Action Research Review

1
Action ResearchReview

• INFO 515
• Glenn Booker

2
Why do we do this?

• Measurements are needed to understand a system,
  and predict its future behavior
• Statistical techniques provide a commonly
  accepted means of analyzing measurements
• Statistics is based on recognizing that
  measurements tend to fall over a range of values,
  not just one precise number

3
Types of Research

• Historical (what happened?)
• Descriptive (what is happening?)
• Developmental (over time)
• Case and Field (study an organization)

• Correlational (does A affect B?)
• Causal Comparative (what caused it)
• True Experimental (single / double blind)
• Quasi-Experimental
• Action Research

4
Data Analysis

• Raw data, such as one survey result
• Refined data, such as the distribution of ages of
  Philadelphia residents
• Derived data, such as comparing the age
  distribution of Philadelphia residents to that
  of the country

5
Population vs. Sample

• Often the subject of interest (population) is so
  big it isnt feasible to measure it all
• Then a sample of measurements can be made, and we
  want to relate the sample measurement to the
  population

6
Sampling

• Sampling can be done using probabilistic
  techniques (e.g. various random samples)
• Simple or stratified random,
• Cluster (geographic), or
• Systematic (every Nth) samples
• Or using non-probabilistic methods (whoevers
  convenient, specific groups, or experts)

7
Customer Satisfaction Surveys

• A special case of sampling, customer satisfaction
  surveys are often done using
• In person interview
• Telephone interview
• Questionnaire by mail
• Sample sizes are based on the allowable error,
  population size, and the result obtained

8
Measurement Scales

• Measurements can use four major types of scales
  the types of analysis possible depend strongly on
  the type of measurements used
• Nominal (named buckets, without sequence)
• Ordinal (ordered buckets)
• Interval (intervals mean something, can -)
• Ratio (you can form ratios, can -/ )

9
Discrete versus Continuous

• Discrete (nonparametric) measurements use nominal
  or ordinal scales only specific values are
  allowed
• Car make Chevy, or cost High
• Continuous (parametric) measurements use interval
  or ratio scales, and generally have integer or
  real number values
• Temperature 98.6 deg F, Height 172.1 cm

10
Descriptive Statistics

• Many common statistics can describe the central
  tendency of a set of measurements
• Average (arithmetic mean)
• Minimum, Maximum, Range
• Median (middle value)
• Mode (most common value)

11
Normal Distribution

• Many measurements can be described by a normal
  distribution, which is summarized by an average
  value and a standard deviation, s or s
• We can predict how likely any range of values is
  to occur for a normal distribution (how often is
  X between 5 and 8?)

12
Z Score

• Z scores measure how far from the mean a single
  measurement isz (Xi - m) / s
• Same formula used for finding t too
• Does not only apply to a normal distribution, but
  if it does, then we can predict the probability
  of that value or higher/lower occurring

13
Standard Error

• A sample of N measurements will have a standard
  error SEx s / sqrt(N)
• The standard error allows us to define the
  confidence interval, CICI mean /-
  critSExwhere crit is the critical z score for
  a large sample, or the critical t score for a
  small sample

14
Critical z and t

• The critical z score is only a function of the
  desired confidence level of the results (zc
  1.96 for 95 confidence level)
• Critical t score is a function of the sample size
  (degrees of freedom, df n-1) and the desired
  confidence level
• As df gets very large, critical t ? critical z

15
Confidence Level

• We have to accept some level of uncertainty in a
  statistical analysis our conclusion might be
  wrong!
• Generally, a 95 level of confidence is used,
  unless life is on the line - then a 99 level of
  confidence is required
• Use 95 typically, hence critical significance
  is 0.050

16
Confidence Level

• The level of confidence of your results, plus the
  critical significance, always equals exactly one
• For practically every statistical test, having
  the Significance of the result less than the
  critical value means to reject the null
  hypothesis
• If Sig actual lt Sig crit, reject null hypothesis

17
Frequency and Percentage

• Frequency graphs and crosstabs can provide a lot
  of information just from counts of a nominal or
  ordinal measurement occurring, possibly given
  with the percentages of each events occurrence
• Histograms can provide similar charts for ratio
  or interval scaled data

18
Scatterplots

• Scatter plots or diagrams show the relationship
  between two or more measures
• The horizontal axis is generally the independent
  variable (X), sometimes also called a factor or
  grouping variable
• The vertical axis is generally the dependent
  variable (Y), which is the measure youre trying
  to understand

19
Hypothesis Testing

• Some statistics are used in the context of
  testing a hypothesis - a statement whose truth
  you wish to determine
• Are Philadelphians more likely to be Nobel Prize
  winners?
• The Null hypothesis is the opposite of the
  hypothesis, and generally says there is no
  difference or no effect observed
• Philadelphians no more likely to be Nobel Prize
  winners than any other group

