Design of a High-Speed Asynchronous Turbo Decoder

1
Design of a High-Speed Asynchronous Turbo Decoder
Pankaj Golani, George Dimou, Mallika Prakash and
Peter A. Beerel Asynchronous CAD/VLSI Group Ming
Hsieh Electrical Engineering Department University
of Southern California ASYNC 2007 Berkeley,
California March 12th 2007
2
Motivation and Goal

• Mainstream acceptance of asynchronous design
• Leverage-off of ASIC standard-cell library-based
  design flow
• Achieve significant benefits to overcome sync
  momentum
• Our research goal for async designs
• High-speed standard-cell flow
• Applications where designs yield significant
  improvement
• throughput and throughput per area
• energy efficiency

3
Single Track Full Buffer (Ferretti02)
L
R

• Follows 2 phase protocol
• High performance standard cell circuit family
• Comparison to synchronous standard-cell
• 4.5x better latency
• 1GHz in 0.18µm
• 2.4X faster than synchronous
• 2.8x more area

4
Block Processing Pipelining and Parallelism
M people pipelines
Steinhart Aquarium
Latency l
First M cases arrive at t l
Let c be the person cycle time
Subsequent M cases arrive every c time units

• Consider two scenarios
• Baseline
• cycle time C1, latency L1
• Improved
• cycle time C2 C1/2.4, latency L2 L1/4.5
• Questions
• How does cycle time affect throughput?
• How does latency affect throughput ?

5
Block Processing Combined Cycle Time and
Latency Effect
Large K throughput ratio ? cycle time ratio
Small K throughput ratio ? latency ratio
6
Talk Outline

• Turbo coding and decoding an introduction
• Tree soft-input soft-output (SISO) decoder
• Synchronous turbo decoder
• Asynchronous turbo decoder
• Comparisons and conclusions

7
Turbo Coding Introduction

• Error correcting codes
• Adds redundancy
• The input data is K bits
• The output code word is N bits (NgtK)
• The code rate is r K/N
• Type of codes
• Linear code
• Convolutional code (CC)
• Turbo code

8
Turbo Encoding - Introduction
Inner CC
Interleaver
Outer CC
Turbo Encoder

• Turbo Encoding
• Berrou, Glavieux and Thitimajshima (1993)
• Performance close to Shannon channel capacity
• Typically uses two convolutional codes and an
  interleaver
• Interleaver used to improve error correction
• increases minimum distance of code
• creates a large block code

9
Turbo Decoding

• Turbo decoder components
• Two soft-in soft-out (SISO) decoders
• one for inner CC and one for outer CC
• soft input a priori estimates of input data
• soft output a posterior estimates of input data
• SISO often based on Min-Sum formulation
• Interleaver / De-interleaver
• maps SISO outputs to SISO inputs
• same permutation as used in encoder
• Iterative nature of algorithm leads to block
  processing
• One SISO must finish before next SISO starts

Received Data memory
Inner SISO
De- interleaver
Outer SISO
Interleaver
10
The Decoding Problem

• Requires finding paths in a graph called a
  trellis
• Node State j of encoder at time index k
• Edge Represents receiving a 0 or 1 in node for
  state j at time k
• Path Represents a possible decoded sequence
• the algorithm finds multiple paths
• Example Trellis
• For a 2-state encoder, encoding K bits

t 0
t K
t k
Sent bit is 1
Sent bit is 0
Decoded Sequence
0 1 0 0 0
1 0 1 0 0
11
Min-Sum SISO Problem Formulation

• Branch and path metrics
• Branch metric (BM)
• indicates difference between expected and
  received values
• Path metric
• sum of associated branch metrics
• Min-Sum Formulation for each time index k find
• Minimum path metric over all paths for which bit
  k 1
• Minimum path metric over all paths for which bit
  k 0

t 0
t k
t K
1
Sent bit is 1
Sent bit is 0
Minimum path metric when bit k 1 is 13
Minimum path metric when bit k 0 is 16
12
Talk Outline

• Turbo coding and decoding an introduction
• Tree SISO low-latency turbo decoder architecture
• Synchronous turbo decoder
• Asynchronous turbo decoder
• Comparisons and conclusions

13
Conventional SISO - O(K) latency

• Calculation of the minimum path can be divided
  into two phases
• Forward state metric for time k and state j
• Backward state metric for time k and state j
• Data dependency loop prevents pipelining
• Cycle time limited to latency of 2-way ACS
• Latency is O(K)

t k
t K
t k-1
t k1
t 0
Received bit is 1
Received bit is 0
14
Tree SISO low latency architecture

• Tree SISO (Beerel/Chugg JSAC01)
• Calculate BMs for larger and larger segments of
  trellis.( )
• Analogous to creating group-wise PG logic for
  tree adders
• Tree SISO can process the entire trellis in
  parallel
• No data dependency loops so finer pipelining
  possible
• Latency is O(log K)

