Reasoning

1
Reasoning

• Shyh-Kang Jeng
• Department of Electrical Engineering/
• Graduate Institute of Communication Engineering
• National Taiwan University

2
References

• J. P. Bigus and J. Bigus, Constructing
  Intelligent Agents with Java, Wiley Computer
  Publishing, 1998
• S. Russell and P. Norvig, Artificial
  Intelligence A Modern Approach, Englewood
  Cliffs, NJ Prentice Hall, 1995

3
Goal-Based Agents
Sensors
Environment
State
Environment Model
Options
Decision Maker
Goals
Agent
Effectors
4
Knowledge-Based Agents
Sensors
Environment
Knowledge Base Management System
Knowledge Base
Agent
Effectors
5
Knowledge Base

• A set of representation of facts about the world
• Each individual representation is a sentence
• Sentences are expressed in a knowledge
  representation language
• Knowledge representation languages are composed
  of symbols
• Representation and reasoning support the
  operation of a knowledge-based agent, accessed
  through a knowledge base management system (KBMS)

6
General Knowledge-Based Agent (1)

• class KBAgent
• KnowledgeBase kb
• KBMS kbms
• counter t // indicating time
• public KBAgent()
• kb new KnowledgeBase()
• kbms new KBMS( kb )
• t 0

7
General Knowledge-Based Agent (2)

• public Action run(Percept percept)
• kbms.tell(new
• PerceptSentence(percept, t))
• Action action kbms.ask( new
• ActionQuery(t) )
• kbms.tell( new
• ActionSentence(action,t) )
• t return action

8
Rule-Based System

• Rule-basde processing system
• Rule base
• Working memory
• Inference engine
• Rules
• Antecedent clauses
• Consequent clauses
• Trigger or ready to fire
• Sensors and effectors
• Retractions

9
Vehicles Rule Bases (1)

• Bicycle IF vehicleType cycle
• AND num_wheel 2
• AND motor no
• THEN vehicle Bicycle
• Tricycle IF vehicleType cycle
• AND num_wheel 3
• AND motor no
• THEN vehicle Tricycle

10
Vehicles Rule Bases (2)

• Motorcycle IF vehicleType cycle
• AND num_wheel 2
• AND motor yes
• THEN vehicle Motorcycle
• SportsCar IF vehicleType automobile
• AND size small
• AND num_doors 2
• THEN vehicle Sports_Car

11
Vehicles Rule Bases (3)

• Sedan IF vehicleType automobile
• AND size medium
• AND num_doors 4
• THEN vehicle Sedan
• MiniVan IF vehicleType automobile
• AND size medium
• AND num_doors 3
• THEN vehicle MiniVan

12
Vehicles Rule Bases (4)

• SUV IF vehicleType automobile
• AND size large
• AND num_doors 4
• THEN vehicle Sports_Utility_Vehicle
• Cycle IF num_wheelslt4
• THEN vehicleType cycle
• Automobile IF num_wheels 4
• AND motor yes
• THEN vehicleType automobile

13
Forward-Chaining Reasoning

• Load rule base to the inference engine, and any
  facts from the knowledge base into the working
  memory
• Match the rules to obtain the conflict set
• Use the conflict resolution procedure to select a
  single rule from the conflict set
• Fire the selected rule
• Repeat steps 2,3,4 until the conflict set is empty

14
Conflict Resolution Alternatives

• Select the first rule
• Select the rule with the highest specificity or
  number of antecedent clauses
• Select the rule that refers to the data which has
  changed most recently
• If the rule has fired on the previous cycle, do
  not add it to the conflict set
• In case where there is a tie, select a rule
  randomly from this subset of the original
  conflict set

15
A Forward-Chaining Example (1)

• Data in working memory
• num_wheel 4
• motor yes
• num_doors 3
• size medium
• Trigger rule Automobile
• Conflict set rule Automobile
• Fire rule Automobile

