1
Jens Froese Hamburg Technical University (TUHH)
RFID Deployment in Europe
2

• RFID still an issue of research including some
  testbeds rather than extensive applications
• International agreements on frequencies required
• Impacts expected on logistics processes within
  the whole supply chain from intralogistics via
  transport logistics to production supply
• Tracking of carriers and goods to be integrated
  into ERP systems
• Tracing carriers and goods when required
• Self-organizing components and systems
• Internet of things will allow components and
  systems to communicate according to pre-defined
  rules or sophisticated heuristics
• 5 years to mature and effortable systems.

Current European RFID Aspects
3

• Costs is an issue especially for mass products
  (disposable tags)
• Cheaper polymere-electronics RFID chips under
  development in Germany.

Current European RFID Aspects
4

• Current logistics applications mainly for
  intralogistics operations
• automated reading of package documents
• warehouses
• integration of RFID and pick by voice?
• car production
• recycling information
• general production and distribution
• product information including manuals
• department stores.

Current European RFID Aspects
5

• Metro Group and GS1 Germany just got the contract
  to develop an EPCglobal accredited research and
  test lab
• Metro Group one of Europes biggest trading and
  department store companies
• GS1 service and competence centre for
  inter-industry business processes
• EPC Electronic product code to support the use
  of RFID
• Network consisting of
• ID system of tags and readers
• Object name service (ONS)
• Physical markup language (PML)
• Savant software components interface standards
• Global Data Synchronization Network (GDSN)
• Global Standards Management Process (GSMP)
• Yellow pages of the global supply chain (GEPIR).

Research and Unique Identifiers
6
Will RFID replace bar codes? Not for the time
being because of very wide applications and easy
to use. Excellent back up for RFID.
Bar Codes
7

• Adequate technologies are of paramount importance
  to transport service providers. To determine what
  is adequate all leading transport service
  providers are currently performing tests
• Docking of automated carriers at ramps
• Acceptance and storage of goods in warehouses
  (RFID communication between packages and
  forklifts)
• Warehouse deliveries
• Shipping of cars
• Some car terminals provide transport plus value
  added services like
• de-waxing/cleaning
• mounting of extras.

Application for Transport Processes
8
Passive Tags
9

• ABX Logistics
• no interests in being an early adopter
• cost-benefit ratio currently insufficient
• multi-use containers rather than one-way
  packages
• bar code scanner systems can become modified for
  RFID
• TNT
• 6 projects with clients from branches for
• hightech
• automotive
• telecommunication
• pharma
• from USA, France, UK, Germany, Netherlands,
  Scandinavia and China.

Industrial Voices (Users)
10

• trans-o-flex
• plans to integrate RFID technology into existing
  IT-network
• joint venture with ORACLE
• integration of sensors (e.g. temperature)
• active tags
• Logistics Service Award 2005 (Germany)
• Deutsche Post
• DRFID-project just launched combination of RFID
  with re-writable display-modules (e-ink
  technology) for courier services (re-usable
  containers).

Industrial Voices (Users)
11

• Siemens
• Simatic RF600 family of RFID products
• Stationary and mobile read/write devices and
  antennas 860 956 MHz frequencies
• Data carriers including smart labels and tags
• Software linking RFID devices to manufacturing
  execution systems (MES) and enterprise resource
  planning (ERP) applications.

Industrial Voices (Manufacturer)
12
Bosch service seamless surveillance of
transports including counter actions in case of
disturbancies (active system!).
Industrial Voices (Manufacturer Service
Provider)
13
White Paper RFID Technology, Systems and
Applications BITKOM 11 August 2005 (currently
only in German).
BITKOM White Paper
14
RFID Layers of Logistics Units
Layer 5ISO TC 104 (ISO 14816)ISO TC 204IATA
ISO TC 8AAR
Movement Vehicle (truck, airplane, ship, train)
Layer 4 (UHF)ISO TC 104 (ISO 10374)ISO TC 104
(ISO 18185)ISO TC 104 (ISO 23389)ISO TC 104
(ISO 14816)ISO TC 122/104 JWG
Container (e.g., 40 foot Sea Container)
Layer 3 (UHF)ISO TC 122/104 JWG ANSI
MH10.8.4AIAG (TBD)EIA (TBD)EAN.UCC GTAG
Layer 2 (UHF)ISO TC 122/104 JWG ANSI
MH10.8.8AIAG (TBD)TCIF (TBD)
Seetransport ist immer intermodal
Layer 1ISO TC 122/104 JWG
Layer 0 ISO TC 122/104 JWG AIAG B-11
15
Seetransport ist immer intermodal
RFID Focused ISO Standards
16
315 MHz Proposed for use under tri-frequency
active protocol ISO 18185 Asia
433 MHz Proposed as stand-alone active protocol
and as part of tri-frequency active protocol ISO
18185 Europe, North America, Asia
915 MHz Proposed as stand-alone active protocol
and as part of tri-frequency active protocol ISO
18185 ISO 10374 (read-only container
standard) Americas
Frequencies
862 928 MHz Agreed for passive protocol under
ISO 18185 Pursuing global approval.
17
Thank you!
