XML DATABASES

1
XML DATABASES
2
Acknowledgement

• Some of the work is taken from various members
  of EXEL Research Group at Faculty of IT, UTS
  (http//exel.it.uts.edu.au/)
• Mr Rajugan Rajagopalapillai
• Prof. Tharam S. Dillon
• Dr. Wenny Rahayu (La Trobe University)
• Mr. Torab Torabi (La Trobe University)

3
WEB Databases

• There are two most important framework where web
  databases are needed
• Intensive Data-driven Web Applications - eg.
  student enrolment system, student timetable
  allocation, etc.).
• Intensive Document-driven Web Applications eg.
  on-line business transactions and contracts.
• In this lecture, we will go through basic Web DB
  architecture, and example of three common types
  of Web DB application
• Web Content Management
• E-Commerce Database Management
• XML Database Management

4
WEB Databases - Architectures

• Architecture 1
• Web Browser -gt HTML pages -gt Script Files
  Embedded SQL -gt middleware eg. JDBC, ODBC -gt
  Database
• Architecture 2
• Web Browser -gt HTML pages calls to C or Java
  routine or Active X controls -gt compiled modules
  -gt middleware -gtDatabase
• Architecture 3
• Web Browser -gt Application Server (Oracle Forms
  and Reports, ASP, Scripts, middleware) -gt Database

5
WEB Databases - Architectures (ctd.)

• The three different architectures mentioned in
  the previous slide are generic categories. We can
  easily combine a number of different
  architectures to set up our own web-database
  systems.
• These days, we can see more of Architecture type
  3 made available by software/database industry
  (eg. Oracle 8i/9i, Cold Fusion, etc.). This type
  of architecture hides a lot of the complexity of
  web-database set up into the application layer.

6
Example Application 1 Web Content Management
using Oracle WebDB - Content Management
HTTP Client(s) Developer(s) Administrator(s)
Application Server (Remote Server) Web Server
(OAS, Apache) WebDB Listener
Internet
Internet
HTTP Client(s)
HTTP Client(s)
DB Server
Slide generated by R.Rajugan, Oracle Web DB,
2000
7
Web Content Management

• The concept of consolidating web contents into a
  repository or a database system.
• This new concept of using databases to power web
  sites is gaining popularity due to many benefits
  it provides in managing unstructured data under a
  structured framework.
• For example, Oracle cut 1 billion in costs by
  consolidating contents from more than 40 regional
  Web sites
• In Web Content Management, a web page is divided
  into several sections (called web-assets). These
  web-assets may include page header, page footer,
  menu items, icons/images, and block contents.
• Each web asset will have its own set of
  attributes, eg. Colours, size, etc.
• Web assets are stored in a DBMS following a
  structural design.

8
Web Content Management (example from Managing
Web Content from File system to Database, Oracle,
2000)
9
Example Application 2 A three-tier Web and
E-Commerce architecture
Incoming internet request
Web servers in web server layer
E-Commerce servers in Mid-Tier layer
Catalog database
Application server in Back-end layer
ERP or Mainframe with inventory data
10
A three-tier Web and E-Commerce architecture (ctd)

• Web server layer web servers route we requests
  to e-commerce servers and assemble returned data
  into web pages for clients.
• Mid-tier layer e-commerce servers do the hard
  work of authenticating users, generating
  transactions, and retrieving data from back-end
  systems.
• Catalog databases hold specifications of
  products that can be ordered.
• Back-end layer ERP (Enterprise Resource
  Planning) such as SAP or Mainframe applications
  hold back-end inventory database.

11
Database Driven E-Catalog (based on Sherif
Danish, ACM Sigmod Record Special Section on
E-Com 274 December 1998)

• Creation of a product information database in the
  enterprise (see catalog database in middle-tier
  layer from previous slides), and using this
  database as a foundation for deploying an
  electronic catalog.
• Motivation we cant simply use memo or BLOB type
  to store unstructered data for a catalog. Hence,
  a new method of storing catalog is needed.

Structured Catalog Database
Paper catalog
12
Database Driven E-Catalog - ctd. (based on Sherif
Danish, ACM Sigmod Record Special Section on
E-Com 274 December 1998)

• Implementation issues
• Generic Model contains attributes in the form of
  name/value pairs. This form allows storage of
  attributes for any product type in the same
  table.

13
Database Driven E-Catalog - ctd. (based on Sherif
Danish, ACM Sigmod Record Special Section on
E-Com 274 December 1998)

• Implementation issues
• Multiple Language attributes are stored in coded
  name/value pairs, attribute name codes are then
  represented in different languages in a separate
  table. Attribute value codes are translated in a
  similar table.