16
A Forward-Chaining Example (2)

• Data in working memory
• num_wheels 4
• motor yes
• num_doors 3
• size medium
• vehicleType automobile
• Trigger rule MiniVan
• Conflict set rule MiniVan
• Fire rule MiniVan

17
A Forward-Chaining Example (3)

• Data in working memory
• num_wheels 4
• motor yes
• num_doors 3
• size medium
• vehicleType automobile
• vehicle MiniVan
• Trigger rule MiniVan
• Not added to the conflict set
• Conflict set is empty

18
Forward-Chaining vs. Backward-Chaining Reasoning

• Forward-chaining
• Used to produce new information
• Backward-chaining
• Used to answer questions about whether a goal
  clause is true or not
• Goal-directed inferencing
• More focused

19
Backward-Chaining Reasoning (1)

• Load the rule base into the inference engine, and
  any facts from the knowledge base into the
  working memory
• Specify a goal variable for the inference engine
  to find
• Find the set of rules which refer to the goal
  variable in a consequent clause. Put each rule
  on the goal stack
• If the goal is empty, halt
• Take the top rule off the goal stack

20
Backward-Chaining Reasoning (2)

• 6. For each antecedent clause
• If the clause is true, go on to the next
  antecedent clause
• If the clause is false, pop the rule off the goal
  stack and go to step 4
• If the truth value is unknown, go to step 3, with
  the antecedent variable as the new goal variable
• If all antecedent clauses are true, fire the
  rule, setting the consequent variable to the
  consequent value, pop the rule off the goal
  stack, and go to step 4

21
A Backward-Chaining Example (1)

• Query vehicle MiniVan?
• Working memory empty
• Goal stack (vehicle, rule Minivan)
• Antecedent vehicleType automobile?
• Goal stack (vehicleType, rule Automobile),
• (vehicle, rule MiniVan)
• Antecedent num_wheels 4?
• No rules that have num_wheels 4 as a
  consequence

22
A Backward-Chaining Example (2)

• Ask the user to obtain that num_wheels 4
• Working memory
• num_wheels 4
• Antecedent motor yes?
• Ask the user to know that motor yes
• Working memory
• num_wheels 4
• motor yes

23
A Backward-Chaining Example (3)

• Fire and pop off rule Automobile
• Working memory
• num_wheels 4
• motor yes
• vehicleType automobile
• Goal stack (vehicle, rule MiniVan)
• Antecedent size medium?

24
A Backward-Chaining Example (4)

• Ask the user to find size medium
• Working memory
• num_wheels 4
• motor yes
• vehicleType automobile
• size medium
• Antecedent num_doors 3?
• Ask the user to know num_doors 3
• Fire and pop off rule MiniVan
• vehicle MiniVan

25
RuleBase Test
26
Class Diagram of RuleBase
RuleBase
Rule
RuleVariable
Clause
Condition
27
Class RuleBase Fields

• String name
• HashMap variableList
• Clause clauseVarList
• ArrayList ruleList
• ArrayList conclusionVarList
• Rule rulePtr
• Clause clausePtr
• Stack goalClauseStack

28
Some Class RuleBase Methods

• public void reset()
• public void forwardChain()
• public ArrayList match()
• // determine which rules can fire
• public Rule selectRule()
• // select a rule to fire based on
• // specificity
• public void backwardChain()

29
Method RuleBase.forwardChain()

• public void forwardChain()
• ArrayList conflictRuleSet new
• ArrayList()
• conflictRuleSet match(true)
• while( conflictRuleSet.size() gt 0 )
• Rule selected
• selectRule(conflictRuleSet)
• selected.fire()
• conflictRuleSet match(false)

30
Method RuleBase.backwardChain() (1)

• public void backwardChain(
• String goalVarName)
• RuleVariable goalVar (RuleVariable)
• variableList.get(goalVarName)
• ListIterator goalClauses
• goalVar.clauseRefs.listIterator()
• while(goalClauses.hasNext())
• Clause goalClause (Clause)
• goalClauses.next()
• if( !goalClause.isConsequent )
• continue
• goalClauseStack.push(goalClause)

