The Physical Origin of Negative Superhumps

1
(No Transcript)
2
Introduction

• AM CVn stars show both positive and negative
  superhumps
• Common superhumps shown by Whitehurst and several
  others to be the result of tidal driving of the
  disk at the inner Lindblad resonance
• Patterson et al. (1993) suggested AM CVn
  photometric variations are superhumps in helium
  accretion disks
• Simpson Wood (1998) modeled these disks using
  SPH and found superhumps consistent with the
  observations
• Plots of the energy generation versus time showed
  strong likeness to observed light curves

3
Smoothed Particle Hydrodynamics

• SPH is a Lagrangian numerical technique (Monoghan
  1992)
• Kernel interpolation to obtain fluid properties
  and non-gravitational body forces
• Particle size ? smoothing length h
• Time step using the leapfrog method
• Artificial viscosity
• Effectively "point markers" in the fluid

4
SPH Lightcurves
Bolometric light curve resulting primarily
from viscous dissipation
5
SPH Lightcurves
Note pulse shape is more sawtoothed when pulses
begin and take on a smaller amplitude with more
rounded pulses after a couple dozen cycles,
similar to observed superhumps
6
Light curve from q0.25 simulation (Wood,
Montgomery, Simpson 2000) The SH start doesnt
happen until orbit 110 (versus 40 for q0.07).
Once resonance starts, strong SH driven to
non-linearity. System eventually settles down to
quasi-stationary pulseshape.
7
q 0.075
8
Superhump Oscillation

• The physical origin of the positive superhumps is
  a driven oscillation of the disk (32 resonance)
• It is insufficient to describe positive SH as the
  result of an elliptical precessing disk as
  often seen in the literature it is more complex
  and interesting!
• Bright spot has little effect on the light curve
  the bright spot is not the SH light source

9
The SPH Model

• 50,000 particles
• 5,000 particles/orbit for 10 orbits
• Replace accreted/ejected particles at L1
• SH begin near orbit 40
• Light curve calculated from viscous dissipation
  (primarily)
• Visualized using IDL and Adobe Premier

10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21

• Positive Superhumps Movie
• Density Light Curve

22

• Positive Superhumps Movie
• Particle Luminosity
• Note in the animation the coming and going of the
  white particles in the spiral arms in the disk
  this is the origin of the observed superhumps
• The arms advance 180 degrees in the co-rotating
  frame once a superhump cycle
• Thus, the two spiral arms alternate in their
  interaction with the secondary
• As viewed in a frame orbiting at 1.5 times the
  superhump frequency (2/3 orbital period), the
  spiral pattern should be roughly stationary
  Doppler tomography may be able to reveal this
  structure, and datasets exist!

23

• Apsidal Superhumps in the
• Frame of the Spiral Arms

24
Negative (Nodal) Superhumps

• First observed in the mid 1980s as a 5.2-h
  photometric period in TV Col, which has Porb
  5.5 h
• More rare than positive SH, only 17 systems
  known
• Only AM CVn itself has been shown to display
  negative SH among the helium cataclysmics
• Bonnet-Bidaud, Motch, Mouchet (1985) first to
  suggest the 5.2-hr period in TV Col could be the
  signature of an accretion disk which is tilted
  out of the orbital plane and which as a result
  precesses slowly in the retrograde direction.

25
Negative SH

• Barrett et al. (1988) also suggested that
  negative SH were involved a freely precessing
  tilted disk, with a magnetic field at L1
  directing the accretion flow out of the orbital
  plane
• They also suggested (!) the negative superhump
  light source was the bright spot migrating across
  the face of the tilted accretion disk
• Our models confirm this suggestion, as we discuss
  below

26
The SPH Models

• Assume M1 1.0 Msun, M2 0.4 Msun, which gives
  Porb 4.3 hr
• 50,000 particles
• 4,000/orbit for 12.5 orbits
• Relax simulation to equilibrium solution until
  orbit 100, replacing accreted/ejected particles
  at L1
• Tilt disk by 5 degrees and continue simulation
• Add new burst of particles of 4,000/orbit for 5
  orbits to help visualize the bright spot migration

27
Simulation Light Curve
28
Neg SH Light Source

• Because we effectively integrate over 4pi sr, our
  light curves peak twice per orbit (? 2.1 orb-1)
• The ray-traced visualizations show that a given
  observer would only see one face of the tilted
  optically-thick disk (? 1.05 orb-1)
• Because the disk has a finite opening angle, as
  the disk precesses the apparent brightness of the
  bright spot crossing will change, leading to the
  beat period of order a few days, for systems
  with i gt 45o or so

29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
Negative Superhumps The Movie
41
Negative Superhumps The Movie Sideways
42
Tilting the Disk

• The major question is how to tilt the disk
• Barrett et al. (1988) suggested a magnetic field
  at L1 could direct the flow out of the page (but
  )
• Murray et al. (2002) found that turning on a
  magnetic field on the secondary star would
  warp/tilt the disk (but again )
• Our experiments
• Murrays explanation is probably correct, but
  probably need magnetically-active secondary -gt
  magnetic reconnections can change the field on
  short timescales applying impulses to the disk
  (Hellier 1993 TV Col flare?)

43
Conclusions

• The physical origin of both positive and negative
  superhumps is now relatively well understood
• Positive
• Driven oscillation of a disk (not precessing
  elliptical disk)
• Found in models for mass ratios 0.03 lt q lt 0.34
• Models at q 0.075 develop SH fastest very
  very slow at extreme boundaries of the range
• Negative migration of bright spot across the
  face of a tilted precessing disk
• Works for any mass ratio
• Tilt must be more than 3o in the simulations

44
Conclusions II

• Future work
• FITDisk Windows GUI SPH toy code (V1.0
  released Fall 2005)
• Viscosity physics (magnetorotational instability)

• Radiative transfer
• Inclination dependent light curves
• Velocity map images of real superhumps
• Use models to generate velocity map images for
  comparison with observations
• What really tilts the disks, and how to keep them
  out of the plane?

45
Discussion?