14
Current Research on Database Support for
E-Commerce (based on Martin Birchler et al, ACM
Sigmod Record Special Section on E-Com 274
December 1998)

• New Roles of DB Management Systems traditional
  database applications vs. component-based
  software engineering
• XML based document databases finding the best
  solution for storing XML documents
• Database support for large scale repositories of
  business process components such as a data
  warehouse issues of data warehouse for
  documents.

15
Example Application 3 XML Database Management

• XML (eXtensible Markup Language) is a document
  description meta language that is used to
  represent large-scale data and documents in the
  World Wide Web
• XML enables information exchange and
  interoperability between applications
• In the last few years researchers have
  investigated the best database storage for XML
  Document Management

16
XML Background and Overview

• XML is designed to
• separate syntax from semantics to provide a
  common framework for structuring information
• allow tailor-made markup for any imaginable
  application domain

17
Current XML Technologies
XML Background and Overview

• XML Schema is used to define the structure of the
  XML documents
• XSL (eXstensible Stylesheet Language) and CSS
  (Cascading Style Sheet) are used to display XML
  documents
• XSLT is used to transform the XML document into
  XHTML (or HTML) or plain text, including
  automatic construction of index, references, etc.
  XSLT is a subset of XSL. It is mainly used to
  perform data extraction, sorting and
  restructuring of XML documents

18
Current XML Technologies
XML Background and Overview

• XPath is a querying language that allows
  retrieval of specified parts of an XML document
  (e.g. all article titles with the abstract and
  section titles).
• XQuery will be used to express queries on XML
  documents (SQL for XML).

19
XML Document Example
XML Background and Overview

• lt?xml version1.0 encodingISO-8859-1?
  standaloneyes
• lt?xml-stylesheet typetext/css
  hrefgreeting.css?gt
• ltdocument_taggt
• ltsection_taggtsectioncontentlt/section_taggt
• ltsubsection_taggtsubsection content
• lt/subsection_taggt
• lt/document_taggt
• lt!--this is a template XML Document-gt

EPILOG Comment
20
XML Elements Example
XML Background and Overview

• ltbookgt
• lttitlegtMy First XMLlt/titlegt
• ltprod id"33-657" media"paper"gtlt/prodgt
• ltchaptergtIntroduction to XML
• ltparagtWhat is HTMLlt/paragt
• ltparagtWhat is XMLlt/paragt lt/chaptergt
• ltchaptergtXML Syntax
• ltparagtElements must have a closing taglt/paragt
• ltparagtElements must be properly nestedlt/paragt
• lt/chaptergt
• lt/bookgt

Elements
21
XML Schema Basics
XML Background and Overview

• Schema refers to the structure of data
• Builds a data model
• Inherently defines structure and relationships
  between data
• Readable by both people and machines

22
Why Schemas Are Important?
XML Background and Overview

• Provide standard structures for data exchange
• Provide constraints for testing document validity
• Help manage integration of documents and data
• Framework for both document and data structures
• Help separate parts of documents for intelligent
  search/manipulation

23
XML Document Example personxml.xml
XML Background and Overview

• lt?xml version"1.0" encoding"UTF-8"?gt
• lt?xml-stylesheet type"text/xsl"
  href"personxsl.xsl"?gt
• ltPersonInfo xmlnsxs"http//www.w3.org/2001/XMLSc
  hema" xsschemaLocation"personxmlschema.xsd"gt
• ltPersongt
• ltnamegtLee Cottrelllt/namegt
• ltaddressgt123 Herelt/addressgt
• ltcitygtMelbournelt/citygt
• ltgendergtFlt/gendergt
• lt/Persongt
• ltPersongt
• ltnamegtDavid Schmidtlt/namegt
• ltaddressgt707 Therelt/addressgt
• ltcitygtSydneylt/citygt
• ltgendergtMlt/gendergt
• lt/Persongt
• lt/PersonInfogt

24
XML Schema Example personxmlschema.xsd
XML Background and Overview

• ltxsdschema xmlnsxsd"http//www.w3.org/2001/XMLS
  chema" version"1.0"gt
• ltxsdelement name"PersonInfo"gt
• ltxsdcomplexTypegt
• ltxsdelement name"Person"gt
• ltxsdcomplexTypegt
• ltxsdsequencegt
• ltxsdelement name"name"
  type"xsdstring" maxOccurs"1" minOccurs"1" /gt
• ltxsdelement name"address"
  type"xsdstring" maxOccurs"unbounded"
  minOccurs"0" /gt
• ltxsdelement name"city"
  type"xsdstring" maxOccurs"unbounded"
  minOccurs"0" /gt
• ltxsdsimpleType name"gender"gt