31
Method RuleBase.backwardChain() (2)

• Rule goalRule goalClause.getRule()
• Boolean ruleTruth goalRule.backChain()
• if( ruleTruth null )
• // can't determine truth value
• else if( ruleTruth.booleanValue()
• true )
• // rule is OK, assign consequent
• // value to variable
• goalVar.setValue(goalClause.rhs)
• goalVar.setRuleName(goalRule.name)
• goalClauseStack.pop()

32
Method RuleBase.backwardChain() (3)

• if(goalClauseStack.empty())
• //Found Solution for goal
• break
• else
• // clear item from subgoal stack
• goalClauseStack.pop()
• if(goalVar.value null)
• //Could Not Find Solution for goal

33
Class Rule Fields

• RuleBase rb
• String name
• Clause antecedents
• Clause consequent
• Boolean truth
• // states null(unknown),
• // true or false
• boolean fired false

34
Some Class Rule Methods

• Boolean check()
• // check if antecedent is true and // rule has
  not fired
• void fire()
• public static void checkRules
• // a variable value was found, so
• // reset all clauses
• // that reference that variable,
• // and then all rules which
• // reference those clauses
• Boolean backChain()

35
Method Rule.BackChain() (1)

• Boolean backChain()
• for(int i0 iltantecedents.length i)
• if(antecedentsi.truth null)
• rb.backwardChain(
• antecedentsi.lhs.name)
• if(antecedentsi.truth null)
• antecedentsi.lhs.askUser()
• truth antecedentsi.check()

36
Method Rule.BackChain() (2)

• if(antecedentsi.
• truth.booleanValue() true)
• continue
• else
• truth new Boolean(false)
• return truth
• truth new Boolean(true)
• return truth

37
Class Clause Fields

• ArrayList ruleRefs
• RuleVariable lhs
• Condition cond
• String rhs
• boolean isConsequent
• Boolean truth
• // states null(unknown), true or // false

38
Class Clause Methods

• Boolean check()
• // evaluate the truth value of the
• // clause
• Rule getRule()
• void setFlagConsequent()
• void addRuleRef()

39
Class Condition

• Fields
• int index
• String symbol
• // ,gt,lt,!
• Methods
• public String toString()

40
Class RuleVariable Fields

• String name
• String value
• ArrayList clauseRefs
• String promptString
• ArrayList labels

41
Class RuleVariable Methods

• void updateClauses()
• public String getName()
• public void setValue()
• String askUser()
• void addClauseRef()
• public void setPromptText()
• public ArrayList getLabels()
• public String getLabel()
• public String getLabelsString()
• int getIndex()

42
Initializing a RuleBase (1)

• Stack goalClauseStack rb.getGoalClauseStack()
• HashMap variableList rb.getVariableList()
• RuleVariable vehicle new RuleVariable("vehicle")

• vehicle.setLabels("Bicycle Tricycle MotorCycle
  Sports_Car Sedan MiniVan " "Sports_Utility_Vehic
  le")
• vehicle.setPromptText("What kind of vehicle is
  it?")
• variableList.put( vehicle.getName(), vehicle )
• . . . . . .

43
Initializing a RuleBase (2)

• Condition cEquals new Condition("")
• Condition cNotEquals new Condition("!")
• Condition cLessThan new Condition("lt")
• ArrayList ruleList rb.getRuleList()
• Rule bicycle new Rule( rb, "bicycle",
• new Clause(vehicleType, cEquals,
• "cycle"),
• new Clause(num_wheels, cEquals, "2"),
• new Clause(motor, cEquals, "no"),
• new Clause(vehicle, cEquals,
• "Bicycle") )
• . . . . . .

