Performance Based Specifications

1
(No Transcript)
2
Ultra Thin Whitetopping (UTW)

• Thin layer (50-100mm) of PCC concrete over an
  existing distressed AC pavement
• Similar to mill/inlay
• Bond developed between AC and PCC forming a
  composite pavement
• PCC is usually high early strength and fiber
  reinforced.
• Joint spacing is much shorter (1-3m)
• Requires thick underlying AC

3
Contents

• Study Background
• Scope of the Study
• Life-cycle Cost Methodology
• Analysis Sites - Data set
• Parametric Data
• Pavement performance models, user costs,
  treatments, trigger limits, discount rate
• Results
• Conclusions

4
How the Study Came About

• BC Redimix Association
• Had heard of the UTW technology and wanted to
  know if it could be used in the lower mainland
• City of Surrey
• Was interested in knowing if UTW would be a
  viable strategy in Surrey
• Canadian Portland Cement Association
• Agreed to fund a study

5
Scope of the UTW Study

• Identify sites thought to be suitable candidates
  for UTW (intersections prone to rutting, AC
  thickness greater than 120mm)
• Assemble data (traffic geometry, structure,
  construction and performance history)
• Assemble parametric information (available
  treatments, rehab strategies, user costs,
  pavement performance models, discount rates
• Conduct LCC analysis
• Report on effectiveness of UTW vs other strategies

6
Study Methodology

• Life-cycle Benefit/Cost for infrastructure
  preservation planning

7
Life-cycle Cost

• Total Present Value (P.V.) of all costs over the
  on-going life of the pavement
• Life-cycle cost Initial Construction
  Costs
• P.V. Rehabilitation Costs
• P.V. Maintenance Costs
• P.V User Costs
• - P.V. Salvage costs

8
Life-cycle costs for Preserving existing pavements

• Life cycle costspv
• P.V. Rehabilitation Costs
• P.V. Maintenance Costs
• P.V. User Costs
• (the analysis period is made long enough that the
  salvage value is exhausted - 50 years)

9
Pavement Preservation Rehabilitation and
Maintenance Treatments

• Crack Sealing
• Patching
• UTW 50mm/80mm/100mm
• Overlay
• Reclaim
• Reconstruction

10
Treatment application timing is a variable
11
Pavement Strategies

• Strategy is comprised of combinations of
  individual treatments and treatment application
  timings
• Therefore, for a given site there are dozens of
  potential strategies.

12
Example Pavement Strategies(combinations of
treatments)
13
Two methods of determining User Costs Savings
(benefits)

• Measure User Costs Directly (with Road User Cost
  Models)
• Vehicle Operating cost models
• Delay Cost Models
• Accident Cost Models
• Measure User Costs Indirectly (by measuring the
  Area Under a Performance Curve)

14
Direct Measurement of User Costs
Vehicle Repair costs Roughness Fuel
Consumption Roughness Delay Costs
Treatment application rate, Detour
Length
15
RUCdo-nothing - RUCstrat 1 RUCBenefit strat 1
Calculating Strategy Benefits Using RUC
16
Area-Under the-Curve Methodof measuring strategy
benefits
Calculating Strategy Benefits Using AUC
17
List of Strategies (cost benefit)
18
Strategy Costs are Compared with benefits to
measure cost effectiveness
19
5 Methods of Defining Cost Effectiveness

• Minimum LCC called Total Transport Cost (TTC)
• Minimum of (rehab Maintenance user costs)
• B/C
• (RUCdo-nothing - RUCstrategy) / (rehab maint
  costs)
• Min Cost (to meet Performance Specification)
• Minimum of (rehab Maint) (ie. ignore
  benefit to minimize cost)
• Maximum AUC Benefit
• Maximize the Area under the performance curve
  (ignore cost to maximize benefit)
• Maximum AUC B/C
• AUC / (rehab Maint)

20
Cost Effectiveness ( using RUC)
Max Benefit/Cost
.
Min PV Cost
Min TTC
Worst First
21
Cost Effectiveness (using AUC)
Max Benefit/Cost
Maximum Benefit
Min PV Cost
22
Common Policies for selection of effectiveness
measurement method

• Worst First (used in the absence of preservation
  planning)
• Minimum total LCC (TCC) - (minimizes total cost
  to the economy)
• Max benefit/cost - used when funding is severely
  constrained (attempts to provide best public bang
  for the tax buck)
• Minimum PV Cost to meet performance based
  objectives (used with performance based specs
  such as in Australian/New Zealand Maintenance
  Contracts)
• Maximum Benefit - Minimizes delay costs
  (ignoring direct agency costs).