25
XML Schema Example (cont)
XML Background and Overview

• ltxsdrestriction
  base"xsdstring"gt
• ltxsdenumeration value"M" /gt
• ltxsdenumeration value"F" /gt
• lt/xsdrestrictiongt
• lt/xsdsimpleTypegt
• lt/xsdsequencegt
• lt/xsdcomplexTypegt
• lt/xsdelementgt
• lt/xsdcomplexTypegt
• lt/xsdelementgt
• lt/xsdschemagt

26
XSL Example personxsl.xsl
XML Background and Overview

• ltxslstylesheet version"1.0" xmlnsxsl"http//ww
  w.w3.org/TR/WD-xsl"gt
• ltxsltemplate match"/"gt
• lthtmlgt
• ltheadgt
• lttitlegtThis is the person pagelt/titlegt
• lt/headgt
• ltbodygt
• lth1gtPerson Databaselt/h1gt
• ltpgtThis simply displays the data on the page with
  some formattinglt/pgt
• lttable border"1"gt
• lttrgt
• ltthgtNamelt/thgt
• ltth colspan"2"gtAddresseslt/thgt

27
XSL Example (cont)
XML Background and Overview

• ltth colspan"2"gtCitylt/thgt
• ltthgtGenderlt/thgt
• lt/trgt
• ltxslfor-each select"PersonInfo/Person"gt
• lttrgt
• lttdgtltbgtltigtltxslvalue-of select"name"/gtlt/igtlt/bgtlt/
  tdgt
• lttdgt
• ltxslfor-each select"address"gt
• lttdgt
• ltxslvalue-of select"."/gt
• lt/tdgt
• lt/xslfor-eachgt
• lt/tdgt

28
XSL Example (cont)
XML Background and Overview

• lttdgt
• ltxslfor-each select"city"gt
• lttdgt
• ltxslvalue-of select"."/gt
• lt/tdgt
• lt/xslfor-eachgt
• lt/tdgt
• lttdgtltbgtltigtltxslvalue-of select"gender"/gtlt/igtlt/bgt
  lt/tdgt
• lt/trgt
• lt/xslfor-eachgt
• lt/tablegt
• lt/bodygt
• lt/htmlgt
• lt/xsltemplategt
• lt/xslstylesheetgt

29
The output (XML-XMLSchema-XSL)
XML Background and Overview
30
Different Storage for XML

• There are several options for XML repository,
  from file system to the Native XML database
• There are also products that utilize their mature
  DBMS technology with some adjustment to
  facilitate XML. This product can be categorized
  as XML-Enabled database, eg. Oracle9i

31
XML Relational Data in Oracle

• Oracle Database is originally a pure RDBMS. Since
  Oracle8i, the database has shifted to become an
  ORDBMS. The generation of Oracle9i and above aims
  to become an XML-enabled DBMS
• To achieve full integration of XML and
  (object-)relational data, two aspects of
  functionality need to be addressed by Oracle
• From a data storage perspective, both XML and
  relational data should be supported in the same
  database
• From a query language perspective, both SQL-based
  and XML-based query should be available

32
Storing XML in Oracle9i

• Oracle strategy for XML storage will depend on
  the nature of the XML document
• For data-centric, the XML documents can be stored
  in one or more tables
• For document-centric, Oracle original solution is
  by storing the document in unstructured LOBs
  (Large Objects)
• A newer approach is by introducing XMLType from
  Oracle 9i onward

33
Storing XML in Oracle9i - 2
34
Processing XML Document Oracle Storage

• Regardless of how Oracle stores the XML document,
  they have some basic components below

XML Documents
Oracle Text Cartridge
Oracle XML Parser
Oracle Database
Oracle XML SQL Utility
Oracle XPath Engine
XML Infoset
Oracle XSLT Processor
35
Data-Centric in Relational Tables

• Oracle stores the data-centric XML elements into
  Object-Relational (OR) tables and columns,
  including as the collection, nested table, object
  types, and other Oracle OR features
• Once stored in the OR form, the data can be
  easily updated, queried, rearranged and
  reformatted as needed using SQL
• The capability for viewing XML data as relational
  data is useful to maximize the applicability of
  relational technology and tools for data mining,
  analysis, report generation, etc

