Overview of EFDA activities 27th July 2006

1
Overview of EFDA activities27th July 2006
2
EFDA activities (up to mid 2007)Collective use
of the JET activitiesEU participation to
ITERFusion Technology RD
3
EFDA organisationEFDA Leader (J.Pamela) based
in GarchingAssociate Leader in charge of JET
(F.Romanelli) based in CulhamAssociate Leader
in charge of Technology (M.Gasparotto) based in
GarchingThree Close Support Units in
Garching, Barcelona and Culham
4
JET
5
JET preparing ITER operation
Size gt Plasma parameters closest to ITER
4m
6
JET a powerful asset to prepare ITER operation

• plasma parameters closest to those of ITER (R
  3m Ip up to 4 4.5 MA alpha particles
  confined ITER plasma shape)
• the only Tokamak that handles Tritium
• tests of several ITER-relevant technologies e.g.
  unique remote handling capability, ITER-like
  ICRH-antenna, burning plasma diagnostics
• unique capability to use the same plasma facing
  materials as foreseen for ITER (beryllium) gt
  ITER-like wall project

7

• JET
• Routine performance of in-vessel remote handling
  tasks

8
Modified JET Divertor (MkII-HD) allowing
operation with ITER-shape plasmas since end 2005
Wide-angle IR view
9
Improved JET diagnostics allowing physics studies
on key ITER issues
Example New divertor bolometer used for ELM
studies
During ELM
Between ELMs
10
14 MeV Neutron tomography Studies of
tritium transport Excellent capability to
predict T transport confirmed by 14 MeV D-T
neutrons tomography
11
ITER-like ICRH antenna

• Antenna assembly ongoing
• Installation during Winter/Spring 07 shutdown
• Aim at demonstration of ITER ICRH antenna concept

• ELM resilience
• High power density

12
JET preparing ITER operation

• Materials of ITER plasma facing components will
  be installed in 2008-2009
• CFC tiles to be replaced by Be tiles and W
  tiles W-coated tiles
• A key step in support for ITER
• Plasma scenarios fully compatible with Be W
• Mixed materials issues
• Control of power transients
• Reduced T retention

13
JET a facility collectively used in preparation
of ITER
Participation of European Physicists in JET 2006
Experimental Campaigns

• About 300 different European physicists and
  collaborators from USA, Japan, Russian
  Federation, China conduct experiments on JET
• Brazilian participation through Portugal

14
Technology (ITER-DEMO)
15
EFDA Technology Activities

• Preparing for the construction of ITER
• Preparing in the longer term for DEMO
• Activities include
• research and development work
• design tasks
• manufacturing and testing of components
• EFDA coordinates the technology activities in the
  Associations and European industry

16
Technology RD EFDA CSU Garching/Barcelona
Close Support Unit Garching 73 persons Close
Support Unit Barcelona 16 persons
17
ITER Lines of Activities (1)
Technology Workprogramme 2006 - 2007
Activities focused on the design and RD towards
the ITER procurement, defined in close
collaboration with the ITER International Team
(IT)

• Assisting the IT in the preparation of the most
  urgently needed technical specifications
  (magnets, vacuum vessel, buildings and site
  preparation).
• Investigation on the manufacturing of the most
  critical components (divertor, vacuum vessel,
  shield modules).
• Preparation of European test facilities (Dipole,
  HELOKA, DTP-2, ECRH Test Facility, HeFUS3)

18
Technology Workprogramme 2006 - 2007
ITER Lines of Activities (2)

• Focused effort in areas where design and RD are
  still needed Machine Assembly, Remote Handling,
  ITER Test Blanket Modules, Diagnostics, Heating
  and Current Drive.
• Assisting the IT in the preparation of safety and
  licensing documentation for ITER and related
  safety studies.
• Preparing EU laboratories European Industries
  for ITER construction.

19
ECRH antenna upper launcher
ITER Physics Integration
Circular waveguides
Isolation valves CVD diamond windows
Focussing Mirror
Mirror
Frictionless Steering mechanisms
Flexible cooling tubes
spring-bellow actuator
Flexure pivot
20
ITER Vessel / In-Vessel
Full-Scale Vertical Target Prototype
Thermal fatigue testing of the full-scale
divertor vertical target prototype manufactured
by HIP was previously reported with 1000 cycles
at 20 MW/m2 plus additional 1000 cycles at 23
MW/m2 on CFC. The testing has now been
completed also on the W armoured part where 1000
cycles at 20 MW/m2 have been achieved.
Cu-cast W-lamellae monoblocks
21
ITER Vessel / In-Vessel
VV Individual Parts 3-D formed plates
2 x 3 metre, curved parts of the walls of the VV
need to be 3-D formed. A study being carried out
to determine press shape and forces required.
Trial forming to validate computer model
22
ITER Vessel / In-Vessel
RH Design Activities
RH Transfer Cask (EFET task)
Cassette Toroidal Mover - CTM (EFET task)
23
Magnets Full Size Conductor Tests
ITER Magnets Structure and Integration

• Two full size conductor samples tested in SULTAN
  facility

TFAS1
TFAS2
24
Other EFDA Technology activitiesDEMO Technology
RD- Tritium Breeding- Materials- DEMO
conceptual studies Preparation for Broader
Approach collaboration- Satellite Tokamak-
IFERC- IFMIF EVEDA
25
2007 organisation in Europe will change New
Joint Undertaking in Barcelona- EU domestic
agency for ITER gt EU contribution to ITER
construction- Broader Approach- DEMO activities
(details tbd)EFDA - Collective use of the JET
activities- Reinforced coordination between
European laboratories gt EU tokamak physics in
support of ITER- Other Technology RD
(programme-oriented)