20
Hypothesis Testing

• Cant truly PROVE anything - only determine if
  the differences observed are not likely to be
  due to chance
• Select one or more Tests of Significance to
  determine if there is a statistically significant
  difference (Yes/No) if Yes, then can
• Select one or more Measures of Association to
  describe the strength of the difference, and
  possibly its direction

21
One versus Two Tailed Tests

• A null hypothesis which tests for no difference
  uses a two tailed test
• A null hypothesis which specifically tests for
  greater than uses a one tailed test
• A null hypothesis which specifically tests for
  less than uses a one tailed test
• One versus two tailed changes the critical z or
  t score generally makes the test easier to show
  significance thats why two-tailed tests are
  used

22
Z or T Test

• The z or t tests can be used to compare two
  distribution means, or compare one distribution
  mean to a fixed value (interval or ratio data)
• Compare the actual z or t score to the critical z
  or t score
• If the actual z or t score is closer to zero than
  the critical value, accept the null hypothesis

23
Z or T Test (Two Tailed)
Notice this is for the x or t value, NOT the
significance of that value
24
Z or T Test (One Tailed)
(Case here is testing if the actual value is
greater than the mean for a less than case,
use only the negative critical value.)
25
Is My Sample Normal?

• Boxplots and stem-and-leaf diagrams can help show
  graphically whether a sample has a fairly normal
  distribution
• The skewness and kurtosis of a data set can help
  identify non-normality, if their values are more
  than two times their own standard errors

26
T Tests

• T tests compare means for ratio or interval data
• Independent t test is for two different strata
  within one data set
• Paired t test is to compare measures of the same
  group before and after some event (drug test), or
  the samples are otherwise believed to be
  dependent on each other
• One-sample t test compares one sample to a fixed
  value

27
T Tests

• Null hypothesis is that there is no difference
  between the means
• Results (e.g. significance) may differ if
  variances are not equal, since df changes
• The Levene test checks for equal variances
• Null hypothesis for the Levene test is that the
  variances are equal
• If the Levene significance lt 0.050, variances are
  not equal (reject the null hypothesis)

28
Independent T Test Evaluation

• Three ways to check the results of a T test
• If the T tests significance lt 0.050, reject the
  null hypothesis
• Check the stated t value against the critical t
  value for this df level if t(actual) gt
  t(critical) reject the null hypothesis
• If the confidence interval for the difference
  between the means does not include zero, reject
  the null hypothesis

29
Evaluating Significance
30
Paired T Test Evaluation

• Checks before and after test cases
• Includes a correlation factor (like r)
• Can use paired test if significance lt 0.050
• Larger correlation factor means stronger
  relationship between the variables
• Test evaluation as Independent T Test
• Significance, t value, and confidence interval

31
One-Sample T Test

• Compare a sample mean to a fixed value
• Test shows the actual values of means, with their
  std deviation and std error
• Same interpretation of results
• Significance, t value, and confidence interval

32
F Test and ANOVA

• Compare several means against each other using
  Analysis of Variance (ANOVA) and the F test
• Like extending the T tests to many variables
• Want data from random samples of normal
  populations with equal variances

33
F Test and ANOVA

• Output includes the Levene test
• Want significance for Levene gt 0.050, so that
  equal variances can be assumed
• Otherwise, should not use ANOVA
• Evaluate F by its significance
• If Sig. lt 0.050, reject the null hypothesis
  (there is a significant difference among the
  means)

34
Additional ANOVA Tests

• Once the F test shows there is some difference in
  the means across a subset, additional ANOVA tests
  can help identify more specific trends and
  differences
• Types of tests (see end of lecture 6) include
• Pairwise Multiple Comparisons
• Post Hoc Range Tests

35
Pairwise Multiple Comparisons

• Pairwise Multiple Comparisons check two subsets
  of data at a time
• Bonferroni test is better for a small number of
  subsets
• Tukey test is better for many subsets
• Both assume subset variances are equal
• For each pair of subset values, Sig lt 0.050
  means the difference in means is significant

36
Post Hoc Range Tests

• Post Hoc Range Tests look for groups within each
  subset which all have similar variances
• Tukey and Tukeys-b tests include Post Hoc Range
  Tests
• Each column of the output is a subset with
  statistically similar means
• Subsets may overlap substantially

37
Contrasts Across Means

• Look across subset means to see if there is a
  trend, such as a linear increase or decrease
  across subsets
• Can check for Linear, Quadratic, or Cubic
  relationships
• (i.e. first, second, or third order polynomials)
• Check Significance of F for the Unweighted
  version of each relationship (Linear, etc.) if
  Sig. lt 0.050, reject the null hypothesis

