Introduction to bioinformatics

1
??????? ????? ?????? ???? - 20436

• ??????????? ??????
• ???? ???? ???????
• ????? ??? 2003?

2
Information SystemsDevelopment in Action

• The problem decomposition process

3
Steps in the Systems Development Process

• System identification, selection, and planning
• System analysis

• System design
• System implementation
• System maintenance

4
Entity-Relationship Diagram
5
Three views of the system data
Structure
Function
Entity Relationship diagram (ERD)
Data Flow diagrams (DFD)
System data
Entity Life History (ELH)
Sequence
6
Conceptual Data Modeling

• Representation of organizational data
• Purpose is to show rules about the meaning and
  interrelationships among data
• Entity-Relationship (E-R) diagrams are commonly
  used to show how data are organized
• Main goal of conceptual data modeling is to
  create accurate E-R diagrams
• Methods such as interviewing, questionnaires and
  JAD are used to collect information
• Consistency must be maintained between process
  flow, decision logic and data modeling
  descriptions

10.6
7
Process of Conceptual Data Modeling

• First step is to develop a data model for the
  system being replaced
• Next, a new conceptual data model is built that
  includes all the requirements of the new system
• In the design stage, the conceptual data model is
  translated into a physical design
• Project repository links all design and data
  modeling steps performed during SDLC

10.7
8
Figure 10-3Sample conceptual data model diagram
10.8
9
Gathering Information for Conceptual Data Modeling

• Two perspectives
• Top-down
• Data model is derived from an intimate
  understanding of the business
• Bottom-up
• Data model is derived by reviewing specifications
  and business documents

10.9
10
Introduction to Entity-Relationship (E-R) Modeling

• Notation uses three main constructs
• Data entities
• Relationships
• Attributes
• Entity-Relationship (E-R) Diagram
• A detailed, logical representation of the
  entities, associations and data elements for an
  organization or business

10.10
11
Entity-Relationship (E-R) ModelingKey Terms

• Entity
• A person, place, object, event or concept in the
  user environment about which the organization
  wishes to maintain data
• Represented by a rectangle in E-R diagrams
• Entity Type
• A collection of entities that share common
  properties or characteristics
• Attribute
• A named property or characteristic of an entity
  that is of interest to an organization

10.11
12
Elements of an ERD

• Relationships
• Association between entities
• Labeled with a verb
• Specialization
• Aggregation
• Cardinality
• Associative object type indicators

13
ERD Symbols
Entity Name
Rectangle represents entities
RelationshipName
Diamond represents relationships
Line links entities and relationships
14
ERD Examples
Specialization
Named Relationship
15
ERD Examples
Aggregation Hierarchy Cardinality
Car
Engine
Chassis
3
2
Wheel
Axle

16
ERD Cardinality Notation
1
Exactly one
01
Zero or one
1
Mandatory many
0
Optional many
17
Entity

• Something of importance to the a user that needs
  to be represented in a database.
• In an entity-relationship diagram, entities are
  restricted to things that can be represented by a
  single table.

18
Entity Class

• A set of entities of the same type, for example,
  EMPLOYEE and DEPARTMENT

19
Entity Instance

• A particular occurrence of an entity, for
  example, Employee 100, and the Accounting
  Department

20
Attributes

• Column of a relation
• called
• field
• column
• data-item
• A property in an ERD
• Represented as an oval

21
ERD Attributes
LNAME
FNAME
PADDRESS
STUDENT
SSN
GENDER
ADDRESS
22
ERD EXAMPLE
23
Modeling the Business
Activities
What It Does
What It Needs to Know
Data
24
Data Model
25
Data Model Components

• Subject areas
• Entity types
• Relationships
• Attributes

26
Subject Areas
Products
Personnel
Customers
A natural area of interest of an enterprise
centered on a major resource or activity of the
enterprise and consisting of a set of data
objects
27
Entity Types
Shipment
Employee
Product
Types of things the business needs in order to
operate
28
Entity Occurrence or Instance or sometimes
just Entity
Gone with the Wind Casablanca Are Entity
Occurrences or Instances of
FILM
29
Relationship
A reason of relevance to the enterprise for
associating occurrences of one or more entity
types.
TAPE
Member
TAPE
MEMBER
RENTS
30
Relationship Pairing
Specific entity occurrences participate in an
occurrence of the relationship.
Bob Allen
Casablanca
Gone with the Wind
Ann Smith
of
MEMBER
TAPE
RENTS
31
Two Relationship Memberships
One way
places
STORE
ORDER
is placed by
32
Reading ERDs

• Entity type names should always be singular. Ex.
  Employee, Member
• Read starting with Each. Ex. Each store places
  one or more orders. Each order is placed by one
  and only one store.

