BPM module UU

1
BPM module UU

• Start BPMS case,
• Wk 2 Introduction Practical information
• Teachers
• Jos van Reenen, Gerrit Spronk

2
Bpms case

• Is about
• Collaboration between business partners
• Agreements about shared processes
• Implementation of internal and external processes
• Implementation of automated supply chain
  processes

3
BPMS case

• 3 tier supply chain
• retailer ??wholesaler ??manufacturer
• Bicycles and accessories
• Current orderprocess via snailmail/fax/telephone
• Change required!
• Integration of orderprocesses across the supply
  chain and its systems
• Systems like SAP Baan Oracle MSSQL
• Restriction to MSSQL, but similar challenges
• Challenges like

4
BPMS case
Manufacturer
Wholesaler
Retailer
5
Retailer sales purchase process
6
Detailed investigation required

• Example
• Order process at retailer ordering at the
  wholesaler
• Which objects are involved?
• .
• .
• .

7
Detailed investigation required (2)

• Orderstatusses(table PO_status)
• PO_stat_id and PO_stat_descr
• 1 in order
• 2 partially delivered
• 3 delivery completed

8
Detailed investigation required (3)

• Orderheader (PO_Header)
• PO_id
• PO_vendor_id
• PO_status
• PO_date
• Product
• Prod_id
• Prod_descr
• Prod_numb
• Prod_color
• Prod_pur_price
• Prod_sls_price
• Prod_vendor_id
• Prod_qty_on_stock
• Prod_qty_on_order

• Orderlines (PO_lines)
• PO_id
• PO_LIne_id
• PO_Prod_id
• PO_order_qty
• PO_prom_del_date
• PO_rec_qty
• PO_rec_date
• Warning tables, fields and content may differ
  from partner to partner. The same identifier may
  signify different objects.

9
Wholesale Decrease inventory

• The decrease inventory BPM allows the
  wholesaler/manufacturer to deal with inventory
  distributed over more than one location. The
  input parameters are ltproduct_idgt and
  ltquantitygt.
• The first activity is to locate the first
  position containing the product with quantity gt 0
• Then it is checked if the quantity available in
  that location is enough to fulfill the order
• if so the inventory is updated with the decreased
  quantity
• otherwise, the process begins a loop in which the
  quantity available in that position is completely
  decreased, and the process continues until a
  location is found which can fulfill the remainder
  and the process concludes.
• precondition TotalStock of a product is bigger
  than or equal to the requested amount.

10
Wholesale Decrease inventory (2)

• You can import this example under
  studio/settings/content transfer utility.
• This file is needed decreasestock.vcmdata
• After import you can view the bpm including
  messagemap details. However, the methods are not
  available. You will have to make them yourselves.

11
Wholesale sales process
12
Retail Receipt process
13
Wholesale receipt of goods
14
DEMO

• Retailer09 ??wholesaler09
• Opening xform at retailer
• Browse stock, purchase orders, place order
• Place order, check new order, show bpms, inbox
  messages etc.

15
Practical info

• Groups of up to 5 persons per supplychain
• Formation of groups
• Groups should consist of both technically as
  business oriented students.
• Hand in group details to teachers
• Get cordys group accounts

16
Dont forget

• Use Cordys Basic Constructs and read the reading
  advice
• Functional Design helps to focus
• You may not see much happening when straight
  through processing is chosen
• Where human interaction is required you may wish
  to use XForms

17
Schedule
18
Model to import

• Rightclick package object/edit package/file/save
  contents
• Name should have extension vcmdata
• ltltltltlt BACK

19
Collect your account details for bpms case

• Ready to go