38
Determine Linearity

• An option under Compare Means / Means allows
  checking just for linearity
• This confirms the ANOVA test result for Linearity
• And gives R and Eta parameters, which are
  Measures of Association

39
R and Eta

• Pearsons R measures how well the data fits the
  regression (-1 is a perfect negative correlation,
  0 is no relationship, 1 is perfect positive
  correlation), and describes the amount of shared
  variance between them
• Eta squared gives how much of the variance in one
  variable is caused by the changes in the other
  variable

Named for English statistician Karl Pearson,
1857-1936 (per http//human-nature.com/nibbs/03/kp
earson.html)
40
Regression Analysis

• Regression Analysis looks at two interval or
  ratio-scaled variables (generically X and Y) and
  tries to fit an equation between them
• A dozen different equations are available
• Linear, Power, Logarithmic, Exponential, etc.
• Significance is checked by ANOVA F, and Sig. of
  the regression coefficients association is
  measured with R Squared

41
Regression Analysis

• For a regression to have any significance, we
  must have ANOVAs Sig. F lt 0.050
• Then each variables coefficient (b0, b1, etc.)
  must have significance lt 0.050
• Otherwise the coefficient might be zero
• Then the better regression equations are ranked
  in order of strength by R Square, which is
  confirmed visually by plotting

42
Regression Analysis

• The standard error of coefficients is given, so
  confidence intervals can be formed
• Also helps report them meaningfully, so you dont
  report a value as 4.861435 if it has a standard
  error of 0.92
• Depending on the accuracy of the source data, you
  could report that result as 5 /- 1, or 4.9 /-
  0.9, or 4.86 /- 0.92

43
Crosstabs

• Crosstabs display data sorted by two or more
  variables in table form
• Often just counts of each category, and/or the
  percentage of counts
• Recoding data allows interval or ratio scale
  data to be put into groups (e.g. age 18-25)

44
Pearsons Chi Square

• Measures how well the actual (observed) data
  differs from a even (expected) distribution of
  data
• The expected data can be a random distribution
  (same number of counts per cell), or adjusted for
  the actual total counts for each row and column

45
Pearsons Chi Square Evaluation

• When chi square is larger than the critical
  value, reject the null hypothesis
• Or if the significance of chi square is lt 0.050,
  reject the null hypothesis
• Can also generate Chi square for a single
  variable
• Beware that Chi square is less meaningful for
  large matrices
• Or, its too easy for large matrices to show
  significance falsely using Chi square

46
Residuals

• A residual is the difference between the Observed
  and Estimated values for a cell
• Residuals can be plotted to look for outliers
• Residuals can be standardized by dividing by
  their standard deviation
• Cells with a standardized residual magnitude gt 2
  contribute a lot to Chi square

47
Measures of Association

• Measures of Association between two variables can
  be symmetric or directional
• Dozens of measures have been developed to work
  with chi square test
• Interpret them like r - zero means no
  correlation, larger values mean a stronger
  correlation
• Some can be gt 1

48
Measures of Association

• Symmetric measures dont care which variable is
  dependent (Y)
• Directional measures DO care which variable is
  dependent (A f(B) is not B f(A))
• Some directional measures have a symmetric
  value, the weighted average of the other two

49
Symmetric Measures

• The Contingency Coefficient is the main
  symmetric measure with a Chi Square test
• Works even with nominal data
• Evaluated like Pearsons r
• Phi and Cramers V are other symmetric measures

50
Directional Measures

• Directional measures range from 0 to 1
• Lambda is the recommended directional measure -
  tells what proportion of the dependent variable
  is predicted by the independent variable (like
  Eta)
• Eta can be applied here if one variable is
  interval or ratio scaled

51
Relative Risk and Odds Ratio

• Use only with 2x2 tables
• Are quite directional
• Tells how much more likely one cell is to occur
  than the others
• Need to be very careful when interpreting

52
Square Tables

• Tables with the same number of rows and columns
  (RxR), and the same variables in those rows and
  columns, can use kappa
• Measures strength of association, like r
• Check results for significance (lt0.050)
• Then judge the value of kappa using a fixed
  scale

53
General RxC Measures

• Many measures can be used with a general table of
  R rows and C columns
• Gamma is the recommended measure (symmetric)
• Spearmans Correlation Coefficient is also widely
  used
• Ranges from -1 to 1, based on ordered categories

54
Yules Q

• Yules Q is a special case of gamma for a 2x2
  table
• Is judged on a fixed scale, like r