44
ForwardChain Demo

• HashMap variableList rb.getVariableList()
• ((RuleVariable) variableList.get("vehicle")).setVa
  lue(
• null)
• ((RuleVariable) variableList.get("vehicleType")).
• setValue(null)
• . . . . . .
• rb.displayVariables(logsArea)
• rb.forwardChain()
• rb.displayVariables(logsArea)

45
BackwardChain Demo

• HashMap variableList rb.getVariableList()
• ((RuleVariable) variableList.get("vehicle")).setVa
  lue(
• null)
• ((RuleVariable) variableList.get("vehicleType")).
• setValue(null)
• . . . . . .
• rb.displayVariables(logsArea)
• rb.backwardChain("vehicle")
• rb.displayVariables(logsArea)

46
Logics

• A logic consists of
• A formal system for describing states of affairs,
  consisting of the syntax and the semantics of the
  language
• A proof theory
• The ontological commitments of a logic have to do
  with the nature of reality in the related world
• The epistemological commitments of a logic have
  to do with states of knowledge an agent can have

47
Some Formal Languages
48
Propositional Logic Syntax

• Syntax in Backs-Naur Form (BNF)
• Example

49
Inference Rules (1)

• The soundness of an inference can also be
  established through truth tables
• Inference rules are some inference patterns that
  occur frequently
• Inference rules can be used to make inferences
  without going through the tedious process of
  building truth tables
• The inference rule that b can be derived from a
  is denoted as

50
Inference Rules (2)

• Conjunctions and conjuncts
• Disjunctions and disjuncts

51
Inference Rules (3)

• Modus Ponens or Implication-Elimination
• And Elimination

52
Inference Rules (4)

• And-Introduction
• Or-Introduction

53
Inference Rules (5)

• Double-Negation Elimination
• Unit Resolution

54
Inference Rules (6)

• Resolution
• b cannot be both true and false, one of the
  other disjuncts must be true in one of the
  premises
• Or, equivalently, implication is transitive

55
First-Order Logic Syntax
56
Inference Rules Involving Quantifiers (1)

• Substitution
• Example
• Universal Elimination

57
Inference Rules Involving Quantifiers (2)

• Existential Elimination
• Existential Introduction

58
An Example Proof (1)

• Situation
• The law says that it is a crime for an American
  to sell weapons to hostile nations. The country
  Nono, an enemy of America, has some missiles, and
  all of its missiles were sold to it by Colonel
  West, who is American
• To be proved
• West is a criminal

59
An Example Proof (2)

• Facts in first-order logic

60
An Example Proof (3)

• Proof

61
An Example Proof (4)
62
Proof as a Search Process

• Initial state Knowledge base
• Operators applicable inference rules
• Goal test Knowledge base containing the
  sentence to be proved
• The branching factor increases as the knowledge
  base grows
• Universal Elimination can have enormous branching
  factor on its own

63
Generalized Modus Ponens (1)

• And-Introduction, Universal Elimination, and
  Modus Ponens can be combined
• Example

64
Generalized Modus Ponens (2)

• There is a substitution q such that

65
Canonical Form

• Horn sentences
• Horn Normal Form
• A knowledge base consisting of only Horn
  sentences
• An inferencing mechanism with one inference rule,
  the generalized Modus Ponens, can be built

66
Unification

• A unification routine, UNIFY, takes two atomic
  sentences and returns a substitution that would
  make both sentences look the same, i.e.,
• Example

67
Standardize Apart

• Rename the variables of one or both sentences,
  when two sentences are being unified
• Example

68
Sample Proof Revisited (1)

• Facts

69
Sample Proof Revisited (2)

• Proof

70
Composition of Substitution

• Composition of substitution is the substitution
  whose effect is identical to the effect of
  applying each substitution in turn
• SUBST(COMPOSE(q1, q2), p)
• SUBST(q2, SUBST(q1, p))

71
Algorithm FORWARD-CHAIN(KB, p)

• If there is a sentence in KB that is a renaming
  of p then return
• Add p to KB
• For each in KB
• such that for some i, UNIFY(pi, p) q
• succeeds do

