Title: GPS Modernization


1
Presentation GNSS 4.2 by H. Cabler
ICAO CAR/SAM ATN/GNSS SEMINAR
2
Modernization History
  • Need for GPS Modernization recognized by US as
    GPS entered Full Operational Capability (1995)
  • Recognized growing importance of GPS to both
    sectors
  • National Policy imperative to enhance GPS as
    single world standard
  • Better, more reliable civilian service
  • Need to rethink GPS architecture for the future
  • Multiple studies indicated diverse set of needs
  • New signals, Higher Power, Greater Accuracy
  • Greater focus on dual-use nature
  • System Integrity, Survivability, and Prevention
    of hostile use
  • Better Spectrum Management

3
Background
  • 1996 Presidential Decision Directive (PDD) and
    1998/99 Vice Presidential announcements committed
    US to modernization and improvement path
  • Selective Availability (SA) turned to zero NLT
    2006
  • Two new civil signals and new military signals
  • Free world-wide use
  • Move from studies to action initiated in FY 2000
  • SA Set to zero in May 00
  • directed changes to existing and future
    satellites
  • IIF program terminated at 12 satellites and GPS
    III development began

Modernization Now in Full Swing
4
GPS Modernization at a Glance
Increasing System Capabilities Increasing
Civil/Defense Benefit
Full Civil Rqmts Addl Capabilities
New Civil Signal L5
L2C on L2
Basic GPS
SA Set to 0
GPS III
GPS IIR-M, IIF
  • GPS-III
  • Increased power (20dB)
  • Increased Accuracy
  • Greater Availability
  • Controlled Integrity
  • Greater Survivability

GPS IIA/IIR
  • IIR-M Improved on all IIA capabilities and
    added
  • 2nd Civil Signal on L2
  • New L1 L2 M-Code
  • IIF IIR-M capability and
  • Add 3rd Civil Signal on L5
  • Standard Service (100 m)
  • Precise Service (16 m)
  • Two Nav frequencies
  • L1 Civil (C/A) Precise
  • code, Navigation
  • L-2 P-code Nav

5
New Civil Signals
  • Many consider setting SA 0 as the 1st step in
    modernization
  • New Signals can be considered the 2nd/3rd Steps
  • Civil Users Currently Limited to One GPS Signal
  • C/A-code at L1 frequency (1575.42 MHz)
  • Adding a Second Civil Signal
  • C/A-type code at L2 frequency (1227.60 MHz)
  • Adding a Third Civil Signal
  • P-type codes at L5 frequency (1176.45 MHz)
  • Higher power signal, intended for precision
    navigation

6
SA Set to Zero on 2 May 2000
  • Selective Availability (SA) Intentional
    Degradation
  • President decided to discontinue SA to aid
    peaceful civil users
  • Civil user accuracy dramatically increased on 2
    May 2000

7
Block IIR Modernization
  • Pre-Modernization/IIR
  • Heritage Signals
  • L1 C/A
  • L1, L2 P(Y)
  • On Orbit Life
  • 10.6 Years MMD
  • Post Modernization/IIR-M
  • Modernized Signals
  • Flexible, Higher Power
  • L1 C/A, L2C (or C/A)
  • L1, L2 P(Y)
  • L1, L2 M-Code)
  • On-Orbit Life
  • 8.6 Years MMD

Design Life/MMD analysis completed Nov 01.
L2 Second Civil signal design supports varying
code length and data structure
8
Block IIF Modernization
  • Post Modernization
  • Modernized Signals
  • Flexible, Higher Power
  • L1 C/A, L2C
  • L1, L2 P(Y)
  • L1, L2 M-Code
  • L5 Third Civil
  • Design Life
  • 12 Years
  • 10 Year MMD
  • Pre-Modernization
  • Heritage Signals
  • L1, L2 C/A
  • L1, L2 P(Y)
  • Design Life
  • 15 Years

L2 Second Civil signal design supports
varying code length and data structure L5
Third Civil signal at -154dBw
9
New Civil Signal Roll-Out
  • Second Civil Signal (L2C) - Block IIR-M
    Satellites
  • First launch in 2003, then every satellite
    thereafter
  • Provides a redundant signal for civil users
  • Improved continuity in case L1 signal reception
    is lost
  • Improved accuracy via dual-frequency ionosphere
    correction
  • Wide-lane for extremely-precise local area
    differential GPS
  • Third Civil Signal (L5) - Block IIF Satellites
  • First launch in 2005, then subsequent satellites
    thereafter
  • Provides redundant dual-frequency capability for
    civil users
  • Improved continuity in case L1 or L2 signal
    reception is lost
  • Improved accuracy via triple-frequency ionosphere
    correction
  • Tri-lane for ultra-precise local area
    differential GPS

10
New Capability Schedule
18
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
19
FY
1st GPS-III SV
System Milestones
1st L2C SV
L2C IOC
L2C FOC
1st L5 SV
GPS-III FOC
L5 IOC
L5 FOC
GPS-III IOC
Space Segment
Heritage Launches
Modernized (IIR-M/IIF) Launches
1st IIR-M
1st IIF
GPS III Launches
GPS III Launches
EMD
1st GPS III
SAASM
M-Code
11
GPS III System Vision
The GPS III System
Second Civil Signal
Third Civil Signal
  • Relook at Entire GPS Architecture to
  • Achieve long term GPS performance goals
  • Reduce long term total ownership costs
  • Ensure GPS III is Synergized with
  • Military and Civil Needs/Systems
  • Possible augmentation opportunities
  • Build Best GPS for the Next 30 Years

