (fundamental hazard)
  • ground travel instead of flying, water instead of
    toluene
  • Simplify process

35
Summary
  • Safety - prevent damage to
  • People ? Equipment ? Environment
  • Risk hazard probability consequence
  • identify haz. ? measure prob/conseq. ? design
    solut.
  • Engineers lower risk
  • Society decides acceptable level
  • Risk reduction
  • procedural ? active ? passive ?
    inherent