36
XML SQL Utility (XSU)

• The mapping process is enabled by Oracle XML SQL
  Utility (XSU)
• XSU
• accepts the application queries, passing them to
  the database and returning the resulting data in
  an XML format corresponding to the database
  schema of the query
• accepts an XML Document conformant to the
  database schema and save the data untagged in the
  database across this schema
• creates the DTD/XML Schema that represents the
  queried database schema
• XSU installation requires the following
  components
• Database connectivity JDBC driver
• XML Parser Oracle XML Parser version2 (comes
  with Oracle 8i and 9i)
• XSU comes with a simple command line front end
  which gives you quick access to XML generation
  and insertion.

37
Mapping XML Data and OR Features

• This option maps an XML Document to the
  underlying OR storage and conversely provides the
  capability to retrieve the OR data as an XML
  document
• The basis for both direction is a schematic
  mapping from relational structure to XML.
• The whole query results is enclosed by
  ltROWSETgtlt/ROWSETgt
• Each tuple of the result is put in ltROWgt lt/ROWgt
• Attribute values turn into tags ltNamegtlt/Namegt
• Object types becomes inner tags according to the
  internal structure
• Collection has it name as the tag to encloses the
  collection value

38
Mapping XML Data and OR Features -2

• Sample Object-Relational tables
• CREATE TYPE AddressType AS OBJECT
• ( STREET VARCHAR2(20),
• CITY VARCHAR2(20),
• STATE CHAR(2),
• ZIP VARCHAR2(10) ) /
• CREATE TYPE EmployeeType AS OBJECT
• ( EMPNO NUMBER,
• ENAME VARCHAR2(20),
• SALARY NUMBER,
• EMPADDR AddressType
• )
• /
• CREATE TYPE EmployeeListType AS TABLE OF
  EmployeeType
• /

39
Mapping XML Data and OR Features - 3

• Sample Object-Relational tables (ctd)
• CREATE TABLE dept
• (DEPTNO NUMBER,
• DEPTNAME VARCHAR2(20),
• DEPTADDR AddressType,
• EMPLIST EmployeeListType )
• NESTED TABLE EMPLIST STORE AS EMPLIST_TABLE
• Assume that valid values are stored in table dept
  above.
• For the query
• select from dept
• XSU generates the following XML document

40
Mapping XML Data and OR Features - 4

• lt?xml version'1.0'?gt
• ltROWSETgt
• ltROW num"1"gt
• ltDEPTNOgt100lt/DEPTNOgt
• ltDEPTNAMEgtSportslt/DEPTNAMEgt
• ltDEPTADDRgt
• ltSTREETgt100 Redwood Shores Pkwylt/STREETgt
• ltCITYgtRedwood Shoreslt/CITYgt
• ltSTATEgtCAlt/STATEgt
• ltZIPgt94065lt/ZIPgt
• lt/DEPTADDRgt
• ltEMPLISTgt
• ltEMPLIST_ITEM num"1"gt
• ltEMPNOgt7369lt/EMPNOgt
• ltENAMEgtJohnlt/ENAMEgt
• ltSALARYgt10000lt/SALARYgt
• ltEMPADDRgt
• ltSTREETgt300 Embarcaderolt/STREETgt
• ltCITYgtPalo Altolt/CITYgt

41
XML Query Example

• ltPROTEIN xmlnssql"urnschemas-microsoft-comxml-
  sql"gt
• ltsqlheadergt
•   ltsqlparam name"DatabaseEntryValue"gtpmap1lt/sq
  lparamgt
•   lt/sqlheadergt
•   ltsqlquerygtSELECT FROM DatabaseEntry WHERE
  ENTRYID _at_DatabaseEntryValue FOR XML AUTO
• SELECT FROM Entry WHERE ENTRYID
  _at_DatabaseEntryValue FOR XML AUTO, ELEMENTS
• SELECT FROM Compounds WHERE ENTRYID
  _at_DatabaseEntryValue FOR XML AUTO, ELEMENTS
• SELECT FROM Source WHERE ENTRYID
  _at_DatabaseEntryValue FOR XML AUTO, ELEMENTS
• lt/sqlquerygt
• lt/PROTEINgt

42
Mapping XML Data and OR Features - 5

• Using the above technique, we can use regular SQL
  expressions for insert, update, and delete in
  order to modify the data in the database. All
  these changes will be reflected in the XML
  document when retrieved using the XSU component.
• For more examples, you can refer to the online
  oracle documentation.