12
GPS III Addresses MultipleGPS Needs
  • Significantly Increased Integrity
  • Crucial for anticipated civil aviation uses
  • Also important for military use
  • High level of Signal Availability
  • Equally important to both military and civilian
  • Significantly Increased Accuracy
  • Driven by evolving nature of warfare and civil
    uses
  • Additional GPS needs Future flexibility, nav
    related messaging, reprogramability

These Needs not able to be addressed without
significant architectural change
13
GPS III Integrated Approach
  • GPS Originally Designed without benefit of an
    Established User Base
  • Civil Users Previously Solicited for Suggested
    Changes to Existing System to Meet their Needs
  • GPS III has Novel Approach for Integrating Needs
    of the DoD, DOT, FAA
  • Just completed System Architecture and
    Requirements Definition phase gathered and
    identified future requirements
  • Interagency Forum for Operation Requirements
    created to identify and assemble new requirements
    for GPS
  • Civil and military requirements to be approved in
    totality by joint committee
  • Coast Guard Navigation Center soliciting
    requirements via website

14
Stressing Civil Missions
.
.
.
Other Civil Missions (over 140 total)
Other Civil Missions
Stressing Civil Missions
  • Category IIIB/C instrument landing at approved
    airport
  • Precision automatic highway vehicle guidance
    (including collision avoidance), including in
    urban canyon conditions
  • Mobile personal systems wireless communications
    synchronization for advanced performance
    signaling protocols
  • Computing/communications network synchronization
  • Electric power grid synchronization
  • Precision construction equipment guidance
  • Construction surveying
  • Crustal motion monitoring
  • Weather monitoring (tropospheric water content)
  • Scientific instrument synchronization
  • Open loop antenna pointing for mobile satcomm
    users, other instrument pointing
  • Hiker navigation
  • Civilian spacecraft position and attitude
    determination for sensor pointing

15
GPS III Increased Capability
  • Assured Delivery of GPS Signals
  • Higher Power Military Civil Signals
  • Higher Accuracy Service for All Users
  • Increased Integrity Inherent in GPS

16
GPS III Assured Delivery
  • Dual-Use GPS is more than just Adding Civil
    Signals
  • Assuring availability and continuity of signals
  • Realization that GPS is considered a Critical
    Part of Worldwide Infrastructure
  • Availability/Continuity Key Factors in GPS III
    Design
  • Crosslink architecture
  • Number of orbital planes
  • Number of satellites
  • Sparing strategy
  • Replacement strategy
  • Control segment

17
GPS III Increased Accuracy
  • Augmented and standalone missions identified that
    require more accuracy than modernized GPS
  • Signal-in-space improvements must keep pace with
    those in users equipment
  • Advanced technology clocks
  • Inter-satellite ranging
  • Improved ephemeris and orbital models
  • Age of Data reduction and more timely updates via
    crosslinks

18
GPS Accuracy
19
GPS III Increased Integrity
  • Aviation applications one of key drivers
  • GPS III architectural changes
  • Improved monitoring and reporting
  • Planned interfaces between GPS and augmentations
  • Potential for meeting broad array of civil and
    military needs via GPS alone

20
Sufficient Means of Navigation?
  • Sufficient to be used anywhere, anytime
  • Without precluding use of other systems or
    augmentations
  • Without requiring use of other systems or
    augmentations
  • Except for most demanding applications (LAAS)
  • With assured delivery
  • Availability and continuity (and higher power)
  • With high accuracy
  • With high integrity

21
Ground Augmentation
  • By itself, GPS III will have very good Accuracy
    and Integrity
  • Good enough for most navigation applications
  • Ground Augmentation Gives Major Improvements
  • For Ultra High Accuracy
  • 1 m with Local Area Differential GPS (LADGPS)
  • 1 cm with Real-Time Kinematic (RTK)
  • For Ultra High Integrity
  • ?1-1x10-9/operation or even better is achievable
  • Precision Landing Needs High Accuracy/Integrity
  • Prime example of GPS ground augmentation system
    usage
  • Civil Local Area Augmentation System (LAAS)

22
Challenges
  • Maintaining a healthy constellation while adding
    system capabilities
  • Constellation sustainment strategies
  • Operational Control Segment (OCS) upgrades
  • Testing / validating new signals - design and
    operations
  • Transition to modernized OCS
  • Spectrum Protection
  • International Cooperation

23
International Cooperation
  • Need a strategic view for US interaction with
    Galileo
  • Work the policy and technical issues on how these
    two system can coexist and leverage one another
  • Opportunity is now for us to begin working to
    ensure a single, integrated Navigation service
  • Improves civil aviation, interoperability, and
    spectrum protection
  • Will save money if done properly
  • GPS III Acquisition effort is the right place to
    push for this to happen

24
Summary
  • GPS Modernization activities well underway
  • GPS Modernization offers superb opportunity to
    satisfy both military requirements and civil
    needs
  • GPS III exploring complementary DoD/civil
    augmentation opportunities
  • Working through challenges
  • GPS III Architecture Working hard toward a
    robust, supportable, flexible, international
    capability for the next 30 years