15
Remainder of Talk Outline

• Turbo Coding an introduction
• Turbo Decoding
• Tree SISO low-latency turbo decoder architecture
• Synchronous turbo decoder
• Asynchronous turbo decoder
• Comparisons and conclusions

16
Synchronous Base-Line Turbo Decoder

• Synchronous turbo decoder base-line
• IBM 0.18µm Artisan standard cell library
• SCCC code was used with a rate of ½
• Number of iterations performed is 6
• Gate level pipelined to achieve high throughput
• Performed timing-driven PR
• Peak frequency of 475MHz
• SISO area of 2.46mm2
• To achieve high throughput, multiple blocks
  instantiated

17
Asynchronous Turbo Decoder

• Static Single Track Full Buffer Standard-Cell
  Library (Golani06)
• Total of (only) 14 cells in IBM 0.18µm process
• Extensive spice simulations were performed
• optimized trade-off between performance and
  robustness
• Chip design
• Standard ASIC place-and-route flow
  (congestion-based)
• ECO optimization flow
• Chip level simulation
• Performed on critical sub-block (55K transistors)
• Verified timing constraints
• Measured latency and throughput using Synopsys
  Nanosim

18
Static Single Track Full Buffer (Ferretti01)
1-of-N data
Receiver
Sender
SST channel
1-of-N static single-track protocol
Holds low Drives high
Holds high Drives low
Statically drive line ? improves noise margin
19
Asynchronous Implementation Challenges - I

• Degradation in throughput
• Unbalanced fork and join structure
• The token on the short branch is stalled due to
  imbalance
• This leads to over all slowing down of the fork
  join

• Slack matching
• Improves the throughput because of an additional
  pipeline buffer
• Identify fork / join bottlenecks and resolve by
  adding buffers
• After PR long wires can also create such a
  problem
• This can be solved by adding buffers on long
  wires using ECO flow

20
Asynchronous Implementation Challenges - II
Full Adder

Fork
Full Adder with Integrated Fork

• SSTFB implements only point to point
  communication
• Use dedicated Fork cells
• Creates another pipeline stage
• To slack match buffers are needed on the other
  paths
• Integrate Fork within Full Adder

45 less area than full adder and fork Decreases
the number of slack matching buffers required
21
Asynchronous Implementation Challenges III

• 60 of the design are slack matching buffers
• Most of the time these buffers occur in linear
  chains

Slack2
Buffer
Buffer

• To save area and power two new cells were created
• SLACK2
• SLACK4

17 area and 10 power improvement for
SLACK2 30 area and 19 power improvement for
SLACK4
22
Remainder of Talk Outline

• Turbo Coding an introduction
• Turbo Decoding
• Tree SISO low-latency turbo decoder architecture
• Synchronous turbo decoder
• Asynchronous turbo decoder
• Comparisons and conclusions

23
Comparisons

• Synchronous
• Peak frequency of 475MHz
• Logic area of 2.46mm2
• Asynchronous
• Peak frequency of 1.15GHz
• Logic area of 6.92mm2
• Design time comparison
• Synchronous 4 graduate-student months
• Asynchronous 12 graduate-student months

24
Synch vs Async
Received Memory
M pipelined 8-bit Tree SISOs
Interleaver/ De-interleaver
Latency l
First M bits arrive at t l
K bits
Let c be the sync clock cycle time (475 MHz)
Subsequent M bits arrive every c time units

• Two implementations
• Synch cycle time C1 and latency L1
• Async cycle time C2 C1/2.4
• latency L2 L1/4.5
• Desired comparisons
• Throughput comparison vs block size
• Energy comparison vs block size

25
Comparisons Throughput / Area
1.28 M3
2.13 M8
3.91 M11

• For small block sizes asynchronous provides
  better throughput/area
• As block size ? the two implementations become
  comparable
• For block sizes of 512 bits synchronous cannot
  achieve async throughput

26
Comparisons Energy/Block

• For equivalent throughputs and small block sizes
  asynchronous is more energy
  efficient than synchronous
• Async advantages grow with larger async library
  (e.g., w/ BUF1of4)

27
Conclusions

• Asynchronous turbo decoder vs. synchronous
  baseline
• static STFB offers significant improvements for
  small block sizes
• more than 2X throughput/area
• higher peak throughput (500Mbps)
• more energy efficient
• well-suited for low-latency applications (e.g.
  voice)
• High-performance async advantageous for
  applications which require
• high performance (e.g., pipelining)
• low latency
• block processing for which parallelism has
  diminishing returns
• synchronous design requires extensive parallelism
  to achieve equivalent throughput

28
Future Work

• Library Design
• Larger library with more than 1 size per cell
• 1-of-4 encoding
• Async CAD
• Automated slack matching
• Static timing analysis

29
Questions ??