72
Algorithm FIND-AND-INFER(KB, premises,
conclusion, q)

• If premise then
• FORWARD-CHAIN(KB,
• SUBST(q,conclusion))
• else for each p in KB such that
• UNIFY(p,SUBST(q,FIRST(premises)))q2
• do
• FIND-AND-INFER(KB, REST(premises),
• conclusion, COMPOSE(q1, q2))

73
Example of Forward-Chaining (1)

• Knowledge base

74
Example of Forward-Chaining (2)

• FORWARD-CHAIN(KB,American(West))
• FORWARD-CHAIN(KB,Nation(Nono))
• FORWARD-CHAIN(KB,Enemy(Nono,America))
• FORWARD-CHAIN(KB,Hostile(Nono))
• FORWARD-CHAIN(KB,Owns(Nono,M1))
• FORWARD-CHAIN(KB,Missile(M1))
• FORWARD-CHAIN(KB,Sells(West, Nono, M1)
• FORWARD-CHAIN(KB,Missile(M1))
• FORWARD-CHAIN(KB,Weapon(M1))
• FORWARD-CHAIN(KB,Criminal(West))

75
Algorithm BACK-CHAIN(KB,q)

• BACK-CHAIN-LIST(KB,q,)

76
Algorithm BACK-CHAIN-LIST(KB, qlist, q) (1)

• answers empty
• If qlist is empty return q
• qFIRST(qlist)
• For each atomic sentence qi in KB such that
• qi UNIFY(q,qi ) succeeds do
• Add COMPOSE(q,qi) to answers

77
Algorithm BACK-CHAIN-LIST(KB, qlist, q) (2)

• 5. For each sentence
• in KB such that qi UNIFY(q,qi) succeeds do
• Return the union of

78
Proof Tree
Criminal(x)
Sells(West,Nono,M1)
American(x)
Yes, x/West
Weapon(y)
Hostile(Nono)
Owns(Nono,M1)
Missile(y)
Yes,
Yes, y/M1
Missile(M1)
Nation(z)
Enemy(Nono,America)
Yes,
Yes, z/Nono
Yes,
79
Incompleteness of Modus Ponens

• A proof procedure using Modus Ponens is
  incomplete
• Example We can not derive S(A) using chaining of
  Modus Ponens from the following knowledge base

80
Gödels Completeness Theorem

• For first-order logic, any sentence that is
  entailed by another set of sentences can be
  proved from that set
• In other words, a complete proof procedure can be
  generated to prove a sentence entailed by another
  set of sentences
• A such procedure is the resolution algorithm
  proposed by Robinson

81
Resolution

• Resolution
• b cannot be both true and false, one of the
  other disjuncts must be true in one of the
  premises
• Or, equivalently, implication is transitive

82
The Resolution Inference Rule

• Generalized resolution (disjunctions)
• Generalized resolution (implications)

83
Canonical Forms for Resolution

• Conjunctive Normal Form
• Example
• Implicative Normal Form
• Example

84
Resolution Proofs Using Forward-Chaining Algorithm
y/w
w/x
x/A,z/A
85
Resolution with Refutation

• Chaining with resolution is still not complete
• Example For an empty KB, we can do nothing with
• Proof by contradiction (reduction ad absurdum)
• Example
• To prove P, assume that P is false, and prove a
  contradiction

86
Proofs Using Resolution with Refutation
87
Conversion to Normal Form (1)

• Any first-order logic sentence can be put into
  implicative (or conjunctive) normal form
• Conversion procedure
• 1. Eliminate implications
• 2. Move negation inwards by de Morgans law

88
Conversion to Normal Form (2)

• Conversion procedure (continue)
• 3. Standardize variables
• 4. Move quantifiers left
• 5. Skolemize

89
Conversion to Normal Form (3)

• Conversion procedure (continue)
• 6. Distribute AND over OR
• 7. Flatten nested conjunctions and disjunctions
• 8. Convert disjunctions to implications

90
Dealing with Equality

• Demodulation rule