33
Cardinality
The number of pairings in which an entity
occurrence may participate
PURCHASE ORDER(S)
Only1?
The Video Store
Each
PLACES
1ormore?
STORE
34
Cardinality of Relationships
OFFERS
FILM
DISTRIBUTOR
IS OFFERED BY
IS RENTED AS
STORE TAPE COPY
RENTAL ITEM
IS THE RENTAL OF
INCLUDES
RENTAL ITEM
RENTAL
IS INCLUDED ON
35
Mandatory Relationship Memberships
Business rule 1. Each RENTAL always CONTAINS
one or more RENTAL ITEM 2. Each RENTAL ITEM
always IS CONTAINED IN one RENTAL
CONTAINS
RENTAL ITEM
RENTAL
IS CONTAINED IN
36
Optional Relationship Membership
Business rule 1. Each STORE sometimes PLACES
one or more ORDER 2. Each ORDER always IS
PLACED BY one STORE
PLACES
ORDER
STORE
IS PLACED BY
37
Attributes
Facts the business needs to keep about
EMPLOYEE
EMPLOYEE
NameNumberStreet AddressCityStatePostal
CodePhone Number
The Entity Type
The Person
38
Attribute Value
For entity type
STORE
Attribute Value Number 56 200 30 Manag
er Name Pat Jones Jasmine Schwartz Chris
Corrigan
An occurrence of an attribute is its value
39
Attribute Optionality
Attribute
Status Must always have a value
Mandatory Phone Number May not always have a
value Optional
40
Attribute Detail - Domains
Text or
Alphanumeric - Character and Number Used
for fields not used in calculations. Number or
Numeric - Integer or decimal Use integer if
no decimals are needed. Define larger than
you think you need. Date - YYYYMMDD
8 (Full year and month and day) Best
if defined as 3 fields. Time - HHMMSS
6 Memo - Highly variable-length text
fields Avoid if possible.
41
Entity Type Identifiers
Passport
Distinguishing between entities of an entity type
is accomplished by selecting identifiers.
42
An Attribute as an Identifier
Entity Type CUSTOMER
Attributes
What is a Primary Key?
STATUS NAME STREET ADDRESS CITY STATE POSTAL
CODE NUMBER MAILING AUTHORIZATION CODE
Single Identifier
NUMBER
43
Relationship Membership as part of an Identifier
(requires that the entity be dependent)
Entity Type ORDER ITEMs identifier
Attributes
Relationships
PK-ORDER NUMBER PK-ITEM NUMBER SALE PRICE QUANTITY
IS INCLUDED ON
ORDER ITEM
ORDER
INCLUDES
Note this line
PK-ORDER NUMBER
Identifier is a combination of
ITEM NUMBER and the fact that
Each ORDER ITEM IS INCLUDED ON one ORDER
To indicate Order Number as PK, click Primary
UID box on the relationship line in Designer. Do
not add an attribute and make it a PK. Line on
relationship indicates PK.
44
Relationship Memberships as an Identifier
(intersection or associative entity)
Entity Type STORE MEMBERSHIP
CLUB MEMBERSHIP
STORE
ISSUES
POSSESSES
IS ISSUED BY
STORE MEMBERSHIP
BELONGS TO
Combination of Each STORE MEMBERSHIP BELONGS
TO one CLUB MEMBERSHIP Each STORE MEMBERSHIP
IS ISSUED BY one STORE
45
Relationships (Foreign Keys) in Child, Dependent
or Weak entity types

• When a relationship exists between a strong
  (independent) (parent) (one-side) entity type and
  a weak (dependent) (child) (many-side) entity
  type, it is called a foreign key.
• The identifier attribute in the parent entity
  type is automatically copied to and becomes an
  attribute in the child entity type by
  Designer/2000. Do not put the attribute in the
  child entity type.
• Foreign keys allow tables to be joined (records
  to be matched) in a relational database.

46
Entity Type Normalization
The process of ensuring an attribute describes
only the entity type in which it is placed and
there are no repeating groups of fields.
Before Normalizing
COURSE
Name . . . Instructor Name
Also describes the instructor
After Normalizing
INSTRUCTOR
COURSE
Name
Name
47
Practice Exercise - ERD

• Draw the ERD for problem 5 on p. 341

48
ERD Examples
Ternary Relationships
49
ERD Examples
Associative Object Type Indicators
Purchase
Item
Customer
Purchase is both object type AND relationship
50
Exercise Time!
51
ERD Exercise

• Problem statement
• Model a travel agency. The TA can sell rooms,
  apartments and houses to customers or resellers.
  The TA gets reservation (booking) options or
  fixed booking contingents from hotels, pensions
  or private persons. Contingents are bookings that
  are reserved exclusively for the TA while options
  can only be sold if there are vacancies. This
  requires confirmation by the client prior to
  reservation. Clients are informed about current
  offers by a schedule.

52
ERD Exercise

• Bookings can be made in the TA office or by phone
  or mail. Private persons have to pay a certain
  amount upfront and have to pay the remaining
  amount 14 days before departure, resellers get an
  invoice for the entire amount. Contingents are
  paid immediately, regardless if they could be
  re-sold or not. For bookings based on options the
  TA pays the supplier the amount the client paid
  less a commission.
• Consider modeling the relations to customers and
  suppliers separately, i.e. using two diagrams.
  If you think anything is missing, make any
  (sensible) assumption that you need. There is no
  perfect solution!

53
Private Person
Pension
Provider
owns
1
Object
Hotel
1
1
Calendar
Accommodation
1
Reser- vation
Payment
Apartment

Room
Option
Contingent
54
Customer
Private Person
Reseller
Booking
Calendar
Accomo dation
Price
55
Cardinality

• Maximum Cardinality In a binary relationship,
  the maximum number of elements allowed on each
  side of the relationship.
• 11, 1N, NM
• Minimum Cardinality
• optional-optional
• optional-mandatory
• mandatory-optional
• mandatory-mandatory

56
ERD with Cardinality
1 M
