1
Propagation Channel Characterization and Modeling
Outdoor Power Supply Gridsas Communication
Channels Prof. Dr.-Ing. habil. Klaus Dostert
Institute of Industrial Information
Systems UNIVERSITY OF KARLSRUHE (TH)
2
Overview
Communication over outdoor electrical power
supply lines

• Network structures and their basic properties
• Access domain in Europe, ASIA, America

• Analysis of line and cable properties
• characteristic impedance
• branching matching

• General aspects of channel modeling
• transfer function, impulse response, channel
  parameterization
• interference scenario

• PLC channel simulation and emulation
• channel adapted system development

Conclusions and further work
3
History Carrier Frequency Transmission since
1920 (on the high voltage level only)

• no branching
• optimal wave guiding by network
  conditioning

4
Current and Upcoming PLC Applications
5
The European Power Supply Network Structure
6
Typical Topology of European Power
DistributionNetworks in Residential Areas
7
Some Details of Last Mile and Last Meter
Environments
ZL2
8
Power Supply Structures in Asia and America

• small supply cells
• few households per transformer
• cable length ?? 100m
• grounding of 3rd wire
• highly unsymmetrical

9
The Ideal Two-Wire System
10
Symmetry in Multi-Wire Structures
open wires
X

11
Simplified Analysis of a Two-Wire System
12
RF Properties of Typical Supply Cables
13
The problem of Branching and Possible Solutions
14
Some Ideas for Signal Coupling with Enhanced
SymmetryImproving EMC
15
Reflections Causing Echoes and Inter-Symbol
Interference
16
Approaches Toward Deterministic Network Modeling
source
sink
line element
bq ri

• high computational effort
• requires detailed knowledge of
• network topology and device parameters
• not applicable in practice

17
The Echo-based Channel Model
considering only echoes kiconst
18
H(f) single reflection, no losses
19
Two-Path Channel without Losses but Varying Path
Weights
Path 1
0.52
0.26
0.173
0.46
0.71
0.793
0.627
Path 2
0.347
0.208
0.149
0.76
0.817
20
A First Realistic Example
path di/m gi
1 200 0.64
2 222.4 0.38
3 244.8 -0.15
4 267.5 0.05
21
A Second Example (more complex)
path di/m gi
1 90 0.029
2 102 0.043
3 113 0.103
4 143 -0.058
5 148 -0.045
6 200 -0.040
7 260 0.038
8 322 -0.038
9 411 0.071
10 490 -0.035
11 567 0.065
12 740 -0.055
13 960 0.042
14 1130 -0.059
15 1250 0.049
22
Transmission Characteristics According to Length
Classes
0
10
Attenuation in dB
20
30
150 m
40
200 m
50
60
300 m
70
380 m
80
2
4
6
8
10
12
14
16
18
Frequency in MHz
23
A General Powerline Interference Model
24
Idea of a Universal PLC-Channel Emulator
25
Some Details Toward Emulator Realization
26
A First Powerline Channel Emulator Prototype
modified filter structure
reference channel
coeff. filter 1 coeff. filter 2
H in dB
simulations, implementation
H in dB
hardware
f in MHz
verification measurements
f in MHz
27
Why OFDM for PLC?
Channel Transfer Function
restricted e.g. for protection of broadcast
services
f
fN
f1
f2
f3
28
Conclusions and Further Work
