Title: Floppy Drives


1
Chapter 7
  • Floppy Drives

2
You Will Learn
  • How floppy drives work
  • How to exchange and support floppy drives

3
How Floppy Drives Work
  • How data is physically stored on a floppy disk
  • How the OS logically views that data

4
Floppy Drive Subsystem
  • Many people have called the floppy dead. There
    are some applications where a floppy can be very
    useful. For example, when installing Windows XP,
    you press F6 to install SATA drivers from floppy.
  • A floppy fits in a 3.5 external bay connected
    to the motherboard through a 34 pin ribbon
    cable. The twist goes towards the floppy.
  • Systems support two floppy drives with reserved
    letters A and B
  • Floppy drives use Berg connectors for power.

5
How Data Is Physically Stored on a Floppy Disk
  • Floppy drives hold 720 kB, 1.44 MB, or 2.88 MB of
    data. The most common is 1.44 MB.
  • 720 KB - Double density
  • 1.44 MB High density
  • 2.88 MB Extra-high density
  • In concentric circles (tracks or cylinders)
  • Each track is divided into sectors
  • Each sector holds 512 bytes of data

6
How Data Is Physically Stored on a Floppy Disk
7
How Floppy Disks Vary
  • Organization of tracks and sectors
  • Density at which data can be stored
  • Intensity of magnetic spots on magnetized plastic
    surface of the disk

8
Inside a Floppy Disk Drive
9
How Data Is Physically Stored on a Floppy Disk
10
How Data Is Logically Stored on a Floppy Disk
  • Cluster
  • Smallest logical unit of space allocated to a
    file
  • On a 3½-inch high-density floppy disk, one
    cluster one sector (512 bytes)

11
How Data Is Logically Stored on a Floppy Disk
12
Ways to Format a Floppy Disk
  • Format command from a command prompt
  • Windows Explorer, right-click the 3½ Floppy (A)
    icon and select Format on shortcut menu

13
Formatting Process for a Floppy
  • Creates tracks and sectors
  • Creates boot record
  • Creates two copies of file allocation table (FAT)
  • Creates root directory

14
Boot Record
  • First sector of the disk - The boot record is
    always located at the beginning of the disk at
    track 0, sector 1.
  • Stores basic information about how the disk is
    organized
  • Has a bootstrap loader that can be used to boot
    from the disk.
  • IO.SYS or NTLDR make it bootable
  • To make a floppy bootable, you have to copy the
    boot files with format a /s, sys a, or select
    the Create an MS-DOS startup disk check box in
    Windows Explorer.

15
File Allocation Table (FAT)
  • Lists location of file segments (clusters) on a
    disk in a one-column table
  • Width of each entry in the column is 12 bits
    that is why it is called FAT12
  • Lists how each cluster on the disk is currently
    used

16
Root Directory Table
  • Lists all files and subdirectories assigned to
    this table
  • Contains a fixed number of rows to accommodate a
    predetermined number of files and subdirectories

17
Important Items in the Root Directory
  • Filename and extension this includes both 8.3
    and LFN format names
  • Time and date of creation or last update
  • File attributes R, A, S, H

18
Exchanging and Supporting Floppy Drives
  • How to replace the drive
  • How to add an additional floppy drive to a
    computer system
  • Problems that can occur with a floppy drive and
    its support system

19
Replacing a Floppy Drive
  • Check that computer and other peripherals are
    working
  • Turn off computer and remove cover
  • Unplug data cable and power cable from old drive
    unscrew and dismount the drive
  • Slide new drive into the bay reconnect data
    cable and power cable
  • Turn on computer check setup test the drive
    turn off computer and replace the cover

20
Removing the Power Cable
21
The Data Cable
  • This is a 34-pin data cable for floppy drives.
  • The larger connectors were designed to connect to
    very old 5 ¼ floppy drives.
  • The drive at the twisted end will be drive A.
    The drive in the middle, before the twist, is
    drive B The twist in the cable replaces drive
    configuration jumpers.