23
Analysis Data Set Requirements

• Site data affecting pavement performance
• subgrade, pavement structure, traffic volumes,
  vehicle loadings, climate and construction
  history
• Site data affecting Road User Costs
• traffic volumes and mix, intersection
  configuration, and/or detour lengths
• Site data required for calibrating pavement
  performance prediction models
• rutting history, roughness history, cracking
  history

24
City of Surrey Supplied

• Existing AC thickness is the most important
  consideration for UTW
• Surrey has an extensive pavement thickness
  database
• selected 150 arterial and collector intersections
  with AC thickness greater than 120mm
• Historical roughness, rutting and cracking data
• Locally calibrated RUC models
• Locally calibrated pavement performance models
• 1999 Traffic AADT Volume Data, 1995
  Classification data

25
Parametric Data Requirements

• pavement performance models
• Asphalt
• UTW
• set of potential treatments and costs
• maintenance treatments
• rehab treatments
• treatment trigger limits
• potential strategies
• combinations of treatments required to preserve
  the pavement indefinitely
• road user cost models
• discount rate

26
Performance Prediction Models
Crack Strength, Traffic, Age Rut
Crack, Strength, Traffic,
Age Roughness Rut, Crack, Strength,
Traffic, Age, Environment
27
Example Crack Prediction Model
28
Example Rut Prediction Model
29
Example Roughness Prediction Model
30
Pavement Quality Index (PQI)(Composite Index for
AUC Calculations)
Overall Condition of the pavement Cond. Index
Roughness, Cracking, Rut etc. This Index is used
extensively in BC
31
Overall Pavement Quality
32
Rehabilitation Treatments and Costs (Can)

• For intersections in Surrey (weekend work, all
  inclusive)
• Reconstruction 50/m2
• Mill/Inlay 50mm 18/m2
• Deep Patch (prior to inlay) 13-55/m2
• 100mm UTW 45/m2
• 80mm UTW 40/m2
• 50mm UTW 37/m2

33
Maintenance Treatments and Costs

• Crack Sealing 1.50/ln-m
• Route Seal Cracks 2.50/ln-m
• Thin Overlay/Patching 8/m2

34
Treatment Triggers/Limits

• Reconstruction rutting (20 - 40mm) cracking (
  gt 20)
• Mill/Inlay rutting (20 - 40mm) cracking ( 5 -
  25)
• UTW rutting (20 - 40mm) cracking ( 5 - 40 )
• Crack Seal All low severity cracks every 3
  years
• Route Seal All medium severity cracks every 3
  years
• Patching All high severity cracks every 3 years

35
Predicted Cracking - Overlay in 2004
36
Predicted Rut - Overlay in 2004
37
Predicted Roughness - Overlay 2004
38
Overall Pavement Condition - Overlay in 2004
39
Reconstruct - 2008
40
Reconstruct - 2009
41
Reconstruct - 2010
42
UTW Pavement Performance Models

• Inferred from UTW design charts
• provide design life in terms of allowable trucks
  to the end of design life
• PCC industry claims
• very little load related cracking or rutting
  until the end of the design life
• Assumed that at the end of the design life the
  pavement deteriorates at the rate of the
  remaining underling AC (which is now thinner)

43
UTW - 2004
44
UTW - 2004
45
UTW - 2004
46
UTW - 2004
47
UTW - 2005
48
UTW - 2006
49
UTW - 2007
50
Road User Cost Models

• Vehicle Operating Costs (models are available)
• Fuel Consumption
• Vehicle Repair and parts consumption
• Delay Costs (no readily available models)
• Freight Rates
• Value of Commercial Time
• Value of Personal Time
• Idling Fuel Consumption
• Detour Costs (more easily calculated than delay
  costs)
• Fuel Consumption
• Vehicle Repair and parts consumption
• Amortization, Insurance etc.

51
VOC Model Used
Surrey Model
Ontario Model
58 of Ontario
52
VOC models used
Ontario Model
58 of Ontario
Surrey Model
53
Delay Costs (not used)

• Most Significant Cost
• at 5/car/hr and 10/truck/hr a 30 min delay over
  two days at major intersection could cost as much
  as 500K
• Difficult to agree on
• Longer life treatments such as PCC or
  reconstruction are heavily favoured
• Therefore the study assumed that all traffic
  would be detoured.

54
Detour Costs

• Detour Length 1.6 km (Surrey Arterial grid)
• VOC
• 0.35/car/km
• 1.00/truck/km
• Off-peak Closure Period
• Reconstruction 4 days
• UTW 2 days
• Mill/inlay 1 day

55
4 6 Discount Rate

• 4 is the long term difference between B of
  Canada prime and Inflation
• 4 is used by BC Alberta Governments
• NWT uses 6
• Ontario uses 7
• Arguably should use greater than 4 to allow for
  future lower costs resulting from new technology

56
The Analysis

• Used Deighton Associates Limited - Total
  Infrastructure Management System (dTIMS) LCC
  analysis software
• Tested 150 intersections
• Approximately 44 strategies/intersection
• Cost effectiveness of 6,600 strategies measured
  by each of the 5 cost effectiveness methods

57
The Results

• The strategy selected is heavily dependant on the
  cost effectiveness method used
• It is impossible to have exactly the same
  strategy selected by all methods
• It is possible to have a strategy comprised of
  the same underlying treatment (applied in
  different years perhaps) selected by all 5
  methods
• example at a given intersection
• 50mm UTW lowest cost
• 100mm UTW Max AUC
• 75mm UTW Max B/C

58
UTW Effectiveness
59
Example Effects of selection criteria on a
network of pavements
60
(No Transcript)
61
(No Transcript)
62
The bad news

• Hard to find thick pavements
• Of the 36 sites where UTW is most effective, only
  2 are warranted to be done in 2000/2001
• The AC thickness must be uniform ie. Continuously
  thick (additional pavement thickness survey cost)
• UTW is less compatible (than AC) with future
  geometric changes

63
