VB Constructs

1
VB Constructs
2
More on Comments

• Should you comment every declaration and every
  line of code?
• NO!!
• Comments should ADD information
• Always include the Header comment (unit1)
• Comment declarations ONLY if meaningful name is
  insufficient to explain purpose
• Comment a line or block of code ONLY if purpose
  is not obvious

3
More on Data Types

• The Integer Data Type
• Dim NumberOfCars As Integer
• Used to store WHOLE numbers
• Use for whole numbers that will be used in
  calculations
• If a car dealer has 36 cars in stock and a
  delivery of a further 10 then
• NumberOfCars NumberOfCars NewCars

4
Given
Variables NumberOfCars NewCars accessed
current values stored brought forward
NumberOfCars NumberOfCars NewCars
Calculation performed giving result of 46. This
result is then saved back into variable
NumberOfCars thus overwriting the old value,36,
that had been stored there
After assignment
5
More on Arithmetic Operators - Comparison

• Values can be compared
• These comparisons can be used by program at run
  time to make decisions about what code to execute
  next
• In computing a comparison is called a condition
• Conditions are built using relational operators

6
Relational Operators

• Symbol Relation Tested
• gt greater than
• lt less than
• equal to
• (note same symbol as for assignment!)
• ltgt not equal to
• gt greater than or equal to
• lt less than or equal to

7
Using Conditions - If, Then, Else, EndIf
Statement
8
If, Then, Else, EndIf Statement

• The condition following If is tested
• If condition is TRUE all statements between Then
  and Else are executed
• Processing then goes to statement AFTER Endif
• If condition is FALSE all statements between Else
  and EndIf are executed
• Processing then goes to statement AFTER Endif

9
Commenting If statements

• If age gt cDriveAge Then
• user can drive
• MsgBox You are old enough, vbOKonly
• Else
• user cant yet drive
• calculate how many years until driving age
• yearsUntilDriving cDriveAge - age
• MsgBox yearsUntilDriving _
• years until able to drive, vbOkonly
• End If

10
Commenting If statements

• In example, condition tests to see if someone is
  17 or more years of age.
• If condition is true, comment that user is old
  enough to drive
• If condition is false, comment that user is not
  yet old enough. Additional comment highlights
  that program will calculate how long it will be
  before user can drive

11
The Problem

• To write a program to calculate the factorial of
  a number between 2 and 12.
• Questions to answer
• How is a factorial calculated in maths?
• How can we ensure that the user only inputs a
  number between 2 and 12?
• We will start with the second question which
  refers to concept of Data Validation

12
Data Validation

• In our problem, we need to ensure that user
  inputs a number between 2 and 12
• Programmers should NEVER assume that a user will
  always get it right first time!
• If we need to ask for input, check whether it is
  valid and re-ask until it is, this implies that
  we may need to do the same thing several times -
  iteration
• Computers are very good at iteration!

13
A Validation Loop

• Consider the following piece of code
• number InputBox (Please enter number -
• in range 2-12)
• Do While condition
• number InputBox (Please re-enter -
• must be in range 2-12)
• Loop
• User is prompted to enter number, then
  re-prompted within a loop construct until some
  condition is met

14
The Do While Loop
15
Do While Loop

• Upon entering the loop, the condition is
  evaluated
• If FALSE, statements within loop are ignored and
  processing moves to the statement after Loop
• If TRUE, statements within loop are executed and
  then the condition is re-evaluated. This
  continues until the condition evaluates FALSE

16
Do While Loop

• Allows open-ended iteration
• However, beware - at some point the condition
  MUST evaluate FALSE otherwise program NEVER
  leaves the loop
• So - it is usual that one or more statements
  within the loop will affect the condition
• Always establish a value within variable to be
  tested BEFORE the Do While statement

17
Do While Loop Condition

• Looked at conditions use of relational
  operators in unit 4
• Problem requires a number between 2 12
• So if number is less than 2 or greater than 12 it
  is not acceptable
• (number lt 2) Or (number gt 12)
• This is called a Compound Condition where we join
  two simple conditions with a boolean logical
  operator

18
Boolean Logical Operators

• Anything of type boolean can be only either TRUE
  or FALSE

Operator Meaning Or if one condition or both
conditions are true, entire condition is true
And Both conditions must be true for entire
condition to be true Not Reverses truth of
condition
19
The Finished Validation Loop
number InputBox (Please enter number -
in range 2-12) Do While (number lt 2) Or (number
gt 12) number InputBox (Please re-enter
- must be in range 2-12) Loop
20
The Second Question - How is a factorial
calculated in maths?

• All to do with developing an algorithm
• An Algorithm is a set of rules that define or
  perform or solve a specific problem. (Collin S,
  1989, Hamlyn Dictionary of Computing)
• Factorial - product of positive integers from 1
  to n
• 2! 1 x 2 2
• 4! 1 x 2 x 3 x 4 24
• 8! 1 x 2 x 3 x 4 x 5 x 6 x 7 x 8 40320

21
Large Integers

• In unit 4, looked at Integer Data Type
• In Visual Basic the Integer data type can store
  any whole number between
• -32,768 and 32,767
• 8! 40320 - too large for Integer data type
• Long data type - can store any whole number from
• -2,147,483,648 to 2,147,483,647

22
Calculating the factorial

• Uses iterative multiplication
• This indicates that we need to use a loop
  construct again. But
• this time we know how many times we will go round
  the loop -
• for 2! - 1 multiplications
• for 4! - 3 multiplications
• for 8! - 7 multiplications
• Generalises to (number-1) multiplications

23
The For Next Loop
For loopIndex startNumber To finishNumber Step
stepSize statements forming body of loop Next
loopIndex
24
Back to calculating the factorial

• Given variables
• number receives number of factorial to be
  calculated
• fact holds the factorial during and after
  calculation
• count the loop index for the For Next loop
• Set fact 1 and then start the loop at 2 with
  the finish point being number

25
The Factorial Calculation
fact 1 For count 2 to number Step 1 fact
fact count Next count
Note that Step 1 is not essential. The default
is to add 1 to the loopIndex
26
Calculating 3!
fact count number number InputBox()
3 fact 1 1 For count 2 to number Step
1 2 count lt number so iteration starts
fact fact count 2 Next count
3 count number so iteration continues
fact fact count 6 Next count
4 count gt number so iteration stops
27
Dim number As Integer Dim count As Integer Dim
fact As Long number InputBox (Please enter
number in range 2-12) Do While (number lt 2) Or
(number gt 12) number InputBox (Please
re-enter - must be in range
2-12) Loop fact 1 For count 2 to number
Step 1 fact fact count Next
count MsgBox number factorial is fact
