Frequent Itemsets Mining for Database autoadministration

1
Frequent Itemsets Mining for Database
auto-administration
International Database EngineeringApplications
Symposium
2
Plan

• Introduction
• State of the art
• Our proposal
• Experiment results
• Conclusion and perspectives

3
Introduction

• Database administration
• Definition of conceptual schema
• Definition of files and disc storage
• Data access optimization (creation of indexes and
  materialized views)
• Minimize and automate the administration
  functions
• Auto-select indexes
• Using data mining (frequent itemsets)

4
State of the art

• Frank et al., 1992 (Georgia Tech)
• Construction of an index graph based on a
  workload
• Dialogue with the query optimizer ? index cost
• Choice of the least expensive indexes for the
  workload
• Chaudhuri et al., 1997-2001 (Microsoft)
• Selection of indexable attributes based on a
  workload
• Construction of mono and multi-attribute
  configuration
• Dialogue with the query optimizer ? configuration
  cost
• Choice of the optimal configuration
• Brunel, Rollin et al., 2001 (Lyon 2 - Oklahoma)
• Based on the work of Frank et al.
• First work about the extraction of workload
  characteristics

5
Log file of transactions
Log file extraction
SQL query syntactic analyzer
Ensemble dattributs candidats
Construction of the Queries-attributes matrix
Queries-attributes matrix
Frequent Itemsets search
Database and workload
Set of frequent itemsets
Candidate indexes
Index construction
6
Queries-attributes matrix

• For each query within the workload? extract
  attributes present on the clauses
• Where
• Group by
• Order By

Xij 1 if the attribute j appears in the clauses
of the query i Xij 0 in the other case
7
Example
Q1 Select from T1, T2 where A between 1 and
10 And C D Q2 Select from T1, T2 where B
like sample and C 5 and E lt 100 Q3 Select
from T1, T2 where A 30 and B gt 3 group by C
Having Sum(E) gt 2 Q4 Select from T1 where B
gt 2 and E in (3,2,5) Q5 Select from T1, T2
where A 30 and B gt 3 group by C Having Sum(E) gt
2 Q6 Select from T1, T2 where B gt 3 group by
C Having Sum(E) gt 2
Application of Close with a minimal support
minsup 2/6
8
Indexes construction

• Building all indexes
• For each frequent itemset corresponds an index
• This method is feasible when the number of
  indexes is relatively small
• Building indexes on large tables
• Reduce the number of indexes to build
• The DBA defines whether a table is large or not

9
Database experiments

• TPC-R Database
• Transaction Processing Council
• Decision support benchmark TPC-R
• 8 Tables
• Size 1 GB
• Accidentology Data Mart
• BDD research group (ERIC)
• One Fact table Accident and 4 Dimension tables
  Place, Date, Condition and PersonResponsible
• 65 000 Records

10
TPC-R results- All indexes
11
TPC-R results - Indexes on large tables
12
Data Mart results
13
Conclusions

• Use of data mining to determine an index
  configuration
• Mono et multi-attribute indexes are generated on
  the fly
• Response time improvements of 20 to 25 for
  decision support worklod (TPC-R)
• Response time improvements is about 14

14
Perspectives

• Improve index selection by designing more
  elaborated strategies (cost model, weighting the
  workloads queries
• Tests on large data warehouses
• Comparison with the Microsoft technique (query
  optimizer vs. frequent itemsets)
• Extending or coupling our approach with other
  performance optimization (materialized views,
  physical clustering, ...)
• Exploit other data mining algorithms (functional
  dependencies or inclusion dependencies)