22
Reconnecting the Data Cable
  • Floppy drives lack the consistency of hard
    drives with the red stripe for pin 1. The red
    stripe is still for pin 1, but it may be on the
    right or the left.
  • To make sure you turn the cable correctly, look
    for a pin 1 designation and turn the red stripe
    towards it. You can also hope the connector is
    keyed most of them are not.
  • If you turn the computer on and the floppy drive
    access light stays on, you have the data cable
    backwards on either the motherboard or the drive.

23
Requirementsfor Adding a New Drive
  • Empty external 3.5 bay
  • Extra power cable (or Y splitter)
  • Extra connection on floppy drive data cable.
    Some floppy cables dont have two connectors, so
    you may need to replace the data cable.

24
Adding a New Drive
  • Slide the drive into the bay screw it down
  • Connect the cable and power cable
  • Change setup in BIOS

25
When a Floppy Disk Doesnt Work
  • Check simple things first
  • Check physical condition of the floppy diskette
  • Check error messages
  • Error messages in 600 range occur when a floppy
    drive does not pass POST test
  • Check CMOS settings is the drive enabled in
    BIOS
  • Check data and power cables connected to the drive

26
Potential Problems
  • Application points to a different drive If an
    application is trying to save a file on another
    drive, it wont magically show up on the floppy.
  • Unrelated error locked up the system not all
    errors that occur after installing a floppy drive
    are related to the floppy drive.
  • System BIOS or CMOS setup is not correctly
    configured
  • Disk in drive is not formatted change to a
    known good floppy diskette
  • Floppy drive or floppy diskette may be bad

27
Potential Problems
  • Shuttle window on floppy disk cannot open fully
    try another floppy
  • Cable on motherboard to the drive is damaged or
    poorly connected. Also look to see if someone
    else damaged the pins.
  • Edge color, typically red, on cable is not
    aligned with pin 1. Look for the pin 1
    indicator, a 1, a 2 or a ?. Also, understand
    that if a pin is labeled 33 or 34, place the red
    side of the data cable on the other end.
  • Power supply or power lead from supply is bad.
    Test with a power supply tester.

28
Potential Problems
  • Power supply cable to the drive is loose or
    disconnected. Also, check to see if a power
    connector pin is bent.
  • Command just issued has a mistake or is the wrong
    command
  • Disk is not inserted correctly. Is it all the
    way in until it clicks this is how you can tell
    it is seated.

29
Common Error Messages
  • Non-system disk or disk error. Replace and strike
    any key when ready. No operating system was
    found on the floppy. This is often because
    someone accidentally left a floppy in the drive,
    and it is listed before the HDD in the boot order
    in the BIOS.
  • Bad or missing COMMAND.COM - An error such as
    "Bad or missing COMMAND.COM" means that the two
    hidden files are present but Command.com is not
    present or is corrupt. (Win9x)
  • Error in Config.sys line xx this usually
    indicates you had a syntax error when you edited
    the config.sys file, which loads real-mode
    drivers.
  • Himem.sys not loaded this means the himem.sys
    was not loaded , so extended memory will be
    unavailable (Win9x)
  • Missing or corrupt Himem.sys this means the
    himem.sys was not loaded because it was missing
    or had been damaged, so extended memory will be
    unavailable (Win9x)

30
Common Error Messages
  • Invalid Drive Specification The drive that you
    specified was not detected by the BIOS. Reboot
    and check the BIOS configuration.
  • Not ready reading drive A, Abort, Retry, Fail?
    The floppy diskette was not readable. Reseat it.
    If it still doesnt work, replace it.
  • General failure reading drive A, Abort, Retry,
    Fail? This is much like the last error message
    but worse. Reseat the diskette, replace the
    diskette, or replace the drive.
  • Track 0 bad, disk not usable This means your
    floppy is bad throw it away. Track 0 is bad.
    It is also possible that the drive is bad. Try
    another diskette.
  • Write-protect error writing drive A - Someone
    moved the write protect tab or covered the hole
    with tape.

31
Summary
  • Main uses of floppy drives
  • Troubleshooting a failed boot
  • Quick and easy way to transfer small files from
    one PC to another
  • How data is physically and logically stored on a
    floppy disk
  • Sector (physical storage)
  • Cluster (logical storage)
  • How to install a floppy drive on a PC
